Agrimate Af 4000nk User manual

User Manual

BEFORE OPERATING THIS MACHINE,

PLEASE READ THESE INSTRUCTIONS CAREFULLY

AF 4000NK - VM AUTO

Fogger

Vehicle Mount Type

DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE

SUBJECT TO CHANGE WITHOUT NOTICE

AF 4000NK - VM AUTO

Fogger

Vehicle Mount Type

MACHINE FEATURES

1. This machine has a control box, so the machine can be placed in the back of an open bed truck and

operated by a passenger in the vehicle.

2. Start-up is simple

The 12V DC battery of the truck is used by connecting it to the control box. Then you simply press the

start and fuel button at the same time, and the machine will start.

3. Durability of the machine

This machine is made almost entirely of Stainless Steel (chemical tank, fuel tank etc), which prevents

corrosion due to chemical, and fuels.

4. It is not necessary to use additional battery because you can use the battery of the vehicle.

5. Little Heat Generation

The machine has been designed so it is cooled by two air-intake valves that are connected to the fuel

ignition part of the machine. This allows the machine to remain cool during use.

6. Strong Igniter

The igniter uses a 12V DC battery so that starting the machine is quick and easy.

7. Easily Repaired

All components are designed for easy assembly/disassembly, the fuel line is made of a transparent

material. And the spark plug is easily seen, so it is easy to spot problems when they happen.

HOW TO USE

1. Items to check before using

a. Make sure fuel and chemical caps are tightly closed (The machine will not operate if they are not)

b. Make sure the connecting wires are tightly connected to the main body. (main body connector,

power connector, chemical coupling etc.)

c. Open fuel valve and chemical adjustment valve on the machine.

2. How to start-up

a. Turn on power by ﬂipping power switch up, red light is on the power lamp should come on.

b. To start the machine, hold the start button down while continuously pumping the fuel button. It is

operating when the green light appears on the control box.

c. If it does not operate, press the start button repeatedly until it in makes a ‘vroom’ sound which

means combustion is occurring in the carburetor.

d. Repeat steps a to c, until it starts.

3. How to spray chemical

a. Flip chemical switch up after the machine is started.

b. Adjust the spray to the right amount of the chemical by using the chemical adjustment valve.

4. When you are ﬁnished using the machine

a. Flip the chemical spray switch down.

b. You should wait for about 10 seconds.

c. And ﬂip the fuel button down.

d. Open the chemical tank cap.

5. What to do when use is complete

a. Clean the heat pipe with the cleaning rod. Insert the rod then turn it in a clockwise motion, in order

to prevent damage to the machine.

b. If carbon has collected in the spark plug, take out the plug and remove the carbon. (When

replacing the plug make sure it maintains a 2-3mm gap)

1. Completely empty the chemical and fuel tanks, then clean them thoroughly by the following method. Fill

with acetone liquid, screw the caps completely shut and leave for one hour. Put light oil, or water in the

chemical tank then operate it by spraying. Then clean any remaining sediment in the chemical tank.

2. Clean the residue from the chemicals by using an acetone liquid. Clean the residue due to oil by using

gasoline.

3. Set it in an upright position (with the start button pointing towards the ceiling) and cover it with vinyl to

protect it from dirt and other foreign materials.

1. Do not add gasoline or chemicals into the machine while it is hot.

2. When spraying poisonous chemicals, wear a mask. If you are going to reuse the mask make sure it is

thoroughly cleaned after every use.

3. When the machine is not running, make sure the chemical valve and the fuel valve are closed on the

control box because there is possibility of ﬁre.

STORAGE

CAUTION

Product Speciﬁcation

Type

Division

AF 4000NK - VM AUTO

TYPE Thermal Aerosol Fog Or U.L.V.

Starting Method Fully Automatic Complete Control

Power Supply 12V DC Vehicle Battery

Dimensions (mm) W : 710 x L : 1330 x H : 490

Weight (empty) 45kg

Gasoline Tank Capacity 16L

Gasoline Consumption 3.3L/h

Solution Tank Capacity 100L~150L

Solution Output 85L/h

Solution Tank Material Stainless Steel 304L

Shipping Data (mm) W : 730 x L : 1400 x H : 510

Shipping Data Weight (empty) 50kg

A. If there is a banging or coughing sound before machine it shuts itself off.

HOW TO CHECK/REPAIR MACHINE IN CASE OF PROBLEMS

Cause How to Check Solution

1. Gasoline doesn’t

ﬂow freely due to a

blocked fuel nozzle.

