Aiwa NSX-S303 User manual

S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
•If requiring information about the CD mechanism, see Service Manual of
4ZG-1, S/M Code No. 09-978-221-20T.
NSX-S303
NSX-S307
• BASIC TAPE MECHANISM: 6ZM–3 YPR1N, PR1NM
• BASIC CD MECHANISM: 4ZG–1 Z3DSHNM •TYPE:EZ,K,V,307EZ
S/M Code No. 09–982–248–4FE
COMPACT DISC STEREO
CASSETTE RECEIVER
SYSTEM SPEAKER CD-CASSEIVER
NSX-S303
(TYPE : EZ,K,V) SX-NS302 CX-NS303
NSX-S307
(TYPE : EZ) SX-NS303 CX-NS307

ELECTRICAL MAIN PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
303K ...................XX...........................................J..........
303EZ ..................XX............................................K.........
303V ...................XX.............................................L........
307EZ ..................XX...............................................N......
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
88-NF8-205-010 0E GUIDE,FL .BC.EFGHI..LM.OPQRS.
88-NF8-206-010 0E GUIDE,PLAY REV .BC.EF......M.OP.RS.
88-NF8-207-010 0E GUIDE,FF .BC.EFGHI..LM.OPQRS.
88-NF8-208-010 0E GUIDE,PLAY 1WAY ......GHI..L....Q...
C 38 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 37 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 36 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 39 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 42 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 44 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 45 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 41 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 40 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 43 87-010-322-080 0E C-CAP,S 100P-50 CH .BC.EFGHI..LM.OPQRS.
C 46 87-012-156-080 0E C-CAP,S 220P-50 CH .BC.EFGHI..LM.OPQRS.
C 151 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 153 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 150 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 154 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 152 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 208 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 202 87-010-198-080 0E CAP, CHIP 0.022 .BC.EFGHI..LM.OPQRS.
C 203 87-010-198-080 0E CAP, CHIP 0.022 .BC.EFGHI..LM.OPQRS.
C 207 87-010-312-080 0E C-CAP,S 15P-50 CH .BC.EFGHI..LM.OPQRS.
C 205 87-010-316-080 0E C-CAP,S 33P-50 CH .BC.EFGHI..LM.OPQRS.
C 206 87-010-318-080 0E C-CAP,S 47P-50 CH .BC.EFGHI..LM.OPQRS.
C 209 87-010-494-040 0E CAP,E 1-50 GAS .BC.EFGHI..LM.OPQRS.
C 204 87-012-140-080 0E CAP 470P .BC.EFGHI..LM.OPQRS.
C 201 87-018-205-080 0E CAP, CERA-SOL 0.022 .BC.EFGHI..LM.OPQRS.
C 211 87-010-194-080 0E CAP, CHIP 0.047 .BC.EFGHI..LM.OPQRS.
C 213 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 217 87-010-197-080 0E CAP, CHIP 0.01 DM .BC.EFGHI..LM.OPQRS.
C 214 87-010-405-040 0E CAP,E 10-50 .BC.EFGHI..LM.OPQRS.
C 218 87-010-555-040 0E CAP,E 100-10 GAS .BC.EFGHI..LM.OPQRS.
C 212 87-010-555-040 0E CAP,E 100-10 GAS .BC.EFGHI..LM.OPQRS.
C 216 87-012-156-080 0E C-CAP,S 220P-50 CH .BC.EFGHI..LM.OPQRS.
C 215 87-012-156-080 0E C-CAP,S 220P-50 CH .BC.EFGHI..LM.OPQRS.
C 210 87-A10-189-040 0E CAP,E 220-10 .BC.EFGHI..LM.OPQRS.
C 250 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 307 87-015-686-040 0E CAP,E 22-25 M 7L SRA .BC.EFGHI..LM.OPQRS.
C 355 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 354 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .BC.EFGHI..LM.OPQRS.
C 404 87-010-194-080 0E CAP, CHIP 0.047 .BC.EFGHI..LM.OPQRS.
C 406 87-010-197-080 0E CAP, CHIP 0.01 DM .BC.EFGHI..LM.OPQRS.
C 405 87-010-246-040 0E CAP,E 47-35 SME .BC.EFGHI..LM.OPQRS.
C 401 87-010-405-040 0E CAP,E 10-50 .BC.EFGHI..LM.OPQRS.
C 402 87-010-405-040 0E CAP,E 10-50 .BC.EFGHI..LM.OPQRS.
CON 102 87-099-015-010 0E CONN,13P 6216V .BC.EFGHI..LM.OPQRS.
CON 301 87-099-013-010 0E CONN,11P 6216 V .BC.EFGHI..LM.OPQRS.
D 151 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 150 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 152 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 153 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 208 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 203 87-A40-470-080 0E DIODE,1SS254 .B..........M.O..RS.
D 206 87-A40-470-080 0E DIODE,1SS254 ..C.EFGHI......PQ...
D 202 87-A40-470-080 0E DIODE,1SS254 ...........L........
D 207 87-A40-470-080 0E DIODE,1SS254 ......GHI..L....Q...
D 213 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 218 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 217 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 214 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 216 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 219 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 215 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 212 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 228 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 223 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 222 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 229 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 221 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 224 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 220 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 225 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 236 87-017-932-080 0E ZENER,MTJ6.2B .BC.EFGHI..LM.OPQRS.
D 233 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 234 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 232 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 239 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 231 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 235 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 237 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 238 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.
D 230 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHI..LM.OPQRS.

