Agilent 34410A and 34411A Multimeters
Data Sheet
Agilent 34410A 61/
2-Digit
High-Performance DMM
• 10,000 readings/s @ 5 1/
2-digits
direct to PC
• 1,000 readings/s @ 6 1/
2-digits
direct to PC
• 30 PPM 1-year Basic DC accuracy
• LAN, USB & GPIB standard
• DCV, ACV, DCI, ACI, 2-wire and
4-wire Resistance, Frequency,
Period, Continuity, and Diode Test
• Capacitance & Temperature
measurements
• Expanded measurement ranges
• Data logger with 50 k reading
non-volatile memory
Agilent 34411A 61/
2-Digit
Enhanced-Performance DMM
All the features of the 34410A, plus:
• 50,000 readings/s @ 41/
2-digits
direct to PC
• 1 million volatile reading memory
• Analog level triggering
• Programmable Pre/Post triggering
The Best Just Got Better
The Agilent 34410A and 34411A
61/
2-Digit DMMs represent the lat-
est generation of multimeters from
Agilent Technologies. Building on the
phenomenal success of the industry-
standard Agilent 34401A, these new
meters offer improved accuracy,
expanded measurement capability,
dramatically improved measurement
speed and throughput, and modern
computer interfaces including LAN
and USB. The dual display offers
both dual measurement capabilities
and ease of use when setting up and
configuring the DMM. Improvements
have been made in every facet of the
34401A to make the best even bet-
ter, whether you use it on the bench
or in a system.
Dramatic Speed Improvements
Whether it’s raw reading speed or
fast system throughput, the 34410A
sets a new benchmark in perfor-
mance. Using a new A/D technology,
the 34410A achieves an impressive
10,000 readings a second at 51/
2-dig-
its, and can stream readings to
your computer at this same speed!
Triggering is fast and precise, with
both trigger latency and trigger jit-
ter less than 1 µs, while bus query
response is less than 500 µs. ACV
measurements are faster as well
thanks to a digital measurement
technique that additionally improves
accuracy at high and low frequen-
cies. For even greater reading speeds,
select the 34411A, which achieves
50,000 readings a second at 41/
2-dig-
its.
Enhanced Measurement Performance
The 34410A and 34411A offer
Temperature and Capacitance
capabilities, in addition to those mea-
surements you have come to expect,
such as DCV, ACV, DCI, ACI, 2-wire
and 4-wire Resistance, Frequency,
Period, Continuity and Diode Test.
You also get Offset Compensated
Ohms, allowing you to accurately
measure resistance in the presence of
voltages. Measurement ranges have
been expanded as well; for example,
DC and AC Current Ranges now go
down to 100 µA, resulting in 100
pA resolution. Real-time math and
statistics are included, and a peak-
detect capability allows you to cap-
ture peaks as short as 20 µs.
See Agilent's Truevolt Series of DMMs
• Display DMM results in ways you never have before
• Measure with unquestioned Truevolt confidence
• Move to the next generation 34401A DMM with 100% assurance
www.agilent.com/find/dmm

Even Greater Performance
with the 34411A
The 34411A has all the features
of the 34410A, plus additional
performance that makes it even
more powerful. With the ability to
make 50,000 readings per second at
41/
2-digits, Analog Level Triggering,
programmable Pre- and Post-Trigger
and 1 million readings of volatile
memory in addition to 50,000
reading of non-volatile memory,
you now have the ability to cap-
ture low-frequency waveforms,
characterize device performance
and transfer results for analysis on
your computer.
Data Logger Function
A front panel data logger function
allows you to set the meter up to
make unattended, paced measure-
ments over a fixed time or number
of events, then pull up the results
later for review or transfer to a
computer for analysis. Set the
meter up to take measurements
every 10 seconds for an hour, go
have lunch, and check the results
upon your return. The contextual
front panel sequences make setup
and read back a breeze.
Improved Ease of Use
From the inclusion of a second
display to configuring setups for
each of the measurement functions,
these new DMMs offer significant
improvements in usability. Simple
things are simple; more complicated
setups are easier than ever. There
is even a new probe set designed
to more easily probe today’s fine-
pitch components. Finally, there is
a built-in Graphical Web Interface
that allows you to interactively
control the DMM without the
hassle of programming at all!
