Airwell XLM36IRCB Specification sheet

AIR CONDITIONER
SPLIT WALL-MOUNTED
PROGRAMING OPERATION MANUAL & INSTALLATION INSTRUCTIONS
MODELS: XLM36IRCB / GC34RCC

CONTENTS
INTRODUCTION
SYSTEM DESCRIPTION
MODES OF OPERATION, FUNCTIONS AND FEATURES
USE OF WIRELESS REMOTE CONTROL
ON-UNIT INDICATORS AND CONTROLS
REMOTE CONTROL
OPERATION PROCEDURE
PROTECTION MODES
CARE AND MAINTENANCE
OPERATING TIPS
PRECAUTIONS
BEFORE CALLING FOR SERVICE
1
2
4
6
7
9
10
10
10
10
10
10
10
11
11
11
11
11
12
12
12
13
13
13
13
13
14
15
17
18
19
●Turning on the air conditioner
●Ventilating operation
●Cooling operation
●Cooling operation with auto fan mode
●Heating operation
●Heating operation with auto fan mode
●Auto cooling/heating operation
●Dry operation
●Selecting the temperature
●I FEEL function
●Sleep function
●Timer operation
●Timer operating modes
●Room temperature display
●Air direction operation
●Turning off the air conditioner
●On-unit operation
●Current clock time set
●Lock function
IF YOUR AIR CONDITIONER
IS FOR COOLING ONLY,
PLEASE DISREGARD THE
HEATING INSTRUCTIONS
PLEASE READ THESE
INSTRUCTIONS BEFORE
OPERATING THE AIR
CONDITIONER

INTRODUCTION
This Split Air Conditioner is designed for versatile applications:
● Cooling air in the summer.
●Dehumidifying the air at high humidity conditions.
● Heating.
●Air Filtration.
●Ventilation.
,03257$17127,&(
●7KLVDLUFRQGLWLRQHUPXVWEH
JURXQGHGWRSURWHFWDJDLQVW
HOHFWULFDOVKRFN
●,QVWDOODWLRQRIWKHDLU
FRQGLWLRQHUPXVWEH
SHUIRUPHGE\DQH[SHULHQFHG
DLUFRQGLWLRQLQJLQVWDOOHU
REVHUYLQJJRRGUHIULJHUDWLRQ
SUDFWLFH
●(OHFWULFDOFRQQHFWLRQVDQG
SRZHUFRUGUHSODFHPHQW
VKRXOGRQO\EHPDGHE\
DXWKRUL]HGHOHFWULFLDQVDQGLQ
DFFRUGDQFHZLWKHOHFWULFDO
UHJXODWLRQVDQGORFDOFRGHV
●)DLOXUHWRFRPSO\ZLWKWKH
PDQXIDFWXUHUVLQVWDOODWLRQ
DQGRSHUDWLRQLQVWUXFWLRQV
FRXOGDIIHFWWKHSHUIRUPDQFH
RIWKHDLUFRQGLWLRQHUDQGWKH
YDOLGLW\RIWKHZDUUDQW\
23(5$7,1*7(03(5$785(
5$1*(
&RROLQJ
°°&
+HDWLQJ
°°&
°°&
°°&
,QGRRU 2XWGRRU
1

SYSTEM DESCRIPTION
Air purifying filter
(optional)
Air outlet
Remote control holder
Remote control
Outdoor unit air
outlet
Outdoor unit air
intake
Condensate tube
Control wire
Power cable
Liquid line
Suction line
Horizontal air flow
deflecting blades
Unit's indicators and
controls
Power cable
Air filter grip
Supply air flap (louvre)
Air intake grille
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
2
MODELS: XLM36IRCB / GC34RCC
-+
TEMP