S 420 87-A90-680-080 0E SW,TACT KSM0612BTS .BC.EFGHI..LM.OPQRS.
S 425 87-A90-680-080 0E SW,TACT KSM0612BTS .BC.EFGHI..LM.OPQRS.
S 423 87-A90-680-080 0E SW,TACT KSM0612BTS .BC.EFGHI..LM.OPQRS.
SW 201 87-A90-535-010 1B SW,RTRY EC16B24304 .BC.EFGHI..LM.OPQRS.
SW 202 88-NF8-615-010 1B SW,RTRY EC16B24204L=25 .BC.EFGHI..LM.OPQRS.
X 201 87-A70-075-080 0E VIB,CER 4.19MHZ CRHF .BC.EFGHI..LM.OPQRS.
C 502 87-010-177-080 0E C-CAP,S 820P-50 SL .B..........M.O..RS.
C 508 87-010-248-040 0E CAP,E 220-10 SME .B..........M.O..RS.
C 505 87-010-321-080 0E CHIP CAPACITOR,82P(J) .B..........M.O..RS.
C 501 87-010-401-040 0E CAP,E 1-50 SME .B..........M.O..RS.
C 506 87-010-405-040 0E CAP,E 10-50 .B..........M.O..RS.
C 504 87-010-544-040 0E CAP,E 0.1-50 SME .B..........M.O..RS.
C 509 87-010-545-040 0E CAP,E 0.22-50 SME .B..........M.O..RS.
C 514 87-010-186-080 0E CAP,CHIP 4700P .B..........M.O..RS.
C 510 87-010-196-080 0E CHIP CAPACITOR,0.1-25 .B..........M.O..RS.
C 513 87-010-405-040 0E CAP,E 10-50 .B..........M.O..RS.
C 511 87-010-406-040 0E CAP,E 22-50 SME .B..........M.O..RS.
D 501 87-A40-470-080 0E DIODE,1SS254 .B..........M.O..RS.
EMI 501 87-008-372-080 0E FILTER, EMI BL OIRNI .B..........M.O..RS.
IC 501 87-017-888-080 1A IC,NJM4558MD .B..........M.O..RS.
J 501 87-A60-284-010 0E JACK,3.5MO (MSC) .B..........M.O..RS.
Q 501 87-A30-087-080 0E C-FET,2SK2158 .B..........M.O..RS.
VR 501 87-NB7-602-010 1A VR,RTRY 10KAX1 1 V .B..........M.O..RS.
FC 2 87-A90-505-080 0E FUSE CLAMP,TP00351-51 ......GHIJKL.N..Q...
FC 1 87-A90-505-080 0E FUSE CLAMP,TP00351-51 ......GHIJKL.N..Q...
PR 2 87-026-681-080 0E PROTECTOR,5A 60V 491 .........JKL.N......
PR 5 87-026-681-080 0E PROTECTOR,5A 60V 491 .BC.EF......M.OP.RS.
PR 4 87-026-681-080 0E PROTECTOR,5A 60V 491 .BC.EF......M.OP.RS.
PR 1 87-026-681-080 0E PROTECTOR,5A 60V 491 .........JKL.N......
R 2 87-A00-261-080 0E RES,M/F 0.56-1W J .BC.EF......M.OP.RS.
R 1 87-A00-261-080 0E RES,M/F 0.56-1W J .BC.EF......M.OP.RS.
T 1 87-A60-317-010 0E TERMINAL, 1P MSC ......GHIJKL.N..Q...
T 2 87-A60-317-010 0E TERMINAL, 1P MSC ......GHIJKL.N..Q...
C 108 87-010-381-080 0E CAP, ELECT 330-16V .BC.EFGHIJKLMNOPQRS.
C 109 87-010-382-080 0E CAP, ELECT 22-25V ......GHI.......Q...
C 109 87-010-383-080 0E CAP, ELECT 33-25V .........JKL.N......
C 107 87-010-384-080 0E CAP, ELECT 100-25V .BC.EFGHIJKLMNOPQRS.
C 109 87-010-384-080 0E CAP, ELECT 100-25V .BC.EF......M.OP.RS.
C 102 87-010-385-080 0E CAP, ELECT 220-25V .BC.EF......M.OP.RS.
C 106 87-010-408-080 0E CAP, ELECT 47-50V .BC.EFGHIJKLMNOPQRS.
C 103 87-010-917-090 1D CAP,E 3300-50 M SMG .BC.EF......M.OP.RS.
C 101 87-010-917-090 1D CAP,E 3300-50 M SMG ......GHIJKL.N..Q...
C 101 87-016-495-090 1B CAP,E 3300-25 SMG .BC.EF......M.OP.RS.
C 105 87-018-127-080 0E CAP, CER 470P-50V .BC.EFGHIJKLMNOPQRS.
C 104 87-A10-627-090 1B CAP,E 2200-50 M SMG .BC.EFGHIJKLMNOPQRS.
C 111 87-010-247-080 0E CAP, ELECT 100-50V .BC.EF......M.OP.RS.
