AIR-O-LATOR ICE-AWAY IA-5 Manual

1
8100-04 Paseo, Kansas City, Missouri 64131
800-821-3177
INSTALLATION
OPERATION
AND
MAINTENANCE
OF THE
ICE-AWAY
DO NOT DESTROY!
This manual is designed for your use in the installation, operation and maintenance of the Ice-
Awayde-icer. Store this document in an easily accessible location.
The following information is provided to alert persons to potential personal injury hazards
inherent with products.
! DANGER:Indicates an eminently hazardous situation which, if not avoided, will result in
death or serious injury.
! WARNING:Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
! CAUTION: Indicates a potentially hazardous situation, which may result in minor or
moderate injury.
January 1, 2005

2
SAFETY DATA INFORMATION SHEET
! DANGER: RISK OF ELECTRIC SHOCK. DO NOT INSTALL THIS
EQUIPMENT IN SWIMMING AREAS. THIS EQUIPMENT HAS
NOT BEEN INVESTIGATED FOR USE IN SWIMMING AREAS.
! WARNING: DISCONNECT AND LOCK OUT ELECTRICAL POWER
BEFORE ANY SERVICE IS PERFORMED ON THIS DEVICE.
! WARNING: THE CONTROL PANEL AND UNIT MUST BE GROUNDED. FAILURE TO CONNECT
TO A PROPER GROUND COULD RESULT IN PERSONAL INJURY OR DEATH.
! WARNING: BEFORE ATTEMPTING TO INSTALL, SERVICE OR MAINTAIN
THE UNIT AND/OR FLOTATION IN ANY BODY OF WATER A
COAST GUARD APPROVED PERSONAL FLOTATION DEVICE
(PFD, TYPE III OR HIGHER) MUST BE WORN.
! WARNING: THE FLOTATION PROVIDED FOR THIS EQUIPMENT, HAS
NOT BEEN INVESTIGATED PERSONAL FLOTATION DEVICE.
! WARNING: ATTEMPTING TO INSTALL OR SERVICE EQUIPMENT FROM
AN UNSTABLE WORK PLATFORM COULD RESULT IN DEATH
OR INJURY.
! WARNING: POSSIBLE CUTTING HAZARD. ROTATING PROPELLER COULD RESULT IN
SERIOUS INJURY. TURN OFF POWER AND LOCK OUT BEFORE INSTALLATION
OR SERVICING.
! NOTICE: DO NOT OPERATE THIS EQUIPMENT OUT OF THE WATER.
(EXCEPTION:) IT IS PERMISSABLE TO BUMP RUN 3-PHASE
EQUIPMENT OUT OF THE WATER TO VERIFY COUNTER
LOCKWISE MOTOR ROTATION WITH A RAPID ON/OFF
OPERATION.
! CAUTION: INSTALLATION OR SERVICE WORK MUST BE PERFORMED
FROM A STABLE WORK PLATFORM TO AVOID THE
POSSIBILITY OF CAPSIZING.

3
ASSEMBLY AND OPERATING INSTRUCTIONS
For MODEL #IA-5 ICE-AWAY
Remove unit from carton - shipped completely assembled.
INSTALLATION
STEP 1 Remove the Ice-Away from the carton, place on a flat surface. Note that the Ice-
Away has two (2) 10-foot suspension ropes already attached to the
diffuser.
! CAUTION: DO NOT TURN THE UNIT ON UNTIL THE MOTOR IS SUBMERGED IN
WATER. THE MOTOR IS WATER-COOLED AND WATER-LUBRICATED.
THE ICE-AWAY MUST NOT BE ALLOWED TO BE BURIED IN SAND OR
MUD. IF THIS OCCURS, SERIOUS MOTOR DAMAGE WILL RESULT
AND WARRANTY WILL BE VOIDED.
STEP 2 Attach the opposite ends of the rope to the vessel (as shown in Illustration A) or
dock/pier mount (as shown in Illustration B).
MOORING OF FLOTATION (as shown in Illustration C) Float to be purchased separately
STEP 1 Insert one sling rope end into one of the molded holes in the corner of the flotation
and tie off. Do the same with the other sling rope diagonal to the first corner.
Only two opposing corners are needed for the suspension of the Ice-Away.
STEP 2 The flotation mooring ropes (supplied by others) may be tied off to the shore, or
as is most commonly done, anchored by means of concrete blocks. See
Illustration C.

