SERVICE MANUAL
DATA
COMPACT DISC
STEREO SYSTEM
XR-MK111
HC
S/M Code No. 09-00C-432-8S1
SUPPLEMENT
BASIC TAPE MECHANISM: 2ZM-1 YR12NC
BASIC CD MECHANISM: 3ZG-3 E10NC
•This Service Manual contains information about the difference between
XR-MK111(HC) and XR-MK111(HR). If requiring other information, see
Service Manual of XR-MK111(HR), (S/M Code No. 09-00A-432-8R1).
REMOTE
CONTROLLER
RC-ZAT05
SYSTEM
XR-MK111
SPECIFICATIONS
ACCESSORIES / PACKAGE LIST
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
<FM Tuner section>
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity(IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
<AM Tuner section>
Tuning range 531 kHz to 1602 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz step)
Usable sensitivity 350 uV/m
Antenna Loop antenna
<Amplifier section>
Power output Rated: 12 W + 12 W
(8 ohms, T.H.D. 1%, 1 kHz)
Reference: 15 W + 15 W
(8 ohms, T.H.D. 10 %, 1 kHz)
Total harmonic distortion 0.07 % (7.5 W, 1 kHz, 8 ohms,
DIN AUDIO)
Inputs VIDEO/AUX: 0.4 V
Outputs VIDEO OUT: 1.0 Vp-p (75 ohms)
LINE OUT: 0.4 V (47 kohms load)
SUB WOOFER: 1.0 V
SPEAKERS: accept speakers of
8 ohms or more
PHONES (stereo minijack):
accepts headphones of 32 ohms
or more
<Cassette deck section>
Track format 4 tracks, 2 channels stereo
Frequency response Normal tape: 50 Hz – 15000 Hz
Signal-to-noise ratio 50 dB
Recording system AC bias
Heads Recording/Playback head x 1
Erase head x 1
<Compact disc player section>
Laser Semiconductor laser (λ =780 nm)
D-A converter 1 bit dual
Signal-to-noise ratio 75 dB (1 kHz, 0 dB)
Harmonic distortion 0.1 % (1 kHz, 0 dB)
Wow and flutter Unmeasurable
Video signal NTSC/PAL color format (selectable)
Video data MDEG 1
Audio data MPEG 1, LAYER 2
<Speaker system>
Cabinet type 2 way, bass reflex
Speaker Woofer:
120 mm (4 3/4in) cone type
Tweeter:
20 mm ( 13/16 in) ceramic type
Impedance 8 ohms
Output sound pressure level 87 dB/W/m
Dimensions (W xH xD) 150 x 256 x 210 mm
(6 x 10 1/8x 8 3/8in.)
Weight 1.4 kg (3 lbs 1 oz)
<General>
Power requirements AC: 120 V/ 220 V - 240 V,
Switchable 50/60 Hz
Power consumption 45 W
Dimensions of main unit 168 x 256 x 255 mm
(W xH xD) (6 5/8x 10 1/8x 10 1/8in)
Weight of main unit 3.5 kg
(7 lbs 11 oz.)
Standby power consumption If the power-economizing mode is
on: 1.0 W
If the power-economizing mode is
off: 10 W
• Design and specifications are subject to change without
notice.
– 2 –
1 8A-CG9-902-010 IB,H (EC-K)-IN
2 8A-CL9-157-010 PLATE,NAME
3 87-043-115-010 ANT,FEEDER FM
4 87-A80-167-010 CORD,PIN 1PY 150CM
5 87-A90-030-010 ANT,LOOP AM-NC C
6 87-A91-015-010 PLUG,CONVERSION JT-0475A
7 8Z-CG8-952-010 RC UNIT,RC-ZAT05
!