C 112 87-010-263-080 0E CAP, ELECT 100-10V .BC.EFGHIJKLMNOPQRS.
C 114 87-010-374-080 0E CAP, ELECT 47-10V .BC.EFGHIJKLMNOPQRS.
C 110 87-010-382-080 0E CAP, ELECT 22-25V ......GHI.......Q...
C 110 87-010-383-080 0E CAP, ELECT 33-25V .........JKL.N......
C 110 87-010-384-080 0E CAP, ELECT 100-25V .BC.EF......M.OP.RS.
C 113 87-010-403-080 0E CAP, ELECT 3.3-50V .BC.EFGHIJKLMNOPQRS.
C 111 87-010-430-080 0E CAP, ELECT 100-63 ......GHIJKL.N..Q...
C 123 87-010-382-080 0E CAP, ELECT 22-25V ......GHI.......Q...
C 122 87-010-382-080 0E CAP, ELECT 22-25V ......GHI.......Q...
C 123 87-010-383-080 0E CAP, ELECT 33-25V .........JKL.N......
C 122 87-010-383-080 0E CAP, ELECT 33-25V .........JKL.N......
C 122 87-010-384-080 0E CAP, ELECT 100-25V .BC.EF......M.OP.RS.
C 123 87-010-384-080 0E CAP, ELECT 100-25V .BC.EF......M.OP.RS.
C 124 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 130 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
D 103 87-070-178-090 0E DIODE,1N5402-BD54 ......GH.JKL.N..Q...
D 101 87-070-178-090 0E DIODE,1N5402-BD54 ......GH.JKL.N..Q...
D 102 87-070-178-090 0E DIODE,1N5402-BD54 ......GH.JKL.N..Q...
D 104 87-070-178-090 0E DIODE,1N5402-BD54 ......GH.JKL.N..Q...
D 105 87-070-274-080 0E DIODE,1N4003 SEM .BC.EFGHIJKLMNOPQRS.
D 104 87-070-274-080 0E DIODE,1N4003 SEM .BC.EF......M.OP.RS.
D 103 87-070-274-080 0E DIODE,1N4003 SEM .BC.EF......M.OP.RS.
D 102 87-070-274-080 0E DIODE,1N4003 SEM .BC.EF......M.OP.RS.
D 106 87-070-274-080 0E DIODE,1N4003 SEM .BC.EFGHIJKLMNOPQRS.
D 101 87-070-274-080 0E DIODE,1N4003 SEM .BC.EF......M.OP.RS.
D 103 87-A40-393-090 0E DIODE,1N5402GW(F20) ........I...........
D 104 87-A40-393-090 0E DIODE,1N5402GW(F20) ........I...........
D 102 87-A40-393-090 0E DIODE,1N5402GW(F20) ........I...........
D 101 87-A40-393-090 0E DIODE,1N5402GW(F20) ........I...........
D 107 87-A40-435-080 0E ZENER,MTZJ30D .BC.EFGHIJKLMNOPQRS.
D 108 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 109 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 115 87-002-225-010 1B DIODE,DBF40C-K10 .BC.EF......M.OP.RS.
D 116 87-070-274-080 0E DIODE,1N4003 SEM .BC.EFGHIJKLMNOPQRS.
D 117 87-070-274-080 0E DIODE,1N4003 SEM .BC.EFGHIJKLMNOPQRS.
D 110 87-A40-345-080 0E ZENER,MTZJ10C .BC.EFGHIJKLMNOPQRS.
D 112 87-A40-470-080 0E DIODE,1SS254 .BC.EF......M.OP.RS.
D 111 87-A40-470-080 0E DIODE,1SS254 .BC.EF......M.OP.RS.
Q 104 87-A30-196-080 0E TR,2SC4115SRS .BC.EFGHIJKLMNOPQRS.
Q 108 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 107 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 103 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 109 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 106 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 105 89-113-187-880 0E TRNSISTOR,2SA1318 (0.5W) .BC.EFGHIJKLMNOPQRS.
Q 101 89-213-702-010 1A TR,2SB1370 (1.8W) .BC.EFGHIJKLMNOPQRS.
ELECTRICAL MAIN PARTS LIST - 2

