1
Ver 1.0 2004. 01
Model Name Using Similar Mechanism CDX-R3000/R3000T
CD Drive Mechanism Type MG-611XC-186//Q
Optical Pick-up Name KSS1000E
SERVICE MANUAL
US Model
Canadian Model
CDC-X104/X144
AEP Model
UK Model
CDC-R104/X104
CDC-R104/X104/X144
AUDIO POWER SPECIFICATIONS (US MODEL)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
22 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
Tuner section
FM
Tuning range US, Canadian Model:
87.5 – 107.9 MHz
AEP, UK Model:
87.5 – 108 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 – 15,000 Hz
AM (US, Canadian Model)
Tuning range 530 – 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
MW/LW (AEP, UK Model)
Tuning range MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity MW: 30 µV
LW: 40 µV
CD player section
Signal-to-noise ratio US, Canadian Model: 110 dB
AEP, UK Model: 120 dB
Frequency response 10 – 20,000 Hz
Wow and flutter Below measurable limit
SPECIFICATIONS
Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 – 8 ohms
Maximum power output 45 W ×4 (at 4 ohms)
General
Outputs Audio outputs terminal (rear/sub switchable)
Power antenna relay control terminal
Power amplifier control terminal
Inputs Telephone ATT control terminal (AEP, UK Model)
Antenna input terminal
Tone controls Low: ±10 dB at 60 Hz (HIP-HOP)
Mid: ±10 dB at 1 kHz (HIP-HOP)
High: ±10 dB at 10 kHz (HIP-HOP)
Power requirements 12V DC car battery (negative ground)
Dimensions Approx. 178 ×50 ×176 mm
(7 1/8 ×2 ×7 in.) (w/h/d)
Mounting dimensions Approx. 182 ×53 ×161 mm
(7 1/4 ×2 1/8 ×6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg (2 lb. 10 oz.)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
Design and specifications are subject to change without
notice.
• The tuner and CD sections have no adjustments.
Sony Corporation
e Vehicle Company
Published by Sony Engineering Corporation
9-877-520-01
2004A04-1
© 2004. 01
Photo: CDC-X104
FM/AM COMPACT DISC PLAYER
US, Canadian model
FM/MW/LW COMPACT DISC PLAYER
AEP, UK model

14
CDC-R104/X104/X144
3-1. IC PIN DESCRIPTIONS
• IC1 µPD63712GC-8EU-A (RF AMP, DIGITAL SERVO, DIGITAL SIGNAL PROCESSOR) (SERVO BOARD)
Pin No. Pin Name I/O Pin Description
1LDOLaser diode ON/OFF control signal output (L: laser OFF, H: laser ON)
2PDIDimmer monitor input from optical pick-up laser diode.
3PNINot used. (Fixed at L in this set)
4AVDD — Analog power supply pin (+3.3V)
5DGND — Ground
6RFOK O RFOK signal output to system control IC.
7INTQ O CD text pack synchronization signal output to system control IC.
8RST I CD reset signal input from system control IC.
9A0I
Command/parameter discrimination signal input from system control IC.
(L: command transmission, H: parameter transmission)
10 STB I Data strobe signal input from system control IC.
11 SCK I Serial clock input from system control IC.
12 SO O Serial data output to system control IC.
13 SI I Serial data input from system control IC.
14 DVDD — Power supply pin (+3.3 V)
15 DAVDD — D/A converter power supply (+) pin (+3.3 V)
16 ROUT O Analog audio signal output (R-ch)
17 DAGND — Ground
18 REGC — Capacitor connection pin for SCF regulator.
19 DAGND — Ground
20 LOUT O Analog audio signal output (L-ch)
21 DAVDD — D/A converter power supply (+) pin (+3.3 V)
22 XVDD — Power supply pin (+3.3V)
23 XTAL O Main system clock output (16.9344 MHz)
24 XTAL I Main system clock input (16.9344 MHz)
25 XGND — Ground
26 DVDD — Power supply pin (+3.3 V)
27 C1D1/FZD O Not used. (Open)
28 C1D2/TZD O Not used. (Open)
29 C2D1/RMUTE O CD R-ch data zero detection signal output
30 C2D2/LMUTE O CD L-ch data zero detection signal output
31 C2D3/SHOCK/SBSY O Not used. (Open)
32 LOCK/FR O Not used. (Open)
33 WFCK/MIRR O Not used. (Open)
34 RFCK/HOLD O Not used. (Open)
35 PLCK O Not used. (Open)
36 C16M O Not used. (Open)
37 DGND — Ground
38 TX O Not used. (Open)
39 EMPH/RAMOVER O Not used. (Open)
40 FLAG O Not used. (Open)
41 DVDD — Power supply pin (+3.3 V)
42 LIMIT I Not used. (Fixed at L in this set)
43 XTALEN I Oscillation circuit ON/OFF control signal input (L: ON, H: OFF)
(Fixed at L in this set)
44 DGND — Ground
45 DIN I Not used. (Connect to DOUT in this set)
46 DOUT O Not used. (Connect to DIN in this set)
47 SCKIN I Not used. (Connect to SCKO in this set)
48 SCKO O Not used. (Connect to SCKIN in this set)
49 LRCKIN I Not used. (Connect to LRCK in this set)
SECTION 3
DIAGRAMS