It is normal when the gasoline

ﬂows evenly when the start

button is pressed or pumped

Clean the fuel nozzle opening

with a thin metal wire.

Replace the o-ring of the fuel

nozzle clean the fuel nozzle

completely.

2. When gasoline does

not go through the

fuel ﬁlter.

Normally gasoline goes through

the fuel ﬁlter right away when

the start button is pressed or

pumped.

Replace and clean the fuel ﬁlter

if it does not.

3. Defective rubber liner

of the fuel tank check

valve.

• It is normal. If air goes in one

direction but cannot go out

the way it came in, does not

leak from the check valve of

the main body of the machine

causing blowing or a sucking

sound.

• It is defective if the side of

the liner is torn or swollen.

Replacement should be

performed carefully to

guarantee that the air only exits

the machine in one direction. To

check the liner put your tongue

in the middle of it and when

blow, air should move freely

through the liner.

If you try to suck air through the

liner using the same method

as above no air should move

through the liner.

4. The air pump is not

working well when

you don’t have

enough air exiting

the machine.

• The machine is normal

when strong wing exits the

machine, when the start

button is pressed.

• Check if air pump hose is

properly inserted.

• Check to see if the air pump

hose is securely attached.

• Replace air pump.

5. Insufﬁcient battery

charge is happening

when the battery

does not operate the

motor and ignition

after being changed.

• The charge is normal when

a strong spark occurs hen

touching +and-terminals of

the battery to each other.

• Check to see if the voltage

falls in the following range:

9V+for manual and 12V+for

automatic.

• Replace or recharge the

battery.

• Charge the battery until the

red signal light ﬂickers in

the automatic mode. If the

signal light doesn’t ﬂicker

then check the charger and

connections.

6. Damaged rubber

packing on the fuel

cap or the cap doesn’t

screw closed tightly.

• The cap is defective when the

user must hold the cap with his/

her hand to start the machine.

• Rubber packing is swollen.

• Replace packing

• Make sure the cap is closed

completely.

7. Leaking air from the

nipple.

To check use soap and water

to ﬁnd where the air is leaking

from then replace the nipple

from which the air is leaking.

Replace the nipple

8. Insufﬁcient gasoline

or chemical/foreign

materials in the fuel

tank.

Check out fuel tank

• Clean the fuel tank

completely

• Change the gasoline

9. Carbon build up in the

thermal pipe.

Check to see if this is the

problems by using a ﬂashlight.

If this is the problem then clean

the thermal pipe completely

with the cleaning rod.

Check the spark plug and if

there is a carbon build-up

remove it with a screwdriver.

B. When air leaks and makes a puck or when sound and the machine won’t start.

Possible damage to the thermal pipe. Check to see what the damage is by using a ﬂashlight.

To correct this problem replace the thermal pipe.

C. Chemical spraying won’t work after the machine is started.

Cause How to Check Solution

1. Defective

rubber liner in

the chemical

check valve

Normally air enters the machine in only one direction, without any leaks. It is

defective if the side of the packing is torn or swollen. You should then replace

the packing in the chemical check valve.

To check the liner, put your tongue in the middle of it and when you blow, air

should move freely through the liner. If you try to suck air through the liner

using the same method as above no air should move through the liner.

2. Blockage of the

chemical spray

pipe

If you separate the chemical spray pipe from

the chemical nozzle and the chemicals do

not came out of the chemical tank then the

chemical spray pipe could be blocked.

Using an air compressor,

blow the obstruction out of

the pipe.

3. Blockage of the

chemical nozzle

If you separate the chemical spray pipe from

the chemical nozzle and then chemicals do

not come out of the chemical tank then the

chemical nozzle could be blocked.

• Replace chemical nozzle.

• Clean chemical nozzle

with a thin metal wire.

4. Blockage of the

chemical valve.

If you separate the chemical spray pipe from

the chemical valve and then the chemicals do

not come out of the chemical tank then the

chemical valve could be blocked.

• Replace chemical valve.

• Clean the chemical valve

by using air compressor

to force air through the

blockage.

5. Chemical cap

refuses to

close tightly

• The cap is defective when the user must hold

the cap with his/her hand to start the machine.

• Rubber packing is swollen.