Q 102 89-333-317-880 0E TR,2SC3331 (0.5W) .BC.EFGHIJKLMNOPQRS.
Q 115 87-026-219-080 0E TR,DTA144ES (0.3W) .BC.EFGHIJKLMNOPQRS.
Q 110 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
R 124 87-A00-320-080 1B RES,M/F 3.3-1/4W F SN2E ......GHI.......Q...
RY 1 87-A90-464-010 1C RELAY, DG12D2-O(M) .BC.EF......M.OP.RS.
W 101 83-NE2-618-110 1B F-CABEL,5P-2.5 ......GHIJKL.N..Q...
W 101 85-NF5-628-010 1A F-CABLE 7P-2.5 .BC.EF......M.OP.RS.
87-067-579-010 0E TAPPING SCREW, BVT2+3-8 .BC.EFGHIJKLMNOPQRS.
C 207 87-010-546-080 0E CAP, ELECT 0.33-50V .BC.EFGHIJKLMNOPQRS.
C 208 87-010-546-080 0E CAP, ELECT 0.33-50V .BC.EFGHIJKLMNOPQRS.
C 209 87-018-133-080 0E CAPACITOR,CER 4700P-16V .BC.EFGHIJKLMNOPQRS.
C 213 87-010-260-080 0E CAP, ELECT 47-25V .BC.EFGHIJKLMNOPQRS.
C 214 87-010-260-080 0E CAP, ELECT 47-25V .BC.EFGHIJKLMNOPQRS.
C 211 87-010-404-080 0E CAP, ELECT 4.7-50V .BC.EFGHIJKLMNOPQRS.
C 212 87-010-404-080 0E CAP, ELECT 4.7-50V .BC.EFGHIJKLMNOPQRS.
C 219 87-010-544-080 0E CAP, ELECT 0.1-50V .BC.EFGHIJKLMNOPQRS.
C 210 87-018-133-080 0E CAPACITOR,CER 4700P-16V .BC.EFGHIJKLMNOPQRS.
C 220 87-010-544-080 0E CAP, ELECT 0.1-50V .BC.EFGHIJKLMNOPQRS.
C 229 87-018-123-080 0E CAP, CER 220P-50V .BC.EFGHIJKLMNOPQRS.
C 223 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JK..N......
C 221 87-018-211-080 0E CAP, CER 0.01-50 .........JK..N......
C 222 87-018-211-080 0E CAP, CER 0.01-50 .........JK..N......
C 230 87-018-123-080 0E CAP, CER 220P-50V .BC.EFGHIJKLMNOPQRS.
C 237 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 234 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JK..N......
C 236 87-018-209-080 0E CAP, CER 0.1-50V .BC.EFGHIJKLMNOPQRS.
C 235 87-018-209-080 0E CAP, CER 0.1-50V .BC.EFGHIJKLMNOPQRS.
D 206 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 202 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 209 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 203 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 205 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 201 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 204 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 219 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 216 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 217 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 210 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 218 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 221 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 222 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
D 220 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
J 202 87-033-240-010 1B TERMINAL,SP 4P32SV1-05 .BC.EFGHIJKLMNOPQRS.
J 203 87-A60-398-010 0E JACK,PIN 2P R/W HSP-242V24 ......GHI.......Q...
J 201 87-A60-488-010 1B JACK,DIA6.3 BLK ST W/SW KM16AT .BC.EFGHIJKLMNOPQRS.
J 203 87-A60-547-010 1A JACK,PIN 4P R/W/B ..........KL.N......
L 202 87-003-383-010 1A COIL,1UH-S .BC.EFGHIJKLMNOPQRS.
L 201 87-003-383-010 1A COIL,1UH-S .BC.EFGHIJKLMNOPQRS.
Q 201 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 204 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 203 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 202 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 206 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 207 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 205 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 208 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 214 87-A30-108-010 1B TR,2SB1626 ..C.EF......M..P....
Q 213 87-A30-108-010 1B TR,2SB1626 ..C.EF......M..P....
Q 212 87-A30-109-010 1B TR,2SD 2495 ..C.EF......M..P....
Q 211 87-A30-109-010 1B TR,2SD 2495 ..C.EF......M..P....
Q 213 87-A30-128-010 1A TR,2SB1481 ......GHIJKL.N..Q...
Q 214 87-A30-128-010 1A TR,2SB1481 ......GHIJKL.N..Q...
Q 212 87-A30-130-010 1A TR,2SD2241 ......GHIJKL.N..Q...
Q 211 87-A30-130-010 1A TR,2SD2241 ......GHIJKL.N..Q...
Q 211 87-A30-137-010 1C TR,2SD2494 .B............O..RS.
Q 212 87-A30-137-010 1C TR,2SD2494 .B............O..RS.
Q 213 87-A30-138-010 1C TR,2SB1625 .B............O..RS.
Q 214 87-A30-138-010 1C TR,2SB1625 .B............O..RS.
Q 210 87-A30-190-080 0E TR,CC5551 .BC.EFGHIJKLMNOPQRS.
Q 218 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 215 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
Q 216 87-A30-198-080 0E TR,KTC3199GR .BC.EFGHIJKLMNOPQRS.
R 224 87-A00-258-080 0E RES,M/F 0.22-1W J .BC.EFGHIJKLMNOPQRS.
R 223 87-A00-258-080 0E RES,M/F 0.22-1W J .BC.EFGHIJKLMNOPQRS.
R 249 87-A00-258-080 0E RES,M/F 0.22-1W J .BC.EFGHIJKLMNOPQRS.
R 250 87-A00-258-080 0E RES,M/F 0.22-1W J .BC.EFGHIJKLMNOPQRS.
C 308 87-010-263-080 0E CAP, ELECT 100-10V .BC.EFGHIJKLMNOPQRS.
C 307 87-010-263-080 0E CAP, ELECT 100-10V .BC.EFGHIJKLMNOPQRS.
C 309 87-018-115-080 0E CAP, CER 47P-50V .........JK..N......
C 301 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 303 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 302 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 304 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 315 87-010-374-080 0E CAP, ELECT 47-10V .BC.EFGHIJKLMNOPQRS.
C 318 87-010-546-080 0E CAP, ELECT 0.33-50V .BC.EFGHIJKLMNOPQRS.
C 317 87-010-546-080 0E CAP, ELECT 0.33-50V .BC.EFGHIJKLMNOPQRS.
C 310 87-018-115-080 0E CAP, CER 47P-50V .........JK..N......
C 361 87-010-374-080 0E CAP, ELECT 47-10V .BC.EFGHIJKLMNOPQRS.
C 360 87-010-401-080 0E CAP, ELECT 1-50V .BC.EFGHIJKLMNOPQRS.
C 402 87-010-401-080 0E CAP, ELECT 1-50V .BC.EFGHIJKLMNOPQRS.
C 401 87-010-401-080 0E CAP, ELECT 1-50V .BC.EFGHIJKLMNOPQRS.
C 403 87-018-118-080 0E CAP,TC-U 82P-50 B .BC.EFGHIJKLMNOPQRS.
ELECTRICAL MAIN PARTS LIST - 3