15
CDC-R104/X104/X144
Pin No. Pin Name I/O Pin Description
50 LRCK O Not used. (Connect to LRCKIN in this set)
51 DVDD — Power supply pin (+3.3 V)
52 FD+ O Focus servo drive PWM signal output (+)
53 FD– O Focus servo drive PWM signal output (–)
54 TD+ O Tracking servo drive PWM signal output (+)
55 TD– O Tracking servo drive PWM signal output (–)
56 SD+ O Sled servo drive PWM signal output (+)
57 SD– O Sled servo drive PWM signal output (–)
58 MD+ O Spindle servo drive PWM signal output (+)
59 MD– O Spindle servo drive PWM signal output (–)
60 DGND — Ground
61 TESTEN I Test setting input (Fixed at L in this set)
62 to 66 TEST4 to TEST0 I Test setting input (Fixed at L in this set)
67 ADGND — A/D converter power supply (–) pin
68 EFM O EFM signal output
69 ASY I EFM comparator reference voltage input
70 ADVDD — A/D converter power supply pin (+3.3 V)
71 RFI I RF signal input for EFM data growing.
72 EQ2 — Not used. (Open)
73 EQ1 — RF amplifier equalizer parts connection pin
74 RF– I Not used. (Open)
75 RF2– I RF amplifier inversion input
76 AGCO O RF signal output after on AGC.
77 AGCI I RF AGC signal amplifier input
78 RFO O RF signal output before onAGC.
79 ATEST I Not used. (Open)
80 C3T — Capacitor connection pin for 3T detection.
81 AGND — Ground
82 A I Signal input (A) from optical pick-up detector.
83 C I Signal input (C) from optical pick-up detector.
84 B I Signal input (B) from optical pick-up detector.
85 D I Signal input (D) from optical pick-up detector.
86 F I Signal input (F) from optical pick-up detector.
87 E I Signal input (E) from optical pick-up detector.
88 VREFIN I Reference voltage (+1.65 V) input
89 AVDD — Analog power supply pin (+3.3 V)
90 REFOUT O Reference voltage (+1.65 V) output
91 REFC — Capacitor connection pin for reference voltage output.
92 FE– I Focus error signal amplifier inversion input
93 FEO O Focus error signal amplifier output
94 ADCIN I Not used. (Open)
95 TE- I Tracking error signal amplifier inversion input
96 TEO O Tracking error signal amplifier before output
97 TE2 O Tracking error signal amplifier after output
98 TEC I Tracking error signal comparator input
99 AGND — Ground
100 PWMSW I Not used. (Fixed at L in this set)

16
CDC-R104/X104/X144
• IC501 MN101E01KAB (SYSTEM CONTROL) (MAIN BOARD (1/2))
Pin No. Pin Name I/O Pin Description
1DAVDD — Power supply pin for D/A output converter (+3.3 V)
2BBE-MP O Not used in this set. (Open)
3DAVSS — Ground pin for D/A output converter
4 to 6 NCO O Not used in this set. (Open)
7UNISO O SONY-BUS data signal output Not used in this set. (Open)
8UNISI I SONY-BUS data signal input Not used in this set.
9UNICKO O SONY-BUS clock signal output Not used in this set.
10 VDD1 — Power supply pin for internal core (+3.3 V)
11 MMOD I Flash microcomputer write detection signal input Not used in this set.
12 OSCOUT O High speed operation clock signal output (27 MHz)
13 OSCIN I High speed operation clock signal input (27 MHz)
14 VSS1 — Ground pin for internal core
15 XIN I Low speed operation clock signal input (32.768 kHz)
16 XOUT O Low speed operation clock signal output (32.768 kHz)
17 VDD2 — Power supply pin for internal core (+3.3 V)
18 MOD1 — Pull up: “H”
19 RESET I Reset signal input
20 NCO O Not used in this set. (Open)
21 ACC IN I Accessory power supply detection signal input
22 TEST IN I Test mode detection signal input
23 TEL ATT I Telephone attenuate detection signal input
24 ATT O Audio mute control signal output
25 XKEYON O Key power supply control signal output Not used in this set. (Open)
26 NCO O Not used in this set. (Open)
27 KEYACK I Key acknowledge detection signal input
28 TU ATTIN I Tuner mute ZERO cross detection signal input
29, 30 NCO O Not used in this set. (Open)
31 BUIN I Back up power supply detection signal input
32 CD INTQ I CD servo IC CD text pack synchronization signal input
33 CD SO O CD servo IC serial data signal output (for command/text)
34 CD SI I CD servo IC serial data signal input (for command/text)
35 CD SCK O CD servo IC serial clock signal output (for command/text)
36 BUSON O BUS on signal output
37 SYSRST O System reset signal output
38 CD RFOK I CD servo IC RFOK signal input
39 CD RST O CD servo IC reset signal output
40 CD A0 O CD servo IC command/parameter identification signal output
Command transmission: “L”, Parameter transmission: “H”
41 CD STB O CD servo IC data strob signal output
42 CD MUTE R I Mechadeck mute zero cross detection signal input R
43 CD MUTE L I Mechadeck mute zero cross detection signal input L
44 CD INSW I CD mecha disc in switch detection signal input
45 CD SELFSW I CD mecha self load position detection switch signal input
46 CD LM LO O CD mecha loading motor control signal output
47 CD LM EJ O CD mecha eject motor control signal output
48 CD DSW I CD mecha down switch detection signal input
49 CD LIMIT I CD mecha in-limit switch signal input
50 NCO O Not used in this set. (Open)
51 AREASEL1 I Destination function setting input 1
52 AREASEL2 I Destination function setting input 2
53 AREASEL3 I Destination function setting input 3

