AGP CS320 User manual
Warning:
For tools equipped with over load protection, when motor has shut
down o due to over load, always run machine with no load for at least
3 minutes to reduce temperature before returning to operation to avoid
burn out of the motor.
ORIGINAL INSTRUCTIONS
For your personal safety,
READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Version:20130909
2
SPECIFICATIONS
Voltage 110-120V~ 50-60Hz , 220-240V~ 50-60Hz
No load min-1 1700
Power input 110-120V: 1700W, 220-240V: 1800W
Max blade diameter 320mm
Arbor hole diameter * 25.4mm (1 inch)
Max cutting depth 121mm (on guide rail)
Net weight 8 kg (17.6 lbs.)
*Flanges supplied vary with different markets.
FUNCTIONAL DESCRIPTION
Fig.1
Depth Scale
Depth Lock Lever
Power Supply Cable
Main Handle
Lock Release ButtonLoad Indicator Light Dust Extractor Port
Kicker Lever
Side Handle
Guide Clearance
Adjustor Motor Unit
Arbor Lock Lever
Base Plate
L-Hex Key stored
in main handle
Dust Port Cap
Dust Extractor Port
Clip
Upper Blade Guard
Dust Chamber Cover
Lower Blade Guard
3
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your
mains operated (corded) power tool or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2) ELECTRICAL SAFETY
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use an earth leakage circuit
breaker. Use of an earth leakage circuit breaker reduces the risk of electric shock.
3) PERSONAL SAFETY
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
4
your finger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5) SERVICE
Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
Symbols used in this manual
V…….......volts
A…….......amperes
Hz……......hertz
5
W……......watt
~………....alternating current
n
0
………..no load speed
min-1….....revolutions or reciprocation per minute
.…...class II tool
....read these instructions
....Always wear eye protection
.....Always wear a dust mask.
.....Always wear hearing protection
do not dispose of electric tools, accessories and packaging together with household
waste material
SPECIFIC SAFETY RULES
1. DANGER: Keep hands away from cutting area and blade. Keep your second hand on auxiliary
handle. If both hands are holding the saw, they cannot be cut by the blade.
2. Do not reach underneath the work. The guard cannot protect you from the blade below the work.
3. Adjust the cutting depth to the thickness of the workpiece. Less than a full tooth of the blade teeth
should be visible below the workpiece.
4. NEVER hold piece being cut in your hands or across your leg. It is important to support the work
properly to minimize body exposure, blade binding, or loss of control.
5. Hold tool by insulated gripping surfaces when performing an operation where the cutting tools
may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts
of the tool “live” and shock the operator.
6. When ripping, always use a rip fence or straight edge guide. This improves the accuracy of cut and
reduces the chance of blade binding.
7. Always use blades with correct size and shape (diamond versus round) of arbour holes. Blades that
do not match the mounting hardware of the saw will run eccentrically, causing loss of control.
8. Never use damaged or incorrect arbor flanges or bolts. The arbor flanges and bolt were specially
designed for your saw, for best performance and safety of operation.
9. Use extra caution when making a Pocket Cut into existing walls or other blind areas. The
protruding blade may cut objects that can cause KICKBACK.
10. Dust mask should be equipped when cutting wood.
Kickback causes and related warnings
6
• kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing an
uncontrolled saw to lift up and out of the workpiece toward the operator;
• when the blade is pinched or bound tightly by the kerf closing down, the blade stalls and the
motor reaction drives the unit rapidly back toward the operator;
• if the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the blade can
dig into the top surface of the wood causing the blade to climb out of the kerf and jump back
toward the operator.
Kickback is the result of saw misuse and/or incorrect operating procedures or conditions and can
be avoided by taking proper precautions as given below.
A). Maintain a firm grip with both hands on the saw and position your arms to resist kickback
forces.
Position your body to either side of the blade, but not in line with the blade. Kickback could cause
the saw to jump backwards, but kickback forces can be controlled by the operator, if proper precautions
are taken.