MODES OF OPERATION, FUNCTIONS
AND FEATURES
HOT KEEP In HEATING and in AUTO FAN, the fan will be turned off when the compressor
is not in operation and will not be restarted, unless the indoor coil reaches
adequate temperature. This HOT KEEP feature prevents uncomfortable cold
air drafts. Use ofAUTO FAN is, therefore, recommended when the air conditioner
is in HEATING mode.
COOL Cools, dehumidifies and filters the room air. Maintains desired room
temperature.
AUTO Automatically switches from COOLING to HEATING or from HEATING to
COOLING, maintaining the desired temperature according to the room
conditions.
Dehumidifies and softly cools the room In DRY Mode, the air conditioner
operates at an increased dehumidifying power. This function is recommended
to be used when temperature is rather low but the humidity is high.
DRY
FAN Recirculates and filters the room air. Maintains constant air movement in the
room.
AUTO FAN The air conditioner automatically selects the FAN speed in accordance with the
room temperature.At the start, the unit operates at high fan speed.As the room
air approaches to the desired temperature, the fan switches to a lower speed
for quieter operation.
I FEEL Switches the temperature sensing point to the place where the remote control
is located. (Generally the temperature sensor is located behind the intake grille
of the air conditioner). This function is designed to provide a personalized
environment by transmitting the temperature control command from the location
next to you. The communication between the Remote Control and the unit is
done by infra-red signal. Therefore, in using this function, the Remote Control
should always be aimed, without obstructions, at the air conditioner.
TIMER Real time control and display, automatically turns the air conditioner ON and
OFF according to the time of day setting, ensuring comfort conditions before
returning home, without wasting electricity. It turns the air conditioner off
automatically when sleeping.
HEAT Heats and filters the room air. Maintains desired room temperature.
SLEEP Designed to create comfortable sleeping conditions. When in COOLING mode,
the temperature rises one degree centigrade after each consecutive hour, up to
three hours, from the start of the mode. The temperature rise prevents the feeling
of over-cooling while sleeping (when your body is at rest). In HEATING mode
the reverse occurs; the air conditioner lowers its temperature one degree every
hour. When in SLEEP mode, the air conditioner will be automatically turned off
after seven hours. The result is a more comfortable and invigorating sleep, which
leaves you feeling fresh and energetic in the morning.
3

4
ROOM
TEMPERATURE Measures and displays room temperature.
BUZZER A soft buzzer will sound from the indoor unit display to indicate that a command
sent by the remote control has been accepted and stored in the unit s memory.
This feature may be easily cancelled by the user from the display panel.
3-MIN
DELAYED RUN
This compressor is protected by a three-minute delayed restart.
MEMORY The microprocessor retains the last data entry whether or not the unit is plugged
in. Therefore, when the unit restarts after a power disruption or failure, it will
resume operating in the same mode as before the power was disrupted.
LOCK Freezes the last operation setting on the remote control. When LOCK is
activated, the remote control will not be able to control the air-conditioner.
AUTO FLAP The air flap (louvers) is automatically positioned for the most suitable blow-out
angle, when COOL, HEAT, DRY or FAN modes are selected. When the air
conditioner is turned off, the flap will close automatically for an aesthetic
appearance.
ON UNIT
OPERATION
The air conditoner can be turned ON for COOLING or HEATING or be turned
OFF directly form the indoor unit display panel without the use of the remote
control.
They are capable of capturing small particles down to 0.1 microns,
Such as atmospheric and house hold dust, coal dust, insecticide dust,
mites, pollen, pet dander, tobacco smoke particles, cooking smoke and
grease, mold fungi, bacteria, viruses and more.
ELECTROSTATIC
FILTER
(optional)
IONIZER
(optional)
Ionizer make the air more fresh and more comfort.
Slide switch (M) to the ON position and use the remote control to activate the
ionizer. The blue light indicator (L) on the unit will light up indicating the ionizer
in operation. To cancel the operation set slide switch to OFF position
Important Notice: When the air-conditioner is turned OFF or if the indoor
fan stops operation the IONIZER stops automatically.
Auto swing and fixed direction is circle and modulators;When press key
once,fan direction board will be automatic,press again and fan direction
board will be fixed.It retains when mode is switchover.
Vertical swing is controlled by 2 step motors A1 &A2.There are 7kinds of
modes:1) A1 &A2 at left together,2) A1 & A2 at left-middle together,3) A1
& A2 at middle together,4) A1 &A2 at right-middle together,5) A1 & A2 at
right together,6) A1 at left and A2 at right,7) A1 & A2 auto swing.
Vertical
swing key
(A1 &A2)
Horizontal
swing key
%RH
Measures and displayes relative humidity between 30% and 90% at a temperature
HUMIDITY range of 15 C to 45 C.
MEASUREMENT
(OPTIONAL)
OO

Prior to operating your air
conditioner, make sure that:
● The red tab protecting the
remote control battery has been
removed.
● For clock setting see page 11.
USE OF WIRELESS REMOTE CONTROL
PRIOR TO
OPERATION
WIRELESS REMOTE
CONTROL PUTS ALL
FUNCTIONS AT YOUR
FINGERTIPS
● Aim at the infrared signal receiver on the room air conditioner when operating.
● The remote control signal can be received at a distance of up to about 8 m.
● Ensure that there are no obstructions between the remote control and the
signal receptor.
● Do not drop or throw the remote control.
● Do not place the remote control in a location exposed to direct sunlight, or
next to a heating unit, and/or other heat source.
● Do not expose the air conditioner signal receiver to a strong light such as
fluorescent lamp or sunlight
REMOTE CONTROL BATTERY CHANGE
● Remove the batteries from the remote control as shown.
● Use two 1.5 volt size AAA batteries
● For protecting the enviroment, please, return used batteries for recycling
process.
REMOTE CONTROL
HOLDER
Use the remote control holder
when unit is not in use.
Remote control can be slipped
in or out its holder.
5

