air choice KPT-2001D User manual

Instruction Manual
PTC Fan Heater
MODEL NO. KPT-2001D
Please Keep This User Manual For Future Reference.

PREPARING THE HEATER
WARNING: Risk of Overloading Circuit!
High wattage: 1500W, Rated current: 12.5A. Do not operate
another high wattage product on the same circuit. Receptacle
requirements: NEMA #5-20R, 125-volt grounding receptacle,
20 ampere.
1. Set the heater on a flat, even and steady surface.
2. Plug into AC 120V 60Hz power supply.
NOTE: To prevent personal injury, always use a licensed electrician to install new outlets or circuits.
No adapter should be used with this product.
CONTROL PANEL & REMOTE
Back side of
Remote
Button battery
CR2025 3V
Positive pole
PUSH
1. REMOVE the insulating sheet for the first use. There are 5 buttons on
the remote, which are equivalent to the functions of the control panel.
2. Point the remote to control panel, and the maximum signal range is
16 feet.
PRODUCT STRUCTURE
Control panel
Font cover Back cover
Air outlet Air inlet
Base
Tip-over switch at the
bottom of the base
Handle
O N /O F F
M O D E LOCK-
S C R E E N
TIMER O S C .
LOCK-
SCREEN
O S C . TIMER M O D E ON/OFF
DO NOT COVER
Power cord

OPERATION AND USE
Model
Power
Product size
Mode
KPT-2001D
120V AC, 60Hz, 1500W, 12.5A
6.3*7.0*20.5 inch
Fan / Low / High
TIMER
OSC
CAUTION: Start-up current (need 20 amp circuit breaker)
Some appliances, such as heating appliances, TV, motors, power tools, require 1.5
times more watts at start-up than the printed rated wattage. So we recommand to turn
on the heater by LOW gear firstly, then, after 1 minute, turn to HIGH gear. CAUTION:
Thermal protection / Resetting the heater
Overheat Protection System will shut the unit off when a potential overheat
temperature is reached. Unplug the heater and wait 30 mins.
SPECIFICATIONS
ON/OFF
MODE
LOCK-SCREEN
Press the button to turn on the heater, and press it again to turn off. For
safety, the fan will continue to cool down in 15s.
Press the mode button to enter Fan/Heat mode. Press HEAT button
again, it works as Low heating --> High heating --> Fan --> Low
heating circularly.
Press the button to turn off the screen.
Press the button to set timer: 0-12H circularly.
Press the button to allow oscillation. Press it again to stop.

CLEANING AND MAINTENANCE
1. Switch off the product, unplug it and wait unitl it cools down.
2. Clean the product with a dry towel or vacuum cleaner. Be sure not to wet
the heating element and the switches.
3. Always UNPLUG it when not in use. HOUSEHOLD USE ONLY!
Breakdown
No power or
do not work
Burning smell
Possible Causes and Solutions
1. Overheat protection
Unplug the heater and wait about 30 minutes to cool down, then plug
the product in again.
2. Tip-over protection
Move the heater to a firm, level surface.
3. Room reaches the desired temperature. Set Thermostat to 90°F or
turn off this function.
4. The power socket is no power.
Try another 120V power socket, whose receptacle should be at least
20A 125VAC.
5. Breaker/Fuse has been tripped.
Check the breaker of your electrical box - 20 amp circuit breaker. Do
not operate another high wattage product on the same circuit.
1. First use
It is normal for the heater to emit some odor when it is turned on for the
first time or after a long time not being used. The odor will disappear
once the heater has been running 30 minutes.
2. Check and ensure the surrounding. Remove any combustible items
within 0.9 meters (3 ft.). Use it in a well-ventilated area.
TROUBLESHOOTING
WARNING: Do not attempt to repair the heater. No user-serviceable parts inside.
Not hot Ensure a MINIMUM CLEARANCE of 6 inches (15cm) from both sides
and rear of the heater.
Inaccurate temp. The temp. sensor is at the back of the heater. There always is thermal
error. Same as A/C.