B).When blade is binding, or when interrupting a cut for any reason, release the trigger and hold
the saw motionless in the material until the blade comes to a complete stop. Never attempt to
remove the saw from the work or pull the saw backward while the blade is in motion or KICKBACK
may occur.Investigate and take corrective actions to eliminate the cause of blade binding.
C).When restarting a saw in the workpiece, center the saw blade in the kerf and check that teeth
are not engaged into the material. If saw blade is binding, it may walk up or KICKBACK from the
workpiece as the saw is restarted.
D).Support large panels to minimize the risk of blade pinching and KICKBACK. Large panels tend to
sag under their own weight. Supports must be placed under the panel on both sides, near the line of
cut and near the edge of the panel.Do not use dull or damaged blade. Dull blades produce a narrow
kerf causing excessive friction, blade binding, and KICKBACK.
F).Blade depth and bevel adjusting locking levers must be tight and secure before making cut. If
blade adjustment shifts while cutting, it may cause binding and kickback.
G).Use extra caution when sawing into existing walls or other blind areas. The protruding blade may
cut objects that can cause kickback
11. Use only recommended blades, rated at the machine’s maximum rated RPM or higher with correct arbor
hole.
Lower guard function
a) Check lower guard for proper closing before each use. Do not operate the saw if lower guard
does not move freely and close instantly. Never clamp or tie the lower guard into the open
position. If saw is accidentally dropped, lower guard may be bent. Raise the lower guard with the
retracting handle and make sure it moves freely and does not touch the blade or any other part, in
all angles and depths of cut.
7
b) Check the operation of the lower guard spring. If the guard and the spring are not operating
properly, they must be serviced before use. Lower guard may operate sluggishly due to
damaged parts, gummy deposits, or a build-up of debris.
c) Lower guard may be retracted manually only for special cuts such as "plunge cuts" and
"compound cuts". Raise lower guard by retracting handle and as soon as blade enters the material,
the lower guard must be released. For all other sawing, the lower guard should operate
automatically.
d) Always observe that the lower guard is covering the blade before placing saw down on bench
or floor. An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is
in its path. Be aware of the time it takes for the blade to stop after switch is released.
12. Tighten blade retaining bolt and all clamps before operating.
13. Secure workpiece properly. Workpiece should be straight and firmly clamped to avoid possible
movement and pinching as the cut nears completion.
14. Allow the blade to come to a complete stop before removing or securing workpiece, or changing
workpiece angle.
15. Check the inside surfaces of the arbor flanges as well as the sides of the blade for freedom from any
foreign matter.
16. Check the blade for cracks or other damage before operation. Replace cracked or damaged blade
immediately.
17. Never start the tool with the workpiece against the blade.
18. Allow the motor to achieve full speed before cutting.
19. Important: After completing the cut, release power switch and wait for coasting blade to stop
completely before putting the saw down.
20. Never operate the tool in an area with flammable solids, liquids, or gases. Sparks from the commutator/
carbon brushes could cause a fire or explosion.
21. There are certain applications for which this tool was designed. The manufacturer strongly
recommends that this tool NOT be modified and/or used for any application other than for which it was
designed. If you have any questions relative to its application DO NOT use the tool until you have
written the manufacturer and have been advised
WARNING: Always wear hearing protection with this tool.
1. Intended use
This saw is designed exclusively for the sawing of metal and aluminum. This machine should not be
used for cutting other materials. Do not use this saw to cut wood. The machine should not be
converted or modified, e.g. for any other form of use, other than as specified in these operating
instructions. The user shall be liable for damages and accidents due to incorrect use.
8
CAUTION: Do not overheat the blade tips. Use of undue force will not speed up the cutting operation.
Allow the tool to determine the best feed rate.
2. Electrical connection
The network voltage must conform to the voltage indicated on the tool name plate. Under no
circumstances should the tool be used when the power supply cable is damaged. A damaged cable
must be replaced immediately by an authorized Customer Service Center. Do not try to repair the
damaged cable yourself. The use of damaged power cables can lead to an electric shock.
3. Extension cable
If an extension cable is required, it must have a sufficient cross-section so as to prevent an excessive
drop in voltage or overheating. An excessive drop in voltage reduces the output and can lead to
failure of the motor. The following table shows you the correct cable diameter as a function of the
cable length for this machine. Use only U.L. and CSA listed extension cables. Never use two extension
cables together. Instead, use one long one.