C 404 87-018-118-080 0E CAP,TC-U 82P-50 B .BC.EFGHIJKLMNOPQRS.
C 412 87-010-405-080 0E CAP, ELECT 10-50V .BC.EFGHIJKLMNOPQRS.
C 411 87-010-405-080 0E CAP, ELECT 10-50V .BC.EFGHIJKLMNOPQRS.
C 452 87-010-382-080 0E CAP, ELECT 22-25V .BC.EFGHIJKLMNOPQRS.
C 459 87-018-128-080 0E CAP, CERA-SOL SS 560P .BC.EFGHIJKLMNOPQRS.
C 458 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 462 87-018-126-080 0E CAP,TC-U 390P-50 B .BC.EFGHIJKLMNOPQRS.
C 461 87-018-126-080 0E CAP,TC-U 390P-50 B .BC.EFGHIJKLMNOPQRS.
D 401 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
IC 301 87-017-889-010 1A IC,NJM4558LD .BC.EFGHIJKLMNOPQRS.
IC 401 87-017-889-010 1A IC,NJM4558LD .BC.EFGHIJKLMNOPQRS.
JW 311 87-008-372-080 0E FILTER, EMI BL OIRNI .........JK..N......
L 451 87-007-342-010 0E COIL,OSC 85K BIAS .BC.EFGHIJKLMNOPQRS.
Q 306 87-026-218-080 0E TR,DTC144ES (0.2W) .BC.EFGHIJKLMNOPQRS.
Q 303 87-A30-090-080 0E FET,2SK2541 .BC.EFGHIJKLMNOPQRS.
Q 304 87-A30-090-080 0E FET,2SK2541 .BC.EFGHIJKLMNOPQRS.
Q 302 87-A30-091-080 1E FET,2SJ460 .BC.EFGHIJKLMNOPQRS.
Q 301 87-A30-091-080 1E FET,2SJ460 .BC.EFGHIJKLMNOPQRS.
Q 305 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 309 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 308 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 307 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 310 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 442 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 443 87-A30-197-080 0E TR,KTA1267GR .BC.EFGHIJKLMNOPQRS.
Q 455 87-A30-198-080 0E TR,KTC3199GR .........JK..N......
Q 453 89-333-317-880 0E TR,2SC3331 (0.5W) .BC.EFGHIJKLMNOPQRS.
Q 451 89-333-317-880 0E TR,2SC3331 (0.5W) .BC.EFGHIJKLMNOPQRS.
Q 454 89-333-317-880 0E TR,2SC3331 (0.5W) .BC.EFGHIJKLMNOPQRS.
SFR 452 87-A90-432-080 0E SFR,30K H NVZ6TLTA .BC.EFGHIJKLMNOPQRS.
SFR 451 87-A90-432-080 0E SFR,30K H NVZ6TLTA .BC.EFGHIJKLMNOPQRS.
C 601 87-018-195-080 0E CAP, CER 1200P-16V .BC.EFGHIJKLMNOPQRS.
C 602 87-018-195-080 0E CAP, CER 1200P-16V .BC.EFGHIJKLMNOPQRS.
C 616 87-010-408-080 0E CAP, ELECT 47-50V .BC.EFGHIJKLMNOPQRS.
C 617 87-010-408-080 0E CAP, ELECT 47-50V .BC.EFGHIJKLMNOPQRS.
C 614 87-010-545-080 0E CAP, ELECT 0.22-50V .BC.EFGHIJKLMNOPQRS.
C 611 87-010-545-080 0E CAP, ELECT 0.22-50V .BC.EFGHIJKLMNOPQRS.
C 613 87-010-545-080 0E CAP, ELECT 0.22-50V .BC.EFGHIJKLMNOPQRS.
C 612 87-010-545-080 0E CAP, ELECT 0.22-50V .BC.EFGHIJKLMNOPQRS.
C 615 87-018-104-080 0E CAP,TC-U 10P-50 SL .BC.EFGHIJKLMNOPQRS.
CON 602 87-099-194-010 0E CONN,6P 6216V .BC.EFGHIJKLMNOPQRS.
D 601 87-A40-466-080 0E ZENER,MTZJ2.7A .BC.EFGHIJKLMNOPQRS.
D 602 87-A40-466-080 0E ZENER,MTZJ2.7A .BC.EFGHIJKLMNOPQRS.
IC 602 87-001-486-080 0E FUSE, ICP-N15 ......GHI.......Q...
IC 601 87-A20-715-010 1C IC,M62439SP .BC.EFGHIJKLMNOPQRS.
J 601 87-A60-398-010 0E JACK,PIN 2P R/W HSP-242V24 .BC.EFGHIJKLMNOPQRS.
C 707 87-010-112-080 0E CAP, ELECT 100-16V .BC.EFGHIJKLMNOPQRS.
C 709 87-010-248-080 0E CAP, ELECT 220-10V .BC.EFGHIJKLMNOPQRS.
C 701 87-010-404-080 0E CAP, ELECT 4.7-50V .BC.EFGHIJKLMNOPQRS.
C 706 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 704 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 705 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 703 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 702 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 710 87-010-112-080 0E CAP, ELECT 100-16V .BC.EFGHIJKLMNOPQRS.
C 714 87-010-112-080 0E CAP, ELECT 100-16V .BC.EFGHIJKLMNOPQRS.
C 715 87-018-119-080 0E CAP, CER 100P-50V .BC.EFGHIJKLMNOPQRS.
C 713 87-018-149-080 0E CAP,TC-U 15P-50 CH .BC.EFGHIJKLMNOPQRS.
C 712 87-018-149-080 0E CAP,TC-U 15P-50 CH .BC.EFGHIJKLMNOPQRS.
D 701 87-A40-234-080 0E ZENER,MTZJ5.6A .BC.EFGHIJKLMNOPQRS.
D 702 87-A40-470-080 0E DIODE,1SS254 .........JK..N......
IC 701 87-070-127-110 1D IC,LC72131 D .BC.EFGHIJKLMNOPQRS.
L 701 87-005-847-080 0E COIL,2.2UH(CECS) .BC.EFGHIJKLMNOPQRS.
Q 701 87-A30-196-080 0E TR,2SC4115SRS .BC.EFGHIJKLMNOPQRS.
R 723 87-A00-320-080 1B RES,M/F 3.3-1/4W F SN2E ......GHI.......Q...
X 701 87-A70-061-010 1A VIB,XTAL 4.500MHZ CSA-309 .BC.EFGHIJKLMNOPQRS.
C 733 87-018-195-080 0E CAP, CER 1200P-16V .........JK..N......
C 746 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 758 87-010-112-080 0E CAP, ELECT 100-16V .BC.EFGHIJKLMNOPQRS.
C 753 87-010-408-080 0E CAP, ELECT 47-50V .BC.EFGHIJKLMNOPQRS.
C 756 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 757 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 759 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ..C.EFGHIJKL.N.PQ...
C 752 87-018-143-080 0E CAP,TC-U 4.7P-50 CH .........JKL.N......
C 762 87-010-400-080 0E CAP, ELECT 0.47-50V .BC.EFGHIJKLMNOPQRS.
C 764 87-010-401-080 0E CAP, ELECT 1-50V .BC.EFGHIJKLMNOPQRS.
C 763 87-010-401-080 0E CAP, ELECT 1-50V .BC.EFGHIJKLMNOPQRS.
C 769 87-010-403-080 0E CAP, ELECT 3.3-50V .BC.EFGHIJKLMNOPQRS.
C 761 87-010-404-080 0E CAP, ELECT 4.7-50V .BC.EFGHIJKLMNOPQRS.
C 766 87-010-407-080 0E CAP, ELECT 33-50V .BC.EFGHIJKLMNOPQRS.
C 765 87-018-115-080 0E CAP, CER 47P-50V .BC.EFGHIJKLMNOPQRS.
C 768 87-018-208-080 0E CAP 0.047-50F .BC.EFGHIJKLMNOPQRS.
C 774 87-010-405-080 0E CAP, ELECT 10-50V .BC.EFGHIJKLMNOPQRS.
C 771 87-010-406-080 0E CAP, ELECT 22-50 .BC.EFGHIJKLMNOPQRS.
C 773 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHI..LM.OPQRS.
C 770 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 789 87-010-403-080 0E CAP, ELECT 3.3-50V .BC.EFGHIJKLMNOPQRS.
C 786 87-010-405-080 0E CAP, ELECT 10-50V .BC.EFGHIJKLMNOPQRS.
C 785 87-010-405-080 0E CAP, ELECT 10-50V .BC.EFGHIJKLMNOPQRS.
C 788 87-018-132-080 0E CAP, CER 2200P-16V ..C.EFGHI..L...PQ...
C 787 87-018-132-080 0E CAP, CER 2200P-16V ..C.EFGHI..L...PQ...
C 788 87-018-196-080 0E CAP, CER 1500P-16V .B.......JK.MNO..RS.
ELECTRICAL MAIN PARTS LIST - 4

