S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with ”Revision Publishing” when it is issued.

CDC-R136

• TYPE: YZ

S/M Code No. 09–993–412–0T1

STEREO CAR CD RECEIVER

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

ELECTRICAL MAIN PARTS LIST - 1/3

NOTE: The characters in the suffix column indicate the part usage.

YZSF ...................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 908 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 909 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 907 87-010-497-040 CAP,E 4.7-35 GAS A...................

C 905 87-010-498-040 CAP,E 10-16 GAS A...................

C 906 87-010-553-040 CAP,E 47-16 GAS A...................

C 912 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 915 87-010-198-080 CAP, CHIP 0.022 A...................

C 918 87-010-198-080 CAP, CHIP 0.022 A...................

C 913 87-010-198-080 CAP, CHIP 0.022 A...................

C 914 87-010-198-080 CAP, CHIP 0.022 A...................

C 910 87-010-221-080 CAP, ELECT 470-10V A...................

C 911 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 917 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 916 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 928 87-010-178-080 CHIP CAP 1000P A...................

C 927 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 920 87-010-198-080 CAP, CHIP 0.022 A...................

C 926 87-010-555-040 CAP,E 100-10 GAS A...................

D 908 87-017-931-080 ZENER,MTZJ5.6B A...................

D 909 87-027-262-010 LEDE,TLR-124(RED) A...................

D 917 87-017-932-080 ZENER,MTJ6.2B A...................

D 916 87-017-932-080 ZENER,MTJ6.2B A...................

D 919 87-017-932-080 ZENER,MTJ6.2B A...................

D 918 87-017-932-080 ZENER,MTJ6.2B A...................

D 910 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 912 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 914 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 913 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 920 87-017-932-080 ZENER,MTJ6.2B A...................

D 924 87-017-932-080 ZENER,MTJ6.2B A...................

D 921 87-017-932-080 ZENER,MTJ6.2B A...................

D 927 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 922 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 928 87-A40-509-080 ZENER,MTZJ6.8C A...................

D 929 87-A40-650-080 ZENER,MTZJ6.8A A...................

D 931 87-017-932-080 ZENER,MTJ6.2B A...................

D 930 87-017-932-080 ZENER,MTJ6.2B A...................

IC 903 87-020-784-080 IC,TC4053BF A...................

IC 901 87-A21-267-010 C-IC,UPD178018AGC-531-3B9 A...................

IC 902 88-KT1-606-080 IC,PST994D A...................

L 902 87-003-149-080 COIL,47UH A...................

L 903 87-003-149-080 COIL,47UH A...................

Q 907 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 908 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 909 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 905 87-A30-301-080 TR,2SD1862 A...................

Q 911 87-A30-287-040 C-TR,DTC114TKA A...................

Q 912 87-A30-287-040 C-TR,DTC114TKA A...................

SW 901 87-A91-070-010 SW,TACT SKHHLV A...................

SW 904 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A A...................

X 901 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 A...................

8Z-KC1-614-010 WIRE,ANT A...................

C 101 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 102 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 106 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 107 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 103 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 108 87-010-494-040 CAP,E 1-50 GAS A...................

C 109 87-010-494-040 CAP,E 1-50 GAS A...................

C 104 87-010-498-040 CAP,E 10-16 GAS A...................

C 105 87-010-498-040 CAP,E 10-16 GAS A...................

C 110 87-010-186-080 CAP,CHIP 4700P A...................

C 112 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 119 87-010-490-040 CAP, ELECT 0.1-50 A...................

C 111 87-010-490-040 CAP, ELECT 0.1-50 A...................

C 113 87-010-495-040 CAP,E 2.2-50 GAS A...................

C 123 87-010-178-080 CHIP CAP 1000P A...................

C 124 87-010-178-080 CHIP CAP 1000P A...................

C 125 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 121 87-010-220-080 C-CAP,S 0.018-25 B A...................

C 122 87-010-220-080 C-CAP,S 0.018-25 B A...................

C 609 87-010-197-080 CAP, CHIP 0.01 DM A...................