4. Saw Blades
Only use saw blades with a diameter in accordance with the markings on the tool name plate:
Only use saw blades with blade set (cutting width) of 1.8 mm to 3.6 mm and blade core thickness
of minimum 1.5mm to maximum 3.0mm. Saw blades must be suitable for speeds of up to 1700 min -1
or faster. Do not use any abrasive wheel with this machine.
UNPACKING
Carefully remove the tool and all loose items from the shipping container.
Retain all packing materials until after you have inspected and satisfactorily operated the machine.
NOTE: An appropriate blade must be mounted to the machine before operating. Refer to the section of
this manual: “INSTALLING THE BLADE”
CARTON CONTENTS
1. Plunge-Cut Circular Saw
2. M6 L-Hex Key
DO NOT OPERATE THIS TOOL UNTIL YOU READ AND UNDERSTAND THE ENTIRE INSTRUCTION MANUAL.
Total Extension Cord Length (feet) Cord Size (AWG)
25 16
50 12
100 10
150 8
200 6
9
INSTALLING THE BLADE -ENSURE THAT TOOL IS DISCONNECTED FROM POWER SOURCE.
To install the blade:
1. Remove any accumulated debris in the guards and around the
arbor.
2. Clean the inner arbor flange(3). Orient the flange so that the
correct side faces the blade and place the new blade on the arbor,
making sure that the teeth point forwards.
NOTE: Use blades that have an arbor bore which can fit, and that are
rated for the machine’s maximum rated speed or higher. Avoid
contact with blade teeth to prevent personal injury.
3. Place the outer arbor flange on the arbor with the correct side
toward the blade. See fig.2
NOTE: Take care to ensure that the blade is centered (it is possible to tighten the blade crooked
between the flanges).
4. Replace and finger-tighten the blade retaining bolt by turning it
clockwise.
5. Push in the arbor lock lever and rotate the arbor by hand until the
lock engages the arbor. Tighten the blade retaining bolt securely.
Rock the arbor with the wrench to ensure that the arbor lock has
released and release the arbor lock. see fig.3
REMOVING THE BLADE - DISCONNECT TOOL FROM POWER SOURCE.
Removal is the opposite of installing the blade, but special care must be taken to avoid injury from the blade.
1. Push in the blade lock lever and rotate the arbor with the wrench on the retaining bolt until the lock
engages the arbor. Loosen the blade retaining bolt with the provided wrench and release the arbor lock.
2. Completely unscrew the blade retaining bolt and lift it and the outer flange away, taking care not to drop
the blade.
3. Carefully rotate the lower blade guard out of the way. The blade may now be removed.
Fig.2
Blade
Outer Arbor Flange
Inner Arbor
Flange
Fig.3
Arbor Lock Lever
10
TO ADJUST DEPTH OF CUT-DISCONNECT TOOL FROM POWER SOURCE.
Adjust the depth of cut as desired. A depth scale is provided.
To adjust the depth of cut:
Loosen the depth lock lever and set the depth to the desired
level. Then tighten the lever. See fig 4
WARNING: Depth adjusting locking lever must be tight
and secure before making cut. If blade adjustment shifts
while cutting, it may cause binding and kickback.
HOW TO USE THE SIGHTING NOTCH
To aid in free-hand cutting, a sighting notch is located at the
front of the base. See fig 5
Align the cutting line on the workpiece with the sighting notch.
Additionally, the blade is visible through small gaps in the cover
for aligning the blade perfectly with the intended line of cut.
BLADE GUARD OPERATIONS
To test the function of the lower blade guard, rotate the guard through the full stroke of its travel and ensure
that the guard is able to fully return back to the closed position
under its own spring tension. If the guard is found to be sluggish
or if it sticks in any position, the problem will need to be
remedied before the machine is used again. It usually just needs
to be cleaned. To clean, first remove the sawblade and then
clean all around the rotating joint of the guard. All other repairs
should be performed by an authorized service center.