• Replace packing

• Make sure the cap is

closed completely.

D. You can hear the air pump operating but the machine will not work.

(That means the ignition is not working)

E. When you can see large sparks in the carburetor then the machine is not working properly.

Cause How to Check Solution

1. Defective igniter or

defective terminal

wires.

It’s normal if a spark occurs when you

hold the spark plug 3-4min from the

ignition terminal.

Make sure the + terminal has ﬁrm

contract with the ground wire.

• Replace the igniter

• Make sure terminal

contract is ﬁrm.

2. Defective spark

plug. Insufﬁcient

spark to start the

machine

Normal when spark occurs when

start button is pushed. The gap of

the spark plug is normal when it is

3-4mm. Check to see if carbon has

built up on the spark plug.

• Replace the spark plug

• Maintain 3mm gap.

• Remove carbon from the

spark plug

3. Too much gas in

the carburetor

has occurred

when there is a

knocking sound is

coming from the

carburetor.

Machine isn’t working correctly if

when you take the carburetor cover

off and cover is very wet.

• Wipe the gasoline off the

carburetor completely.

• Shut the fuel nozzle

and wait until you hear

a cough sound while

operating the machine,

then press the start

button.

4. Thermal pipe coil

damage

Check damage with a strong

ﬂashlight.

Have the thermal pipe coil

repaired.

5. Insufﬁcient battery

charge.

Insufﬁcient charge if the sound of the

machine is weak. Replace recharge the battery.

Cause How to Check Solution

1.Damaged Petal

valve

To check the petal valve

you must take a apart the

carburetor, then replace the

petal valve.

Make sure petal plate is not

moved when removing the

valve.

2. Uneven gap

between the petal

valve and the petal

valve plate.

Check the gap by taking apart the

carburetor.

Replace the petal valve or

adjust the gap so it is even.

DIAGRAM OF AF 4000NK - VM AUTO

FOGGER - VEHICLE MOUNT TYPE

PART NO. PART NAMES

AF 4000NK - VM - 1 Fuel tank

AF 4000NK - VM - 2 Fuel tank cap

AF 4000NK - VM - 3 Fuel check valve

AF 4000NK - VM - 4 Terminal board

AF 4000NK - VM - 5 Igniter

AF 4000NK - VM - 6 Air pump

AF 4000NK - VM - 7 Pressure switch

AF 4000NK - VM - 8 Solenoid valve

AF 4000NK - VM - 9 Connector

AF 4000NK - VM - 10 Air cooling pipe #2

AF 4000NK - VM - 11 Air cooling pipe case

AF 4000NK - VM - 12 Air cooling pipe case ring

AF 4000NK - VM - 13 Air cooling pipe

AF 4000NK - VM - 14 Thermal pipe

AF 4000NK - VM -14A Long Thermal Pipe

AF 4000NK - VM -14B Short Thermal Pipe

AF 4000NK - VM - 15 Carburetor (below)

AF 4000NK - VM - 16 Ignition plug

AF 4000NK - VM - 17 Carburetor gasket

AF 4000NK - VM - 18 Bolt

AF 4000NK - VM - 19 Petal cone

AF 4000NK - VM - 20 Petal

AF 4000NK - VM - 21 Petal plate

AF 4000NK - VM - 22 Petal bullet

AF 4000NK - VM - 23 Carburetor (above)

