Airwell AWSI-HMF009-N12 User manual

HMF Hi wall Series
Indoor Units
OutdoorUnits
AWSI-HMF009-N12
AWAU-YMF009-C12
AWSI-HMF012-N12
AWAU-YMF012-C12
AWSI-HMF018-N12
AWAU-YMF018-C12
AWSI-HMF024-N12
AWAU-YMF024-C12
REFRIGERANT
R410A
COOLONLY
REFRIGERANT
SM HMF 1-A.1 GB
FEB, 2014

HMF Series 2 Version - 0
CONTENTS
1. Precaution .................................................................................................................................................... 3
1.1 Safety Precaution.......................................................................................................................... 3
1.2 Warning......................................................................................................................................... 3
2. Function........................................................................................................................................................ 7
3. Specification ................................................................................................................................................ 8
4. Dimension .................................................................................................................................................. 12
4.1 Indoor Unit................................................................................................................................... 12
4.2 Outdoor Unit................................................................................................................................ 14
5. Refrigerant Cycle Diagram ....................................................................................................................... 15
6. Wiring Diagram .......................................................................................................................................... 16
6.1 Indoor Unit................................................................................................................................... 16
6.2 Outdoor Unit................................................................................................................................ 17
7 Installation Details...................................................................................................................................... 20
7.1 Wrench torque sheet for installation........................................................................................... 20
7.2 Connecting the cables ................................................................................................................ 20
7.3 Pipe length and the elevation ..................................................................................................... 21
7.4 Installation for the first time......................................................................................................... 22
7.5 Adding the refrigerant after running the system for many years ................................................ 25
7.6 Re-installation while the indoor unit need to be repaired........................................................... 26
7.7 Re-installation while the outdoor unit need to be repaired......................................................... 28
8. Operation Characteristics......................................................................................................................... 32
9. Electronic function.................................................................................................................................... 33
9.1 Abbreviation ................................................................................................................................ 33
9.2 Display function........................................................................................................................... 33
9.3 Main Protection........................................................................................................................... 34
9.4 Operation Modes and Functions.................................................................................................35
10. Troubleshooting....................................................................................................................................... 40
10.1 Indoor Unit Error Display........................................................................................................... 40
10.2 Diagnosis and Solution............................................................................................................. 41
11. Exploded View.......................................................................................................................................... 48
11.1 Indoor unit ................................................................................................................................. 48
11.2 Outdoor unit............................................................................................................................... 56

HMF Series 3 Version - 0
1. Precaution
1.1 Safety Precaution
To prevent injury to the user or other people and property damage, the following
instructions must be followed.
Incorrect operation due to ignoring instruction will cause harm or damage.
Before service the unit, be sure to read this service manual at first.
1.2 Warning
Installation
Do not use a defective or underrated circuit breaker. Use this appliance on a dedicated
circuit.
There is risk of fire or electric shock.
For electrical work, contact the dealer, seller, a qualified electrician, or an authorized
service center.
Do not disassemble or repair the product, there is risk of fire or electric shock.
Always ground the product.
There is risk of fire or electric shock.
Install the panel and the cover of control box securely.
There is risk of fire of electric shock.
Always install a dedicated circuit and breaker.
Improper wiring or installation may cause fore or electric shock.
Use the correctly rated breaker of fuse.
There is risk of fire or electric shock.
Do not modify or extend the power cable.
There is risk of fire or electric shock.
Do not install, remove, or reinstall the unit by yourself (customer).
There is risk of fire, electric shock, explosion, or injury.
Be caution when unpacking and installing the product.
Sharp edges could cause injury, be especially careful of the case edges and the fins on the

HMF Series 4 Version - 0
condenser and evaporator.
For installation, always contact the dealer or an authorized service center.
Do not install the product on a defective installation stand.
Be sure the installation area does not deteriorate with age.
If the base collapses, the air conditioner could fall with it, causing property damage, product failure,
and personal injury.
Do not let the air conditioner run for a long time when the humidity is very high and a
door or a window is left open.
Take care to ensure that power cable could not be pulled out or damaged during
operation.
There is risk of fire or electric shock.
Do not place anything on the power cable.
There is risk of fire or electric shock.
Do not plug or unplug the power supply plug during operation.
There is risk of fire or electric shock.
Do not touch (operation) the product with wet hands.
Do not place a heater or other appliance near the power cable.
There is risk of fire and electric shock.
Do not allow water to run into electrical parts.
It may cause fire, failure of the product, or electric shock.
Do not store or use flammable gas or combustible near the product.
There is risk of fire or failure of product.
Do not use the product in a tightly closed space for a long time.
Oxygen deficiency could occur.
When flammable gas leaks, turn off the gas and open a window for ventilation before
turn the product on.
If strange sounds or smoke comes from product, turn the breaker off or disconnect the
power supply cable.
There is risk of electric shock or fire.
Stop operation and close the window in storm or hurricane. If possible, remove the