17 17
CDC-R104/X104/X144
Pin No. Pin Name I/O Pin Description
54 LCD CTL O “H” output: LCD unit and key confusion, power off
“L” output: LCD unit and key confusion, power on
55, 56 NCO O Not used in this set. (Open)
57 DSSA O DSSA on/off change signal output (Cut off rear)
58 PANEL SW I Front panel attachment detection signal input “L”: with panel, “H”: without panel
59 DIAG I Condition signal input from the power IC
60 VOLATT O Electronic volume attenuate control signal output
61, 62 NCO O Not used in this set. (Open)
63 VSS2 — Ground pin for I/O port
64 TU ATT O Tuner mute control signal output
65 NCO O Not used in this set. (Open)
66 NS MASK O Noise mask signal output
67 EEP CKO O Serial clock signal output for EEPROM communication
68 EEP SIO I/O Serial data signal input/output for EEPROM communication
69 NCO O Not used in this set. (Open)
70 AMPSTB O Power regulator IC standby signal output
71 to 73 NCO O Not used in this set. (Open)
74 NCO O Not used in this set. (Open)
75 COL SEL I “H”: Front panel illumination green (Initial value)
“L”: Front panel illumination amber (Initial value)
76 LCDSO O Serial data signal output to the LCD driver
77 LCDCE O Chip enable signal output to the LCD driver
78 LCDCKO O Serial clock signal output to the LCD driver
79 I2C SIO I/O I2C BUS serial data signal input/output
80 NCO O Not used in this set. (Open)
81 I2C CKO O I2C BUS serial clock signal output
82 DAVN I RDS data block synchronization detection signal input
83 SIRCS I Remote control signal input
84 NCO O Not used in this set. (Open)
85 BEEP O Beep signal output to the power amp
86 to 88 NCO O Not used in this set. (Open)
89 VDD3 — Power supply pin for I/O port (+3.3V)
90 COL SW I “L” input: two color change/initial slave color: amber
“H” input: one color/slave color: white
91 VSS3 — Ground pin for I/O port
92 QUALITY I Noise detection signal input
93 VSM I S meter voltage detection signal input
94 KEYIN1 I Key signal input 1
95 KEYIN0 I Key signal input 0
96 NCO O Not used in this set.
97 KEYIN2 I Key signal input (EJECT, OFF, SOURCE switch)
98 RE I Rotary encoder signal input
99 L METER I Level meter voltage detection signal input
100 VREF+ — Power supply pin for A/D input converter

1818
CDC-R104/X104/X144
3-2. BLOCK DIAGRAM — CD SECTION —
76
AGCO
RF AMP,DIGITAL SERVO,
DIGITAL SIGNAL PROCESSOR
IC1
78
RFO
93
FEO
96
TEO
77 AGCI
92 FE–
95 TE– 97
TE2 98 TEC
52 FD+
PD1
PD2
E
F
I-V AMP
PD LD
DETECTOR
71 RFI 68
EFM 69 ASY
84
82
85
83
87
86
E
C
D
A
B
F
1LD 2
PD
(FOCUS)
(TRACKING)
2-AXIS DEVICE
OPTICAL
PICK-UP BLOCK
(KSS1000E)
• Siganal Path
: CD PLAY
LASER DIODE
M
M
M
13
14
VO1–
VO1+
15
16
VO4+
VO4–
17
18 VO3–
VO3+
10
9
VOL+
VOL–
FWD
REV
1
28
OPIN2+ 5
53 FD–
OPIN2– 6
54 TD+
OPIN1+ 2
55 TD–
OPIN1– 3
56 SD+
OPIN4+ 27
57 SD–
OPIN4– 26
58 MD+
OPIN3+ 24
59 MD–
OPIN3– 23
11
12
VO2–
VO2+
M903
(LOADING)
M901
(SPINDLE)
M902
(SLED)
FOCUS/TRACKING COIL DRIVE,
SLED/SPINDLE/LOADING
MOTOR DRIVE
IC2
12
SO
13
SI
11
SCK
6
RFOK
7
INTQ
10
STB
9
A0
8
RST
CD-L MAIN
SECTION
A
20
LOUT
16
ROUT R-CH
35 CD_SCK
38 CD RFOK
32 CD INTQ
41 CD STB
45 CD_SELFSW
44 CD_INSW
49 CD_LIMIT
40 CD_A0
39 CD RST
CD LM LO
46
CD LM EJ
47
SYSTEM CONTROL
IC501 (1/3)
34 CD_SI
33 CD_SO
SW2
(SELF)
48 CD_DSW
SW1
(DOWN)
SW3
(DISC IN)
SW4
(LIMIT)
30
LMUTE 43 CD MUTE L
29
RMUTE 42 CD MUTE R
PD2
E
F
LD
PD
FCS+
FCS–
TRK+
TRK–
PD1
AUTOMATIC
POWER
CONTROL
Q1
• R-ch is omitted due to same as L-ch.
24
23
X1
16.934MHz
XTAL
XTAL
(Page 19)

19 19
CDC-R104/X104/X144
1ANT 7TU-LCH
SOUND CONTROL,
ELECTRONIC VOLUME
IC401
J1
(ANTENNA)
TU1
(TUNER UNIT)
POWER AMP
MULTIPLE VOLTAGE
REGULATOR
IC750
SYSTEM CONTROL
IC501 (2/3)
CN601
6TU-RCH
R-CH (FRONT)
R-CH (REAR)
BATT
9CD-LCH
5AUX-LCH
3AUX-RCH
8CD-RCH
R-CH
4
3
10
VCC
11
TU VDD
15
E2P VDD
13
TU-SCL
14
TU-SDA
9
RDS
6
5
8
MULTI
CONDITION
QUALITY
7
S-METER
16
TU MUTE
E2P SCL
17
E2P SDA
99 L METER
82 DAVM
28 TU ATTIN
92 QUALITY
66 NS MASK
93 VSM
64 TU ATT
67 EEP CKO
68 EEP SIO
AUDIO+8.3V
TU+5V
BACK UP+3.3V
L
R
CD-L
J601
(AUX IN)
R-CH
R-CH
15 OUT-SEL-R
OUT-SEL-L
16
R-CH
17
18
OUT SUB L
OUT SUB R R-CH
L
R
5
3
OUT-FL+
OUT-FL–
OUT-RL+
OUT-RL–
9
7
29
27
AMP-REM
R-CH
ANT-REM
BATT
30
37
AUDIO+8.3V
B.UP+B
31
33
SERVO+3.3V
MECHA+6V
34
PANEL+B
TU+5V
BATT
25
24
OUT-FR
OUT-RR
29
MUTE
2SDA
AUDIO+8.3V
BACK UP+3.3V
SERVO+3.3V
MECHA+6V
PANEL+10V
4SCL
SDA
SCL
16 BEEP
22 STB
25 DIAG
AUDIO+8.3V
35 VP
15
13
7
10
12
11
16
1
9
2
4
3
5
6
30
31
SCL
SDA
SCL
SDA
SCL
SDA
SCL
SDA
81
I2C CKO
79
I2C SIO
60
VOL ATT
24
ATT
85
BEEP
70
AMPSTB
59
DIAG
31
BUIN
22
TEST IN
12 IN-FL FL+
FL–
RL+
RL–
FR+
FR–
RR+
RR–
AMP-REM
ANT-REM
ACC
TEST
23
OUT-FL
11 IN-RL
22
OUT-RL
MUTE
Q431
MUTE
Q481
AUDIO OUT
REAR
MUTE DRIVE
Q491,492
54
LCD CTL
36
BUS ON
37
SYS RST
16 MPX
9XTI
10 XTO
11
SCL
12
SDA
SCL
SDA
15
INTN
7
VDDDVDDA
1
21
ACC IN ACC CHECK
Q631
TU+5V REG
Q1
BATT
BACK UP+3.3V
PANEL+3.3V
LOW VOLTAGE
DETECT
Q581
BATTERY
CHECK
Q582
REAR L/R
CUT OFF
SWITCH
Q403
DSSA ON/OFF
SWITCH
Q402
NS MASK
SWITCH
Q3
LEVEL METER
VOLTAGE DETECT
D401,402,Q401
PANEL +3.3V
SWITCH
Q503
RDS DEMODULATOR
IC51
MUTE
Q451
ATT
23
TEL ATT
57
DSSA
TEL ATT
Q651
D492
FU601
J331
D580
R104/X104:
AEP,UK MODEL
D581
CD
SECTION A
BATT
B+ SWITCH
Q51,52
BACK UP
+3.3V
OVER VOLTAGE
DETECT
Q580
X51
8.664MHz
R104
R104
• Signal Path
• R-CH is omitted due to same as L-CH.
: CD PLAY
: FM
: AM/MW/LW
: AUX
3-3. BLOCK DIAGRAM — MAIN SECTION —
(Page 18)