D 101 88-KC4-607-080 PROTECTOR, DSP-301N-A21F A...................

L 101 87-003-143-080 COIL 4.7 UH A...................

L 104 8Z-KT1-619-010 COIL,68MH K7-D A...................

Q 104 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 101 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 105 87-A30-287-040 C-TR,DTC114TKA A...................

Q 103 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 102 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 108 89-324-122-080 TR,2SC2412K A...................

Q 107 89-324-122-080 TR,2SC2412K A...................

Q 106 89-324-122-080 TR,2SC2412K A...................

Q 109 89-324-122-080 TR,2SC2412K A...................

Q 110 87-026-235-080 CHIP-TR,DTC114EK A...................

SFR 101 87-024-437-080 SFR100K,RH063EC A...................

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

ELECTRICAL MAIN PARTS LIST - 2/3

TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 A...................

C 118 87-010-175-080 CAP 560P A...................

C 115 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 116 87-010-495-040 CAP,E 2.2-50 GAS A...................

C 114 87-012-149-080 C-CAP,S 30P-50 CH A...................

C 117 87-012-157-080 C-CAP,S 330P-50 CH A...................

C 120 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

IC 101 88-KT1-607-080 C-IC,SAA6579T A...................

L 102 87-003-147-080 COIL, 22UH A...................

X 101 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 A...................

C 408 87-010-494-040 CAP,E 1-50 GAS A...................

C 401 87-010-494-040 CAP,E 1-50 GAS A...................

C 407 87-010-494-040 CAP,E 1-50 GAS A...................

C 406 87-010-494-040 CAP,E 1-50 GAS A...................

C 405 87-010-494-040 CAP,E 1-50 GAS A...................

C 402 87-010-494-040 CAP,E 1-50 GAS A...................

C 409 87-010-498-040 CAP,E 10-16 GAS A...................

C 412 87-010-494-040 CAP,E 1-50 GAS A...................

C 411 87-010-494-040 CAP,E 1-50 GAS A...................

C 417 87-010-498-040 CAP,E 10-16 GAS A...................

C 419 87-010-498-040 CAP,E 10-16 GAS A...................

C 413 87-010-498-040 CAP,E 10-16 GAS A...................

C 414 87-010-498-040 CAP,E 10-16 GAS A...................

C 418 87-010-498-040 CAP,E 10-16 GAS A...................

C 410 87-010-498-040 CAP,E 10-16 GAS A...................

C 415 87-010-498-040 CAP,E 10-16 GAS A...................

C 416 87-010-498-040 CAP,E 10-16 GAS A...................

C 421 87-010-494-040 CAP,E 1-50 GAS A...................

C 423 87-010-494-040 CAP,E 1-50 GAS A...................

C 422 87-010-494-040 CAP,E 1-50 GAS A...................

C 424 87-010-494-040 CAP,E 1-50 GAS A...................

C 429 87-010-498-040 CAP,E 10-16 GAS A...................

C 420 87-010-555-040 CAP,E 100-10 GAS A...................

C 428 87-012-140-080 CAP 470P A...................

C 427 87-012-140-080 CAP 470P A...................

C 426 87-012-140-080 CAP 470P A...................

C 425 87-012-140-080 CAP 470P A...................

C 432 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 431 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 439 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 434 87-010-198-080 CAP, CHIP 0.022 A...................

C 433 87-010-198-080 CAP, CHIP 0.022 A...................

C 430 87-010-498-040 CAP,E 10-16 GAS A...................

C 435 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 437 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 438 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 436 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 440 87-010-491-040 CAP,E 0.22-50 GAS A...................

C 441 87-010-491-040 CAP,E 0.22-50 GAS A...................

IC 401 8Z-KT1-622-010 C-IC,LC75374E A...................

Q 401 87-A30-279-040 C-TR,DTC314TK A...................

Q 402 87-A30-279-040 C-TR,DTC314TK A...................

Q 403 87-A30-279-040 C-TR,DTC314TK A...................

Q 404 87-A30-279-040 C-TR,DTC314TK A...................

Q 405 87-A30-287-040 C-TR,DTC114TKA A...................

