Airwell HDLS-025N-01M25 Guide

User & Installation Manual
IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning unit. Make sure to
save this manual for future reference.
21.AW.HDLS.9-24.R410A.UM.IM.EN.AR.07.21
Split Type Air Conditioner
R410A Inverter V01
English Manual
HDLS-025N-01M25 / YDAS-025H-01M25
HDLS-035N-01M25 / YDAS-035H-01M25
HDLS-050N-01M25 / YDAS-050H-01M25
HDLS-070N-01M25 / YDAS-070H-01M25

17
18
27
28

REMOTE CONTROLLER
The out looking and some function of remote controller maybe difference.
The unit confirms the correct reception of each press button with a beep.
To select the mode of operation
To switch on/off the display. (If applicable)
To activate or deactivate of the movement of the horizontal deflectors.
(If applicable)
To activate the function SLEEP
To switch - on /off HEALTH funtion.It is a button which controls the ionizer or
plasma generator. (If applicable)
Press this button to activate / deactivate the ECO function which enables the
unit automatically to sets the operation to achieve energy savings.
Press this button to activate/deactivate the Superfunction which enables the
unit to reach the preset temperature in the shortest time.
Press it to decrease temperature/ time setting.
Press it to increase temperature / time setting.
Press it to start or stop operation.
Press it to set auto-off timer.
To select the fan speed of auto/low/mid/high
8
10
12
6
14
7
9
13
MODE
DISPLAY
SLEEP
HEALTHY / HEALTH /
ECO
SUPER / TURBO
11 CLOCK
1
2
(TEMP DN)
(TEMP UP)
3
4FAN
5TIMER
When you press "3D", the horizontal and vertical vanes will swing together
at the same time. (If applicable)
RESET
ANTI-MILDEW / MILDEW To activate the function ANTI-MILDEW. (If applicable)
To restart REMOTE CONTROLLER. (If applicable)
16
15
When you press this button,the time will be flickering; then through" "and
" ", you can adjust the time (one time you press,one minute you adjust;
and if you continue to press,the time change rapidly), after adjusting to your
required time, please press this button again to fix the time. (If applicable)
ANTI-MOSQUITO To activate the function of ANTI-MOSQUITO. (If applicable)
ON/OFF
or
To activate or deactivate of the movement of the vertical deflectors.
PLASMA
17
Mute
AH
To activate the function of Mute. (If applicable)
To activate the function of Child Lock when press MODE and TIMER buttons
together. (If applicable)
To activate the function of 8 heating. (If applicable)
18
19
20
I FEEL
(MODE+TIMER)
To switch active /deactive "I FEEL" function.The air conditioner will regulate
the room temperature based on the temperature(0 ~50 ) around the
remote controller.This function will terminate 2 hours later once it's active.
(If applicable)
21
3D
SWING X /
SWING L-R
/
SWING / SWING Y /
SWING U-D
/
No.
Buttor Function
HEALTH/MUTE/CLEAN/IFEEL/I SET,SWING(left and right),these are optionalfunction buttons, youwill
hear a beepwhen press itthough the actualmodel haven't thisfunction, we expressour apologies.
22 I SET Switch on/offI SET function
CLEAN Switch on/off self-clean function
Note: Don't press this button frequently, we suggest operate it per 3 months.
23

The out looking and some function of remote controller maybe difference.
Mildew
or or
Health
Mode
Fan
Eco
Temp Swing
Timer
Display
Sleep
Mute Turbo I FEEL
8
3
6
7
9
21
10
5
18
4
1
2
12
19
The shape and position of switches and indicators may be different according to the model, but their
function is the same. The actual shape and position shall prevail.

10

1. This function help carry away the accumulated
dirt, bacteria, etc from the evaporator.
2. Press "CLEAN" button to enter this function in any
mode and it will show "CL" on the display of indoor unit.
3. This function will run about 30 minutes, and it will back
to the mode set before this function .You can press "ON/OFF"
or "Mode" to cancel this function during the process.
You will hear 2 beeps when it's finished or cancelled.
4. It's normal if there are some noise during this function
process, as plastic materials expand with heat and
contract with cold.
5.We suggest operate this function as the following ambient
condition to avoid certain safety protection features.
6. We suggest operate this function per 3 months.
OPERATING INSTRUCTIONS
Self-Clean function(Optional)
Indoor unit
Outdoor unit
Temp<30
5 <Temp<30
In each mode of COOLING/HEATING/FAN/DRY, adjust the
temperature(COOLING/HEATING), fan speed (COOLING/
HEATING/FAN)and swing as your favourite, then keep
pressing "I SET" button over 3 seconds until "AU" appears
on the display and the background of display change to
lighting, the remote controller will run and remember
these settings. You can reset it by repeat the above
operation.
In each mode of COOLING/HEATING/FAN/DRY, press "I SET"
button to active this function, the AC will run as your
favourite setting and you will see AU flashing on the
remote controller. Press it again or other buttons to
cancel this function.
I SET function(Optional)
16
SWING
MUTE HEALTH
SWING
I SETTURBO
IFEELC LEAN
SWING
MUTE HEALTH
SWING
I SETTURBO
IFEELC LEAN

17