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 3 –
ELECTRICAL MAIN PARTS LIST
IC
87-A20-547-010 C-IC,CXA1992AR
87-A20-919-040 C-IC,BA5915FP
87-A20-917-010 C-IC,CXD2540Q-1/2
8A-CG9-670-010 C-IC,UPD78016CFG-584-AB8
87-017-760-080 IC,M51943BML
8A-CG9-685-010 C-IC,M38B57MCH-P257FP
87-A20-602-040 C-IC,M5291FP
87-017-889-010 IC,NJM4558LD
87-A20-925-040 C-IC,BA05FP
87-A20-905-040 C-IC,BA033FP
87-A21-831-010 IC,SPS-442-1-F1
87-001-982-010 IC,TA7291S
87-A20-920-010 C-IC,CL680-D1
87-070-391-040 IC,BA4558F
87-A20-921-040 C-IC,SN74LVU04APW
87-A20-962-040 C-IC,MSM54V16258B/BSL
84-ZG1-695-040 C-IC,LH5V2RN1
87-A20-975-040 C-IC,SN74LV74APW
87-A21-520-040 C-IC,M61509FP
87-A20-918-040 C-IC,SM5878AM
87-A20-974-040 C-IC,LC74781M-9017
87-070-127-110 IC,LC72131D
87-A20-913-010 IC,LA1837NL
87-020-454-010 IC,DN6851
TRANSISTOR
89-111-625-080 TR,2SA1162 (0.15W)
89-213-702-010 TR,2SB1370 (1.8W)
87-026-610-080 TR,KTC3198GR
87-A30-432-040 C-TR,DTC124XKA
89-327-125-080 CHIP TR,2SC2712GR
87-A30-196-080 TR,2SC4115SRS
87-A30-287-040 C-TR,DTC114TKA
87-A30-515-080 TR,2SA1979O/Y
87-A30-198-080 TR,KTC3199GR
87-A30-450-040 C-TR,DTA124XKA
87-A30-427-040 C-TR,DTC114EKA
87-A30-197-080 TR,KTA1267GR
87-026-219-080 TR,DTA144ES (0.3W)
87-A30-127-010 TR,2SD2478
87-A30-126-010 TR,2SB1616
89-406-555-080 TR,2SD655 (0.5W)
87-026-609-080 TR,KTA1266GR
87-A30-117-010 TR,2SA1357
87-026-245-080 TR,DTC114ES
89-112-965-080 TR,2SA1296 (0.75W)
87-A30-090-080 FET,2SK2541
89-111-624-080 TR,2SA1162Y
87-A30-076-080 C-TR,2SC3052F
87-A30-074-080 C-TR,RT1P 141C
87-026-502-080 DTC144TS
87-A30-436-040 C-TR,DTC144TKA
87-A30-257-080 C-TR,2SD1306E
87-A30-075-080 C-TR,2SA1235F
87-A30-234-080 TR,CSC4115BC
89-327-143-080 2SC2714
87-A30-072-080 RT1P144C
87-026-463-080 TR,2SA933SRS
DIODE
87-020-027-080 CHIP-DIODE 1SS184
87-A40-454-080 DIODE,1N5393 GW
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-553-080 DIODE,1N4003 LES
87-A40-781-080 ZENER,UZ36BSA
87-A40-764-080 ZENER,UZ10BSC
87-017-024-040 C-DIODE,DA204K
87-A40-180-040 C-DIODE,SB07-015C
87-001-731-080 ZENER,HZS6C2L
87-A40-739-080 ZENER,UZ2.7BSA
MAIN C.B
C101 87-016-495-000 CAP,E 3300-25 M SMG
C102 87-012-286-080 CAP, U 0.01-25
C104 87-A10-011-090 CAP,E 2200-25 SMG
C105 87-A10-039-080 C-CAP,U 470P-50 J CH
C106 87-010-408-080 CAP, ELECT 47-50V
C107 87-010-384-080 CAP, ELECT 100-25V
C108 87-010-381-080 CAP, ELECT 330-16V
C109 87-010-260-080 CAP, ELECT 47-25V
C110 87-010-260-080 CAP, ELECT 47-25V