C 787 87-018-196-080 0E CAP, CER 1500P-16V .B.......JK.MNO..RS.
C 784 87-018-199-080 0E CAP, CER 3300P .BC.EFGHIJKLMNOPQRS.
C 783 87-018-199-080 0E CAP, CER 3300P .BC.EFGHIJKLMNOPQRS.
C 790 87-010-403-080 0E CAP, ELECT 3.3-50V .BC.EFGHIJKLMNOPQRS.
D 752 87-A40-470-080 0E DIODE,1SS254 .........JK..N......
D 751 87-A40-470-080 0E DIODE,1SS254 .BC.EFGHIJKLMNOPQRS.
IC 751 87-A20-438-010 1D IC,LA1837 .BC.EFGHI..LM.OPQRS.
IC 751 87-A20-913-010 1D IC,LA1837NL .........JK..N......
L 771 87-A50-266-010 1A COIL,FM DET-2N(TOK) .BC.EFGHIJKLMNOPQRS.
L 772 87-A90-052-010 1C FLTR,CFMT-450A(TOK) .B..........M.O..RS.
L 772 87-A90-733-010 1B FLTR,PCFAZH-450 (TOK) ..C.EFGHIJKL.N.PQ...
X 751 87-030-354-010 1A VIB,CF BFU 450C .B..........M.O..RS.
C 856 87-010-405-080 0E CAP, ELECT 10-50V .............N......
C 855 87-010-405-080 0E CAP, ELECT 10-50V .............N......
C 858 87-018-109-080 0E CAP, CER 22P-50V .............N......
C 859 87-018-109-080 0E CAP, CER 22P-50V .............N......
C 852 87-018-123-080 0E CAP, CER 220P-50V .............N......
C 851 87-018-123-080 0E CAP, CER 220P-50V .............N......
C 853 87-018-127-080 0E CAP, CER 470P-50V .............N......
C 857 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .............N......
C 860 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .............N......
IC 851 87-A20-502-010 1H IC,BU1920 .............N......
L 851 87-005-847-080 0E COIL,2.2UH(CECS) .............N......
Q 851 87-A30-198-080 0E TR,KTC3199GR .............N......
X 851 89-KT1-608-010 1C X,TAL,4.332MHZ .............N......
C 803 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 804 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 801 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JK..N......
C 802 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JK..N......
C 809 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JKL.N......
C 808 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .BC.EFGHIJKLMNOPQRS.
C 812 87-010-408-080 0E CAP, ELECT 47-50V .........JKL.N......
C 813 87-018-131-080 0E CAP, CER 1000P-50V .BC.EFGHIJKLMNOPQRS.
C 811 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JKL.N......
C 810 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JKL.N......
C 924 87-014-049-080 0E CAP,PP 470P-100 J .........JK..N......
C 922 87-018-099-080 0E CAP CERA 3.9P-50 .........JK..N......
C 923 87-018-102-080 0E CAP,TC-U 6.8P-50 SL .........JK..N......
C 921 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .........JK..N......
C 931 87-010-263-080 0E CAP, ELECT 100-10V .B..........M.O..RS.
C 932 87-010-400-080 0E CAP, ELECT 0.47-50V .B..........M.O..RS.
C 939 87-014-073-080 0E CAP,PP 4700P-100 J .B..........M.O..RS.
C 938 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .B.......JK.MNO..RS.
C 936 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .B..........M.O..RS.
C 935 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .B..........M.O..RS.
C 934 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .B..........M.O..RS.
C 937 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 .B.......JK.MNO..RS.
C 940 87-014-051-080 0E CAPACITOR (PP), 560P .B..........M.O..RS.
C 941 87-018-109-080 0E CAP, CER 22P-50V .B..........M.O..RS.
C 944 87-018-147-080 0E CAP,TC-U 10P-50 CH ..C.EFGHI..L...PQ...
CF 802 82-785-747-010 1A CF MS2 GHY R .........JK..N......
CF 802 87-008-261-010 1A FILTER, SFE10.7MA5-A ...........L........
CF 801 87-008-261-010 1A FILTER, SFE10.7MA5-A .BC.EFGHI..LM.OPQRS.
CF 801 87-008-423-010 1A CERAMIC FILTER, SFE10.7 .........JK..N......
D 923 87-A40-470-080 0E DIODE,1SS254 .........JK..N......
D 921 87-A40-470-080 0E DIODE,1SS254 .........JK..N......
D 922 87-A40-470-080 0E DIODE,1SS254 .........JK..N......
D 941 87-A40-470-080 0E DIODE,1SS254 .B..........M.O..RS.
FFE 801 A8-6ZA-193-030 6ZA-1 FEVNM ...........L........
FFE 801 A8-6ZA-195-130 6ZA-1 YFEENM .........JK..N......
FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM .B..EF.H....M....RS.
FFE 801 A8-8ZA-191-030 8ZA-1 YFEUNM ..C...G.......OPQ...
FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC ........I...........
J 801 87-033-230-010 1B TERMINAL,ANT AJ-2016 .........JK..N......
J 801 87-A60-202-010 1A TERMINAL,ANT 4P MSP-154V-02 .BC.EFGHI..LM.OPQRS.
L 801 87-005-847-080 0E COIL,2.2UH(CECS) .BC.EFGHIJKLMNOPQRS.
L 934 87-005-372-080 0E COIL S 1MHM .B..........M.O..RS.
L 933 87-A50-159-010 0E COIL,10MH K C2B .B..........M.O..RS.
L 942 87-A50-019-010 0E COIL,OSC LW(COI) .........JK..N......
L 941 87-A50-020-010 0E COIL,ANT LW(COI) .........JK..N......
L 941 87-A50-022-010 0E COIL,ANT SW(COI) .B..........M.O..RS.
L 942 87-A50-173-010 0E COIL,OSC SW-N(COI) .B..........M.O..RS.
L 981 87-NF4-650-010 1D COIL,AM PACK 4N(TOK) ..C.EFGHI..L...PQ...
L 981 87-NF4-651-010 1D COIL,AM PACK2N(TOM) .........JK..N......
L 981 88-NF8-625-010 1D COIL,AM PACK3N(TOK) .B..........M.O..RS.
Q 801 87-026-214-080 0E TR,DTA114YS (0.3W) .BC.EFGHIJKLMNOPQRS.
Q 802 87-026-214-080 0E TR,DTA114YS (0.3W) .B..........M.O..RS.
Q 803 89-305-352-380 0E TR,2SC535(B/C) .........JKL.N......
Q 935 87-A30-092-080 0E FET,2SK439E/F .B.......JK.MNO..RS.
Q 936 87-A30-164-080 0E TR,CSC2001K .B..........M.O..RS.
Q 933 87-A30-164-080 0E TR,CSC2001K .B.......JK.MNO..RS.
Q 931 87-A30-164-080 0E TR,CSC2001K .B..........M.O..RS.
Q 938 87-A30-197-080 0E TR,KTA1267GR .B..........M.O..RS.
Q 939 87-A30-197-080 0E TR,KTA1267GR .B..........M.O..RS.
Q 937 87-A30-198-080 0E TR,KTC3199GR .B..........M.O..RS.
Q 932 87-A30-198-080 0E TR,KTC3199GR .B..........M.O..RS.
Q 934 87-A30-198-080 0E TR,KTC3199GR .B..........M.O..RS.
Q 941 87-026-269-080 0E TR,DTA114ES .B.......JK.MNO..RS.
Q 940 87-026-269-080 0E TR,DTA114ES .B..........M.O..RS.
Q 942 87-A30-164-080 0E TR,CSC2001K .........JK..N......
TC 941 87-011-220-080 1A TRIMMER CAP 20P VTC .B..........M.O..RS.
TC 942 87-011-221-080 1A CAP, TRIMMER 30P .........JK..N......
ELECTRICAL MAIN PARTS LIST - 5

