Agromehanika AG-TRONIK S1 User manual

Instructions for use
Remote electronic regulation
AG-TRONIK S1

AG-TRONIK
2

AG-TRONIK
3
1 SAFETY INSTRUCTIONS................................................................................................................................................ 5
1.1. Basic Safety Instructions......................................................................................................................................... 5
1.2. Structure and meaning of safety advices................................................................................................................ 6
1.3. User Requirements ................................................................................................................................................. 7
1.4. Proper Use.............................................................................................................................................................. 7
2 PREDSTAVITEV AG-TRONIK-a S1................................................................................................................................. 8
3 AG-TRONIK-a S1 CONNECTION .................................................................................................................................. 10
3.1. Antenna (NMEA) –standard equipment ............................................................................................................... 10
3.2. Speed sensor (additional equipment) ................................................................................................................... 11
3.3. GPS (additional equipment) .................................................................................................................................. 12
3.4. MOUNTING TO THE VACUUM HOLDER (additional equipment) ....................................................................... 13
4 BUTTONS OF AG-TRONIK S1 ...................................................................................................................................... 14
4.1. Buttons.................................................................................................................................................................. 14
4.2. Setup fields ........................................................................................................................................................... 15
4.3. Information fields................................................................................................................................................... 16
5 PARAMETER SETTINGS - PROGRAMMING ............................................................................................................... 17
5.1. Filling the Tank...................................................................................................................................................... 17
5.2. Hectare Dose (HD)................................................................................................................................................ 18
5.3. Speed Constant (SC) ............................................................................................................................................ 19
5.3.1. Automatic Correction of SC......................................................................................................................... 19
5.3.2. Manual Correction of SC ............................................................................................................................. 20
5.4. Flow Constant (FC) ............................................................................................................................................... 21
5.4.1. Automatic Correction of FC ......................................................................................................................... 22
5.4.2. Manual / Direct FC Correction ..................................................................................................................... 23
5.5. Working Width (WW)............................................................................................................................................. 24
5.5.1. Working Width (m)....................................................................................................................................... 24
5.5.2. Working Width (Nozzles) ............................................................................................................................. 25
5.6. Nozzle Selection ................................................................................................................................................... 25
5.7. Antenna, GPS and Speed Sensor ........................................................................................................................ 26
5.7.1. Speed Sensor NMEA - Antenna.................................................................................................................. 26
5.7.2. GPS (additional equipment) ........................................................................................................................ 27
5.7.3. Wheel Speed Sensor (optional)................................................................................................................... 28
5.8. Settings ................................................................................................................................................................. 28
5.8.1. General Settings (GS) ................................................................................................................................. 28
5.8.2. Minimum Speed (MS).................................................................................................................................. 29
5.8.3. Date and Time ............................................................................................................................................. 29
5.8.4. Screen brightness........................................................................................................................................ 30
5.8.5. Simulacija .................................................................................................................................................... 30
5.8.6. Language..................................................................................................................................................... 31
5.9. Service .................................................................................................................................................................. 31

AG-TRONIK
4
5.10. Flow Analysis ........................................................................................................................................................ 32
5.11. Daily Counters....................................................................................................................................................... 32
6 DESCRIPTION OF HANDLING WITH AG-TRONIK S1 ................................................................................................. 33
6.1. Manual Regime ..................................................................................................................................................... 33
6.2. Automatic regime .................................................................................................................................................. 34
6.3. SPRAYING GUIDELINES..................................................................................................................................... 34
6.3.1. Preparation for Spraying.............................................................................................................................. 34
6.3.2. Spraying ...................................................................................................................................................... 35
6.3.3. Completion of spraying................................................................................................................................ 35
7. ANALYSIS ...................................................................................................................................................................... 36
7.1. Work...................................................................................................................................................................... 36
7.2. Printouts................................................................................................................................................................ 37
7.2.1. Inserting a USB Key .................................................................................................................................... 37
7.2.2. Data Transfer to PC..................................................................................................................................... 37
7.2.3. Printout format on PC .................................................................................................................................. 38
8. DESCRIPTION - REGULATOR PR10EC....................................................................................................................... 40
8.1. Plain Regulation –Components of the Assembly ................................................................................................. 40
8.2. Bypass regulation –components of the assembly................................................................................................ 41
9. DESCRIPTION OF MAIN COMPONENT PARTS OF THE REGULATOR .................................................................... 42
9.1. Central-regulation Part .......................................................................................................................................... 42
9.2. Self-Cleaning Filter................................................................................................................................................ 42
9.3. Distribution Valve (manual) ................................................................................................................................... 43
9.4. Distribution Valve EC ............................................................................................................................................ 43
9.5. Flow Sensor .......................................................................................................................................................... 43
9.6. Regulation Valve with Filter................................................................................................................................... 44
9.7. Set of distribution valves (EC-06, EC-08, EC-06RV, EC-08RV) ........................................................................... 45
9.8. Manometer ............................................................................................................................................................ 46
9.9. Pressure Sensor (additional equipment)............................................................................................................... 46
9.10. Electrical Connection Cabinet .......................................................................................................................... 47
9.11. Speed Sensor (additional equipment)................................................................................................................... 48
10. WIRING DIAGRAM......................................................................................................................................................... 49
10.1. Regulation with MAIN Valve.................................................................................................................................. 49
10.2. Bypass Regulation ........................................................................................................................................... 49
11. MAINTENANCE.............................................................................................................................................................. 50
12. SETTING THE PARAMETERS IN THE AG-TRONIK .................................................................................................... 50