C111 87-010-247-080 CAP, ELECT 100-50V
C112 87-010-263-080 CAP, ELECT 100-10V
C113 87-010-403-080 CAP, ELECT 3.3-50V
C114 87-010-374-080 CAP, ELECT 47-10V
C115 87-A11-007-080 CAP,M 0.047-50 J DE
C116 87-A11-007-080 CAP,M 0.047-50 J DE
C122 87-010-260-080 CAP, ELECT 47-25V
C123 87-010-260-080 CAP, ELECT 47-25V
C131 87-A12-317-080 C-CAP,U 0.1-50 Z F
C132 87-A12-317-080 C-CAP,U 0.1-50 Z F
C200 87-012-286-080 CAP, U 0.01-25
C201 87-012-286-080 CAP, U 0.01-25
C207 87-010-546-080 CAP, ELECT 0.33-50V
C208 87-010-546-080 CAP, ELECT 0.33-50V
C209 87-012-282-080 CAP, U 4700P-50
C210 87-012-282-080 CAP, U 4700P-50
C211 87-010-403-080 CAP, ELECT 3.3-50V
C212 87-010-403-080 CAP, ELECT 3.3-50V
C213 87-010-260-080 CAP, ELECT 47-25V
C214 87-010-260-080 CAP, ELECT 47-25V
C217 87-010-959-080 CHIP CAP,U 0.056-16F
C218 87-010-959-080 CHIP CAP,U 0.056-16F
C219 87-012-286-080 CAP, U 0.01-25
C220 87-012-286-080 CAP, U 0.01-25
C227 87-010-260-080 CAP, ELECT 47-25V
C229 87-012-199-080 CAP 220P
C230 87-012-199-080 CAP 220P
C261 87-012-286-080 CAP, U 0.01-25
C273 87-A12-319-080 C-CAP,U 0.1-25 K B
C303 87-012-273-080 C-CAP,U 820P-50 B
C304 87-012-273-080 C-CAP,U 820P-50 B
C307 87-010-263-080 CAP, ELECT 100-10V
C308 87-010-263-080 CAP, ELECT 100-10V
C311 87-010-758-080 C-CAP,U 0.068-25F
C312 87-010-758-080 C-CAP,U 0.068-25F
C313 87-012-280-080 CAP, U 3300P-50
C314 87-012-280-080 CAP, U 3300P-50
C315 87-010-374-080 CAP, ELECT 47-10V
C317 87-010-546-080 CAP, ELECT 0.33-50V
C318 87-010-546-080 CAP, ELECT 0.33-50V
C320 87-010-401-080 CAP, ELECT 1-50V
C321 87-010-405-080 CAP, ELECT 10-50V
C340 87-012-199-080 CAP 220P
C349 87-012-195-080 C-CAP,U 100P-50CH
C350 87-012-195-080 C-CAP,U 100P-50CH
C361 87-010-374-080 CAP, ELECT 47-10V
C362 87-010-401-080 CAP, ELECT 1-50V
C386 87-012-286-080 CAP, U 0.01-25
C393 87-012-274-080 CHIP CAP,U 1000P-50B
C394 87-012-274-080 CHIP CAP,U 1000P-50B
C401 87-010-401-080 CAP, ELECT 1-50V
C402 87-010-401-080 CAP, ELECT 1-50V
C403 87-012-193-080 C-CAP,U 82P-50 CH
C404 87-012-193-080 C-CAP,U 82P-50 CH
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 4 –
C405 87-012-284-080 CAP, U 6800P-50
C406 87-012-284-080 CAP, U 6800P-50
C407 87-010-784-080 C-CAP,U 0.012-25 B
C408 87-010-784-080 C-CAP,U 0.012-25 B
C451 87-010-787-080 CAP, U 0.022-25
C452 87-010-382-080 CAP, ELECT 22-25V
C453 87-012-279-080 C-CAP,U 2700P-50 B
C454 87-012-279-080 C-CAP,U 2700P-50 B
C455 87-012-279-080 C-CAP,U 2700P-50 B
C456 87-012-286-080 CAP, U 0.01-25
