airhood AH-01BE User manual

Airhood (AH-01BE) | 1
Wireless Portable Air Cleaner
(AH-01BE)
USER MANUAL
EN FR ES

2| EN | Airhood (AH-01BE) Airhood (AH-01BE) | EN | 3
SAFETY INFORMATION
Please read and save these instructions carefully before using your AirHood and keep for
future reference. If you pass this AirHood to another person, make sure to include this manual.
■Use the AirHood only for its intended purpose and as described in this manual. Improper
use may result in an electric shock, re or serious injury and may void the warranty. In the
event of improper use or incorrect operation, we do not accept any liability for resulting
damages.
■The AirHood is intended to be used in household applications only.
■The AirHood is not intended for commercial, industrial or outdoor use.
■To prevent the risk of an electrical shock, do not place the AirHood near a source of water
or where water may splash or drip on it. Never immerse the AirHood, plug or charger/
power cord in water.
■Do not operate the AirHood with a damaged charger/power cord or plug, after a
malfunction, or if dropped or damaged in any manner. Never attempt to dismantle or repair
the AirHood. If the AirHood, cord or plug are damaged in any way, do not use the AirHood
and contact an authorized service center.
■The AirHood is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the AirHood by a person responsible for
their safety.
■The AirHood is not a toy. Always supervise children to make sure they do not play with
the AirHood. Close supervision must be provided when the AirHood is used by or near
children. Make sure it is stored in a location that is inaccessible to children.
■Never leave the AirHood unattended while it is in operation.
■Always unplug the AirHood from the mains outlet when it is unattended, not in use,
when moving the AirHood, before changing lters and cleaning.
■The AirHood should not be operated by an external timer switch or remote control.
■Place the AirHood on a at, dry, heat-resistant and stable surface.
■Avoid using the AirHood in front of air conditioners, fans or open windows as they may
reduce the effectiveness of the AirHood.
■Before rst use, make sure the power voltage matches the information on the AirHood
rating label.
■When charging, keep away from heat, oil or ammable objects. When the AirHood is not
being used for a week or more, unplug the charging cable. Only use the charger provided.
■Do not let the charger/power cord hang over sharp edges, the edge of a table or counter
or touch any hot objects. Arrange the cord in a location where it cannot be easily caught on.
■To disconnect the AirHood from the mains power, pull the plug out. Do not pull the
charger/power cord.
■Only use the manufacturer’s approved accessories.
■Never cover the AirHood. Ensure there is sufcient ventilation.
■Never insert ngers, pencils or other similar objects through the covers.
■The AirHood must be assembled completely before use.
■Keep hair or loose clothing away from the AirHood when it is in use, as there is a danger
that they can be caught in the AirHood and cause injury.
■Never operate the AirHood with wet hands or when standing on wet ground.
■RISK OF SUFFOCATION! KEEP OUT OF REACH OF CHILDREN – Keep all packaging
materials out of the reach of babies, children and pets.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to t in a polarized outlet only one way.
If the plug does not t fully in the outlet, reverse the plug.
If it still does not t, contact a qualied electrician.
Do not attempt to defeat this safety feature.
Battery-related safety instructions
■The built-in battery must only be replaced by a qualied service provider using the exact
same or equivalent type battery. Incorrect battery installation could lead to an explosion.
■Keep the unit in a temperate climate. High temperatures can damage the AirHood’s
performance and reduce the battery’s lifespan. Exposure to low temperatures and then
warmer temperatures can cause condensation inside the unit that may damage the
electronic circuits.
■Disposal of a battery into re or a hot oven, or mechanically crushing or cutting
of a battery, can result in an explosion.
■Danger of explosion! A battery subjected to extremely low air pressure, extremely high
temperatures or intense heat sources such as direct sunlight or naked ames may result
in an explosion or leakage of ammable liquid or gas.

4| EN | Airhood (AH-01BE) Airhood (AH-01BE) | EN | 5
DESCRIPTION OF PARTS
1
5
6
8
9
7
10
2
3
4
1. Power switch
O – Off
I – Low
II – Medium
III – High
2. Air duct tab
3. Air duct with front lter
4. Main body
5. Air diffuser with tab
6. Handle
7. Battery indicator lights
8. Charging socket
9. Charger cord and plug
10. Rear lter (charcoal lter)
Front view Rear view
■High or low extreme temperatures that a battery can be subjected to during use, storage
or transportation:
– during use: -10°C to 40°C / 14°F to 104°F
– storage: -10°C to 40°C / 14°F to 104°F
– transportation: -10°C to 40°C / 14°F to 104°F
■Do not charge the battery longer than specied as this can reduce the battery’s lifespan.
Charge the battery fully when using the unit for the rst time.
■Charge the battery at least once a month, even if you are not using it, to protect the
battery and ensure its longevity.
■In the event of a leak, immediately contact the wholesaler, retail outlet or service centre
for assistance. If the battery acid has leaked, avoid any contact with the skin, eyes, and
mucous membranes. Should you accidentally come into contact with the battery acid,
rinse the affected area and contact a doctor.
■To prevent the battery from overheating:
– When the room temperature ambient temperature reaches 65°C, the protection
will be activated. All device functions will turn off (light, fan, charging circuit).
– When the ambient temperature drops to about 60°C, the functions will not be restored
immediately. The user needs to perform operations to restore the device’s function.
– When the function is available, all battery indicator lights will turn on until the user
resets the device.
– To initiate the reset the user will have to slide the switch to “O” level. If it is already
on “O” level, then it needs to slide to another level and return to “O” so that the PCB
can receive the signal.
READ AND SAVE THESE INSTRUCTIONS