Kicker Lever: When cutting materials with a soft core, such as
sandwich panel, often the lower blade guard will not be able to
bump open automatically. In this case the kicker lever may be
used to allow the lower blade guard to open just enough to get started. Simply push the lever with the thumb
Kicker Lever
Fig.6
Depth Scale
Depth Lock Lever
Fig.4
Sighting Notch
Fig.5
11
of the left hand without removing one's hand from the side
handle. After it begins, allow the guard to function automatically
as usual. See fig 6, 6-1
DUST COLLECTION SYSTEM
Dust collection should always be used to minimise dust. Attach an appropriate hose and vacuum cleaner
system to the dust extractor port on the machine. See fig 7
If a vacuum cleaner is not available, close the cap of the dust
port. There is a dust chamber which can collect a small amount
of dust or chips which is built into the upper blade guard. Clear
the dust chamber frequently to avoid it being overfilled. To clear
the dust chamber, push up on the clip and rotate the dust
chamber cover to the open position and dump out the dust.
Once finished clip the the cover back to the closed position.
STARTING AND STOPPING TOOL
Make sure that the power circuit voltage is the same as that shown on the specification plate of the machine
and that switch is “OFF” before connecting the tool to the power circuit.
Switching the machine on and off
Keep the machine steady during switching and during use by holding the main handle and the side handles
with both hands.
To switch on:
first push the lock release button , and then press the trigger switch .See fig 8
To switch off:
Release the trigger switch. After the machine has been switched
off, the saw blade will still rotate for a time.
Take care that parts of your body do not come into contact with
the saw blade while it is still rotating!
As soon as you remove the machine from the workpiece, always
allow the lower blade guard to close completely. In this way the
saw blade is again completely covered by the outer protective
cover.
Fig.6-1
Lower Blade Guard
Fig.7
Dust Port Cap
Dust Extractor Port
Clip
Dust Chamber Cover
Dust Chamber
Fig.8
Lock Release Button
Trigger Switch
12
ELECTRONIC OVERLOAD PROTECTION AND LOAD INDICATOR LIGHT
This machine is equipped with a load indicator light that will
inform the operator of load conditions. Whenever the switch is
turned on and load conditons are normal, the indicator light will
be a solid green color. See fig. 9
If load is approaching overload conditions, the indicator light will
flash red. If the operator continues to run the machine in
overload conditions for a sustained period of time, the electronic
overload protection unit will shut the machine off. The higher the
level of overload, the more quickly the machine will shut down.
When this happens, always remove the machine from the
workpiece and run the machine at no load for a few minutes to
allow the motor to cool before continuing to avoid burning out the motor.
HOW TO USE THE TOOL
Effective control of this powerful saw requires two-handed operation for maximum protection.
Do not use this tool continuously over 30 minutes. Support the work properly and to hold the saw firmly WITH
BOTH HANDS to prevent loss of control which could cause personal injury. Always hold the side handle with
the left hand and the rear handle with the right hand for proper hand support of the saw. Protect your eyes
from injury with safety glasses or goggles. Do not use cutting fluids or lubricants on the blade.
Sawing
The machine must reach full speed before cutting begins and should only be switched off once cutting has
finished. Only operate the saw away from you (pushing the circular saw forwards) and never towards you
(pulling the circular saw backwards). If you saw towards yourself, there is the danger that the circular saw
might be accelerated out of the cutting groove (recoil) and cause serious injury.
The lower blade guard should open automatically when it hits the edge of the workpiece. If it doesn't open
automatically, give it a little help at the beginning of the cut by pushing the kicker lever with the thumb of the
left hand. This will open the lower blade guard by about 20 degrees.
Sawing sections:
• Makesurethecuttingdepthissetasdesired
• Placethefrontpartofthesawbenchontheworkpiece.
• Switchthemachineon.
• Pushthemachineinthedirectionofcut.Takecarethatthesawbaseremainsfirmlyontheworkpiece.
• Switchthemachineoffandallowthelowerbladeguardtoclosecompletelywhencuttingiscompleted.
