OPERATION MANUAL
OPERATION MANUAL
Professional PA Wireless Microphones
Thank you for purchasing the AHUJA Professional PA Wireless Microphones.
Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this
manual will enable you to obtain optimum performance from your new AHUJA Professional PA Wireless Microphones.
Please retain this manual for future reference.
®
FEATURES
Compact,lightweight,DualChannelVHFWirelessMicrophoneSystemavailablein5differentfrequencies.
OperatesatQuartzCrystalLockedVHFHighBandfrequency.Twomicrophoneswithseparate frequenciesand
onenon-diversityreceiver.
InternalAntennas in the Microphones and two telescopicAntennas in the Receiver for clear and distortion free
reception.
Receiveroperates on 9V DCthrough anACAdaptorsupplied alongwith the system. Microphoneoperates with
a9VDryBattery.
Microphonewith3-positionslideswitchfor'AudioOn'-'AudioMute'-'Off'positions.
GreenLEDsforChannel-1&Channel-2signalindicationonreceiver.
AudiooutputfromreceiveravailableatOUT1&OUT2individuallyandasmixedoutputatOUT(1+2).
n
n
n
n
n
n
n
AHUJAintroducesAWM-490V2 as an affordable high performance VHF Wireless Microphone System. It consists
of two wireless microphones and a highly sensitive dual channel non-diversity receiver. This ensures an effective
longdistancecoverageofmorethan150 feet,underidealworkingconditions.
AWM-490V2
CARDIOID
DYNAMIC
2
CHANNEL
RECEIVER
OF SI A WI ELEC VPR ES ON L RESS R EI ER
1
CH–
O EP W ROL MEV U
SIGNAL
VH DUA CHA NE
F L N L
AWM-490V2 SIGNAL
VOME
LU
2CH–
ON ON

Rear Panel
DC: 9VOUT 1+2 OUT.2 OUT.1 ANT. 1ANT. 2
9 10 11 12 14
78 13
Frequency
Sticker Frequency Sticker
• Receiver: Front & Rear Panel Controls & Features
Front Panel
1. Power Switch 5. Signal Indicator Channel-2
Green LED glows when MIC of Channel-2 is switched
2. Power Indicator 'ON'.
Red LED glows when receiver is switched 'ON'. 6. Channel-2 Volume Control
3. Channel-1 Volume Control
4. Signal Indicator Channel-1
Green LED glows when MIC of Channel-1 is switched
'ON'.
7. Antenna 2 11. Audio Out Channel 1
8. Frequency Sticker for Channel 2 12. DC Socket
For connecting a DC plug of AC Adaptor.
9. Audio Out Channel 1+2
Mixed output of Channel 1 and Channel 2. 13. Frequency Sticker for Channel 1
10. Audio Out Channel 2 14. Antenna 1
AWM-490V2
SIGNAL SIGNAL
VHF DUAL CHANNEL
PROFESSIONAL WIRELESS RECEIVER
POWER VOLUME VOLUME
CH-1 CH-2
1 2 3456

• Operation & Battery Insertion
Receiver Hand-held Microphone
Insert the DC Plug of AC Adaptor in to the receiver. Insert a 9V battery in the battery compartment of
Insert AC Adaptor into the socket of AC mains the hand-held microphone by unscrewing the lower
supply. part of the microphone body.
Insert one end of connecting cable to Audio Output
socket of Receiver and other end of the cable to Ensure the 9V battery is inserted with correct
the Mic input of an amplifier. polarity.
The microphone has a 3-position slide switch:
In top position, the microphone is ON and Red LED
glows.
Ensure both the telescopic
antennas are fully extended
vertically. The centre of the switch is 'Standby' or 'Audio
Mute'. In this position Red LED will glow, RF
Carrier frequency will be transmitted, but 'Audio'
Switch ON the Power Switch of will be muted.
the Receiver. Red LED on front
panel will glow.
When the switch is at the lowest position, the
microphone will be completely switched off.
Always keep the receiver antennas away from
metal and other reflecting surfaces and
obstructions.
To AC mains
To DC Socket
of Receiver
12
To Audio Output
of the Receiver
To Mic Input
of an Amplifier
9ON ON ON
OFF OFF OFF
Top Position Centre Position Lowest Position
Frequency
Sticker
Unscrew
to open
ON
9V
Battery
Battery

Licensing Information:
IMPORTANT: Licensing of Ahuja wireless microphone system is the user's responsibility and licensability depends on the user's classification and application, and on the selected
frequency. Ahuja strongly urges the user to contact the appropriate telecommunications authority concerning proper licensing, and before choosing and ordering frequencies.
Microphone
RF Output Power 15mW (Max.)
RF Carrier Frequencies Available in five different VHF High Band frequencies of 201.8MHz,
225.2MHz and 205.3MHz, 229.2MHz and 209.5MHz, 227.9MHz and
215.2MHz, 249.2MHz and 219.2MHz, 247.2MHz
Modulation Mode FM(F3E)
Microphone Element Dynamic, cardioid
Dynamic Range 100dB
Spurious Emission <45dB
Maximum Deviation ±25kHz
Frequency Response 50-15,000Hz
Antenna Type Internal dipole
Current Consumption <60mA
Battery Life 6-8 hrs. with 9V battery
Controls Microphone On/Mute/Off Switch
Indication Red & Green LEDs for indicating microphones On
Dimensions ø52 (L242) mm
Weight 0.20kg (w/o battery) approx.
3K/05/08/R2
AHUJA RADIOS • 215, Okhla Industrial Estate, New Delhi - 110 020, INDIA
Tel.: [phone] Fax: [phone]
E-mail: [email protected], [email protected]
Website: www.ahujaradios.com
Design and Specifications are subject to change without notice. is a registered trademark of Ahuja Radios in India and other countries.
© Copyright Ahuja Radios, 2006, reprint 2008. All rights reserved.Any unauthorized reproduction or use of logos, images or design elements is strictly prohibited by law.
No part of the compilation may be reproduced in any manner or translated without written permission.
• Specifications
Receiver
RF Carrier Frequencies Available in five different VHF High Band frequencies of 201.8MHz,
225.2MHz and 205.3MHz, 229.2MHz and 209.5MHz, 227.9MHz and
215.2MHz, 249.2MHz and 219.2MHz, 247.2MHz
Frequency Stability ± 0.005% Quartz Crystal Controlled
Receiving Method Non-diversity
Audio Output Channel 1: 0-55mV / 1k
Channel 2: 0-55mV / 1k
Channel 1+2: 0-55mV / 1k
S/N Ratio 100dB
Distortion 0.5%
Frequency Response 50-15,000Hz
Maximum Deviation ±25kHz
Antenna Telescopic
Power Requirement 240VAC 50Hz for AC adaptor (supplied along with)
Controls Power On / Off Switch, Volume Control for Channel-1, Volume Control
for Channel-2
Indications Red LED for Power ON
Green LED for RF reception on Channel-1
Green LED for RF reception on Channel-2
Dimensions W210 x H42 x D152 mm
Weight 0.70kg approx.
Accessories 2 × Connection Cable, 1 × AC Adaptor, 2 × 9V Battery