Modern I/O for Improved Connectivity
When connecting to a computer,
select LAN, USB or GPIB inter-
faces; all three are standard on the
34410A and 34411A. Concerned
about the viability of your existing
software programs? These new DMMs
respond to Standard Commands
for Programmable Instrumentation
(SCPI), and there is even a 34401A
Emulation Mode to ensure the
easiest upgrade possible. Agilent’s
I/O Library Suite ships with the
34410A and 34411A to help you
quickly establish an error-free
connection between your PC and
instrument. It provides robust
instrument control and works
with the software development
environment you choose.
LXI – Class C
LAN Extensions for Instruments (LXI)
provides the next generation I/O
for system applications requiring
the highest throughput. Transfer
rates of over 250,000 readings/s are
attainable ensuring even the most
data intensive measurements are
fast, without the overhead cost
of an instrument cardcage. Both
the 34410A and the 34411A are
LXI – Class C compliant.
Built To Last
Our new DMMs were designed
to high standards of ruggedness
and reliability. From the robust
package with its shock absorbing
bumpers to careful selection of
components and conservative
circuit design, these meters are
built to last. Calculated Mean
Time Between Failure (MTBF) is in
excess of 100,000 hours. Backed by
a 1-year warranty and a worldwide
network of service centers, you can
buy with confidence.
Go to the Web
For the latest information on
these or other Agilent DMMs,
go to www.agilent.com/find/dmm
Accessories Included:
• Test Lead Kit with probes
and SMT attachments.
• Test report, power cord,
and USB interface cable.
Product Reference CD-ROM with
soft documentation and software:
• Programmer’s Reference Help
• Quick Start Tutorial
• User’s Guide
• Service Guide
• Programming Examples
• IntuiLink for Multimeters
• LabVIEW and IVI-COM drivers
Optional Printed Documentation:
• Quick Start Tutorial
• User’s Guide
• Service Guide
Bench Dimensions:
System Dimensions:
2
261.2 mm
103.8 mm
88.3 mm
303.2 mm
212.8 mm
272.3 mm

3
Accuracy Specifications ± (% of reading + % of range)1
Function Range3Frequency, 24 Hour2 90 Day 1 Year Temperature
Coefficient/°C
Test Current or Tcal ± 1 °C Tcal ± 5 °C Tcal ± 5 °C 0 °C to (Tcal -5 °C)
Burden Voltage (Tcal +5 °C) to 55 °C
DC Voltage 100.0000 mV 0.0030 + 0.0030 0.0040 + 0.0035 0.0050 + 0.0035 0.0005 + 0.0005
1.000000 V 0.0020 + 0.0006 0.0030 + 0.0007 0.0035 + 0.0007 0.0005 + 0.0001
10.00000 V 0.0015 + 0.0004 0.0020 + 0.0005 0.0030 + 0.0005 0.0005 + 0.0001
100.0000 V 0.0020 + 0.0006 0.0035 + 0.0006 0.0040 + 0.0006 0.0005 + 0.0001
1000.000 V40.0020 + 0.0006 0.0035 + 0.0006 0.0040 + 0.0006 0.0005 + 0.0001
True RMS 100.0000 mV 3 Hz – 5 Hz 0.50 + 0.02 0.50 + 0.03 0.50 + 0.03 0.010 + 0.003
AC Voltage5to 750.000 V 5 Hz – 10 Hz 0.10 + 0.02 0.10 + 0.03 0.10 + 0.03 0.008 + 0.003
10 Hz – 20 kHz 0.02 + 0.02 0.05 + 0.03 0.06 + 0.03 0.005 + 0.003
20 kHz – 50 kHz 0.05 + 0.04 0.09 + 0.05 0.10 + 0.05 0.010 + 0.005
50 kHz – 100 kHz 0.20 + 0.08 0.30 + 0.08 0.40 + 0.08 0.020 + 0.008
100 kHz – 300 kHz 1.00 + 0.50 1.20 + 0.50 1.20 + 0.50 0.120 + 0.020
Resistance6100.0000 Ω 1 mA 0.0030 + 0.0030 0.008 + 0.004 0.010 + 0.004 0.0006 + 0.0005
1.000000 k Ω 1 mA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