AF 4000NK - VM - 24 Air nozzle board

AF 4000NK - VM - 25 Air nozzle for carburetor

AF 4000NK - VM - 26 Carburetor bolt

AF 4000NK - VM - 27 Fuel nozzle

AF 4000NK - VM - 28 Fuel valve

AF 4000NK - VM - 29 Carburetor Assy. Unit

AF 4000NK - VM - 30 Control Unit

SPARE PARTS OF AF 4000NK - VM AUTO

FOGGER - VEHICLE MOUNT TYPE

PART NAME AND FUNCTION

Name of Part Function

1 Fuel Tank Keeps and stores gasoline

2 Fuel Check Valve Keeps air ﬂowing in one direction within the fuel tank

3 Fuel Solenoid Valve Opens and closes fuel aperture

4 Terminal Board Connects the electric wires to the main body of the machine

5 Igniter Ignition is created by changing the low voltage into

high voltage

6 Air Pump Generates air during the operation of machine

7 Pressure Switch Continuously supplies gas by turning the solenoid valve

while the machine is running

8 Chemical solenoid valve Opens and closes the chemical aperture

9 Machine Main Body Connector Connects the control box to the machine’s main body

9 Power Connector Connects the battery to the machine’s main body

10 Air Cooling Pipe #2 Brings in air to cool machine during operation

13 Air Cooling Pipe #1 Brings in air to cool machine during operation

14 Thermal Pipe Where fuel is burned

15~23 Carburetor Mixes fuel with air and ignites it

18 Chemical coupling Connects the machine’s main body to the chemical tank

27~28 Fuel Nozzle Valve Adjusts quantity of fuel used by opening and closing the

aperture

For safety use, make sure the machine is cleaned every three-months. Before working, make sure

to inspect the ﬁlter and the nozzle,and ensure there is no impurity. After working, make sure there

is no water in the pump and the hose.

If the machine needs to be repaired in the guarantee period, please return the machine to the

shop. You need to provide the certiﬁcate of purchase in order to repair or get the substitute.

Before Packing, the machine should be cleaned, then use closed packaging, packaging should be

ﬁrm. Store the machine in dry place.

For transportation safety. The machine should comply with ISTA.

Meaning of crossed - out wheeled dustbin:

Do not dispose of electrical machines as unsorted municipal waste, use separate collection

facilities.

If electrical machines are disposed of in landﬁlls or dumps, hazardous substances can leak into

the groundwater and get into the food chain, damaging your health and well-being.

When replacing old machines with new ones, the retailer is legally obligated to take back your

old machine for disposals at least free of charge.

INSPECTION & MAINTENANCE



Purchaser’s Name & Address

Product Name

Product Serial No.

Invoice / DN No.

Date of Delivery

Dealer’s Ofﬁce Seal

Dealer Sign

Customer Sign.

I/We accept the terms and conditions of Warranty

as in the Warranty Card.

CUSTOMER COPY

Warranty Card

Purchaser’s Name & Address

Product Name

Product Serial No.

Invoice / DN No.

Date of Delivery

Dealer’s Ofﬁce Seal

Dealer Sign

Customer Sign.

I/We accept the terms and conditions of Warranty

as in the Warranty Card.

DEALER’S COPY

Warranty Card

Purchaser’s Name & Address

Product Name

Product Serial No.

Invoice / DN No.

Date of Delivery

Dealer’s Ofﬁce Seal

Dealer Sign

Customer Sign.

I/We accept the terms and conditions of Warranty

as in the Warranty Card.

COMPANY COPY

Warranty Card

AF 4000NK - VM AUTO Fogger-Vehicle Mount Type

AF 4000NK - VM AUTO

Fogger

Vehicle Mount Type

1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED

WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective

material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under

warranty will be accepted on submission of Warranty Card duly ﬁlled and stamped by authorized dealer together with the original purchase

document. : b. Shipping / transportation / Incidental charges incurred in replacing defective parts under warranty shall be borne by the purchaser.

WARRANTY null & void if

(i) Lack of maintenance, (ii) Incorrect use of the machine or tampering, (iii) Use of non-genuine spare parts, (iv) Usage of acids, solvents, or any

ﬂammable materials, (v) Non-usage of ﬁlter water / clear water / soft water & using water above 40°C temperature, (vi) While using the pressure

washers to draw water which is contaminated with dust & solvents (eg. paint thinners, gasoline, oil, etc.), (vii) Repair done by unauthorized

service people, (viii) Those parts subject to wear & tear due to normal operations and plastic parts, rubber items etc, (ix) Loose connections,

faulty electrical ﬁxtures & ﬂuctuations in power supply.

4. Should any failure occur during or after the warranty period, customer does not have the right to interrupt payment / price discount.

5. Incidental or consequential damages like inconvenience commercial loss, loss of tie, mental agony etc.

6. Loss of any nature due to operation or non-operation is not covered under warranty.

7. All free service are at Dealer’s service point only.

8. Warranty ceases if service is not done periodically.

9. The attached card should be completed and returned to Ratnagiri Impex Pvt. Ltd. for registration immediately after sale / delivery.

10. The warranty is void unless you register the warranty card with Ratnagiri Impex Pvt. Ltd.

11. The decision of Ratnagiri Impex Pvt. Ltd., in settling the warranty is ﬁnal in all respects.

12. All disputes are subject to Bangalore Courts Jurisdiction