C457 87-A10-772-080 CAP,M 5600P-50 J
C458 87-012-274-080 CHIP CAP,U 1000P-50B
C459 87-012-271-080 CAP, U 560P-50
C461 87-012-269-080 C-CAP,U 390P-50 B
C462 87-012-269-080 C-CAP,U 390P-50 B
C601 87-012-276-080 CAP, CHIP SS 1500 PBK
C602 87-012-276-080 CAP, CHIP SS 1500 PBK
C603 87-012-195-080 C-CAP,U 100P-50CH
C604 87-012-199-080 CAP 220P
C609 87-012-287-080 C-CAP,U 0.015-25 F
C610 87-010-785-080 C-CAP,U0.015-25BK
C611 87-010-545-080 CAP, ELECT 0.22-50V
C612 87-010-545-080 CAP, ELECT 0.22-50V
C613 87-010-545-080 CAP, ELECT 0.22-50V
C614 87-010-545-080 CAP, ELECT 0.22-50V
C615 87-012-172-080 CAPACITOR CHIP U 10P CH
C616 87-010-408-080 CAP, ELECT 47-50V
C617 87-010-408-080 CAP, ELECT 47-50V
C619 87-010-401-080 CAP, ELECT 1-50V
C620 87-010-401-080 CAP, ELECT 1-50V
C629 87-012-274-080 CHIP CAP,U 1000P-50B
C630 87-012-274-080 CHIP CAP,U 1000P-50B
C631 87-012-286-080 CAP, U 0.01-25
C697 87-012-286-080 CAP, U 0.01-25
C698 87-012-286-080 CAP, U 0.01-25
C705 87-012-282-080 CAP, U 4700P-50
C710 87-010-403-080 CAP, ELECT 3.3-50V
C711 87-010-403-080 CAP, ELECT 3.3-50V
C712 87-010-403-080 CAP, ELECT 3.3-50V
C713 87-010-403-080 CAP, ELECT 3.3-50V
C714 87-A10-249-080 C-CAP,U 1-10 ZF
C717 87-010-405-080 CAP,E 10-50 M 11L SME
C718 87-010-785-080 C-CAP,U 0.015-25 K B GRM
C719 87-010-785-080 C-CAP,U 0.015-25 K B GRM
CN202 87-099-719-010 CONN,30P TYK-B(X)
CN351 87-A60-624-010 CONN,7P V 2MM JMT
CN702 87-099-570-010 CONN,13P TUC-P13P-B1
CON351 88-CL4-701-010 CONN ASSY,7P RPEH
FB101 87-A90-896-080 F-BEAD, 035600STY7
FB102 87-A90-896-080 F-BEAD, 035600STY7
FB401 83-XM1-617-080 C-COIL,BK2125HM601
FB402 83-XM1-617-080 C-COIL,BK2125HM601
FB601 87-A90-896-080 F-BEAD, 035600STY7
FB602 83-XM1-617-080 C-COIL,BK2125HM601
FB604 83-XM1-617-080 C-COIL,BK2125HM601
FB605 83-XM1-617-080 C-COIL,BK2125HM601
FB606 83-XM1-617-080 C-COIL,BK2125HM601
J231 87-A60-420-010 JACK,3.5 ST (MSC)
J241 87-A60-217-010 TERMINAL,SPKR 4P
J601 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J603 87-099-801-010 JACK,PIN 1P BLK
JW203 87-A90-896-080 F-BEAD, 035600STY7
L201 87-005-366-010 COIL, 1UH
L202 87-005-366-010 COIL, 1UH
L451 87-007-342-010 COIL,OSC 85K BIAS
PN101 87-A90-510-010 HLDR,WIRE 2.5-9P
PR201 87-A90-473-080 PROTECTOR,3.5A 491SERIES 60V
PR202 87-A90-473-080 PROTECTOR,3.5A 491SERIES 60V
R223 87-A00-258-080 RES,M/F 0.22-1W J
R224 87-A00-258-080 RES,M/F 0.22-1W J
R249 87-A00-258-080 RES,M/F 0.22-1W J
R250 87-A00-258-080 RES,M/F 0.22-1W J