10.00000 k Ω 100 µA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
100.0000 k Ω 10 µA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
1.000000 M Ω 5 µA 0.0020 + 0.0010 0.010 + 0.001 0.012 + 0.001 0.0010 + 0.0002
10.00000 M Ω 500 nA 0.0100 + 0.0010 0.030 + 0.001 0.040 + 0.001 0.0030 + 0.0004
100.0000 M Ω 500 nA || 10 M Ω 0.200 + 0.001 0.600 + 0.001 0.800 + 0.001 0.1000 + 0.0001
1.000000 G Ω 500 nA || 10 M Ω 2.000 + 0.001 6.000 + 0.001 8.000 + 0.001 1.0000 + 0.0001
DC Current 100.0000 µA < 0.03V 0.010 + 0.020 0.040 + 0.025 0.050 + 0.025 0.0020 + 0.0030
1.000000 mA < 0.3 V 0.007 + 0.006 0.030 + 0.006 0.050 + 0.006 0.0020 + 0.0005
10.00000 mA < 0.03V 0.007 + 0.020 0.030 + 0.020 0.050 + 0.020 0.0020 + 0.0020
100.0000 mA < 0.3 V 0.010 + 0.004 0.030 + 0.005 0.050 + 0.005 0.0020 + 0.0005
1.000000 A < 0.8 V 0.050 + 0.006 0.080 + 0.010 0.100 + 0.010 0.0050 + 0.0010
3.000000 A < 2.0 V 0.100 + 0.020 0.120 + 0.020 0.150 + 0.020 0.0050 + 0.0020
True RMS 100.0000 µA to 3 Hz – 5 kHz 0.10 + 0.04 0.10 + 0.04 0.10 + 0.04 0.015 + 0.006
AC Current73.00000 A 5 kHz – 10 kHz 0.20 + 0.04 0.20 + 0.04 0.20 + 0.04 0.030 + 0.006
Frequency 100 mV to 3 Hz – 5 Hz 0.070 + 0.000 0.070 + 0.000 0.070 + 0.000 0.005 + 0.000
or Period 750 V 5 Hz – 10 Hz 0.040 + 0.000 0.040 + 0.000 0.040 + 0.000 0.005 + 0.000
10 Hz – 40 Hz 0.020 + 0.000 0.020 + 0.000 0.020 + 0.000 0.001 + 0.000
40 Hz – 300 kHz 0.005 + 0.000 0.006 + 0.000 0.007 + 0.000 0.001 + 0.000
Capacitance81.0000 nF 500 nA 0.50 + 0.50 0.50 + 0.50 0.50 + 0.50 0.05 + 0.05
10.000 nF 1 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.05 + 0.01
100.00 nF 10 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
1.0000 µF 10 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
10.000 µF 100 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
Temperature9
RTD
-200 °C to 600 °C 0.06 °C 0.06 °C 0.06 °C 0.003 °C
Thermistor -80 °C to 150 °C 0.08 °C 0.08 °C 0.08 °C 0.002 °C
Continuity 1000.0
Ω 1 mA 0.002 + 0.010 0.008 + 0.020 0.010 + 0.020 0.0010 + 0.0020
Diode Test10 1.0000 V 1 mA 0.002 + 0.010 0.008 + 0.020 0.010 + 0.020 0.0010 + 0.0020
1Specifications are for 90 minute warm-up and 100 PLC.
2Relative to calibration standards.
320% overrange on all ranges, except DCV 1000 V, ACV 750 V, DCI and ACI 3 A ranges.
4For each additional volt over ± 500 V add 0.02 mV of error.
5Specifications are for sinewave input > 0.3% of range and > 1 mVrms. Add 30 µV error for frequencies below 1 kHz.
750 VAC range limited to 8 x 107Volts-Hz. For each additional volt over 300 Vrms add 0.7 mVrms of error.
6Specifications are for 4-wire resistance measurements, or 2-wire using Math Null.
Without Math Null, add 0.2
Ω additional error in 2-wire resistance measurements.
7Specifications are for sinewave input > 1% of range and > 10 µArms. Frequencies > 5 kHz are typical
for all ranges. For the 3 A range (all frequencies) add 0.05% of reading + 0.02% of range to listed specifications.
8Specifications are for 1-hour warm-up using Math Null. Additional errors may occur for non-film capacitors.
9For total measurement accuracy, add temperature probe error.
10 Accuracy specifications are for the voltage measured at the input terminals only. 1 mA test current is typical.
Variation in the current source will create some variation in the voltage drop across a diode junction.

