ORATOR D860TD User manual

ORATOR AUDIO
D860TD
WIRELESS MICROPHONE
SYSTEM
INSTRUCTION
MANUAL

CONTENTS
Fortechnicalassistanceorserviceenquiries,
pleasecontact ORATORAUDIOon:
02.9938 6866
[email protected]
Description PageNumber
Introduction 1
SystemComponents 2
ControlPanels 3-4
SystemSetUp 5
FrequencySetting 6
TroubleShooting 7
TechnicalData 8
ORATOR AUDIO
PO Box 7289,
WarringahMallNSW2100
T: 02.9938 6866 F: 02. 9938 6899
E:[email protected]
W:www.orator-audio.com

Transmitter (hand-held):
RF generation/controI PLL
Frequency range UHF 520 - 694 MHz.
Switching bandwidth Max.32MHz
Channel grid 100 kHz
RF power output 30mW
Nominal/peak deviation +24k Hz / +/- 45 kHz
Current loss 140mA
Use range D860TD: Max 300m (200m ideal)
Pickup Dynamic
Battery AA (1.5V)x2
Power Life 8 - 10 hours
Receiver :
Sensitivity 1 uV (sinad = 12 dB)
Switching bandwidth Max.32 MHz
Receiving frequencies 100
Channel spacing > 400 kHz
Spurious rejection 80 dB
Image rejection 80 dB
Signal/Noise ratio 90 dB
AF output 0 - 300 mV
Receiving channels Two channels
Power DC 13 - 18 V
Power consumption 5W
Size 480 x 180 x 45 mm
Weight 1.65 kg
Introduction:
Your D860TD system has been designed to suit theAustralian
Government’s new laws relating to Wireless Microphones that came into
effect on January 1, 2015. The laws limit the approved UHF frequency
range to 520 - 694 MHz. The available UHF frequency inAustralia has
been significantly reduced in bandwidth, and coupled with the types of
other technology that use this frequency band, notably TV broadcast, there
is now greater potential for frequency interference. For this reason, the
D860TD model has been been developed with 100 selectable frequencies
available, so you can choose an alternative “clean” frequency if necessary.
The frequency that TV stations use does vary by area throughout
Australia, so problem interference frequencies tend to be area specific.
Once you find a suitable frequency for your area, you should find that the
frequency does not need regular changing unless you move around
Australia.
The D860TD is a dual channel (2 microphones) True Diversity system for
professional use, with an operating distance of up to 300m (depending on
local conditions). Wikipedia describes True Diversity as:
“Theprofessional modelstransmitin VHF orUHF radio frequencyand have ‘true’
diversityreception (two separatereceiver modules, eachwithits own antenna),
which eliminates dead spots (caused by phase cancellation) and the effects
caused by the reflection of the radio waves on walls and surfaces in general.”
The whole system circuitry is controlled by a microcomputer chip, and
you can choose the frequency to be used. The frequencies are displayed
on the Receiver screen & Transmitter, allowing for convenient control of
the system. The system uses a PLL synthesiser to generate the
frequency and to ensure better frequency stability, and enable the user to
easily choose a frequency without any interference caused by the local
environment. The Transmitter (hand microphone or beltpack) is
synchronised with the Receiver using infrared technology.
Technical Data:
---1 ---
---8 ---

System Components:
1.Receiver
2.2xHandheldMicrophones
incl batteries
3. DC PowerAdapter
4. 2 x ReceiverAerial
5.Microphonecablewith
6.3mm (1/4”) connectors
6.InstructionManual
and if ordered,
7.OptionalBeltpackTransmitter
with Headset & Lapel Microphones,
incl batteries
Troubleshooting:
1 .The Receiver is turned on but the indicator light is not lit?
Make sure if the DC power cable is properly fiitted into the power
socket & the DC cable is firmly fitted into the Receiver.
2. When you turn on both the Receiver & Transmitter (Microphone or
Beltpack), the RF light does not come on.
The RF light should come on when both transmitter & receiver are
on & the frequencies are matched. Check the power indicator light is
on in the Receiver & the Transmitter is not showing “Low Battery”. If
OK, then check that the frequency is matched & reset if necessary.
3. When you speak into the Microphone, no sound is heard from the
Amplifier/Speaker.
Make sure the volume on the Receiver is turned up, and check that
the audio (6.3mm) cable is properly installed.
4 .The audio output signal is not very good.
Check that you have installed the antennae.
Check that the Transmitter battery is not too low..
Check that the Receiver is within range & not obstructed by too
many solid objects.
Perhaps there is a strong interference in your area & you need to
change frequency.
5. The quality of the sound is not good.
Check that the Transmitter battery is not too low..
Perhaps there is a strong interference in your area & you need to
change frequency.
---2 --- --- 7 ---

System Controls:
1.Receiver:
FRONTPANEL:
REAR PANEL:
1 : Power Switch
2 : UP button (frequency selection)
3: Downbutton(frequency selection)
4 : IR button
5 : LCD Display
6: Volume adjustment.
7:IR LED Receiver
8 : ReceiverAntennae (2)
9 : Balanced Output Connector (Channel B)
10: UnbalancedOutputConnector (6.3mm cableincluded)
11 :Balanced Output Connector(ChannelA)
12. DC power socket
System Set Up:
2. Frequency Setting:
Your system comes with the hand held microphone already set to match
the existing frequency of the Receiver. To get a suitable frequency for your
area, a simple “trial and error” approach is usually the fastest solution.
Simply follow the operating instructions to test the signal quality of the
existing frequency set in the system. If you do suffer some interference,
then follow the instructions below to change your frequency.
A. Press UP button or Down button on ChannelA to choose the working frequency
and press IR Button to confirm.
B. Turn on the Power of the Microphone or Beltpack, put its infrared receiver
towards the infrared Transmitter LED of the Receiver and then press IR Button
on the Receiver. This will match the frequency of the Microphone or Beltpack to
the Receiver. When tho setting is completed, the receiver will exit the IR
transmitting mode.
C. Note that the IR receiver of the Beltpack is in the battery compartment area, so
the compartment door must be opened for the IR receiver to receiver the signal
from the Receiver unit.
D. Repeat StepsA& B on Channel B to choose the working frequency for the
second Transmitter.
E. Your system frequency should now be set (matched) and your system ready to
use.
---3 ---
---6 ---

System Controls:
2.HandHeldMicrophone:
3.BeltpackTransmitter:
1:Microphone head protector
2: Display panel
3:Power on/off’ button
4:IRReceiver
5:Battery cover
1: Mi
2:Power on/off’ button
3:TransmitterAntenna
4:Low VoltageLight
5: Display
6:IRReceiver
7: Battery compartment
System Set Up:
1. Receiver Cable Connections:
The Receiver can be connected to an amplifier or mixer to process the
microphone signal. 2 outputs are provided:
1 balanced (XLR) socket and
2. an unbalanced (6.3mm ~ 1/4”) socket. A 6.3mm cable is included so
you can use this socket to connect your Receiver.
a. Connect the output to the mixer or amplifier input using the 6.3mm cable
provided, or using an XLR cable that you will need to source.
b. Note that the 6.3mm output signal is a “mixed” signal carrying both
microphones together. If this output id used, then you do not need to use a
mixer before inputting the cable to the amplifier.
c. Connect the DC power adapter to the DC power socket on the rear
panel of the Receiver.
d.Attach the aerials provided to the Receiver.
Your system now just needs to be turned on & the system frequency set
(see next section) to be ready to use.
---4 --- --- 5 ---