ON-UNIT INDICATORS AND CONTROLS
STAND-BY
INDICATOR
Lights up when the air
conditioner is connected
to power and ready to
receive the remote control
commands.
A
OPERATION
INDICATOR
Lights up during
operation. Blinks once to
announce that the remote
control infrared signal has
been received and stored.
Blinks continuously in
protection mode.
B
TIMER INDICATOR
Lights up during timer
and sleep operation.
C
FILTER INDICATOR
Lights up when air filter
requires cleaning.
D
COOL / HEAT / OFF /
ON UNIT OPERATION
BUTTON
Used to switch the unit
OFF or to turn it ON for
COOLING or HEATING
without the use of the
remote control.
F
HEATING
INDICATOR
Lights up only when
Mode (F) is pressed.
G
RESET BUTTON
● Press to turn off the
FILTER indicator and to
reset the filter function,
after the clean filter has
been reinstalled.
● Press to cancel the
buzzer announcer, if
elected.
H
SIGNAL RECEIVER
● Receive signals from
the remote control.
I
ON-UNIT OPERATION
If the air-conditioner cannot be operated by the Remote Control unit, it
can be turned on for cooling or heating, or completely turned off, by
pressing MODE button (F on the air-conditioner. The MODE button will
change the operating status of the unit between - COOLING - HEATING
- STAND-BY positions, every time it is pressed. Indicators (E , (G or
(A will light up respectively, to indicate in which mode the air-conditioner
operates.
On units for Cooling only, do not set MODE switch on HEAT position.
AUTO-HORIZONTAL AIR MOVEMENT (J)
For Auto movement turn switch (J to position (1
For desired air blades positioning turn switch momenterily to position
(2 and then to (3 .
Note: in some models this function is manual
Horizontal air
movement switch.
J
COOLING INDICATOR
Lights up only when
Mode (F) is pressed.
E
Lift up
the units
display
cover to
reach
the on
unit
control
6
MODELS: WS 090C / WS 090H / WS 100H

REMOTE CONTROL
7
LOCK button
19
Room temperature
DOWN Button
6
Transmission sign
20
TIMER DOWN button
12
TIMER UP button
11
TIMER button
10
Airflow direction
MANUAL positioning
control button
8
SLEEP button
7
FAN SPEED and AUTO
FAN button
4
I FEEL temperature
sensing mode button
3
Operation mode selection
button
COOLING
HEATING
AUTO COOL / HEAT
DRY
FAN
2
1START/STOP button
Room temperature UP
button
5
TIMER CLEAR button
18
LCD operation display
13
I FEEL sensor
14
Infrared signal transmitter
15
TIMER SET button
17
ROOM temperature
button
16
Airflow direction AUTO-
CONTROL button
9
Note: Open the cover to reach the
control buttons.

OPERATION PROCEDURE
HEATING OPERATION WITH AUTO FAN MODE
This operation starts with the highest air flow in order to quickly raise the
room temperature. It will then automatically switch to a lower air flow to
quietly maintain the selected temperature.
HEATING OPERATION
Select the HEATING mode by pressing MODE button (2). Switch to the
desired FAN SPEED or to AUTO FAN by pressing FAN button (4). Select
suitable temperature setting. By selecting the HEATING mode, the air flap
will move automatically to vertical air delivery position, optimal for
heating.The HOT KEEP function is provided. The fan will be turned off
when the indoor coil temperature is not sufficiently hot to prevent
uncomfortable cold air drafts. In some models the HOT KEEP function is
operating in AUTO FAN mode only.
COOLING OPERATION WITH AUTO FAN MODE
This operation starts with the highest air flow in order to quickly lower the
room temperature. It will then automatically switch to the low air flow to
quietly maintain the selected temperature.
COOLING OPERATION
Select the COOLING mode by pressing MODE button (2). Switch to the
desired FAN SPEED or to AUTO FAN by pressing button (4). Select suitable
temperature setting. By selecting the COOLING mode, the air flap will move
automatically to horizontal air delivery position, optimal for cooling.
VENTILATING OPERATION
Select the ventilating mode by pressing MODE button (2). Switch to the
desired fan speed by pressing FAN speed button (4).
TURNING ON THE AIR CONDITIONER
Press START/STOP button (1) to turn the air conditioner on. The operation
indicator on the air conditioner will light up, indicating that the unit is in
operation. Note that the LCD operation display (13) will always show the last
mode of operation and previous function used.
Follow the instructions if you choose to change the control settings; otherwise,
the air conditioner will start and operate in the same mode and functions
prior to being turned off.
8