2020
CDC-R104/X104/X144
X502
32.768kHz
15
16
13
12
97
76
78
77
27
19
LCD DRIVER
IC901
KEYIN2
CLK
CE
LCD SO
LCD CKO
LCD CE
PANEL+10V
DIMMER
KEYACK
90 COL SW
75 COL SEL
RESET
2IN 1
OUT
XIN
XOUT
OSCIN
OSCOUT
X501
27MHz
S702
RESET
63
64
62
1
COM1
COM4
LCD901
LIQUID
CRYSTAL
DISPLAY
PANEL
LED921,922
LCD
BACK LIGHT
3
|
50
54
|
51
|
SEG3
SEG50
|
DI
SW1
2
LED901-920
BACK UP+3.3V
()
KEY MATRIX
S901-903
95 KEYIN0
KEY MATRIX
S912-920
94 KEYIN1
KEY MATRIX
S904-910
S911 (2/2)
98
SYSTEM CONTROL
IC501 (3/3)
RE
LED DRIVE
Q904-906
LED DRIVE
Q902,903
ROTARY
ENCODER
S911 (1/2)
RESET
IC602
DIMMER
CONTROL
Q901
CL
CE
DIMMER
3-4. BLOCK DIAGRAM — DISPLAY SECTION — 3-5. CIRCUIT BOARDS LOCATION
MAIN board
AUX board
KEY board
SENSOR board SERVO board
tuner uni
t
(TU1)

21 21
CDC-R104/X104/X144
3-7. WAVEFORMS3-6. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)
For schematic diagrams.
Note:
•All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•f: internal component.
•C: panel designation.
For printed wiring boards.
Note:
•X: parts extracted from the component side.
•Y: parts extracted from the conductor side.
•a: Through hole.
•: Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
•A: B+ Line.
•B: B– Line.
•H: adjustment for repair.
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
•CD mechanism section
no mark : CD PLAY
•Main (1/2), (2/2) and Display sections
no mark : FM
():AM
<>:CD PLAY
∗: Impossible to measure
•VoltagesaretakenwithaVOM(Inputimpedance10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
•Circled numbers refer to waveforms.
•Signal path.
J: CD PLAY
F: FM
f: AM/MW/LW
a: AUX
•Abbreviation
CND : Canadian model.
Caution:
Pattern face side: Parts onthepattern facesideseenfromthe
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
Q
C
These are omitted
EB
EThese are omitted CB
CThese are omitted BE
•Abbreviation
CND : Canadian model.
Note:
The components identi-
fied by mark 0or dotted
linewithmark0arecriti-
cal for safety.
Replace only with part
number specified.
Note:
Lescomposantsidentifiéspar
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
— Servo Board —
(MODE: CD PLAY)
IC1 uj (AGCI)
1
2
16.9344MHz
IC1 wd (XTAL)
1.6Vp-p
1.2Vp-p
Approx. 620mVp-p
IC1 od (FEO)
3
0V
4
0V
Approx. 200mVp-p
IC1 oh (TEO)
32.768kHz
IC501 qg (XIN)
— Main Board —
1
2
27MHz
IC501 qs (OSCOUT)
1.8Vp-p
2.2Vp-p
IC51 q; (XTO)
3
0.9Vp-p

23 23
CDC-R104/X104/X144
IC B/D
TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
TP10
TP11
TP12
TP13
TP21
TP24
TP26
TP27
TP28
TP29
TP30
TP31
TP40
TP41
TP70
TP71
TP72
TP73
TP74
TP75
TP80
TP81
TP82
TP83
TP84
TP85
TP87
TP88
TP89
TP90
TP91
TP92
TP93
TP42
TP43
TP44
TP45
TP46
TP47
TP48
TP49
TP50
TP51
TP52
TP53
TP54
TP55
TP56
TP57
TP58
TP59
TP60
TP61
TP62
TP63
TP64
TP65
TP100
TP14
C13
C17
C20
C28
C30
C31
C34
C35
C36
C37
C38
C39
C5
C70
C71
C73
C74
C75
C76
C77
C79
C8
R1
R12
R14 R15
R7
R70 R71
R72 R73
R74 R75
R76 R77 R78R79
R80R81
R82R83
R84R85
TP19 C18
R6
C25
TP20
TP22
TP23
TP25
C32
C27
C26
C29
C1
C2
C3
C7
C11
C78
C72
C19
SW4
SW2
SW3
TP27
TP28
TP29
SW1
TP33TP32
R13
R11
CN2
Q1
M901
M902
M903
C6
X1
R41
R42
CN1
C23 C21
R9
IC1
R44
R45
JR91
JR90
FB1
JR41
JR40
IC2
• Refer to page 21 for Waveforms.
3-9. SCHEMATIC DIAGRAM — CD MECHANISM SECTION — • Refer to page 29 for IC Block Diagram.
(Page 24)