FRONT C.B
C302 87-012-286-080 CAP, U 0.01-25
C304 87-010-405-040 CAP,E 10-50
C305 87-A10-797-040 CAP,E 47-35 M 5L SRM
C307 87-010-421-040 CAP,E 4.7-50 5L
C308 87-010-421-040 CAP,E 4.7-50 5L
C309 87-010-787-080 CAP, U 0.022-25
C313 87-010-378-040 CAP,E 10-16
C314 87-A10-189-040 CAP,E 220-10
C315 87-A10-025-080 C-CAP,U 0.22-16Z F
C316 87-012-286-080 CAP, U 0.01-25
C317 87-010-787-080 CAP, U 0.022-25
C318 87-012-191-080 CHIP CAP 68 PF
C319 87-012-191-080 CHIP CAP 68 PF
C320 87-012-191-080 CHIP CAP 68 PF
C321 87-012-191-080 CHIP CAP 68 PF
C322 87-012-191-080 CHIP CAP 68 PF
C323 87-012-191-080 CHIP CAP 68 PF
C324 87-012-191-080 CHIP CAP 68 PF
C325 87-012-191-080 CHIP CAP 68 PF
C326 87-012-191-080 CHIP CAP 68 PF
C327 87-012-191-080 CHIP CAP 68 PF
C328 87-012-191-080 CHIP CAP 68 PF
C329 87-010-787-080 CAP, U 0.022-25
C330 87-012-188-080 C-CAP,U 47P-50 CH
C331 87-012-176-080 CAP 15P
C333 87-010-494-040 CAP,E 1-50 GAS
C335 87-012-184-080 C-CAP,U 33P-50 CH
C338 87-012-286-080 CAP, U 0.01-25
C339 87-012-286-080 CAP, U 0.01-25
C340 87-012-286-080 CAP, U 0.01-25
C341 87-010-263-040 CAP,E 100-10
C352 87-010-757-080 C.CAP,U 0.047-25F
C395 87-012-197-080 C-CAP,U 150P-50 CH
C397 87-012-197-080 C-CAP,U 150P-50 CH
C398 87-012-195-080 C-CAP,U 100P-50CH
C399 87-012-180-080 C-CAP,U 22P-50 CH
C400 87-012-197-080 C-CAP,U 150P-50 CH
CN4 87-099-032-010 CONN,15P 6216 H
CN301 87-099-720-010 CONN,30P TYK-B(P)
CN302 87-CL4-704-010 CONN ASSY 9P DECK
FB101 83-XM1-617-080 C-COIL,BK2125HM601
FFC302 8A-CL9-671-010 F-CABLE,9P 2.5
FFC4 88-915-301-110 FF-CABLE,15P 1.25
FL301 8A-CL9-682-010 FL,11-BT-179GNK
LED301 87-A40-229-040 LED,SLR-342VR TB7 RED
LED302 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED303 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED304 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED305 87-A40-619-040 LED,SLR-56PT-T31-W GRN
PR301 87-026-689-080 PROTECTOR,1A 60V 491
S301 87-A90-095-080 SW,TACT EVQ11G04M
S302 87-A90-095-080 SW,TACT EVQ11G04M
S303 87-A90-095-080 SW,TACT EVQ11G04M
S304 87-A90-095-080 SW,TACT EVQ11G04M
S305 87-A90-095-080 SW,TACT EVQ11G04M
S306 87-A90-095-080 SW,TACT EVQ11G04M
S307 87-A90-095-080 SW,TACT EVQ11G04M
S308 87-A90-095-080 SW,TACT EVQ11G04M
S309 87-A90-095-080 SW,TACT EVQ11G04M
S310 87-A90-095-080 SW,TACT EVQ11G04M
S311 87-A90-095-080 SW,TACT EVQ11G04M
S312 87-A90-095-080 SW,TACT EVQ11G04M
S313 87-A90-095-080 SW,TACT EVQ11G04M
S314 87-A90-095-080 SW,TACT EVQ11G04M
!