HMF Series 5 Version - 0
product from the window before the hurricane arrives.
There is risk of property damage, failure of product, or electric shock.
Do not open the inlet grill of the product during operation. (Do not touch the electrostatic
filter, if the unit is so equipped.)
There is risk of physical injury, electric shock, or product failure.
When the product is soaked, contact an authorized service center.
There is risk of fire or electric shock.
Be caution that water could not enter the product.
There is risk of fire, electric shock, or product damage.
Ventilate the product from time to time when operating it together with a stove etc.
There is risk of fire or electric shock.
Turn the main power off when cleaning or maintaining the product.
There is risk of electric shock.
When the product is not be used for a long time, disconnect the power supply plug or
turn off the breaker.
There is risk of product damage or failure, or unintended operation.
Take care to ensure that nobody could step on or fall onto the outdoor unit.
This could result in personal injury and product damage.
CAUTION
Always check for gas (refrigerant) leakage after installation or repair of product.
Low refrigerant levels may cause failure of product.
Install the drain hose to ensure that water is drained away properly.
A bad connection may cause water leakage.
Keep level even when installing the product.
It can avoid vibration of water leakage.
Do not install the product where the noise or hot air from the outdoor unit could damage
the neighborhoods.
It may cause a problem for your neighbors.
Use two or more people to lift and transport the product.
Do not install the product where it will be exposed to sea wind (salt spray) directly.

HMF Series 6 Version - 0
It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator fins,
could cause product malfunction or inefficient operation.
Operational
Do not expose the skin directly to cool air for long time. (Do not sit in the draft).
Do not use the product for special purposes, such as preserving foods, works of art etc.
It is a consumer air conditioner, not a precision refrigerant system.
There is risk of damage or loss of property.
Do not block the inlet or outlet of air flow.
Use a soft cloth to clean. Do not use harsh detergents, solvents, etc.
There is risk of fire, electric shock, or damage to the plastic parts of the product.
Do not touch the metal parts of the product when removing the air filter. They are very
sharp.
Do not step on or put anything on the product. (outdoor units)
Always insert the filter securely. Clean the filter every two weeks or more often if
necessary.
A dirty filter reduces the efficiency of the air conditioner and could cause product malfunction or
damage.
Do not insert hands or other objects through air inlet or outlet while the product is
operated.
Do not drink the water drained from the product.
Use a firm stool or ladder when cleaning or maintaining the product.
Be careful and avoid personal injury.
Replace the all batteries in the remote control with new ones of the same type. Do not
mix old and new batteries or different types of batteries.
There is risk of fire or explosion.
Do not recharge or disassemble the batteries. Do not dispose of batteries in a fire.
They may burn of explode.
If the liquid from the batteries gets onto your skin or clothes, wash it well with clean
water. Do not use the remote of the batteries have leaked.

HMF Series 7 Version - 0
2. Function
Model Names of Indoor/Outdoor Units
On-Off
Capacity
Indoor units
Outdoor units
9K
AWSI-HMF009-N12
AWAU-YMF009-C12
12K
AWSI-HMF012-N12
AWAU-YMF012-C12
18K
AWSI-HMF018-N12
AWAU-YMF018-C12
24K
AWSI-HMF024-N12
AWAU-YMF024-C12
Cold catalyst filter
Silver Ico Filter(O)
Vitamin C Filter(O)
3M HAM Filter(O)
Bio Filter(O)
Golden Fin(O)
Ionizer(O)
Compressor Crankcase Heater(O)1W Standby(O)
Louver Position Memory Function
Refrigerant Leakage Detect
Self-diag. Function
Hydrophilic Aluminum Fin
Anti-rust Cabinet
Valve Protection Cover
PTC Heating Belt(O)
Filter 2 ways of drainage(O)
O:optional