2424
CDC-R104/X104/X144
IC B/D IC B/D
R413
R414
R415
R416
R417
R418
R419
D401
C406
C407
L1
R1
R402
R410
R411
R506
R513R514
R531
R532
R534
R543
R636
X502
R595
R406
R407
R408
R409
R5 R4
C4
R559
R15
R16
R405
R505 R566
R428
R429
R510
R511
R512
R521 R522
R535
R579
R591
C6
R61
C404
C403
C419
C420
C7
C8
C428
R592
C510
C425
C426
C401
C430
C402
C427
R539
R573
R556
R552
R547
R509
C501
C512
C514
C502
C517
C504
C509
C9
C5
D1
R540
C301 C305
C302 C310 C307 C303
C304
R557
R544
R541 C511
R504
R501 R596R502 R503 R565
C513
R563
C515
C508
C507
C503
D402
C429
C405
R401 C411
C410
C412
C416
C415
R7
L304
L305
L306
C408
C409
TU1
J1
C1
C2
Q1
R6
R8 R10
R9
Q3
Q51
R59
C52
Q52
C51
C58
R54
R53
C57
C56
C55
C54
C53
C62
R58
C60 C59
X51
R55
Q503
Q403
Q402
L303
L307
L302
L310
R520
R538
R549
R537
R551
R558
C516
R564
R560
C3
R576
R575
R590
R527
R526
R578
R574
R523
R525
R524
R516
R515
JW45
JW46
JC16
R572
R571
R568
R536
X501
R577
R555
R554
IC501
CN301
IC51
Q401
IC401
R567
R550
R56
R57
R51
R52
R12
R11
R422
R421
R508
JW109
• Refer to page 21 for Waveforms.
3-10. SCHEMATIC DIAGRAM — MAIN SECTION (1/2) — • Refer to page 29 for IC Block Diagrams.
(Page 25)
(Page 23)

25 25
CDC-R104/X104/X144
IC B/D
C431
C441
C451
C461
C471
C481
C623
C753
C758
D751
D752
D753
D754
D755
D757
R431
R432
R441
R442
R451
R452
R461
R462
R471
R472
R481 R482
R493
R583
R584
R633
R634
R752
D581
R585 D580
D731
C333
C334
R443 C442
R463 C462
R433 C432
R453 C452
C492
L501
C621
R631
C622
JC2
C755
R701
C602 C601
Q471
Q481
Q451
Q431
Q461
Q441
IC602
C703
C632
R582
R632
L731
C761
C759
C760
C756R756
C491
Q491
Q492
R491
R492
D491
D492
C754
C751
C765 C766 C764
C750
D760
D759
D758
D756
D762
D761
D609
D601
C617
C618
C630
C628
C626
C624
C631
C629
C627
C625
L601
D711 D712
C704
L374
L373 L372
C731
C732
R609
IC750
J331
FU601
S702
L502
Q631 Q651
R653
D651
R654
R652
R651
Q582
Q581
Q580
JW53
CN701
CN601
D703
D702
C701
R731 R732
R735
R734 R733
3-11. SCHEMATIC DIAGRAM — MAIN SECTION (2/2) — • Refer to page 31 for IC Block Diagram.
(Page
24)
(Page 28)

2828
CDC-R104/X104/X144
R987
R915
R994
R908
R927
R988
D992
R995
R917
R996
R909
R906
R918
R913
R911
R905
R919
R916
R920
R904
R912
R907
R914
R928
R926
R950
Q903
Q904
Q905
Q901
JC902
JC903
R984
R986
R978
D901
D902
D904
Q902
LED903
LED904
LED905
LED907
LED909
LED910
LED911
LED912
LED913
LED914
LED915
LED916
LED917
LED918
LED919
LED920
R925
C992
C993
C995
Q906
R955
D991
C994
R992
R993
R962
R961
R922
R921
R931 R932
R933
R934
R935 R936
R937 R938
R939 R940
R941 R942
C906 C907
R923
R981
R982
R983
C903
R975
R901 R902
S901 S902 S903
S904 S905 S906 S907 S908 S909 S910
C901
C902
S920
S919
S918
S917
S916
S915
S914
S913
S912
R910
R903
IC901
LCD901
C904 C905 LED922
LED921
R971
R952
R954
R991
R976
CN901
J601
LED901
LED906
LED902
LED908
R985
JC905
S911
C991
C996
3-14. SCHEMATIC DIAGRAM — DISPLAY SECTION —
(Page
25)

29
CDC-R104/X104/X144
IC2 BA5966FP-FE2 (SERVO Board)
3-15. IC BLOCK DIAGRAMS
+–
+–+–
REV
FWD
OUT F
OUT R
+
–
+
–+
–
+–
+–
+
–
MUTE
+– +– +–
+– +– +– +–
LEVEL
SHIFT LEVEL
SHIFT
–+
LEVEL
SHIFT
–+
LEVEL
SHIFT
–+
–+
VCC
LOADING DRIVER
24 23 22 21 20 19 18 17 16 15
4 5 6 7 8 9 10 11 12 13 1421 3
2728 26 25
REV OPIN4(+) OPIN4(–) OPOUT4 OPIN3(+) OPIN3(–) OPOUT3 MUTE BIAS GND VO3(–) VO3(+) VO4(–) VO4(+)
FWD
OPIN1(+) OPIN1(–)
OPOUT1
OPIN2(+) OPIN2(–)
OPOUT2
VCC
VOL(–) VOL(+) VO2(–) VO2(+) VO1(–) VO1(+)
IC51 TDA7333-013TR (MAIN Board)
VDDA
INTERPOLATOR
RAM
BUFFER
&
CONTROL
LOGIC
TEST LOGIC
&
PIN MUX'S
I
2
C/SPI
INTERFACE
BAND PASS
FILTER
SIGMA DELTA
CONVERTER
SINC4
FILTER
REF3
REF2
REF1
VSS
VDDD
RESETN
TM
1
MPX
16
CSN
SDAOUT
RDSREG
3
INTN
MPX
SINC4REG
SDAIN
SCK
SPI
TESTREG
14
2
3
4
5
6
7
8
INTN
15
SA_DATAOUT
13
SDA_DATAIN
12
SCL_CLK
11
OSCILLATOR
XTO
10
XTI
9
RDS
DEMODULATOR &
SYNCHRONIZATION
2