TC 943 87-011-221-080 1A CAP, TRIMMER 30P .B..........M.O..RS.
* 87-A60-317-010 0E TERMINAL, 1P MSC .BC.EF......M.OP.RST
FC 102 87-033-147-010 0E FUSE CLAMP .BC.EF......M.OP.RST
FC 101 87-033-147-010 0E FUSE CLAMP .BC.EF......M.OP.RST
SW 101 87-A90-165-010 1A SW,SL 1-2-3 SWS2301 .BC.EF......M.OP.RST
ELECTRICAL MAIN PARTS LIST - 6

NOTE: The characters in the suffix column indicate the part usage.
303K ...................XX...........................................J..........
303EZ...................XX............................................K.........
303V ...................XX.............................................L........
307EZ...................XX...............................................N......
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-NFZ-001-010 1B WINDOW,TOP .BC.EFGHIJKLMNOPQRST
87-NB8-005-010 1C PANEL,LEFT .BC.EF...JKLMNOP.RST
87-NB8-009-010 1A WINDOW,CD .BC.EFGHI..LM.OPQRST
87-NB8-012-010 0E WINDOW,CASS 1 .BC.EFGHI..LM.OPQRST
87-NB8-013-010 0E WINDOW,CASS 2 .BC.EFGHI..LM.OPQRST
87-NB8-051-010 1C PANEL,LEFT U ......GHI.......Q...
87-NF9-055-010 1D PANEL,TOP .BC.EFGHIJKLMNOPQRST
88-NF8-001-110 1H CABI,FR U ......GHI.......Q...
88-NF8-002-110 1H CABI,FR H .B..........M.O..RS.
88-NF8-005-110 1H CABI,FR LH ..C.EF.........P...T
88-NF8-021-010 1B WINDOW,DISPLAY U ......GHI.......Q...
88-NF8-022-010 1B WINDOW,DISPLAY H .BC.EF......M.OP.RS.
88-NF8-024-010 1B WINDOW,DISPLAY K ...........L........
88-NF8-027-010 1B WINDOW,DISPLAY LH S305 ...................T
88-NF8-031-010 1C CABI,REAR USTNM .......H............
88-NF8-032-010 1C CABI,REAR LHSTNM ....E...............
88-NF8-033-010 1C CABI,REAR HRJSTNM .B............O..RS.
88-NF8-034-010 CABI,REAR EZSTNE ..........K.........
88-NF8-035-010 1C CABI,REAR KSTNE .........J..........
88-NF8-037-010 CABI,REAR VJSTNM ...........L........
88-NF8-038-010 1C CABI,REAR USTN ......G.............
88-NF8-039-010 CABI,REAR EZSTNE S307 .............N......
88-NF8-040-010 1C CABI,REAR HEJSTNM ............M.......
88-NF8-041-010 1C BOX,CASS 1 REV .BC.EF......M.OP.RST
88-NF8-043-010 1C BOX,CASS 2 1WAY .BC.EFGHI..LM.OPQRST
88-NF8-044-010 1C BOX,CASS 1 1WAY ......GHI..L....Q...
88-NF8-045-110 1H CABI,FR K ...........L........
88-NF8-046-010 1B PANEL,TRAY .BC.EFGHIJKLMNOPQRST
88-NF8-047-010 1C PANEL,RIGHT 2 .BC.EF...JKLMNOP.RST
88-NF8-048-010 1C PANEL,RIGHT 2 U ......GHI.......Q...
88-NF8-051-010 1C CABI,REAR LHSTNFD ..C.................
88-NF8-052-010 CABI,REAR USTNC ........I...........
88-NF8-053-010 1C CABI,REAR LHJSTC1M S305 ...................T
88-NF8-054-010 CABI,REAR LHSTNL S303 ...............P....
88-NF8-055-010 CABI,REAR USTNL ................Q...
88-NF8-058-010 CABI,REAR LHSTNC S303 .....F..............
87-NB8-015-010 1B KNOB,RTRY VOL .BC.EFGHI..LM.OPQRST
87-NB8-017-010 0E KNOB,RTRY MIC .B..........M.O..RS.
87-NB8-021-110 1B KEY,GEQ .BC.EFGHI..LM.OPQRST
87-NB8-022-010 1A KEY,T-BASS .BC.EFGHI..LM.OPQRST
88-NF8-006-110 1A KEY,REC .BC.EFGHI..LM.OPQRST
88-NF8-007-010 1B KEY,FUNCTION .BC.EFGHI..LM.OPQRST
88-NF8-008-010 1A KEY,PLAY REV .BC.EF......M.OP.RST
88-NF8-009-010 0E REFLECTOR,PLAY REV .BC.EF......M.OP.RST
88-NF8-010-010 1B KEY,ASSY PLAY REV .BC.EF......M.OP.RST
88-NF8-011-010 1A KEY,FF .BC.EFGHI..LM.OPQRST
88-NF8-012-010 0E REFLECTOR,FF .BC.EFGHI..LM.OPQRST
88-NF8-013-010 1B KEY,ASSY FF .BC.EFGHI..LM.OPQRST
88-NF8-014-110 1A KEY,CD .BC.EFGHI..LM.OPQRST
88-NF8-016-010 1A KNOB,RTRY JOG .BC.EFGHI..LM.OPQRST
88-NF8-017-010 1A KEY,PLAY 1WAY ......GHI..L....Q...
88-NF8-018-010 0E REFLECTOR,PLAY 1WAY ......GHI..L....Q...
88-NF8-019-010 1B KEY,PLAY 1WAY ASSY ......GHI..L....Q...
81-532-080-010 1A LABEL, CASS. COMPT .BC.EFGHI..LM.OPQRST
84-ZG1-245-210 0E CAP,OPTICAL .BC.EFGHIJKLMNOPQRST
82-NF5-218-010 0E SPR-T,EJECT 1 (SIN) .BC.EFGHIJKLMNOPQRST
82-NF5-219-010 0E SPR-T,EJECT 2 (SIN) .BC.EFGHIJKLMNOPQRST
82-NF5-229-010 0E PLATE,LOCK .BC.EFGHI..LM.OPQRST
86-NF9-224-010 0E SPR-C,LOCK .BC.EFGHI..LM.OPQRST
87-NF4-216-010 0E HLDR,LOCK 1 .BC.EFGHI..LM.OPQRST
87-NF4-217-010 0E HLDR,LOCK 2 .BC.EFGHI..LM.OPQRST
87-NF8-220-010 1A DMPR,150 .BC.EFGHI..LM.OPQRST
87-067-641-010 0E UTT2+3-8(W/O SLOT)BL .BC.EFGHIJKLMNOPQRST
87-067-688-010 0E BVTT+3-6 .BC.EFGHIJKLMNOPQRST
87-067-703-010 0E TAPPING SCREW, BVT2+3-10 .BC.EFGHIJKLMNOPQRST
87-078-019-010 0E S-SCREW,IT+4-6 .BC.EFGHIJKLMNOPQRST
87-721-096-410 0E QT2+3-10 GLD .BC.EFGHIJKLMNOPQRST
87-721-097-410 0E QT2+3-12 GLD .BC.EFGHIJKLMNOPQRST
87-723-096-410 0E QT2+3-10W/O SLOT BL .BC.EFGHIJKLMNOPQRST
87-NF4-224-010 0E S-SCREW,IT3B+3-8 CU .BC.EFGHIJKLMNOPQRST
87-003-317-010 1C F-BEAD,F0H2515-LG7 .........JK..N......
87-050-034-010 1C AC CORD ASSY,E ..........K..N......
87-050-053-010 1B AC CORD ASSY,U-2 ......GHI.......Q...
87-050-079-010 1C AC-CORD ASSY,E .BC.EF.....LM.OP.RST
87-085-185-010 0E BUSHING, AC CORD (E) .BC.EF...JKLMNOP.RST
87-085-189-010 0E BUSHING, CORD (U) ......GHI.......Q...
87-A40-470-080 0E DIODE,1SS254 ......GHI.......Q...
87-A80-023-010 AC CORD,ASSY K 3P W .........J..........
88-906-251-110 1A FF-CABLE,6P 1.25 .BC.EFGHIJKLMNOPQRST
88-911-091-110 1A FF-CABLE,11P 1.25 .BC.EFGHI..LM.OPQRST
88-913-321-110 1B FF-CABLE, 13P 1.25 320MM .BC.EFGHI..LM.OPQRST
C 255 87-018-115-080 0E CAP, CER 47P-50V .........JK..N......
C 256 87-018-115-080 0E CAP, CER 47P-50V .........JK..N......
C 257 87-018-119-080 0E CAP, CER 100P-50V .........JK..N......
MECHANICAL PARTS LIST - 1