Load Indicator Light
Fig.9
13
Plunge cuts:
• Setthedepthstoptothemaximumcuttingdepth and manually open the lower blade guard just
enough so that the blade touches the workpiece.
• Whenthemachineplunges,thecircularsawmustbeheldverysecurely,otherwisethereisthedangerof
a kickback!
• Switchthemachineon,allowittoreachfullspeedandplungethesaw.
• Onceitisfullyinthecut,begintopushthemachineintheforwarddirection.
• Switchthemachineoffoncecuttingiscompletedandallowittocometoafullstopbeforeremoving
• fromtheworkpiece.
CLAMP THE WORKPIECE
Secure the workpiece properly. The workpiece should be straight and firmly clamped to avoid possible
movement and pinching as the cut nears completion. Provide adequate support for long or wide workpieces.
Never position large or long workpieces so that they bend in the middle or at the cutting face. This can lead to
the saw blade jamming and kicking back. Instead, support the workpiece with several wooden battens, close
to the cutting face. Confirm that the blade has come to a complete stop before removing or securing the
workpiece, or changing the workpiece angle.
CAUTION: Keep the cord away from cutting area to prevent it from becoming entangled in the
workpiece.
Do not force the cut. Let the saw do the cutting at the rate of speed permitted by the type of cut and
workpiece.
GUIDE RAIL
Guide rails are available to assist in making precise straight cuts
and enhance safety. (These are an optional accessory) The guide
rail may be secured with C-clamps if desired. There are 2 guide
clearance adjustors for optimum fit and safety. Adjust these
equally so that there is no looseness, yet the base still slides
freely. See fig.10
The rubber sighting strip:
The sighting / anti-splinter strip must be cut to size along its full length before the first use. The rubber strip
must be backed by a workpiece when it is cut for the first time.
Fig.10
Guide Clearance Adjustor
14
CAUTION: Failure to use a backing workpiece on the first cut may result in the rubber strip being torn
or damaged by the blade
Once it is cut to size, it will perfectly correspond to the cutting edge and will also help to protect the material
from splintering. Once it is sized, the operator can know at a glance exactly where the line of cut will be. This
saves a lot of time and effort in making precise cuts.
KEEP TOOL CLEAN
Periodically blow out all air passages with dry compressed air. All plastic parts should be cleaned with a soft
damp cloth. NEVER use solvents to clean plastic parts. They could possibly dissolve or otherwise damage the
material.
Wear safety glasses while using compressed air.
Clean all parts of the lower blade guard mechanism to ensure smooth operation.
MAINTENANCE
The carbon brushes:
The carbon brushes are a normal wearing part and must be
replaced when they reach their wear limit. See fig.11
Caution: Always replace the brushes as a pair
To replace:
1. Remove the brush caps and withdraw the
old brushes. See fig.12
2. Replace with new brushes (always replace as a pair)
ensuring that they align properly and slide freely.
Installation is the reverse of removal.