AG-TRONIK
5
1SAFETY INSTRUCTIONS
1.1. Basic Safety Instructions
Before first use read the instruction manual carefully
•Don't use AG-TRONIK and drive on the road. If so, stop the tractor safely.
•Before maintenance or repair of tractor, disconnect the signal cable between tractor
and AG-TRONIK.
•When charging the tractor battery disconnect the signal cable between tractor and AG-
TRONIK.
•Don’t make any unauthorized changes on AG-TRONIK. Unauthorized changes or
improper use may have negative effects on your safety and also lifespan of AG-
TRONIK. Unauthorized are all changes that are not introduced in this manual.
•Please follow all generally recognized security-technical, branch, medical and traffic
rules.
•This product does not contain parts which could be repaired. Do not open the housing
of AG-TRONIK.
•Read the instruction manual of your agricultural device, which you will use with AG-
TRONIK

AG-TRONIK
6
1.2. Structure and meaning of safety advices
All safety advices, which are in this manual, are introduced below.
WARNING
This signal word identifies medium-risk hazards, which could potentially cause
death or serious physical injury, if not avoided.
CAUTION
This signal word identifies low-risk hazards, which could potentially cause minor
or moderate physical injury or damage to property, if not avoided.
NOTICE
This signal word identifies actions which could lead to operational malfunctions if
performed incorrectly.
These actions require that you operate in a precise and cautious manner in order to
produce optimum work results.
There are some actions that need to be performed in several steps. If there is a risk
involved in carrying out any of these steps, a safety warning will appear in the
instructions themselves.
Safety instructions always directly precede the step involving risk and can be identified by
their bold font type and a signal word.
1. NOTICE! This is a notice. It warns that there is a risk involved in the next step.
2. Step involving risk.

AG-TRONIK
7
1.3. User Requirements
•Learn how to operate with terminal correctly. The terminal may not be operated by anyone
who has not read the Operating Instructions.
•Please read and carefully observe all safety instructions and warning contained in these
Operating instructions and the manuals of any connected vehicles and farm equipment.
1.4. Proper Use
•The terminal is intended exclusively for use in agriculture.
•The manufacturer cannot be held responsible for any installation or use of the terminal that
deviates from or exceeds the scope of intended use.
•The manufacturer cannot be held liable for any personal injury or property damage resulting
from such improper use. All risks involved in engaging in improper usage, lie solely with the
user.
•Intended use also includes compliance with the conditions for operation and repairs
prescribed by the manufacturer.
•The manufacturer cannot be held liable for any personal injury or property damage
resulting from such non-compliance. All risk arising from improper use lies with the
user.
•All applicable accident prevention regulations and all other generally recognized safety,
industrial, and medical standards as well as all road traffic laws must be observed. Any
unauthorized modifications made to the equipment will void the manufacturer's
warranty.

AG-TRONIK
8
2PREDSTAVITEV AG-TRONIK-a S1
•AG-TRONIK is processor-controlled device for monitoring and automatic balancing of spray on
machines for chemical protection of plants.
•It is used on combination with pressure regulator PR10EC.
•Take a few moments to familiarize yourself with component parts of AG-TRONIK.
•In picture below, zones for monitoring and managing of AG-TRONIK are introduced (Figure 1).
Figure 1
•The areas for managing and monitoring the regulation of spraying are described in table below
(Table 1).
IME
OPIS FUNKCIJE
1
ON/OFF DIODE
Informs whether the AG-TRONIK is ON.
2
TOUCH SCREEN
It enables communication with the device.
3
UP/DOWN
It enables to adjust the pressure in the system.
4
AUTOMATIC MODE
Turn ON/OFF automatic mode.
5
MAIN VALVE
Open / close the main (MAIN) valve.
6
BACK
Exit from sub-window
7
OK
Confirm the entered parameters.
8
SECTIONS
Open / close boom section.
Table 1
2
8
5
6
4
3
1
7