IMPORTANT SAFETY INSTRUCTIONS
READ AND KEEP THIS MANUAL FOR FUTURE REFERENCE.
1. This product is intended for indoor, non-commercial, household use for temporarily heating
residential rooms. Do not use the product for any other purpose.
2. Do not leave the product unattended while it is in use. Always unplug the product from the
electrical outlet when it is not in use.
3. Keep the product out of the reach of children and pets. This product is not intended for use by
children.
4. Place the product on a flat, steady, stable, heat-resistant surface. Never place the product
directly in front of or under a socket.
5. This product has hot parts inside. Do not use it in areas where gasoline, paint, or flammable
liquids are used or stored, as there may be a risk of fire or explosion.
6. Use the product in a well-ventilated area. This heater is hot when in use. To avoid burns, do not
let bare skin touch a hot surface. Use the handle when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, paper, clothes, and curtains at least 3 feet (0.9 m)
from all sides of the heater.
7. Use this heater only as described in this manual. Any other use may cause fire, electric shock,
or personal injury.
8. Do not insert or allow foreign objects to enter any opening on the heater as this may cause an
electric shock, fire, or product damage.
9. Do not use this product to dry or heat clothing, shoes, pipes, or other items.
10. This heater is not intended for use in damp/wet locations.
11. Never locate the heater where it may fall into a bathtub or water container.
12. Do not move the product when it is heated. Allow the product to thoroughly cool before
handling it.
13. Plug the product into 120V 60Hz electrical outlet with 15A receptacle.
14. Do not allow the Power Cord to hang (e.g., over the edge of a table or counter) or place/run
the Power Cord under rugs, carpeting, or in high-traffic areas where it may be tripped over or
pulled.
15. To disconnect the product, press the Power button on the display panel and then remove the
plug from the electrical outlet. Never pull on the Power Cord when disconnecting from power
outlet.
16. Do not put any stress on the Power Cord where it connects to the product, as the Power
Cord could fray and break.
17. Do not plug or unplug the product from the electrical outlet with wet hands.
18. Keep the Power Cord and product away from heated surfaces.
19. Do not operate any heater with a damaged cord or plug.
CAUTION
DO NOT TOUCH
WARNING
DO NOT COVER
WARNING
DO NOT OPEN
CAUTION
HOT SURFACE

WARRANTY
AIR CHOICE warrants this product against defects in materials and/or
workmanship under normal use for a period of ONE (1) YEAR from the date of
purchase by the original purchaser (“Warranty Period”). If a defect arises and a
valid claim is received within the Warranty Period, at its option, AIR CHOICE will
either 1) repair the defect at no charge, using new or refurbished replacement
parts, or 2) replace the product with a new product that is at least functionally
equivalent to the original product, or provide a store credit in the amount of the
purchase price of the original product. A replacement product or part, including a
user-installable part installed in accordance with instructions provided by AIR
CHOICE, assumes the remaining warranty of the original product. When a
product or part is exchanged, any replacement item becomes your property and
the replaced item becomes AIR CHOICE’ s property. When a store credit is
given, the original product must be returned to AIR CHOICE and becomes AIR
CHOICE’ s property. To obtain warranty service, e-mail AIR CHOICE Limited
Warranty Service at [email protected]. Please be prepared to
describe the product that needs service and the nature of the problem.
This warranty does not apply to:
a) damage caused by failure to follow instructions relating to product use or
the installation of components;
b) damage caused by accident, abuse, misuse, fire, floods, earthquake or
other external causes;
c) damage caused by service performed by anyone who is not a
representative of AIR CHOICE;
d) accessories used in conjunction with a covered product;
e) a product or part that has been modified to alter functionality or capability;
f) items intended to be periodically replaced by the purchaser during the normal
life of the product including, without limitation, batteries or light bulbs;
g) any product sold “as is” including, without limitation, floor demonstration
models and refurbished items;
h) a product that is used commercially or for a commercial purpose.

Thank you for choosing AIR CHOICE product.
For any customer product questions or honor your warranty, please write to
[email protected]. Our usual response time is within 12 hours!
CONTACT US
