AirLive WN-300R User manual

Wireless 11N Broadband Rou
WN-300R
ter

Table of Contents
List of Lan
g
ua
g
es
Italiano
Magyar
En
g
lish
WN-300R
Česky
..................
Deutsch
...............
Español
Ελληνικός
Français
................
................
...............
............
................
Polski
.................
Português
ий
..............
.............
Русск
Slovensky
............
...............
162
72
12
22
32
42
52
82
92
102
112

1
1
WN-300R English
Declaration of Conformity
We, Manufacturer/Importer
OvisLink Corp.
5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan
Declare that the products
Wireless 11N Broadband Router
AirLive WN-300R
is in conformity with
In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive
Clause Description
■ EN 300 328 v1.7.1 (2006-10) Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission equipment operating in the
2.4GHz ISM band. And using spread spectrum modulation techniques; Part 1：technical Characteristics and test conditions
Part2：Harmonized EN covering. Essential requirements under article 3.2 of the R&TTE Directive
■EN 301 489-1 V1.6.1 (2005-09) Electromagnetic compatibility and Radio spectrum Matters (ERM); Electromagnetic compatibility(EMC) standard
■ EN 301 489-17 V1.2.1 (2002-08) for radio equipment and services; Part 17：Specific conditions for wideband data and HIPERLAN equipment
■ EN 50385:2002 Generic Product standard to demonstrate the Compliance of radio base stations and Fixed terminal stations for wireless
Telecommunication System with the Basic restrictions or the reference levels related to human exposure to radio Frequency
electromagnetic fields ( 110 MHz–40 GHz ) - General public
■EN 60950-1:2001+A11:2004 Safety for information technology equipment including electrical business equipment
■CE marking
Manufacturer/Importer
Signature： ______________
Name ： Albert Yeh
Position/ Title : Vice President
Date： 2008/11/20
English

English
Note on the FCC standard
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferences
when the equipment is operating in a commercial area. This equipment generates, uses and may radiate radio
frequency energy, and if not installed in accordance with the user guide, may cause interference in the
transmission of radio communications. If operating in a residential area, it is probable this equipment will cause
harmful interference, in which case the user will be required to try to correct this interference using his own
means.
Note on CE Marking
This is a Class B product. In a residential area this product may cause radio interference, in which case the user
can be required to take the appropriate measures. OvisLink Corp. hereby declares that AirLive WN-300R meet
the basic requisites of directive 99/05/CE, and is therefore liable for the accuracy of these data:
OvisLink Corp.
5F, No.6 Lane 130,
Min-Chuan Rd, Hsin-Tien City,
Taipei, Taiwan
TEL: [phone]
Warranties
This product has undergone various quality controls to ensure proper operation.
This product is covered by a two-year warranty for countries inside European Union. For other countries, the
warranty period is one year only. In the event of any manufacturing fault or breakdown, it will be repaired by
OvisLink Corp. Please contact your supplier for details on the procedure to follow. This warranty shall not be
applicable in the event of damage caused by improper use of the product, accidents, faulty handling or
manipulation nor any future incompatibility with third party products.
2 WN-300R
English

3
3
WN-300R
English
Default Setting:
Basic Information
English
IP Address: 192.168.1.254
Subnet Mask: 255.255.255.0
Login: admin
LED Indicators
Password: airlive
Wireless Model SSID: airlive
Channel: 6
Power LED On - Power on.
Off - No power.
WLAN LED On - Idle.
Off – non Connection
Flashing - Data is being transmitted or received via the Network.
Internet LED On - Internet connection is available.
Off - non Connection.
Flashing - Data is being transmitted or received.
WAN LED On - Connection to the Broadband Modem attached to the WAN (Internet) port is established.
Off - non Connection.
Flashing - Data is being transmitted or received via the WAN port.
LAN LEDs For each port, there are 1 LED
10 (Orange)/100 (Green)
•On - Corresponding LAN (hub) port is active.
•Off - non Connection.
•Flashing - Data is being transmitted or received via the corresponding LAN (hub) port.
Reset
Button This button has two (2) functions:
•Reboot. When pressed and released, the Wireless Router will reboot (restart).
•Clear All Data. This button can also be used to clear ALL data and restore ALL settings
to the factory default values.
WPS Button •Press for the WPS Connection

4 WN-300R
English
English
Hardware Installation
1. Setup LAN connection: connect an
Ethernet cable from your computer’s
Ethernet port to one of the LAN ports of
this product.
2. Setup WAN connection with your
router: connect the network cable
from your cable (xDSL) modem to the
WAN port of this product.

5
5
WN-300R
English
Installation Steps
1. Please install your network cards first before
the Router.
2. Connect the power, LAN cable and WAN
cable to the back.
3. Use your wireless card to do a site survey, the
default SSID is “airlive” and Channel is “11”.
4. If you need to change router configuration,
please follow the procedure below:
zThe Router default IP address is
192.168.2.1 Please make sure your
computer IP is in the same subnet as the
router (i.e. 192.168.2.X)
zOpen the web browser and enter
192.168.2.1 When asked for the Login
and Password, just type airlive for login
name and airlive for Password.
Wireless Mode Setting
This page includes all primary and major
parameters for the wireless mode setting. Any
parameter change will cause the device to
reboot for the new setting to take effect
Wireless Modes:
AP, Bridge-Point to Point, AP Bridge -Point
to Multi-Point, WDS-Repeater,
Station-Infrastructure, Universal-Repeater.
The default mode is set to AP. You can change
it to another mode.
English

6 WN-300R
English
English
AP Mode
SSID, you can have 2 SSIDs on one AP. For
example, a Guest SSID without encryption for
visitors to have Internet access only, and a
Admin SSID with encryption for private use to
secure your company resources.
Broadcast SSID, If enabled, the Wireless
ADSL Router will broadcast its SSID. This
allows PCs and other wireless stations to
detect this Access Point and use the correct
SSID.
Isolation within SSID, If Enabled, devices
that have the same SSID will not be able to
see each other.
Configure SSID1, to configure your Wireless
Security Setting.
The Settings for Wireless function are as follows:
1. SSID: airlive
2. Channel: The factory setting is channel 6

7
7
WN-300R
English
Bridge Point to Point
In the bridge point to point mode, you can connect
your wireless router with another, to combine two
access points and expand the scope of wireless
network, and all clients (wired only – AP will not
accept wireless clients in this mode) of two wireless
routers will think they’re on the same physical
network. This function is very convenient when you
need to connect two networks between two
buildings.
Bridge Point to Muti Point
In the AP bridge point to multi point mode, you can
connect your wireless router with another, to combine
few of access points and expand the scope of
wireless network, and all clients of four wireless
routers will think they’re on the same physical
network. This function is very convenient when you
need to connect few networks between buildings.
English

8 WN-300R
English
English
Station-Infrastructure
In this mode, you can connect the router to Ethernet
device such us TV, Game player, HDD&DVD to enable
the Ethernet device be a wireless station and join to a
wireless network through an access point or AP router.
WDS- Repeater
In this mode, you can expand the scope of
network by combining up to four other access
points together, and every access point can
still accept wireless clients.