30
CDC-R104/X104/X144
IC401 BD3809FS (MAIN Board)
32 31 30 29 28 27 26 25 24 23 22
I2C BUS
LOGIC VCO
MIX
FADER
(0~-58,
-∞dB)
FADER
(0~-58,
-∞dB)
FADER
(0~-58,
-∞dB)
FADER
(0~-58,
-∞dB)
VOLUME
(+23~-79dB,-∞dB
1dB STEP)
VOLUME
(+23~-79dB,-∞dB
1dB STEP)
INPUT GAIN
(0~15dB,1dB STEP)
INPUT SELECTOR
(4 STEREO INCLUDE 1 ISOLATION INPUT)
INPUT GAIN
(0~15dB,1dB STEP)
ANTI-ALIASING
FILTER
ANTI-ALIASING
FILTER
MUTE
fc:40kHz fc:40kHz
MUTE
6 7 8 9 10 113 4 521
DGND
AGND
FIL
AN
AUX-LCH
AUX-RCH
TU-RCH
TU-LCH
CD-RCH
CD-LCH
BUS-RCH
BUS-LCH
BP11 BP21
NC
OUT-SEL-R
OUT-SEL-L
12 14 1613 15
SDA SCL MUTE SEL ADJ VCC OUT-FR OUT-RR OUT-FL OUT-RL BP22 BP12 NC OUT-SUB-R OUT-SUB-L
21 20 19 18 17
VCC
VCC/2
TONE
PASS
BASS
fo:60,70,80,100,120,140,160,200Hz
Q:0.5,0.75,1,1.25
MIDDLE
fo:500Hz,1kHz
Q:1
TABLE
fo:5,7.5,10,12.5kHz
TONE
PASS
EFFECT (0dB~
+20dB,2dB STEP)
EFFECT (0dB~
+20dB,2dB STEP) 2ND ORDER
LPF
2ND ORDER LPF
fc:OFF,80,120,160Hz
Q: 0.707
BASS,TREBLE, MIDDLE
(-15dB~+15dB,1dB STEP)
BASS,TREBLE, MIDDLE
(-15dB~+15dB,1dB STEP)
GAIN+ATT
(+10~-29,
-∞dB)

31
CDC-R104/X104/X144
IC750 TDA8589BJ/N2 (MAIN Board)
MUTE
MUTE
ENABLE
LOGIC
STANDBY/
MUTE
BATTERY
DETECTION
CHIP DETECT/
DIAGNOSTIC
PROTECTION/
DIAGNOSTIC
SWITCH
REGULATOR
SWITCH
REFERENCE
VOLTAGE
LOADDUMP
PROTECTION
TEMPERATURE
PROTECTION
BACK-UP
SWITCHREGULATOR
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
TAB
OUT-FL-
OUT-FL+
OUT-RL-
OUT-RL+
IN-RL
S-GND
IN-RR
OUT-RR+
OUT-RR-
OUT-FR+
OUT-FR-
DIAG
ANT-REM
AMP-REM
SERVO5V
MECH6V
VP
B.UP+B
SDA
SCL
VP2
PGND3
SVR
IN-FL
IN-FR
BEEP
PGND2
VP1
STB
PGND1
RST
CRES
AUDIO8.3V
GND
PANEL+B
CBU
FL
RL
RR
VP
FR
I
2
C BUS

35
CDC-R104/X104/X144
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
4-4. CD MECHANISM SECTION (2)
(MG-611XC-186//Q)
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour
la sécurité.
Neles remplacerque parune piéce
portant le numéro spécifié.
151 A-3372-445-A CHASSIS (OP) COMPLETE ASSY
152 3-316-938-91 SCREW (B1.4X5), TAPPING
0153 8-820-207-02 OPTICAL PICK-UP (KSS1000E/K1RP)
154 A-3372-448-A CHASSIS (OP) SUB ASSY (including M901)
155 A-3372-449-A ARM SUB ASSY, CHUCKING
156 A-3372-446-A LEVER (SL) SUB ASSY
157 X-3384-090-2 LEVER (SL) ASSY
158 3-264-165-12 SCREW
M902 A-3372-447-A MOTOR ASSY, SL (SLED)
SW4 1-571-099-11 SWITCH (1 KEY) (LIMIT)
#5 7-627-850-77 SCREW, PRECISION +P 1.4X1.8
not supplied
SW4
not supplied
not supplied
not supplied
#5
not supplied
M902
151 152
153
158
154
(including M901)
155
156
157