4
A-to-D Converter Noise Performance
Integration Time Resolution Normal Mode Readings/Second4
(NPLC) (ppm of range)1Rejection (dB)2
0.001530 0 50,000
0.002515 0 25,000
0.006 6 0 10,000
0.02 3 0 3,000
0.06 1.5 0 1,000
0.2 0.7 0 300
1 0.3 55 60 (50)
2 0.2 110330 (25)
10 0.1 11036 (5)
100 0.03 11030.6 (0.5)
1Resolution is defined as the typical DCV 10 V range RMS noise.
Auto-zero on for NPLC
≥ 1. See manual for additional noise characteristics.
2Normal mode rejection for power line frequency ± 0.1%.
3For power-line frequency ± 1% 75 dB and for ± 3% 55 dB.
4Maximum rate with auto-zero off for 60 Hz and (50 Hz) operation.
5Only available for the 34411A.
System Reading and Throughput Rates
DMM memory to PC (Maximum reading rate out of memory)1
Drawing – Path B
Reading GPIB USB 2.0 LAN (VXI-11) LAN (Sockets)
Format Readings/s Readings/s Readings/s Readings/s
ASCII 4,000 8,500 7,000 8,500
32-bit Binary 89,000 265,000 110,000 270,000
64-bit Binary 47,000 154,000 60,000 160,000
Direct I/O Measurements (Single reading – measure and I/O time)1 Maximum Reading
Drawing – Path C Rate into Memory
Function Resolution GPIB USB 2.0 LAN LAN or to Direct I/O
(NPLC) ms ms (VXI-11) (Sockets) (Readings/s)
ms ms Drawing – Path A or C
DCV/2-wire 0.006 (0.001) 2.6 2.9 4.6 3.2 10,000 (50,000)
Resistance
ACV/ Fast Filter 10.0 10.0 10.0 10.0 500
Frequency 1 ms Gate
11/2 scale input signal, immediate trigger, trigger delay 0, auto-zero off, auto-range off, no math, null off,
60 Hz line frequency. Specifications are for 34410A or (34411A). See manual for performance on other functions.
System Performance
Function Range Auto- Maximum Maximum Internal
Change (ms)1Change
(ms)2 range (ms)3External Trigger Rate4
LAN/GPIB Trigger Rate
DCV/2-wire 22 3.9/2.6 7.5 5,000/s 10,000/s
Resistance (50,000/s)
ACV/ 37 6.5/6.4 19 500/s 500/s
Frequency
1 Time to change from 2-wire Resistance to this specified function,
or DCV to 2-wire Resistance using the SCPI “FUNC” command.
2Time to change from one range to the next higher range, ≤ 10 V, ≤ 10 MΩ.
3Time to automatically change one range and be ready for the new measurement, ≤ 10 V, ≤ 10 MΩ.
4Specifications are for 34410A or (34411A).
100
10
1
0.1
0.01
0.001 0.01 0.1 1 10 100
RMS Noise (ppm of range)
Integration Time (NPLC)
System Reading Architecture

DC Voltage
Measurement Method:
Continuously integrating
multi-slope IV A/D converter
Linearity: 0.0002% of reading
(10 V range) + 0.0001% of range
Input Resistance:
0.1 V, 1 V, 10 V 10 MΩ or > 10 GΩ
Ranges (Selectable)
100 V, 1000 V 10 MΩ ± 1%
Ranges (Fixed)
Input Bias Current: < 50 pA at 25 °C
Input Protection: 1000 V
DC CMRR: 140 dB1
True RMS AC Voltage
Measurement Method:
AC-coupled True RMS measurement.
Digital sampling with anti-alias filter.
Crest Factor:
No additional error for crest factors < 10.
Limited by peak input and 300 kHz bandwidth.
Peak Input:
300% of range or 1100 V
Overload Ranging:
Will select higher range if peak input
overload is detected during auto range.
Overload is reported in manual ranging.
AC CMR: 70 dB2
Maximum Input: 400 Vdc, 1100 Vpk
Input Impedance:
1 MΩ ± 2% in parallel with < 150 pF
Input Protection: 750 Vrms all ranges
Resistance
Measurement Method:
Selectable 2-wire or 4-wire.
Current source referenced to LO input.
Offset Compensation:
Selectable on the 100 Ω, 1 kΩ,
and 10 kΩ ranges
Max. Lead Resistance (4-wire):
10% of range per lead for 100 Ω , 1 k Ω .
