Features
PORTABLE
■
•Combination benchtop jointer & planer provides a 2 in 1 machine to maximize workspace
■
•Compact benchtop design ts conveniently in smallshop environments
■
•Integrated cord wrap makes transporting easy and ensures workshop safety
POWERFUL
■
•Heavy-Duty 13 Amp motor for various cutting applications
■
•Two high speed steel knives for precise, smooth cuts
■
•Oversized, ergonomic knobs provide ease of use andmaximum control
PRECISE
■
•Large aluminum extruded fence makes joining stable and precise
■
•Sheet metal outfeed table with height adjustment supports long workpieces and helps
reduce snipe
■
•Planing and joining tables lock to ensure precision cutting
■
•Precision machined table top ensures a smooth, straight cut
Large aluminum extruded fencea.
Sheet metal outfeed table with b.
height adjustment
Planing and joining tables lockc.
Precision ground table topd.
Oversized, ergonomic knobse.
Integrated cord wrapf.
C FB
SPECIFICATIONS
Stock Number 707400
Model Number JJP-8BT
Motor 120V, 60Hz, 13Amp
Knife Size (in.) 8.25 x .65 x .06
Number of Knives (RPM) 2
Cutting Speed 9,000
Cuts Per Minute CPM 18,000
Feed Speed FPM 19.5
Max. Cutting Width (in.) 8
Jointer Max. Cut Depth (in.) 1/8
Planer Max. Cut Depth (in.) .08
Cutting Thickness (in.) .20 - 4.92
Jointer Table Size (LxW/in.) 29 x 8-1/4
Planer Table Size (LxW/in.) 10-5/8 x 8-1/2
Planer Table with Out feed (LxW/in.) 17-3/4 x 8-1/2
Fence Size (LxW/in.) 4-1/8 x 21
Fence Tilt (deg.) 0-45
Gross Wt. / Net Wt. (lbs.) 68.3 / 58.4
jettools.com/b3nch
HEAVY-DUTY B3NCH™
10" JOBSITE TABLE SAW
If you're looking for a jobsite saw that's both powerful and portable, look
no further than the all-new JET®B3NCH 10" Jobsite Table Saw w/stand.
This table saw features a 15 AMP soft start motor, 25" right rip capacity,
a riving knife and anti-kickback pawls for added safety, and a heavy-duty
folding stand with wheels for quick setup and portability. Weighing in at
just under 100lbs, this powerhouse brings the stability of a stationary
table saw to your jobsite, then rolls away when you're done.
THE WOODWORKERS
•
CHOICE FOR
PRECISION
TOOLS
Features
PORTABLE
■
•Easy folding stand for convenient storage, quick setup and portability on the jobsite
■
•Rubber hand grips on each end of the table allow you to conveniently carry without stand
■
•Unique base design allows for adequate tool storage on the jobsite
POWERFUL
■
•Heavy-Duty 15 Amp motor with soft start
■
•Large telescoping extension wing provides a wide 25" ripping capacity
■
•Unique dust shroud design enhances dust and chip removal
PRECISE
■
•Aluminum extruded rails ensure a square fence and sliding precision
■
•Rear extension provides outfeed support and keeps the workpiece at
■
•New riving knife system complies with UL standards and prevents kickback
■
•Convenient push button arbor lock allows for easy and quick blade change
■
•Quick-lock fence slides smoothly and locks securely for accurate cuts
SPECIFICATIONS
Stock Number 707000
Model Number JBTS-10MJS
Motor 15 A, 120 V, 60 Hz
Ripping Capacity (in.) 25 right
Blade Speed (RPM) 4,000
Table Dimensions (LxW/in.) 24 x 21-25/32
Table Dimensions with Extension (LxW/in.) 30-1/4 x 21-25/32
Max. Cut Depth @ 90° (in.) 3-1/8
Max. Cut Depth @ 45° (in.) 2-1/2
Arbor Diameter (in.) 5/8
Blade Type (in.) 10– 40T carbide tipped
Dust Port Diameter (in.) 2-1/2
Net Wt. / Gross Wt. (lbs.) 90.39 / 104.72
Easy folding standa.
Large telescoping extension wingb.
Aluminum extruded railsc.
Quick-lock fenced.
Rear extensione.
New riving knife systemf.
AB
C
E
F
D