AG-TRONIK
9
•Connectors and buttons for operating with AG-TRONIK are shown in pictures below (Figure 2 and
Figure 3)
Figure 2
Figure 3
•Connectors and buttons for operating with AG-TRONIK are introduced in table below (Table 2).
CONNECTOR FUNCTION
TYPE OF CONNECTOR
1
SPEED SENSOR
4-pin. connector
2
REGULATOR CONECTION
7-pin. connector
3
ON/OFF AG-TRONIK
Mechanical switch
4
GPS CONNECTION
RS232 connector (9-pin.)
5
IMPORT / EXPORT DATA
USB
6
GPS POWER SUPLY
2-pin. connector
7
AG-TRONIK POWER SUPLY
3-pin. connector
8
POWER SUPLY OUT
2-pin. connector
9
FUSE
/
Table 2
2
1
3
9
6
4
5
7
8

AG-TRONIK
10
3AG-TRONIK-a S1 CONNECTION
If you are not skilled in such work, we recommend that the electronic regulation is installed by
an authorized service of Agromehanika. If you have decided to install it yourself, a brief installation
description is given further on.
•Working speed may be aquired by 3 different types of equipment: antenna (standard equipment),
Wheel speed sensor (WSS) or GPS device (both additional equipment).
•In subchapters 3.1, 3.2 in 3.3 all three options are introduced.
3.1. Antenna (NMEA) –standard equipment
•Connect power supply in to the corresponding input of the AG-TRONIK (Figure 4).
•Connect regulator cable in to the corresponding input of the AG-TRONIK (Figure 4).
•Connect antenna in to the corresponding input of the AG-TRONIK (Figure 4).
Figure 4

AG-TRONIK
11
3.2. Speed sensor (additional equipment)
•Connect power supply in to the corresponding input of the AG-TRONIK (Figure 5).
•Connect regulator cable in to the corresponding input of the AG-TRONIK (Figure 5).
•Connect speed sensor in to the corresponding input of the AG-TRONIK (Figure 5).
Figure 5

AG-TRONIK
12
3.3. GPS (additional equipment)
•Connect power supply in to the corresponding input of the AG-TRONIK (Figure 6).
•Connect regulator cable in to the corresponding input of the AG-TRONIK (Figure 6).
•Connect GPS device (both, power and signal cable) in to the corresponding input of the
AG-TRONIK (Figure 6).
Figure 6

AG-TRONIK
13
3.4. MOUNTING TO THE VACUUM HOLDER (additional equipment)
•AG-TRONIC and hydraulic control panel may be mounted on the side window of the
tractor by using a vacuum carrier (020.00.123).
•Screw the AG-TRONIK with the four screws in the groove on the back side (Figure 7).
•Using the two screws, screw the control panel into the sliding bracket (Figure 7).
•Clean the vacuum holder and tractor window before assembly.
Figure 7

AG-TRONIK
14
4BUTTONS OF AG-TRONIK S1
•AG-TRONIK enables a full control of spraying by using buttons and touch screen.
•In subchapter 4.1 buttons of AG-TRONIK are introduced, in subchapters 4.2 and 4.3, setup and
information fields are introduced.
4.1. Buttons
•The following table shows the buttons used to control the pressure regulation via
AG-TRONIK (Table 3).
NAME
SIMBOL
DESCRIPTION
AUTOMATIC
When the AUTO mode is on, the light is green. When the AUTO
mode is in standby mode (at least one of conditions is not
fulfilled), the light blinks green. When the AUTO mode is off, the
light is red.
MAIN
VALVE
When the main valve is open the light is green. When the valve is
closed the light is red.
BOOM
SECTIONS
Individual section is switched on, when the light above the key is
green. When the valve is closed the light is red.
PRESSURE
REGULATION
Button for lifting / lowering the pressure. It is active when manual
mode and a main valve are activated at the same time.
OK
Button to confirm the command or enter the sub menu.
BACK
Key to cancel input or exit from the sub menu.
Table 3

AG-TRONIK
15
4.2. Setup fields
•The setup fields are used to enter the spray parameters (Figure 8).
•By pressing the setup fields, the field function is executed, or the new sub window opens where
we can enter the parameters.
Figure 8
•In the table below, the function of each setup field is described (Table 4).
NAME
DESCRIPTION
1
HECTARE DOSE
Specifies the desired hectare consumption.
2
SPEED CONSTANT
CORRECTION
It is used for speed constant correction when using
the wheel speed sensor (optional equipment).
3
GPS
GPS connection settings.
4
GENERAL SETTINGS
Setup of date, time, language, luminance, simulation.
5
WORK
Work allows you to save spraying settings.
6
SERVICE
Service settings are accessible only to authorized
persons.
7
LIGHTS
Turn on / off the lights for night spraying.
8
SECTION VALVES
Turning ON / OFF section valves.
Table 4
1
2
3
4
7
5
6
8