4
MOORING OPTIONS
ILLUSTRATION A ILLUSTRATION B
A PIECE OF ROPE WILL DO IT!
Mounting is simple using the “SLING
APPROACH”. Just sling the unit under
the boat, between pilings OR anywhere that
the most effective results are achieved.
ILLUSTRATION C

5
ELECTRICAL CONNECTIONS
!DANGER: ELECTRIC SHOCK HAZARD. DISCONNECT ELECTRICAL
POWER BEFORE SERVICING MACHINE.
!WARNING:ROTATING PROPELLER COULD RESULT IN SERIOUS IN-
JURY, TURN OFF POWER BEFORE SERVICING MACHINE.
! CAUTION: UNIT MUST BE GROUNDED, FAILURE TO CONNECT TO
PROPER GROUND COULD RESULT IN PERSONAL INJURY.
DETERMINE VOLTAGE OF UNIT (110/120 OR 230/240).
GROUND FAULT PROTECTION IS STRONGLY SUGGESTED
ON ANY ELECTRICAL DEVICE.
A dedicated circuit for the Ice-Away de-icer is strongly advised. Connect power after the unit is
submerged. The motor is internally protected with an automatic thermal overload and is
lightning protected. It is advisable to connect the unit to one (1) 15-amp circuit breaker. The
unit is ready to be placed into operation.
MAINTENANCE
It may be that you will be able to leave the unit in position for occasional operation during the
summer. For warm weather storage out of the water, it is suggested that the unit be stored in an
upright position, in a relatively cool area (not to exceed 100°F).
IMPORTANT: DISASSEMBLY OF THE MOTOR BY ANYONE OTHER THAN A
FRANKLIN AUTHORIZED SERVICE CENTER OR BY THE
FACTORY WILL VOID THE WARRANTY. THERE ARE NO USER
SERVICABLE PARTS IN THE MOTOR.
The Model #IA-5 ICE-AWAY uses a ½-horsepower, super stainless submersible Franklin motor.
These motors are filled with water. It is water-cooled and the bearings are water-lubricated. For
this reason, the prior methods of storage are recommended.
The propeller is what causes the warmer water to move upward. For this reason periodic
inspection of the propeller for damage is suggested to help promote maximum performance and
to minimize out of balance conditions, which can promote premature motor failure.

6
Franklin Electric Submersible Motor Specifications (60 Hz)
Motor Maximum Line to Line S.F. Circuit Breaker Fuse
Amp Size Amp Size
Model Number H.P. Volts S. F. S.F.Amps Watts Resistance PowerFactor % Standard Time Delay
244301 0.5 115 1.6 12.0 1000 1.0-1.3 73.00% 35 20
224302 0.5 230 1.6 6.0 1000 4.2-4.5 73.00% 20 10
Cable Selection Guide
Single Phase, Two Wire with ground cable, 60 Hz
(Maximum length in feet – Service entrance to Ice Away)
HP Volts 12 10 8
0.5 115 150 250 350
0.5 230 650 1000 1600

7
CERTIFICATE OF LIMITED WARRANTY
2004
1. Your Legal Rights Under This Warranty
This warranty is the only express warranty that Air-O-Lator makes for your Air-O-Lator product. This warranty
gives you specific legal rights.
This warranty is only for products sold for use in the USA.
THERE ARE NOT WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE
HEREOF.
This warranty will be governed by the laws of the State of Missouri, USA.
2. What’s Covered
2.1 Basic Warranty
Air-O-Lator warrants to the original purchaser that the equipment delivered by it will be of the kind and
quality described in the order and will be free of defects in workmanship, material or factory
preparation when operated under normal use and services.
A. What’s Covered at No Cost to You
The Basic Warranty covers the cost of all parts needed to repair any defective item on your Air-O-Lator
product – that is, defective in material, workmanship, or factory preparation. Warranty repairs or
adjustments – including all parts and labor connected with them – will be made at Air-O-Lator Corporation
or an AUTHORIZED repair facility.
B. Products Covered
All aerators, fountains and de-icers using Franklin Electric 4” and 6” motors.
C. When It Begins
The Basic Warranty begins on either of the following dates, whichever is earlier:
•The date you take delivery of the Air-O-Lator product or
•The date when the product was first put into service – up to 18 months from the date of manufacture.
D. When It Ends
The Basic Warranty lasts for 36 months for the Font’n-Aire and Aquarian Commercial (12 months for
equipment used in wastewater). Aquarian Residential and the Ice-Away de-icer equipment is warranted for
24 months (12 months for equipment used in wastewater), The Aquarian Aquaculture and Aquarian
Quantum equipment is warranted for 12 months.