C 258 87-018-119-080 0E CAP, CER 100P-50V .........JK..N......
C 320 87-018-209-080 0E CAP, CER 0.1-50V .........JK..N......
F 101 87-035-139-010 1A FUSE, 2.5AT .BC.EF......M.OP.RST
F 101 87-035-223-010 1A FUSE, 1.25AT .........JKL.N......
F 101 87-035-414-010 1A FUSE, T2A 250V UL ......GHI.......Q...
PT 101 88-NF8-604-010 2Y PT,8NF-8U ......GHI.......Q...
PT 101 88-NF8-605-010 2Y PT,8NF-8LH ..C.EF.........P...T
PT 101 88-NF8-606-010 2B PT,8NF-8HR .B..........M.O..RS.
PT 101 88-NF8-608-010 PT,8NF-8E .........JKL.N......
88-NF8-205-010 0E GUIDE,FL .BC.EFGHI..LM.OPQRS.
88-NF8-206-010 0E GUIDE,PLAY REV .BC.EF......M.OP.RS.
88-NF8-207-010 0E GUIDE,FF .BC.EFGHI..LM.OPQRS.
88-NF8-208-010 0E GUIDE,PLAY 1WAY ......GHI..L....Q...
W 101 83-NE2-618-110 1B F-CABEL,5P-2.5 ......GHIJKL.N..Q...
W 101 85-NF5-628-010 1A F-CABLE 7P-2.5 .BC.EF......M.OP.RS.
87-067-579-010 0E TAPPING SCREW, BVT2+3-8 .BC.EFGHIJKLMNOPQRS.
MECHANICAL PARTS LIST - 2

ACCESSORIES / PACKAGE LIST
NOTE: The characters in the suffix column indicate the part usage.
303K ...................XX...........................................J..........
303EZ ..................XX............................................K.........
303V ...................XX.............................................L........
307EZ ..................XX...............................................N......
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
88-NF8-901-010 1D IB,H(ECA)M .B..........M....RS.
88-NF8-902-010 1B IB,LH(ESP)M ..C.E...............
88-NF8-903-010 1C IB,U(ESF)M ......GH............
88-NF8-905-010 IB,K(E)E .........J..........
88-NF8-906-010 IB,E(EGFSDI)E ..........K.........
88-NF8-907-010 IB,V(ER)M ...........L........
88-NF8-911-010 IB,U(ESF)C ........I...........
88-NF8-912-010 IB,LH(ESP)SOL .....F..............
88-NF8-914-010 IB,H(ECA)DIS ..............O.....
88-NF8-915-010 IB,LH(ESP)DIS ...............P....
88-NF8-916-010 IB,E(9L)E 307 .............N......
88-NF8-923-010 IB,U(ESF)DIS ................Q...
88-NF8-922-010 IB,LH(P)CCE 305 ...................T
87-006-225-010 1D AM LOOP ANT NC2 ..C.EFGHIJKL.N.PQ..T
87-043-095-010 1B WIRE ANTENNA .B..........M.O..RS.
87-043-106-010 1A WIRE, FM ANT (Z) .........JK..N......
87-043-115-010 1A ANT,FEEDER FM ........I...........
87-A90-054-010 1B ANT,LOOP AM-CON C .B..........M.O..RS.
87-A90-064-010 1A FEEDER-ANT,FM(SHS) .BC.EFGH...LM.OPQRST
87-A90-312-010 PLUG,CONVERSION WTN-1157R1 .BC.EF......M.OP.RS.
87-NF6-635-010 2A RC UNIT,RC-7AS06 .BC.EFGHIJKLMNOPQRST

SCHEMATIC DIAGRAM -1 (MAIN : 303EZ)

SCHEMATIC DIAGRAM -2 (MAIN : 303K)

SCHEMATIC DIAGRAM -3 (MAIN : 303V)

SCHEMATIC DIAGRAM -4 (MAIN : 307EZ)

SCHEMATIC DIAGRAM -5 (FRONT)

PrintedinSingapore
Tokyo Japan
4
9620450