38
CDC-R104/X104/X144 SECTION 5
ELECTRICAL PARTS LIST
NOTE:
•Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
•-XX and -X mean standardized parts, so
they may have some difference from the
original one.
•RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
•SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
•CAPACITORS
uF : µF
•COILS
uH : µH
•Abbreviation
CND : Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
1-861-211-11 AUX BOARD
**********
< JACK >
J601 1-817-308-11 JACK (AUX IN)
*************************************************************
KEY BOARD
**********
1-780-113-11 CONDUCTIVE BOARD, CONNECTION
3-262-380-01 ILLUMINATOR (LCD)
3-262-382-01 SHEET (LCD), REFLECTION
< CAPACITOR >
C901 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C902 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C991 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C994 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C995 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C996 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CN901 1-817-332-11 PLUG, CONNECTOR 15P
< DIODE >
D901 6-500-886-01 DIODE RSA6.1ENTR
D902 8-719-978-33 DIODE DTZ-TT11-6.8B
D904 8-719-978-33 DIODE DTZ-TT11-6.8B
D991 8-719-069-54 DIODE UDZS-TE17-5.1B
D992 8-719-404-50 DIODE MA111-TX
< IC >
IC901 6-705-180-01 IC LC75827W
< JUMPER RESISTOR >
JC902 1-216-864-11 METAL CHIP 0 5% 1/10W
JC903 1-216-864-11 METAL CHIP 0 5% 1/10W
JC905 1-216-864-11 METAL CHIP 0 5% 1/10W
< LIQUID CRYSTAL DISPLAY >
LCD901 1-805-520-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 6-500-509-01 LED CL-165D/PG-D-T (MENU)
LED902 6-500-509-01 LED CL-165D/PG-D-T (MENU)
LED903 6-500-437-01 LED CL-165D/SYG-D-T (OFF)
LED904 6-500-437-01 LED CL-165D/SYG-D-T
(+ >M/m.–)
LED905 6-500-437-01 LED CL-165D/SYG-D-T (1)
LED906 6-500-509-01 LED CL-165D/PG-D-T (MENU)
LED907 6-500-437-01 LED CL-165D/SYG-D-T (REP/SHUF)
LED908 6-500-509-01 LED CL-165D/PG-D-T (MENU)
LED909 6-500-437-01 LED CL-165D/SYG-D-T (4)
LED910 6-500-437-01 LED CL-165D/SYG-D-T (3)
LED911 6-500-437-01 LED CL-165D/SYG-D-T (2)
LED912 6-500-437-01 LED CL-165D/SYG-D-T (5)
LED913 6-500-437-01 LED CL-165D/SYG-D-T (6)
LED914 6-500-437-01 LED CL-165D/SYG-D-T (ATT)
LED915 6-500-437-01 LED CL-165D/SYG-D-T (EQ)
LED916 6-500-437-01 LED CL-165D/SYG-D-T (DSPL)
LED917 6-500-437-01 LED CL-165D/SYG-D-T (H-BASS)
LED918 6-500-437-01 LED CL-165D/SYG-D-T (BTM/SENS)
LED919 6-500-437-01 LED CL-165D/SYG-D-T (SOURCE/MODE)
LED920 6-500-437-01 LED CL-165D/SYG-D-T (Z)
LED921 6-500-877-01 LED HL002-K11-SS (LCD BACK LIGHT)
LED922 6-500-877-01 LED HL002-K11-SS (LCD BACK LIGHT)
< TRANSISTOR >
Q901 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q902 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q903 8-729-027-58 TRANSISTOR DTC143ZKA-T146
Q904 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q905 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q906 8-729-027-46 TRANSISTOR DTC114YKA-T146
< RESISTOR >
R901 1-216-194-00 METAL CHIP 680 5% 1/8W
R902 1-216-819-11 METAL CHIP 680 5% 1/10W
R903 1-216-194-00 METAL CHIP 680 5% 1/8W
R904 1-216-819-11 METAL CHIP 680 5% 1/10W
R905 1-216-819-11 METAL CHIP 680 5% 1/10W
KEYAUX