Q 406 87-A30-287-040 C-TR,DTC114TKA A...................

C 555 87-010-178-080 CHIP CAP 1000P A...................

C 558 87-010-178-080 CHIP CAP 1000P A...................

C 557 87-010-178-080 CHIP CAP 1000P A...................

C 556 87-010-178-080 CHIP CAP 1000P A...................

C 551 87-010-494-040 CAP,E 1-50 GAS A...................

C 554 87-010-494-040 CAP,E 1-50 GAS A...................

C 553 87-010-494-040 CAP,E 1-50 GAS A...................

C 552 87-010-494-040 CAP,E 1-50 GAS A...................

C 559 87-010-498-040 CAP,E 10-16 GAS A...................

C 563 87-010-497-040 CAP,E 4.7-35 GAS A...................

C 560 8Z-KC1-630-090 CAP,E 3300U-16 M 105 EX A...................

IC 551 87-A20-876-010 IC,HA13158 A...................

C 854 87-010-178-080 CHIP CAP 1000P A...................

C 859 87-010-178-080 CHIP CAP 1000P A...................

C 856 87-010-178-080 CHIP CAP 1000P A...................

C 858 87-010-178-080 CHIP CAP 1000P A...................

C 855 87-010-178-080 CHIP CAP 1000P A...................

C 853 87-010-178-080 CHIP CAP 1000P A...................

C 857 87-010-178-080 CHIP CAP 1000P A...................

C 852 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 851 87-016-669-080 C-CAP,S 0.1-25 K B A...................

C 860 87-010-178-080 CHIP CAP 1000P A...................

C 866 87-010-194-080 CAP, CHIP 0.047 A...................

C 861 87-010-198-080 CAP, CHIP 0.022 A...................

C 867 87-010-237-080 CAP, ELECT 1000-16V A...................

C 864 87-010-498-040 CAP,E 10-16 GAS A...................

C 868 87-010-555-040 CAP,E 100-10 GAS A...................

C 865 87-010-555-040 CAP,E 100-10 GAS A...................

C 869 87-010-555-040 CAP,E 100-10 GAS A...................

C 871 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 870 87-010-555-040 CAP,E 100-10 GAS A...................

C 880 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 998 87-016-669-080 C-CAP,S 0.1-25 K B A...................

D 851 87-001-783-080 DIODE,1N4002 A...................

D 852 87-001-783-080 DIODE,1N4002 A...................

D 855 87-017-932-080 ZENER,MTJ6.2B A...................

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

ELECTRICAL MAIN PARTS LIST - 3/3

D 858 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 856 87-A40-189-080 DIODE,1SR139-400 A...................

D 857 87-A40-189-080 DIODE,1SR139-400 A...................

D 859 87-A40-523-080 ZENER,MTZJ9.1B A...................

D 853 87-A40-523-080 ZENER,MTZJ9.1B A...................

D 854 87-A40-624-080 ZENER,MTZJ10A A...................

D 860 87-070-136-080 ZENER,MTZJ5.1B A...................

D 861 87-A40-189-080 DIODE,1SR139-400 A...................

L 801 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE A...................

L 852 87-003-149-080 COIL,47UH A...................

Q 852 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 857 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 854 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 856 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 858 87-A30-298-080 TR,2SD2396 A...................

Q 853 87-A30-299-080 TR,2SB1326 A...................

Q 851 87-A30-300-080 TR,2SB1277 A...................

Q 859 87-A30-302-040 C-TR,2SD1758-F5 A...................

Q 855 87-A30-302-040 C-TR,2SD1758-F5 A...................

Q 865 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 864 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 862 87-A30-298-080 TR,2SD2396 A...................

Q 860 89-211-323-080 C-TR,2SB1132R A...................

Q 863 89-324-122-080 TR,2SC2412K A...................

ANT 101 8Z-KT1-614-010 ANT,AW-002 A...................

CNA 851 8Z-KT1-620-010 CONN ASSY,8P ISO-BLACK A...................

CNA 852 8Z-KT1-621-010 CONN ASSY,8P ISO-WHITE A...................