HMF Series 8 Version - 0
3. Specification
Model Indoor Unit
AWSI-HMF009-N12
Model Outdoor Unit
AWAU-YMF009-C12
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Capacity (1)
Btu/h
8600
EER /COP (2)
W/W
2.65
Power supply
V/Ph/Hz
220-230V/Single/60Hz
Circuit breaker rating
A
16
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L
RPM
1200 / 950 / 800
Air flow (3)
H/M/L
m3/hr
470/370/310
External static pressure
Min-Max
Pa
0
Sound pressure level(5)
H/M/L
dB(A)
41/34/31
Moisture removal
l/hr
1.0
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
715x188x250
Weight
kg
6.5
Package dimensions
WxHxD
mm
775x260x324
Packaged weight
kg
8.5
OUTDOOR
Refrigerant control
Capillary
Compressor type, model
ROTARY
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
1015
Air flow
H/L
m3/hr
1400
Sound pressure level(5)
H/L
dB(A)
55
Dimensions
WxHxD
mm
685x260x430
Weight
kg
19.5
Package dimensions
WxHxD
mm
795x345x495
Packaged weight
kg
21
Refrigerant type
R410A/380g
Refrigerant charge (standard connecting tubing length)
kg(5m)
0.59
Additional charge per 1 meter
gr / 1m
20
Connections between units
Liquid line
In.(mm)
1/4"(6.35)
Suction line
In.(mm)
3/8" (9.52)
Max.tubing length
m.
20
Max.height difference
m.
8
Operation control type
Remote control
Heating elements
kW
Others

HMF Series 9 Version - 0
Model Indoor Unit
AWSI-HMF012-N12
Model Outdoor Unit
AWAU-YMF012-C12
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Capacity (1)
Btu/h
11000
EER /COP (2)
W/W
2.68
Power supply
V/Ph/Hz
220-230V/Single/60Hz
Circuit breaker rating
A
16
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L
RPM
1200 / 1050 / 900
Air flow (3)
H/M/L
m3/hr
600/530/450
External static pressure
Min-Max
Pa
0
Sound pressure level(5)
H/M/L
dB(A)
42/39/36
Moisture removal
l/hr
1.1
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
800x188x275
Weight
kg
6.5
Package dimensions
WxHxD
mm
865x265x350
Packaged weight
kg
8.5
OUTDOOR
Refrigerant control
Capillary
Compressor type, model
ROTARY
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
1000
Air flow
H/L
m3/hr
1800
Sound pressure level(5)
H/L
dB(A)
56
Dimensions
WxHxD
mm
700x240x540
Weight
kg
23
Package dimensions
WxHxD
mm
815x325x580
Packaged weight
kg
25
Refrigerant type
R410A/440g
Refrigerant charge (standard connecting tubing length)
kg(5m)
0.8
Additional charge per 1 meter
gr / 1m
20
Connections between units
Liquid line
In.(mm)
1/4"(6.35)
Suction line
In.(mm)
3/8" (9.52)
Max.tubing length
m.
20
Max.height difference
m.
8
Operation control type
Remote control
Heating elements
kW
Others

HMF Series 10 Version - 0
Model Indoor Unit
AWSI-HMF018-N12
Model Outdoor Unit
AWAU-YMF018-C12
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Capacity (1)
Btu/h
17500
EER /COP (2)
W/W
2.62
Power supply
V/Ph/Hz
220-230V/Single/60Hz
Circuit breaker rating
A
16
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L
RPM
1280 / 1100 / 950
Air flow (3)
H/M/L
m3/hr
750/640/560
External static pressure
Min-Max
Pa
0
Sound pressure level(5)
H/M/L
dB(A)
44/40/36
Moisture removal
l/hr
1.8
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
940x205x275
Weight
kg
10
Package dimensions
WxHxD
mm
1015x265x350
Packaged weight
kg
12.5
OUTDOOR
Refrigerant control
Capillary
Compressor type, model
ROTARY
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
1070
Air flow
H/L
m3/hr
2000
Sound pressure level(5)
H/L
dB(A)
48
Dimensions
WxHxD
mm
780x250x540
Weight
kg
30.5
Package dimensions
WxHxD
mm
910x335x585
Packaged weight
kg
32
Refrigerant type
R410A/580g
Refrigerant charge (standard connecting tubing length)
kg(5m)
1.6
Additional charge per 1 meter
gr / 1m
40
Connections between units
Liquid line
In.(mm)
1/4(6.35)
Suction line
In.(mm)
1/2"(12.7)
Max.tubing length
m.
20
Max.height difference
m.
8
Operation control type
Remote control
Heating elements
kW
Others