3. Then replace the brush caps.
STANDARD ACCESSORIES
6mm L- hex key
If the replacement of the power supply cord is necessary, this has to be done by the manufacturer or
their agent in order to avoid a safety hazard
Fig.11
Brush Cap
Fig.12
15
WIRING
21
1 2
AC
SWITCH
CARBON BRUSH
STATOR
ELECTRONICS UNIT
RED
BLACK
WHITE
LED
CARBON BRUSH WHITE
16
67
73
72
70
69
68
66
75
76
74
76
75
74
78
65
50
58
59
60
61
62
64
72
73
52
63
51
54 55
56
57 58
52
77
81
80
79
72
83
85
86
24
23
21
22
21
26
27
28
34
35 36 37
39
47
46
45
49
48
29
No.01~87 V1.1
25
33
12
13
14
03
15
07
06
16
09
05
09
10
17
18
12
19
20
11
01
02
05
04
81
72
83
53
38
30
31
32
41
41
43
42
44
39
48
71
40
84
52
82
82
87
EXPLODED VIEW
17
PARTS LIST
NO. Parts Name Q'TY
1 POWER SUPPLY CORD 1
2 CORD ARMOR 1
3 LED INDICATOR LIGHT 1
4 CORD CLIP 1
5 SCREW M4 x 14 3
6 SPRING 1
7 LOCK RELEASE PLUNGER 1
8 N/A -
9 PAN HEAD SCREW M4 x 20 5
10 LOCK RELEASE BUTTON 1
11 L-HEX KEY M6 1
12 FLAT WASHER Ø8 x Ø20 x 1 2
13 HANDLE HALF RIGHT PA66 127.5g 1
14 SCREW M5 x 40 2
15 SWITCH 1
16 HANDLE HALF LEFT PA66 71g 1
17 DEPTH LOCK SHAFT 1
18 DEPTH LOCK LEVER 1
19 SPRING Ø0.7 x Ø10.5 x Ø11.9 x 4T x 18L 1
20 TORX HEAD SCREW M5 x 8 1
21 PAN HEAD SCREW M4 x 10 3
22 COVER TRACK PA66 15g 1
23 FLAT WASHER Ø4 x Ø10 x 1 1
24 DUST PORT PLUG EP 5.5g 1
25 DUST CHAMBER COVER PA66 70.6g 1
26 OUTER BLADE COVER PA66 394g 1
27 INNER PLATE 480.3g 1
28 PAN HEAD SCREW M4 x 6 7
29 SOCKET CAP BOLT M8 x 20 1
30 SPRING WASHER M8 1
31 FLAT WASHER Ø8 x Ø40 x 2.5 1
32 OUTER ARBOR FLANGE 1
33 SAW BLADE Ø320mm 1
34 INNER FLANGE 1
35 FLAT HEAD SCREW M4 x 6 3
36 BEARING COVER PLATE 1
37 LOWER BLADE GUARD 374g 1
38 SPRING 1
39 PAN HEAD SCREW M4 x 6 5
40 KICKER MECHANISM 1
41 EXTERNAL CIRCLIP S-10 2
42 PIVOT PIN 1
43 KICKER LEVER 1
44 SCREW M5 x 25 4
NO. Parts Name Q'TY
45 SCREW M6 x 12 1
46 BUMP STOP 1
47 UPPER BLADE COVER 590g 1
48 PAN HEAD SCREW M4 x 25 5
49 SIDE HANDLE 1
50 GEAR CASE 460g 1
51 SPINDLE 1
52 PARALLEL KEY 5 x 5 x 10 3
53 BALL BEARING 6202-2RS 2
54 INTERNAL CIRCLIP R-35 1
55 SPACER 1
56 OUTPUT GEAR S45C T36 1
57 NUT M14 x P2.0 x 7 1
58 BALL BEARING 608 zz 2
59 INTERMEDIATE PINION SCM415 T11 1
60 INPUT GEAR SCM415 T34 1
61 BALL BEARING 6200 zz 1
62 GEAR PLATE 292g 1
63 BALL BEARING 6002-2RS 1
64 SPINDLE LOCK UNIT 1
65 FAN BAFFLE 1
66 ARMATURE 1
67 BALL BEARING 6200-2RS 1
68 WAVE WASHER Ø29.5 1
69 SCREW W/WASHER M5 x 60 2
70 STATOR 1
71 MOTOR HOUSING 1
72 FLAT WASHER Ø5 x Ø12 x 1 6
73 SCREW W/WASHER M5 x 60 4
74 BRUSH CAP 7 x 17 2
75.) CARBON BRUSH 7 x 17 x 17 2
76 BRUSH HOLDER 7 x 17 2
77 ELECTRONICS UNIT 110V,220V 1
78 SCREW M5 x 20 1
79. PAN HEAD SCREW M5 x 16 2
80 PIVOT BRACKET 140g 1
81 TRUSS HEAD SCREW M5 x 8 2
82 SPRING WASHER Ø5 x Ø12 x 0.5 2
83 GUIDE CLEARANCE ADJUSTOR 2
84 SOCKET SET SCREW M5 x 8 1
85 PIVOT PIN Ø10 x 54 1
86 BASE 717g 1
87 RUBBER WASHER Ø10 x Ø18 x 1.1 1
Table of contents
Other AGP Saw manuals