CON 901 87-A60-861-080 C-CONN,20P 08-6224-020-001 A...................

J 751 88-KTA-604-010 JACK,PIN 4P V-TYPE A...................

C 808 87-010-154-080 CAP CHIP 10P A...................

C 801 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 807 87-010-178-080 CHIP CAP 1000P A...................

C 803 87-010-194-080 CAP, CHIP 0.047 A...................

C 804 87-010-194-080 CAP, CHIP 0.047 A...................

C 802 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 805 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

D 805 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 808 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 809 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 803 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 802 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 807 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 801 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 804 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 810 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 811 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

D 812 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................

IC 802 87-A90-951-010 RCR UNIT,SBX1971-52 A...................

IC 801 88-KT1-608-010 C-IC,LC75854W A...................

J 451 87-A60-249-010 JACK,MOJ-B32 A...................

LCD 801 8Z-KC2-606-010 LCD,ZKC-2 A...................

PL 804 8Z-KT1-641-010 LAMP,T-3 A...................

PL 806 8Z-KT1-641-010 LAMP,T-3 A...................

PL 802 8Z-KT1-641-010 LAMP,T-3 A...................

PL 807 8Z-KT1-641-010 LAMP,T-3 A...................

PL 801 8Z-KT1-641-010 LAMP,T-3 A...................

PL 803 8Z-KT1-641-010 LAMP,T-3 A...................

PL 805 8Z-KT1-641-010 LAMP,T-3 A...................

PL 808 8Z-KT1-641-010 LAMP,T-3 A...................

S 801 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 811 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 816 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 819 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 821 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 820 87-A90-001-080 C-SW,TACT SKQMAL A...................

SW 809 87-A91-159-010 SW,TACT SKHLAD A...................

SW 807 87-A91-159-010 SW,TACT SKHLAD A...................

SW 803 87-A91-159-010 SW,TACT SKHLAD A...................

SW 808 87-A91-159-010 SW,TACT SKHLAD A...................

SW 805 87-A91-159-010 SW,TACT SKHLAD A...................

SW 804 87-A91-159-010 SW,TACT SKHLAD A...................

SW 806 87-A91-159-010 SW,TACT SKHLAD A...................

SW 802 87-A91-159-010 SW,TACT SKHLAD A...................

SW 810 87-A91-159-010 SW,TACT SKHLAD A...................

SW 815 87-A91-159-010 SW,TACT SKHLAD A...................

SW 817 87-A91-159-010 SW,TACT SKHLAD A...................

SW 813 87-A91-159-010 SW,TACT SKHLAD A...................

SW 812 87-A91-159-010 SW,TACT SKHLAD A...................

SW 814 87-A91-159-010 SW,TACT SKHLAD A...................

SW 818 87-A91-159-010 SW,TACT SKHLAD A...................

SW 822 87-A91-159-010 SW,TACT SKHLAD A...................

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

MECHANICAL PARTS LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

YZSF ...................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KC2-001-010 CABI,FRONT -C2 A...................

8Z-KC2-002-010 CABI,REAR -C2 A...................

8Z-KC2-011-010 CABI,BASE -C2 A...................

8Z-KC2-012-010 CABI,TRIM -C2 A...................

8Z-KC3-001-010 WINDOW,LCD NH-C3 A...................

8Z-KC3-003-010 RING,OVAL T-C A...................

8Z-KC1-006-010 BTN,P.SET -C A...................

8Z-KC1-007-010 BTN,+/- -C A...................

8Z-KC1-008-010 BTN,SEL -C A...................

8Z-KC1-010-010 BTN,H-BASS -C A...................

8Z-KC1-011-010 BTN,U/D -C A...................

8Z-KC1-012-010 BTN,DRV -C A...................

8Z-KC1-014-010 BTN,TETRA -C A...................

8Z-KC1-015-010 BTN,TA -C A...................

8Z-KC2-004-010 BTN,PWR -C2 A...................

8Z-KC2-005-010 BTN,EJ -C2 A...................

8Z-KC2-006-010 BTN,CD -C2 A...................

8Z-KC2-008-010 BTN,DETACH -C2 A...................