6| EN | Airhood (AH-01BE) Airhood (AH-01BE) | EN | 7
HOW TO USE
■Unpack and remove all packaging materials from the AirHood and accessories.
■Check for damage. If any parts are damaged or missing, do not use the AirHood
and return it to your retail outlet immediately.
OPERATING INSTRUCTIONS
Your AirHood sucks in contaminated air and lters it. The front lter extracts heavier impurities
in the air such as fat, dust and water vapour, and the rear lter removes smoke, dirt and further
toxic contaminants. The puried air is then passed through the air diffuser on the back.
1. Connect to the power source.
Make sure the battery is charged or the charging cord is plugged in.
2. To attach the Base Boost (if purchased) to the AirHood, align the 4 nodules on the
Base Boost with the grooves on the bottom of the AirHood, and then twist the base
anticlockwise until it locks into place.
CHARGING THE BATTERY
1. Make sure the power switch is set to the off position O.
2. Connect the charging plug to the charging socket on the AirHood and plug the other
end into the mains socket.
– The indicator lights turn on sequentially to show the battery is charging and become
steady to indicate the level of battery charged. All 5 indicator lights are steady when
the battery is fully charged.
– Charge the battery fully the rst time. This takes up to 3 hours and provides up to 3
hours of runtime depending on the power level used.
– After the rst full charge of the battery, you can use the AirHood while the battery
is charging.
3. When the battery is full charged, unplug the charging cord from the AirHood and the
mains power socket.
3. Slide the power switch to the desired setting:
SETTING MEANING
ILow Quiet operation
II Medium Optimal effectiveness, noise-compromise
III High Maximum power
OOff
4. When you are not using the AirHood, make sure the power switch is in the off position O
and make sure it is disconnected from the power supply.
5. Stow your AirHood on a countertop or hang it up and create more space.
13.1” – 15.1”
Adjustable Height

8| EN | Airhood (AH-01BE) Airhood (AH-01BE) | EN | 9
CLEANING AND CARE
The AirHood is designed to make cleaning quick and easy. To keep your AirHood in tip top
condition, we recommend that you clean the main unit and the front lter after each use and
change the rear lter after every 100 hours of use.
1. Make sure the power switch is in the off position Oand that the AirHood is disconnected
from the power supply.
2. The air duct is xed into place with magnets. Simply pull the tab on the top of the air
duct to release and remove it. Similarly, pull the tab on the air diffuser on the back of the
AirHood and remove it.
3. The front lter is attached to the back of the air duct. It comprises 2 parts, the stainless
steel mesh and the frame that holds the mesh in place. Turn the front lter frame
anticlockwise to remove it from the air duct. Then, pop out the wire mesh.
TIP: When reassembling the front lter, make sure you put the mesh into the front lter
frame, align the frame with the groves on the air duct and then twist the front lter frame
clockwise until the two parts slot rmly together.
If the rear lter becomes a bit wet (this may happen when it is used for ltering
water vapor), remove the rear lter and let it dry naturally away from the AirHood.
We recommend that you also check the front lter for moisture and if necessary dry
it with a towel. Only reassemble when both lters are completely dry.
Note
■Do not use solvents, chemical or abrasive cleaning agents, wire brushes, sharp
objects or scouring pads to clean the AirHood.
■Never immerse the AirHood main body, charger/power cord in water.
2
2
5
3
4
4. If it is time to change the rear lter, lift out the old one and replace after cleaning the main body.
TIP: When you handle the rear lter, you may see some carbon / charcoal residues
(little black specks), this is normal and does not mean that the rear lter is degrading.
When inserting a new lter. Make sure the lter is tucked behind the two clips that hold
it in place.
5. Clean the main body with a damp soft cloth.
6. Clean the air duct, front lter and air diffuser using a mild detergent and soft cloth.
Only the front lter is dishwasher safe. Do not put any other parts in a dishwasher.
7. Dry all parts thoroughly and reassemble the AirHood.
STORAGE INSTRUCTIONS
■If you are not using the AirHood for a long period, always clean and store it in its original
packaging in a dust-free, dry environment.
TROUBLESHOOTING
MALFUNCTION CAUSE REMEDY
The AirHood
is not working.
Power supply issues. Connect the charger making sure it is rmly
connected to the charging socket and the
mains socket. Check the battery level and
charge as required.
The AirHood
doesn’t appear
to be working
optimally.
The setting is too low. Try a higher setting.
The AirHood is dirty
and/or the rear lter
needs changing.
Clean the unit as described in the
CLEANING AND CARE section and/or
change the rear lter if it is clogged or
has been used for 100 hours.