HMF Series 11 Version - 0
Model Indoor Unit
AWSI-HMF024-N12
Model Outdoor Unit
AWAU-YMF024-C12
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Capacity (1)
Btu/h
21000
EER /COP (2)
W/W
2.66
Power supply
V/Ph/Hz
220-230V/Single/60Hz
Circuit breaker rating
A
25
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L
RPM
1220 / 1100 / 900
Air flow (3)
H/M/L
m3/hr
1100/990/810
External static pressure
Min-Max
Pa
0
Sound pressure level(5)
H/M/L
dB(A)
49/45/41
Moisture removal
l/hr
2.2
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
1045x235x315
Weight
kg
12
Package dimensions
WxHxD
mm
1135x395x315
Packaged weight
kg
15
OUTDOOR
Refrigerant control
Capillary
Compressor type, model
ROTARY
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
950
Air flow
H/L
m3/hr
2500
Sound pressure level(5)
H/L
dB(A)
60
Dimensions
WxHxD
mm
820x330x595
Weight
kg
37
Package dimensions
WxHxD
mm
940x415x645
Packaged weight
kg
39.9
Refrigerant type
R410A/830g
Refrigerant charge (standard connecting tubing length)
kg(5m)
1.6
Additional charge per 1 meter
gr / 1m
40
Connections between units
Liquid line
In.(mm)
3/8"(9.52)
Suction line
In.(mm)
5/8"(15.9)
Max.tubing length
m.
25
Max.height difference
m.
10
Operation control type
Remote control
Heating elements
kW
Others

HMF Series 12 Version - 0
4. Dimension
4.1 Indoor Unit
WD
H
Model
W
D
H
AWSI-HMF009-N12
715
188
250
AWSI-HMF012-N12
800
188
275
AWSI-HMF018-N12
940
205
275
AWSI-HMF024-N12
1045
235
315

HMF Series 13 Version - 0
Model
L(mm)
R(mm)
H(mm)
Dimension of installation hole(mm)
AWSI-HMF009-N12
85
88
45
￠65
AWSI-HMF012-N12
100
95
45
AWSI-HMF018-N12
110
100
45
Model
L(mm)
R(mm)
H(mm)
Dimension of installation hole(mm)
AWSI-HMF024-N12
293
163
45
￠65
H
L
R

HMF Series 14 Version - 0
4.2 Outdoor Unit
More than 30cm
More than 60cm
More than 200cm
More than 30cm
More than 60cm
(Service space)
Fence or
obstacles
Model
W
D
H
W1
A
B
AWAU-YMF009-C12
685
260
430
742
460
276
AWAU-YMF012-C12
700
240
540
757
458
250
AWAU-YMF018-C12
780
250
540
843
549
276
AWAU-YMF024-C12
820
330
595
870
523
340

HMF Series 15 Version - 0
5. Refrigerant Cycle Diagram
INDOOR OUTDOOR
LIQUID SIDE
GAS SIDE
HEAT
EXCHANGE
(EVAPORATOR) HEAT
EXCHANGE
(CONDENSER)
COMPRESSOR
CAPILIARY TUBE
T2 Evaporator
temp. sensor
T1 Room temp.
sensor
ACCUMULATOR

HMF Series 16 Version - 0
6. Wiring Diagram
6.1 Indoor Unit
AWSI-HMF009-N12,, AWSI-HMF012-N12, AWSI-HMF018-N12

HMF Series 17 Version - 0
AWSI-HMF024-N12
6.2 Outdoor Unit
AWAU-YMF009-C12, AWAU-YMF012-C12

HMF Series 18 Version - 0
AWAU-YMF018-C12
AWAU-YMF024-C12

HMF Series 19 Version - 0

HMF Series 20 Version - 0
7 Installation Details
7.1 Wrench torque sheet for installation
Outside diameter
Torque
Additional tightening torque
mm
inch
N.cm
N.cm
Ф6.35
1/4
1500(153kgf.cm)
1600(163kgf.cm)
Ф9.52
3/8
2500(255kgf.cm)
2600(265kgf.cm)
Ф12.7
1/2
3500(357kgf.cm)
3600(367kgf.cm)
Ф15.9
5/8
4500(459kgf.cm)
4700(479kgf.cm)
Ф19
3/4
6500(663kgf.cm)
6700(683kgf.cm)
7.2 Connecting the cables
The power cord of connect should be selected according to the following specifications sheet.
Rated current of appliance
Nominal cross-sectional area (mm²)
>3 and ≤6
0.75
>6 and ≤10
1
>10 and ≤16
1.5
>16 and ≤25
2.5
The cable size and the current of the fuse or switch are determined by the maximum current indicated
on the nameplate which located on the side panel of the unit. Please refer to the nameplate before
selecting the cable, fuse and switch.
