Agrimate AM-6600-9P User manual

USER MANUAL
INTERCULTIVATOR/POWER WEEDER
AM-6600-9P GASOLINE ENGINE

HEAD ASSAMBLY - A
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-A01 HEAD COVER
2 AM-177FP-A02 GASKET HEAD COVER
3 AM-177FP-A03 BOLT COMP
4 AM-177FP-A04 BOLT COMP
5 AM-177FP-A05 WASHER,BOLT
6 AM-177FP-A06 PLUG SPARK
7 AM-177FP-A07 BOLT STUD
8 AM-177FP-A08 BOLT
9 AM-177FP-A09 BOLT STUD
10 AM-177FP-A10 CYLINDER HEAD ASSY
11 AM-177FP-A11 PIN, DOWEL
12 AM-177FP-A12 GASKET CYLINDER HEAD
13 AM-177FP-A13 WINDSHIELD
14 AM-177FP-A14 BOLT
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

CRANKCASE ASSAMBLY - B
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-B01 CRANKCASE COMP
2 AM-177FP-B02 GOVERNOR ARM SHAFT
3 AM-177FP-B03 LOCKER,GOVERNOR ARM SHAFT
4 AM-177FP-B04 Speed control pendulum oil seal
5 AM-177FP-B05 BEARING
6 AM-177FP-B06 BOLT
7 AM-177FP-B07 Aluminum pad
8 AM-177FP-B08 TUBBER GASKET
9 AM-177FP-B09 OIL SEAL
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

CRANK CASE COVER ASSAMBLY - C
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-C01 COVER, CRANKCASE
2 AM-177FP-C02 OIL SEAL
3 AM-177FP-C03 Hex Flange Bolt
4 AM-177FP-C04 DIPSTICK ASSY
5 AM-177FP-C05 DIPSTICK SEALING RING
6 AM-177FP-C06 OIL FILLER PLUG ASSY
7 AM-177FP-C07 GASKET CASE COVER
8 AM-177FP-C08 PIN DOWEL
9 AM-177FP-C09 BEARING
10 AM-177FP-C10 GOVERNOR KIT COMP
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

CRANK-CONNECTING ROD ASSY- D
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-D01 CRANK SHAFT ASSY
2 AM-177FP-D02 SPECIAL WOODRUFF KEY
3 AM-177FP-D03 BEARING
4 AM-177FP-D04 CONNECTING ROD ASSY
5 AM-177FP-D05 CLIP，PISTON PIN
6 AM-177FP-D06 PIN，PISTON
7 AM-177FP-D07 PISTON
8 AM-177FP-D08 PISTON RING ASSY
9 AM-177FP-D09 GAS RING ONE
10 AM-177FP-D10 GAS RING TWO
11 AM-177FP-D11 FILM LOOP
12 AM-177FP-D12 BUSH RING
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

1
VALVE TRAIN ASSY - E
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-E01 CAMSHAFT ASSY 17 AM-177FP-E17 NUTPIVOT LOCKING
2 AM-177FP-E02 LIFTER VALVE
3 AM-177FP-E03 ROD PUSH
4 AM-177FP-E04 VALVE INLET
5 AM-177FP-E05 VALVE EXHAUST
6 AM-177FP-E06 VALVE SPRING SEAT
7 AM-177FP-E07 VALVE SEAL
8 AM-177FP-E08 SPRING VALVE
9 AM-177FP-E09 OUTTAKE VALVE SPRING SEAT
10 AM-177FP-E10 NA
11 AM-177FP-E11 ADJUSTER EX. VALVE
12 AM-177FP-E12 PLATE PUSH ROD GUIDE
13 AM-177FP-E13 ARM ASSY VALVE ROCKER
14 AM-177FP-E14 BOLT PIVOT
15 AM-177FP-E15 ARM VALVE ROCKER
16 AM-177FP-E16 ADJUSTING NUT VALVE
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

STAR ASSY - F
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-F01 RECOIL STARTER ASSY 17 AM-177FP-F17 BOLT
2 AM-177FP-F02 WIND SCOOPER 18 AM-177FP-F18 Wire clamp
3 AM-177FP-F03 BOLT
4 AM-177FP-F04 SWITH ASSY,ENGINE STOP
4.1 AM-177FP-F4.1 PLUG,RECOIL STARTER
5 AM-177FP-F05 STARTER COMP RECOIL
6 AM-177FP-F06 CENTER POSITION BOLT
7 AM-177FP-F07 RATCHET GUIDE
8 AM-177FP-F08 CENTER POSITION SPRING
9 AM-177FP-F09 RATCHET STARTER
10 AM-177FP-F10 SPRING RETURN
11 AM-177FP-F11 REEL RECOIL STARTER
12 AM-177FP-F12 SPRING STARTER RETURN
13 AM-177FP-F13 STARTER COVER COMP RECOIL
14 AM-177FP-F14 ROPE RECOIL STARTER
15 AM-177FP-F15 HANDLE STARTER
16 AM-177FP-F16 RECOIL STARTER ASSY
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

INLET ASSY - G
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-G01 AIR INTAKE WASHER
2 AM-177FP-G02 INSULATOR
3 AM-177FP-G03 PACKING CARBURETOR
4 AM-177FP-G04 CARBURETOR
5 AM-177FP-G05 GASKET AIR CLEANER
6 AM-177FP-G06 AIR CLEANER ASSY
7 AM-177FP-G07 NUT
8 AM-177FP-G08 BOLT
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

AIR FILTER ASSY - H
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-H01 AIR CLEANER ASSY
2 AM-177FP-H02 AIR CLEANER CASE
3 AM-177FP-H03 WASTE GAS PIPE
4 AM-177FP-H04 PACKING
5 AM-177FP-H05 Air lter oil lter oil cup
6 AM-177FP-H06 SPENGE ELEMENT，AIR CLEANER
7 AM-177FP-H07 Air lter foam lter element
8 AM-177FP-H08 COVER,SEAL
9 AM-177FP-H09 BUTTERFLY NUT
10 AM-177FP-H10 COVER,AIR CLEANER
11 AM-177FP-H11 HAND WHEEL
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

CARBURETOR CIRCUIT ASSY - J
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1 AM-177FP-J01 CARBURETOR 17 AM-177FP-J17 GASKET
2 AM-177FP-J02 CAP,IDLE HOLE 18 AM-177FP-J18 BOLT
3 AM-177FP-J03 IDLE HOLE COMPONENT 19 AM-177FP-J19 BOLT，DRAIN PLUG
4 AM-177FP-J04 JET SET PILOT
5 AM-177FP-J05 CHOKE PLATE HANDLE
6 AM-177FP-J06 SCREW
7 AM-177FP-J07 FUEL SWITCH COVER PLATE
8 AM-177FP-J08 WASHER
9 AM-177FP-J09 FUEL SWITCH HANDLE
10 AM-177FP-J10 FUEL SWITCH SEAL
11 AM-177FP-J11 PIN
12 AM-177FP-J12 NOZZLE MAIN
13 AM-177FP-J13 JET MAIN
14 AM-177FP-J14 FLOAT SET
15 AM-177FP-J15 CHAMBER SET,FLOAT
16 AM-177FP-J16 WASHER
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE

THROTTLE CONTROL ASSY - K
SPARE PARTS DIAGRAM & PARTLIST-AM-MPTC-6600-ENGINE