39
CDC-R104/X104/X144
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R906 1-216-821-11 METAL CHIP 1K 5% 1/10W
R907 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R908 1-216-029-00 METAL CHIP 150 5% 1/10W
R909 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R910 1-216-194-00 METAL CHIP 680 5% 1/8W
R911 1-216-819-11 METAL CHIP 680 5% 1/10W
R912 1-216-819-11 METAL CHIP 680 5% 1/10W
R913 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R915 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R916 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R917 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R918 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R919 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R920 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R921 1-216-037-00 METAL CHIP 330 5% 1/10W
R922 1-216-037-00 METAL CHIP 330 5% 1/10W
R923 1-216-864-11 METAL CHIP 0 5% 1/10W
R925 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R926 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R927 1-216-821-11 METAL CHIP 1K 5% 1/10W
R928 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R931 1-216-029-00 METAL CHIP 150 5% 1/10W
R932 1-216-027-00 METAL CHIP 120 5% 1/10W
R933 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R934 1-216-027-00 METAL CHIP 120 5% 1/10W
R935 1-216-037-00 METAL CHIP 330 5% 1/10W
R936 1-216-037-00 METAL CHIP 330 5% 1/10W
R937 1-216-037-00 METAL CHIP 330 5% 1/10W
R938 1-216-037-00 METAL CHIP 330 5% 1/10W
R939 1-216-037-00 METAL CHIP 330 5% 1/10W
R940 1-216-037-00 METAL CHIP 330 5% 1/10W
R941 1-216-037-00 METAL CHIP 330 5% 1/10W
R942 1-216-037-00 METAL CHIP 330 5% 1/10W
R950 1-216-805-11 METAL CHIP 47 5% 1/10W
R952 1-216-864-11 METAL CHIP 0 5% 1/10W
R954 1-216-807-11 METAL CHIP 68 5% 1/10W
R955 1-216-864-11 METAL CHIP 0 5% 1/10W
R961 1-216-037-00 METAL CHIP 330 5% 1/10W
R962 1-216-037-00 METAL CHIP 330 5% 1/10W
R971 1-216-049-11 RES-CHIP 1K 5% 1/10W
R975 1-216-063-11 RES-CHIP 3.9K 5% 1/10W
R976 1-216-864-11 METAL CHIP 0 5% 1/10W
R978 1-216-864-11 METAL CHIP 0 5% 1/10W
R981 1-216-295-11 SHORT CHIP 0
R982 1-216-295-11 SHORT CHIP 0
R983 1-216-295-11 SHORT CHIP 0
R984 1-216-801-11 METAL CHIP 22 5% 1/10W
R985 1-216-801-11 METAL CHIP 22 5% 1/10W
R986 1-216-801-11 METAL CHIP 22 5% 1/10W
R987 1-216-811-11 METAL CHIP 150 5% 1/10W
R988 1-216-811-11 METAL CHIP 150 5% 1/10W
R991 1-216-864-11 METAL CHIP 0 5% 1/10W
R992 1-216-840-11 METAL CHIP 39K 5% 1/10W
R993 1-216-857-11 METAL CHIP 1M 5% 1/10W
R994 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R995 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R996 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
< SWITCH >
S901 1-771-884-31 SWITCH, TACTILE (Z)
S902 1-771-884-31 SWITCH, TACTILE (OFF)
S903 1-771-884-31 SWITCH, TACTILE (SOURCE)
S904 1-771-884-31 SWITCH, TACTILE (3)
S905 1-771-884-31 SWITCH, TACTILE (2)
S906 1-771-884-31 SWITCH, TACTILE (1)
S907 1-771-884-31 SWITCH, TACTILE (SHUF)
S908 1-771-884-31 SWITCH, TACTILE (REP)
S909 1-771-884-31 SWITCH, TACTILE (SEEK m.–)
S910 1-771-884-31 SWITCH, TACTILE (SEEK + >M)
S911 1-478-474-11 ENCODER, ROTARY (VOLUME/PUSH-MENU)
S912 1-771-884-31 SWITCH, TACTILE (DSPL)
S913 1-771-884-31 SWITCH, TACTILE (H-BASS)
S914 1-771-884-31 SWITCH, TACTILE (EQ)
S915 1-771-884-31 SWITCH, TACTILE (ATT)
S916 1-771-884-31 SWITCH, TACTILE (MODE)
S917 1-771-884-31 SWITCH, TACTILE (BTM/SENS)
S918 1-771-884-31 SWITCH, TACTILE (6)
S919 1-771-884-31 SWITCH, TACTILE (5)
S920 1-771-884-31 SWITCH, TACTILE (4)
*************************************************************
A-3283-518-A MAIN BOARD, COMPLETE (US,CND)
A-3283-533-A MAIN BOARD, COMPLETE (X104:AEP,UK)
A-3283-534-A MAIN BOARD, COMPLETE (R104)
*********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(R104)
C2 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(R104)
C3 1-126-963-11 ELECT 4.7uF 20% 50V
(R104)
C4 1-126-947-11 ELECT 47uF 20% 16V
C5 1-126-947-11 ELECT 47uF 20% 16V
C6 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C7 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C8 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C9 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C51 1-126-947-11 ELECT 47uF 20% 16V
(R104)
C52 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C53 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C54 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C55 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C56 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C57 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
C58 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(R104)
MAINKEY

40
CDC-R104/X104/X144
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C59 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
(R104)
C60 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
(R104)
C62 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(R104)
C301 1-128-551-11 ELECT 22uF 20% 25V
C302 1-128-551-11 ELECT 22uF 20% 25V
C303 1-128-551-11 ELECT 22uF 20% 25V
C304 1-104-665-11 ELECT 100uF 20% 10V
C305 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C307 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C310 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C333 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C334 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C401 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C402 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C403 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C404 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C405 1-126-960-11 ELECT 1uF 20% 50V
C406 1-126-960-11 ELECT 1uF 20% 50V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C409 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C410 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C411 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C412 1-126-947-11 ELECT 47uF 20% 16V
C415 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C416 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C419 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C420 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C425 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C426 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C427 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C428 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C429 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C430 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C441 1-126-964-11 ELECT 10uF 20% 50V
C442 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C461 1-126-964-11 ELECT 10uF 20% 50V
C462 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C471 1-126-964-11 ELECT 10uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C491 1-126-947-11 ELECT 47uF 20% 16V
C492 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-104-665-11 ELECT 100uF 20% 10V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C507 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C508 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C509 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C511 1-126-947-11 ELECT 47uF 20% 16V
C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C516 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(R104)
C517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-131-868-81 ELECT 3300uF 20% 16V
C602 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C617 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C618 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C621 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C622 1-125-710-11 DOUBLE LAYERS 0.1F 5.5V
C623 1-104-665-11 ELECT 100uF 20% 10V
C624 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C625 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C626 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C627 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C628 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C629 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C630 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C631 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C632 1-126-961-11 ELECT 2.2uF 20% 50V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C703 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C704 1-126-934-11 ELECT 220uF 20% 10V
C731 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C732 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C750 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C751 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C753 1-128-551-11 ELECT 22uF 20% 25V
C754 1-126-961-11 ELECT 2.2uF 20% 50V
C755 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C756 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C758 1-126-964-11 ELECT 10uF 20% 50V
C759 1-126-964-11 ELECT 10uF 20% 50V
C760 1-104-665-11 ELECT 100uF 20% 10V
C761 1-126-964-11 ELECT 10uF 20% 50V
C764 1-165-822-11 CERAMIC CHIP 1uF 25V
C765 1-165-822-11 CERAMIC CHIP 1uF 25V
C766 1-165-822-11 CERAMIC CHIP 1uF 25V
< CONNECTOR >
CN301 1-817-536-11 CONNECTOR, BOARD TO BOARD 28P
CN601 1-774-701-21 PIN, CONNECTOR 16P
CN701 1-817-333-11 SOCKET, CONNECTOR 15P
< DIODE >
D1 8-719-069-55 DIODE UDZS-TE17-5.6B
D401 8-719-062-51 DIODE 1PS226-115
D402 6-500-697-01 DIODE UDZS-TE17-3.3B
D491 8-719-069-55 DIODE UDZS-TE17-5.6B
D492 8-719-404-50 DIODE MA111-TX
D580 8-719-056-84 DIODE UDZ-TE-17-7.5B
D581 8-719-083-66 DIODE UDZS-TE17-18B
D601 8-719-049-38 DIODE 1N5404TU
D609 8-719-978-33 DIODE DTZ-TT11-6.8B
D651 8-719-083-66 DIODE UDZS-TE17-18B (AEP,UK)
MAIN
