Ether-FSH2402NT
24+2 Mixed Gigabit Ethernet Switch
he Ether-FSH2402NT is a 24-port mixed
Gigabit switch designed to be the center of
your office network. With 24 x 10/100Mbps ports
and 2 Gigabit ports, you can put the servers on
the Gigabit port while putting the PCs on the
10/100Mbps ports.
T
The switch is enclosed in 19 inch rack mountable housing for easy integrating with the data center.
The comprehensive LED display provides clear traffic status of all the ports.
Rack Mountable
The switch engine features 8K MAC address table for large network. In addition, the 8.8Gbps
throughput ensures wire speed performance for each port.
Fast and reliable switching engine
OvisLink Corp. was one of the very first vendors in the world to introduce Gigabit Ethernet switch,
back in 1997. Our mixed Gigabit switch is known to be very reliable and work over long life time.
The Ether-FSH2402NT is a real cost effective solution to set up Gigabit centralized network. Alleviate
your network traffic problem and upgrade to Gigabit Ethernet today.
Leader in Gigabit Solution
Small Workgroup Segment Bridge
PC PC PC Printer server Server PC PC PC PCPrinter server Server
Ether-FSH2402NT 1234
13 14 15 16
24+2 Mixed Gigabit Ethernet Switch
56
123456
789101112
13 14 15 16 17 18
19 20 21 22 23 24
78
17 18 19 20
9101112
25 2621 22 23 24
POWER
Link 1000M
100M
10M
ACT
Link 1000M
100M
10M
ACT
Link ACT
Ether-FSH2402NT 1234
13 14 15 16
24+2 Mixed Gigabit Ethernet Switch
56
123456
789101112
13 14 15 16 17 18
19 20 21 22 23 24
78
17 18 19 20
9101112
25 2621 22 23 24
POWER
Link 1000M
100M
10M
ACT
Link 1000M
100M
10M
ACT
Link ACT

5F, No.96, Min-ChuanRd, Hsin-tien City, Taipei, Taiwan
Standard
- IEEE802.3
- IEEE802.3u
- IEEE802.3ab
- IEEE802.3x
Interface
- 24 x 10/100Mbps RJ-45 ports
- 2 x 10/100/1000Mbps RJ-45 ports
Transmission Method
- Store-and-Forward
Transmission Speed
- 10/20 Mbps (Half/Full-duplex Ethernet)
- 100/200 Mbps (Half/Full-duplex Fast Ethernet)
- 1000/2000 Mbps (Half/Full-duplex Gigabit
Ethernet)
LED Indicator
- Power
- Link/Act (Port 1 ~ 24)
- 10Mbps, 100Mbps, 1000Mbps, Act (Port 25 ~
26)
MAC Address Table
- 8K
Buffer Memory
- 2.5Mbits.
Temperature
- Operating: 0°C - 50°C (32℉- 122℉)
- Storage: -20°C - 70°C (-4℉- 158℉)
Humidity
- Operating: 10% ~ 90% (non-condensing)
- Storage: 10% ~ 90% (non-condensing)
Power
- 100-240VAC 50/60Hz, Internal Universal
Switching
Power Consumption
- 13.2 watts. (Max.)
EMI & Safety
- FCC Class A, CE
Produce Weight (g)
- g
Dimensions
- 441 x 130 x 44 mm
Specifications
AirLive Ether-FSH2402NT 24+2 Mixed Gigabit Ethernet Switch