AG-TRONIK
16
4.3. Information fields
•Information fields are intended to inform the user about the parameters of spraying (Figure 9).
Figure 9
•The following table describes the individual information fields (Table 5).
Table 5
NAME
DESCRIPTION OF THE FUNCTION
1
CONECTION WITH THE
REGULATOR
☑/☒- connection IS / IS NOT provided
2
TYPE OF REGULATION
Flow or pressure regulation. Flow-1 or flow-2
3
HECTARE DOSE - 1
Current or actual hectare consumption.
4
HECTARE DOSE - 2
Desired hectare consumption.
5
SPEED
Displays the current spray speed.
6
CAPACITY OF THE
RESERVOIR
Displays the initial amount of the chemical
preparation in the reservoir.
7
QUANTITY OF CHEMICAL
PREPARATION
Displays the current amount of the chemical
preparation in the reservoir.
8
SIMULATION
It informs that the simulation is in progress.
9
BOOM WIDTH
Displays the active boom width.
10
EFFICIENCY OF SPRAYING
Displays the efficiency of spraying.
11
FLOW ON NOZZLES
Displays the current flow of the chemical
preparation.
12
PRESSURE
Displays the current pressure of the control system
(in the case of a pressure sensor).
1
2
10
11
12
6
7
8
9
3
4
5

AG-TRONIK
17
5PARAMETER SETTINGS - PROGRAMMING
The use of the screen allows you to control the spray regulation completely. The main menu of
the AG-TRONIK screen is presented in the picture below (Figure 10).
Figure 10
5.1. Filling the Tank
•At each filling of the tank, it is recommended to input the current amount of chemical product in
to the AG-TRONIK.
•If we don’t input initial quantity of the chemical preparation in to AG-TRONIK or the tank is
empty, the display of the reservoir on AG-TRONIK flashes red.
•Enter the current amount of the chemical preparation by pressing icon on main menu
(Figure 10), then press the field marked with the arrow and, finally, enter the filled or initial
quantity added to the reservoir (Figure 11).
Figure 11
•Confirm the entry of a new amount of chemical preparation by pressing icon.

AG-TRONIK
18
5.2. Hectare Dose (HD)
•HD is the basic parameter, which must be set before spraying.
•Enter in the HD input sub window by pressing icon.
•The HD input subwindow where desired HD is entered (Figure 12).
Figure 12
•Confirm the HD by pressing icon.
•HD can also be set by pressing icon on main menu (Figure 10), and then icon.
•AG-TRONIK at the same time, when we adjust HD with pressing and icons,
calculates what area and distance can still be sprayed, depending on the amount of chemical
preparation in the tank (Figure 13).
•HD can be adjusted so that the entire amount of the chemical preparation is used to treat the
field, or HD is set so that we don’t run out of the chemical preparation in the end of treatment.
Figure 13

AG-TRONIK
19
5.3. Speed Constant (SC)
•WARNING! If an antenna or GPS is used, the speed constant is not corrected !
•Correction of the speed constant can be done only if the wheel speed sensor is used!
•WARNING! Speed correction can not be made when driving below 4km / h.
The correction of the speed constant can be done in two ways: the automatic correction of the
speed constant (5.3.1) and the manual / direct correction of the speed constant (5.3.2).
5.3.1. Automatic Correction of SC
•The automatic correction of SC is executed by comparing the speed shown by the AG-TRONIK
with the speed (reference / actual) on the tractor speed meter or the precise GPS device.
•If the reference speed and velocity on AG-TRONIK are different, press icon, and
enter the reference speed in to velocity input subwindow (Figure 14).
Figure 14
•Confirm SC correction by pressing a icon.

AG-TRONIK
20
5.3.2. Manual Correction of SC
•Manual correction of SC is executed by pressing a icon and by entering the
desired SC in to input subwindow (Figure 15).
Figure 15
•SC may be calcualted by using equation stated below (𝑆𝐶 = 𝑁 ×500
𝑟 × 𝜋
Equation 1)
𝑆𝐶 = 𝑁 ×500
𝑟 × 𝜋 Equation 1
N … quantity of marks
r … wheel radius
Figure 16
•Confirm SC by pressing a icon.