8
E. Exceptions
Exceptions to the 36 month warranty and 24 month warranty are: equipment used in severe environments,
which are warranted for 12 months, i.e., wastewater applications or where high concentrations of corrosive
or abrasive material are present.
F. Registration and Operation Requirements
The Basic Warranty covers your Air-O-Lator product only if:
•It was built for sale in the U.S.
•It’s registered in the U.S.
•It’s used in the U.S. and
•It’s operated and maintained in the manner described in your Owner’s Manual.
3. What’s Not Covered
3.1 Modifications Not Covered
A. Some Modifications Don’t Void this Warranty but Aren’t Covered
Certain changes that you might make to your product do not, by themselves, void this warranty. Examples
of some of these changes are:
•Installing non-Air-O-Lator supplied parts, components, or equipment (such as a non-Air-O-Lator supplied
Franklin Electric motor, stainless steel fasteners, or fountain nozzles).
But this warranty does not cover any part that Air-O-Lator did not supply. Nor does this warranty cover the
cost of any repairs or adjustments that might be caused or needed because of the installation or use of non-
Air-O-Lator parts, components, equipment, or materials.
Examples of the types of alterations not covered are:
•Installing accessories – except for genuine Air-O-Lator accessories approved for installation – such as lighting,
propeller guards, rock covers, or motors.
•Labor to install or remove any Air-O-Lator product.
B. Modifications That Will Void Your Warranty
Disconnecting, tampering with, or altering the electric control panels will void your warranty, unless you or
your repairing technician follows Air-O-Lator’s requirements for repairing or replacing the controls.
Removing and operating Air-O-Lator equipment without Air-O-Lator approved electrical controls will also
void this warranty. Using any electric cable, connectors or splices not provided or authorized by Air-O-
Lator will also void this warranty.
3.2 Environmental Factors Not Covered
This warranty does not cover damage caused by environmental factors such as, chemicals, and salt. Nor
does your warranty cover damage caused by windstorms, hailstorms, tornadoes, lightning, power
surges, brownouts, floods, earthquakes debris and animals.
3.3 Maintenance Costs Not Covered
This warranty does not cover the cost of repairing damage caused by poor or improper maintenance.
This warranty does not cover the costs of your equipment’s normal or scheduled maintenance I.e. annual
propeller/impeller replacement, cleaning etc.

9
3.4 Incidental and Consequential Damages Not Covered
This warranty does not cover any incidental or consequential damages connected with Air-O-Lator
products’ failure, either while under warranty or afterward. Examples of such damages include:
•Lost time, Inconvenience; The loss of the use of equipment; The loss of personal or commercial property; The
loss of revenue; and Delay
•
3.5 Certain Kinds of Corrosion Not Covered
This warranty does not cover the following:
•Corrosion caused by accident, damage, abuse, or alteration;
•Surface corrosion caused by such things as, sand, salt, stones and barnacles.
•Corrosion caused by the extensive or abnormal exposure of caustic materials like chemicals, acids, and
fertilizers.
3.6 Freight:
Warranty shipping charges are to be pre-paid by the owner.
Warranty shipping charges are the responsibility of the owner.
4. How To Get Warranty Service
4.1 Where to Take Your Air-O-Lator Product
Air-O-Lator authorizes you to return your Air-O-Lator products to the factory upon notification.
You may contact: Air-O-Lator Corporation: 8100-04 Paseo, Kansas City, MO 64131, 1-800-821-3177.
http//:airolator.com
CUSTOMER REGISTRATION COPY
Owner Name____________________________ Model ______________________________
Date Purchased_________________________ Serial No.___________________________
Owner Address__________________________ Dealer Name_________________________
City__________________________________ Address_____________________________
State__________ Zip__________ City___________ State____ Zip Code_____
NOTE: This information should be retained for your file.
AIR-O-LATOR CORPORATION, 8100-04 PASEO, KANSAS CITY, MO 64131
1-800-821-3177 http//airolator.com

10

11
8100-04 Paseo, Kansas City, Missouri 64131
800-821-3177
MAIL IN FORM
WARRANTY REGISTRATION
Font’ N-Aire Aquarian Ice-Away
Ready ______ ` Residential _______ ________
Platinum ______ Commercial _______
Gulf Stream ______ Aquaculture _______
Quantum _______
Purchase Date Mo.______ Day______ Year_______
Model No._________________________ Serial No.__________________________
Owner Name Dealer Name________________________
Owner Address Dealer Address_______________________
City _______________________________ City________________________________
State___________ ZIP Code _____________ State__________ ZIP Code__________

12

13
AIR-O-LATOR CORPORATION
REPAIR RETURN FORM
To avoid delays in the repair of equipment in question, it is best to call the factory at 1-800-821-
3177. DO NOT DISASSEMBLE ANY PORTION WITHOUT PRIOR AUTHORIZATION!
Shipping costs to and from the factory are the responsibility of the shipper as is the packaging.
Air-O-Lator encourages the use of the original shipping container that is UPS approved for this
equipment to minimize the possibility of shipping damage. Additional charges will apply if
original packaging is not retained.
If the original packaging is not retained and used by the customer, Air-O-Lator will supply
replacement packaging (at a nominal charge) upon return of the equipment to the shipper (call for
current pricing).
Upon the inspection of returned equipment, whether in warranty or not, contact by Air-O-Lator
to proceed with repair will be made to the owner or agent with an explanation of the repairs and
charges if any. NO REPAIRS WILL BE MADE UNLESS AUTHORIZED BY THE OWNER
OR AGENT. If Air-O-Lator is unable to contact the owner/agent within 30 days after receipt of
the equipment for repair, a “signature required” notice will be forwarded to the owner or agent
stating that disposal of the equipment will be made 30 days from the date of the notice.
Name_________________________________________________________________________
Address_______________________________________________________________________
Phone_____________________FAX____________________E-Mail______________________
E-mail______________________ Equipment Serial #__________________________________
Comments:___________________________________________________________________________________
____________________________________________________________________________________________
____________________________________________________________________________________________
