GH-1AD
Audio Only Tenant Station for the GH Series
DESCRIPTION:
The GH-1AD is an audio only tenant station for
the GH series Multi-Unit entry system. It is
equipped with a Talk, Door Release, and
optional service button. When a visitor calls,
the tenant stations rings, and is answered by
one touch of the Talk button.
The GH-1AD also has the capability of calling
the Concierge/Security Guard stations(s),
turning on a light while speaking with a visitor at
the entrance, receiving an emergency tone from
a panic call station, and releasing a door.
The GH-1AD is designed to be surface
mounted, and has a slim, streamlined design.
Up to four GH-1AD units can be used in the
same tenant location.
Communication is hands-free at the entrance
station when a tenant answers the call, and is
either VOX hands-free or push-to-talk at the
tenant station when speaking with the visitor.
FEATURES:
· Hands free audio communication
· Door release to the door where communication is
established
· Call to Security Guard / Concierge station
· Optional individual doorbell rings unique tone,
notifying resident that someone is at their door.
· Optional activation of outside light while talking to
entrance station
· Optional connection of panic call station (GFK-
PS), alerting with tone and call to Concierge
· Separate volume controls for call tone and
communication
· Simple 2-conductor common bus wiring
· Surface mounts to wall on 1-gang box or ring
· ABS plastic construction
Aiphone Corporation
1700 130th Ave NE * Bellevue, WA 98005
Ph: [phone] * Fax: [phone]
[email protected]
GH-1AD Spec Sheet
0709 Pg. 1

GH-1AD
Audio Only Tenant Station for GH Series
Aiphone Corporation
1700 130th Ave NE * Bellevue, WA 98005
Ph: [phone] * Fax: [phone]
[email protected]
SPECIFICATIONS:
Power Source: Supplied by system
Call: Varying ring tones from entrance
panel, concierge, or doorbell
Communication: Hands-free (VOX) after TALK button
is pressed once, or push-to-talk
Capacity: Max. 4 tenant stations per resident
location
Wiring: 2-conductor, PE insulation, common
bus
Wire: Aiphone #87200250C, 2 cond. PE
insulated, non-shielded, 11.05 pf/ft
Wiring Distance: GH-BC to farthest Tenant (Audio
line): 980' with 20AWG
Talk Path: Single channel with privacy
Operating Temp: 32 –104°F (0 ~ 40°C)
Dimensions (HxWxD):
6-7/8" x 4-15/16" x 1-1/4"
(175 x 125 x 32 mm)
Weight: 0.7 lbs (330g)
FEATURE CALL-OUT DEFINITIONS:
[1] Speaker
[2] Microphone
[3] Door release button
[4] Talk button
[5] Light button / Security guard station call button
[6] Service button (option)
The service button is standard equipment with the
GH-1AD-SB.
[7] Talk LED
[8] Call tone off LED
[9] Receive volume control
[10] Call tone volume control
FEATURE CALL-OUTS:
GH-1AD Spec Sheet
0709 Pg. 2
[1]
[3]
[2]
[4][5][6] [7][8]
[9]
[10]