1 kΩ per lead on all other ranges
Input Protection:
1000 V on all ranges
DC Current
Current Shunt:
200 Ω for 100 µA, 1 mA
2 Ω for 10 mA, 100 mA
0.1 Ω for 1 A, 3 A
Input Protection: 3 A, 250 V fuse
5
Measurement Characteristics
1For 1 kΩ unbalanced in LO lead, ± 500 V peak maximum
2For 1 kΩ unbalanced in LO lead and < 60 Hz, ± 500 V peak maximum
3Maximum rate for DCV, DCI, and resistance functions
(using zero settling delay, autozero off, manual range)
434411A only
True RMS AC Current
Measurement Method:
AC-coupled True RMS measurement.
Directly coupled to the fuse and shunt.
Digital sampling with anti-alias filter.
Current Shunt:
200 Ω for 100 µA, 1 mA
2 Ω for 10 mA, 100 mA
0.1 Ω for 1 A, 3 A
Maximum Input:
The peak value of the DC + AC current must
be < 300% of range. The RMS current must be
< 3 A including the DC current content.
Input Protection: 3 A, 250 V fuse
Frequency and Period
Measurement Method:
Reciprocal-counting technique. AC-coupled input
using the AC voltage measurement function.
Input Impedance:
1 MΩ ± 2% in parallel with < 150 pF
Input Protection: 750 Vrms all ranges
Capacitance
Measurement Method:
Current input with measurement of
resulting ramp.
Connection Type: 2-wire
Temperature
Thermistor:
2.2 kΩ, 5 kΩ, and 10 kΩ
RTD: α = 0.00385
Rofrom 49 Ω to 2.1 kΩ
Continuity/Diode Test
Response Time:
300 samples/sec with audible tone
Continuity Threshold: Fixed at 10 Ω
Operating Characteristics
Maximum readings/second
Digits
Function34.5 5.5 6.5
DCV 50 k410 k 1 k
2-wire
Ω 50 k410 k 1 k
DCI 50 k410 k 1 k
Frequency 500 90 10
Period 500 90 10
Filter setting fast med slow
ACV 500 150 50
ACI 500 150 50
Additional 34411A Specifications
Resolution: See table on page 4
Overall Bandwidth, DCV & DCI:
15 kHz typical @ 20 µs aperture (-3 dB)
Triggering: Pre/Post, Int/Ext, Pos/Neg
Timebase Resolution: 19.9524 µs 0.01% accuracy
Trigger Jitter:
2 µs (p-p), 20 µs (p-p) when pre-triggered
Spurious-Free Dynamic Range
& Signal to Noise Distortion Ratio
Function DCV Range Spur-Free SNDR
1 V -75 dB 60 dB
10 V1-70 dB 60 dB
100 V -75 dB 60 dB
110 V range: 2 V (p-p) < signal < 16 V (p-p)
Triggering and Memory
Reading Hold Sensitivity: 1% of reading
Samples per Trigger:
1 to 50,000 (34410A)
1 to 1,000,000 (34411A)
Trigger Delay: 0 to 3600 s (20 µs step size)
External Trigger:
Programmable edge, Low-power TTL compatible
Delay: < 1 µs Max rate: 5,000/s
Jitter: < 1 µs Min Pulsewidth: 1 µs
Voltmeter Complete: 3 V Logic output,
2 µs pulse with programmable edge
Nonvolatile Memory: 50,000 readings
Volatile Memory:
50,000 readings (34410A)
1,000,000 readings (34411A)
Sample Timer:
Range: 0 to 3600 s (20 µs step sizes)
Jitter: < 100 ns
General Specifications
Power Supply:
100 V/120 V/220 V/240 V ± 10%
Power Line Frequency:
45 Hz to 66 Hz and 360 Hz to 440 Hz,
Automatically sensed at power-on
Power Consumption: 25 VA peak (16 W average)
Operating Environment: Full accuracy for
0 °C to 55 °C, 80% R.H. at 40 °C non-condensing
Storage Temperature: -40 °C to 70 °C
Weight: 3.72 kg (8.2 lbs)
Safety: IEC 61010-1, EN 61010-1, UL 61010-1,
CAN/CSA-C22.2 No. 61010-1, Refer to
Declarations of Conformity for current
revisions. Measurement CAT II 300 V,
CAT I 1000 V. Pollution Degree 2
EMC: IEC 61326, EN 61326, CISPR 11, ICES-001,
AS/NZS 2064.1, Refer to Declaration of
Conformity for current revisions.