8Z-KC1-209-010 LENS,IR -C A...................

8Z-KC1-211-010 COVER, TOP -C A...................

8Z-KC1-212-010 COVER, BOTTOM -C A...................

8Z-KC1-213-010 CHAS,SIDE L -C A...................

8Z-KC1-214-010 CHAS,SIDE R -C A...................

8Z-KC1-215-010 HLDR,P-IC -C A...................

8Z-KC1-216-010 HLDR,DECK CDC-01 A...................

8Z-KC1-219-010 HLDR,TR -C A...................

8Z-KC1-249-010 COVER, DUST F-C A...................

8Z-KC1-255-010 HLDR,TR -CA A...................

8Z-KC1-257-010 HLDR,ISO-WIRE -C A...................

8Z-KC2-201-010 CHAS,FRONT -C2 A...................

8Z-KC2-202-010 HLDR,LCD -C2 A...................

8Z-KC2-203-010 LEVER,DFP HOOK -C2 A...................

8Z-KC2-204-010 LEVER,DFP LOCK -C2 A...................

8Z-KC2-205-010 PLATE,CD ENT. A...................

8Z-KC2-211-010 CASE,LCD LENS -C2 A...................

8Z-KC2-212-010 LENS,LCD -C2 A...................

8Z-KC2-213-010 LENS,L -C2 A...................

8Z-KC2-214-010 LENS,R -C2 A...................

8Z-KC2-217-010 HLDR,JACK -C2 A...................

8Z-KC2-221-110 SPR-C,DETACH HOOK-C2 A...................

8Z-KC2-222-010 SPR-T,DETACH LOCK-C2 A...................

8Z-KC2-223-010 SPR-C,DETACH -C2 A...................

8Z-KC3-201-010 COVER, CD BLIND -C A...................

8Z-KT1-236-010 CAP,LAMP BLU A...................

8Z-KT1-237-010 CAP,LAMP GRN A...................

87-251-073-410 SCREW,U+2.6-6 A...................

87-251-075-410 U+2.6-10 A...................

87-251-096-410 U+3-10 A...................

87-432-903-010 WASHER,WTE 2.6 A...................

87-B10-216-010 U+2.6-4.0 ZINC BLK (BH M2.6) A...................

87-B10-259-010 UT2+3.0-10.0 W/O SLOT (BH TAP) A...................

8Z-KC1-251-010 S-SCREW,TH2.6-4.0-0.8 A...................

8Z-KC1-254-010 S-SCREW,PT 2*5 BH+ BLK A...................

8Z-KC2-220-010 S-SCREW,PT 2*10 BH+ BLK A...................

8Z-KC1-614-010 WIRE,ANT A...................

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

ACCESSORIES / PACKAGE LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

YZSF ...................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KC2-901-010 IB,YZ(9L) R146,136 A...................

8Z-KC2-902-010 IB,INST,YZ (6L)R146,136 A...................

8Z-KC2-903-010 IB,INST,YZ (CZ-PO-H)R146,136 A...................

87-B10-141-010 NUT,5 TYPE-2 A...................

87-B10-143-010 UT1+5-15 W/O SLOT A...................

87-B10-144-010 W,5.2-10-0.5 A...................

87-B10-145-010 W-SPR,5.3-8.5-1.5 A...................

87-B10-216-010 U+2.6-4.0 ZINC BLK (BH M2.6) A...................

8Z-KC1-030-010 CASE,DFP -C A...................

8Z-KC1-231-010 HLDR,HALF -C A...................

8Z-KC1-232-010 KEY,REMOVE -C A...................

8Z-KC1-235-010 HLDR,REAR MTG A...................

8Z-KC1-244-010 S-SCREW,5*6 TH+ TAPPING ST A...................

8Z-KC1-250-010 S-SCREW,HEXAGON A...................

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

SCHEMATIC DIAGRAM _1 (MAIN)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

SCHEMATIC DIAGRAM _2 (FRONT)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PrintedinSingapore

Tokyo Japan

9620450

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa CDC-R136 User manual

Popular Car Receiver manuals by other brands
