Sennheiser Evolution Wireless Digital EW-DX EM 2 User manual

Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser.com Printed in Germany
Publ. 04/22, 587467/A01
Quick Guide
Kurzanleitung
Guide rapide
Guida rapida
Guía de inicio rápido
Guia rápido
Beknopte handleiding
Krótka instrukcja obsługi
Snabbguide
Kort vejledning
Pikaohje
Γρήγορος οδηγός
Kısa Kılavuz
Краткая инструкция
快速指南
クイックガ イド
퀵 가이드
Evolution Wireless Digital
EW-DX EM 2
EW-DX SK
EW-DX SKM
EW-D Smart Assist
Sennheiser Documentation App
or online at
www.sennheiser.com/download
EW-DX
Instruction
Manual
EW-DX EM 2
Remote control In the box
Antennas
Audio Out Power supply
Battery
Identify/Battery check EW-DX SK | EW-DX SK 3-PINEW-DX SKM-S | EW-DX SKM
On/Off
MUTESYNC
KOR CNUS UK AU
EU
6.3 mm XLR-3
≥ 0,5 m
≥ 1 m
*
*
*optional accessories:
ADP UHF (470 - 1075 MHz)
AD 1800 (1400 - 2400 MHz)
Wireless Systems Manager (WSM)
www.sennheiser.com/wsm
Sennheiser Control Cockpit (SCC)
www.sennheiser.com/control-cockpit-software
2 AA batteries BA 70 rechargeable battery 2 AA batteries BA 70
rechargeable battery
OR OR
SK SKM(-S)
2 3
1
1 2 3 4
OR
OR
Antenna inputsAudio outputs
Power supply
PoE / Network control
(WSM / SCC)
SYNC
SETUP
DOWN
ESC
Display ON/OFFLED ch. 2Headphone
volume
control
LED ch. 1
Channel 2
Channel 1
Headphone
output
DATA LED
SYNC
MUTE
ON/OFF
ESC
DOWN
SET
UP
LINK LED
DATA LED
SYNC
ON/OFF
LINK LED
UP
SET
ESC
DOWN MUTE
(EW-DX SKM-S)
Display
Display
Off -> OnEM
SKM(-S)
SK
EM/SK/SKM(-S)
short on
On -> Off
EM/SK/SKM(-S)
long off
Rack mount angles
Power supply
Power supply
adapters
*
*
EW-DX SK 3-PIN
EW-DX SK
3.5 mm
jack
3 pin
socket
EW-D Smart Assist App

Display & Menu LEDs
Mute Key Lock
Sync
Auto Setup
MUTESYNC
MUTESYNC
MUTESYNC
MUTESYNC
EM 2
-
-Link ok audio active
-
-No link Device switched off
- No link
-
-Link ok audio muted or
no capsule on SKM
-
-Link ok audio clip
-
-Link ok Low transmitter
battery
LINK LED
(SK/SKM)
LED Ch.1/2
(EM 2)
Firmware update
in progress
Bluetooth active to
- sync with transmitter
- connect with app
DATA LED
(SK/SKM)
LED Ch.1/2
(EM 2)
Instruction
Manual
Instruction
Manual
SKM(-S)
DATA
LINK
DATA
LINK
SK
Radio
frequency
level and
link quality
(Channel 1)
Radio
frequency
level and
link quality
(Channel 2)
Transmitter
audio level
(Channel 1)
Transmitter
battery
(Ch.1/Ch.2)
Transmitter
audio level
(Channel 2)
System Home Screen
Frequency
(Channel 1) Frequency (Channel 2)
Link name
(Channel 1) Link name (Channel 2)
Radio
frequency
level and
link quality Transmitter
audio level
Transmitter
battery Audio settings
Channel 1 Home Screen Channel 2 Home Screen
Frequency
Link name
Radio
frequency
level and
link quality
Transmitter
audio level
Transmitter
battery
Audio settings
Frequency
Link name
short press
select channel & set parameters
short press
short press
SKM(-S) SK
3
21
OR
Instruction manual | Bedienungsanleitung | Notice d'emploi | Istruzioni per l'uso |
Instrucciones de manejo | Manual de instruções | Gebruiksaanwijzing |
Instrukcja obsługi | Bruksanvisning | Betjenings vejledning | Käyttöohje |
Οδηγίες λειτουργίας | Kullanım kılavuzu | Инструкция по эксплуатации | 使用说明书 |
取扱説明書 | 사용�설명서 |
Sennheiser Documentation App
EW-D Smart Assist
SKM-SSK
Mute Lock
Instruction
Manual
Auto Lock
Instruction
Manual
SKM | SKM-S
10 s