Vibration & Shock: MIL-T-28800E,
Type III, Class 5 (Sine Only)
LXI Compliance: LXI Class C, ver. 1.0
Warranty: 1 year

6
Ordering Information
Agilent 34410A and 34411A Multimeters
Accessories included
Test lead kit with probes and
SMT attachments, calibration
certificate, power cord, and USB
interface cable.
Product Reference CD-ROM with
soft documentation and software:
• Programmer’s Reference Help
• Quick Start Tutorial
• User’s Guide
• Service Guide
• Programming Examples
• IntuiLink for Multimeters
• LabVIEW and IVI-COM drivers
Options
Opt. A6J ANSI Z540 compliant
calibration
Probes/Leads/Clip Accessories
11059A Kelvin probe set
11060A Surface mount device (SMD) test probes
11062A Kelvin clip set
34133A Precision electronic test leads
34134A DC coupled current probe
34136A High voltage probe
34138A Test lead set
34171B Input terminal connector
(sold in pairs)
34172B Input calibration short
(sold in pairs)
34308A Thermistor kit
34330A 30 A current shunt
E2308A 5 k thermistor probe
Y1133A Low-thermal external digital multimeter scanning kit
Rack Mount Kits
34190A Rackmount kit: designed for use with only one instrument, mounted
on either the left or the right side of the rack.
34191A 2U dual flange kit: secures the instrument to the front of the rack.
This kit can be used with the 34194A dual lock link kit to mount
two half-width, 2U height instruments side-by side.
34194A Dual lock link kit: recommended for side-by-side combinations and
includes links for instruments of different depths. This kit can be
used with the 34191A 2U dual flange kit to mount two half-width,
2U height instruments side-by-side.
Other Accessories
34131A Hard transit case
34162A Accessory pouch
E5810A LAN/GPIB gateway

www.agilent.com
www.agilent.com/find/DMM
www.agilent.com/quality
www.agilent.com/find/AdvantageServices
Accurate measurements throughout the life of
your instruments.
Agilent Advantage Services
Three-Year Warranty
www.agilent.com/find/ThreeYearWarranty
Agilent’s combination of product reliability
and three-year warranty coverage is another
way we help you achieve your business goals:
increased confidence in uptime, reduced cost
of ownership and greater convenience.
For more information on Agilent
Technologies’ products, applications or
services, please contact your local Agilent
office. The complete list is available at:
www.agilent.com/find/contactus
Americas
Canada [phone]
Brazil (11) 4197 3600
Mexico 01800 5064 800
United States [phone]
Asia Pacific
Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 0120 (421) 345
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Other AP Countries (65) 375 8100
Europe & Middle East
Belgium 32 (0) 2 404 93 40
Denmark 45 45 80 12 15
Finland 358 (0) 10 855 2100
France 0825 010 700*
*0.125 €/minute
Germany
49 (0) 7031 464 6333
Ireland 1890 924 204
Israel 972-3-9288-504/544
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
United Kingdom 44 (0) 118 927 6201
For other unlisted countries:
www.agilent.com/find/contactus
(BP-3-1-13)
Product specifications and descriptions
in this document subject to change
without notice.
© Agilent Technologies, Inc. 2013
Published in USA, April 2, 2013
5989-3738EN
www.lxistandard.org
LAN eXtensions for Instruments puts
the power of Ethernet and the Web
inside your test systems. Agilent
is a founding member of the LXI
consortium.
Agilent Channel Partners
www.agilent.com/find/channelpartners
Get the best of both worlds: Agilent’s
measurement expertise and product
breadth, combined with channel
partner convenience.
www.pxisa.org
PCI eXtensions for Instrumentation
(PXI) modular instrumentation
delivers a rugged, PC-based high-per-
formance measurement and automa-
tion system.
www.axiestandard.org
AdvancedTCA®Extensions for In-
strumentation and Test (AXIe) is
an open standard that extends the
AdvancedTCA for general purpose
and semiconductor test. Agilent
is a founding member of the AXIe
consortium.
www.agilent.com/find/myagilent
A personalized view into the information
most relevant to you.
myAgilent