!
!
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 5 –
S315 87-A90-095-080 SW,TACT EVQ11G04M
S316 87-A90-095-080 SW,TACT EVQ11G04M
S317 87-A90-095-080 SW,TACT EVQ11G04M
S318 87-A90-095-080 SW,TACT EVQ11G04M
S320 87-A90-095-080 SW,TACT EVQ11G04M
S351 87-A91-690-010 SW,RTRY JOG RE0121PVB25FINB
X301 87-030-375-080 VIB,CF 4.19MG200
VCD C.B
C101 87-012-278-080 C-CAP,U 2200P-50 B
C102 87-A12-319-080 C-CAP,U 0.1-25 K B
C103 87-A12-319-080 C-CAP,U 0.1-25 K B
C104 87-A12-319-080 C-CAP,U 0.1-25 K B
C105 87-010-404-040 CAP,E 4.7-50 SME
C106 87-A11-070-080 C-CAP,U 0.033-16 K B
C107 87-012-286-080 CAP, U 0.01-25
C108 87-010-401-040 CAP,E 1-50 SME
C109 87-010-382-040 CAP,E 22-25 SME
C110 87-010-785-080 C-CAP,U0.015-25BK
C111 87-010-263-040 CAP,E 100-10
C112 87-012-286-080 CAP, U 0.01-25
C113 87-A11-070-080 C-CAP,U 0.033-16 K B
C114 87-A11-070-080 C-CAP,U 0.033-16 K B
C115 87-016-114-080 C-CAP,U 0.01-25 J B GRM
C116 87-012-269-080 C-CAP,U 390P-50 B
C117 87-012-197-080 C-CAP,U 150P-50 CH
C118 87-010-401-040 CAP,E 1-50 SME
C119 87-012-176-080 CAP 15P
C120 87-A10-504-080 C-CAP,U 0.047-16 K B
C121 87-A10-504-080 C-CAP,U 0.047-16 K B
C122 87-012-162-080 C-CAP,U 1P-50 C CH
C123 87-A12-319-080 C-CAP,U 0.1-25 K B
C125 87-010-787-080 CAP, U 0.022-25
C126 87-A12-319-080 C-CAP,U 0.1-25 K B
C127 87-010-263-040 CAP,E 100-10
C130 87-010-263-040 CAP,E 100-10
C131 87-010-263-040 CAP,E 100-10
C132 87-012-274-080 CHIP CAP,U 1000P-50B
C133 87-010-263-040 CAP,E 100-10
C134 87-010-759-080 C-CAP,U, 0.1-25F
C135 87-010-759-080 C-CAP,U, 0.1-25F
C136 87-010-759-080 C-CAP,U, 0.1-25F
C137 87-010-759-080 C-CAP,U, 0.1-25F
C138 87-012-280-080 CAP, U 3300P-50
C139 87-012-286-080 CAP, U 0.01-25
C140 87-010-112-040 CAP,E 100-16
C141 87-010-759-080 C-CAP,U, 0.1-25F
C142 87-A12-319-080 C-CAP,U 0.1-25 K B
C143 87-012-286-080 C-CAP,U 0.01-25 K B
C151 87-010-263-040 CAP,E 100-10
C152 87-012-286-080 CAP, U 0.01-25
C153 87-010-221-080 CAP,E 470-10 M SME
C154 87-012-286-080 CAP, U 0.01-25
C155 87-012-280-080 CAP, U 3300P-50
C156 87-010-757-080 C.CAP,U 0.047-25F
C157 87-010-757-080 C.CAP,U 0.047-25F
C158 87-012-199-080 CAP 220P
C159 87-A10-902-080 C-CAP,U 0.47-10 K B
C161 87-012-279-080 C-CAP,U 2700P-50 K B GRM
C162 87-012-274-080 CHIP CAP,U 1000P-50B
C201 87-010-759-080 C-CAP,U, 0.1-25F
C203 87-012-274-080 CHIP CAP,U 1000P-50B
C206 87-012-195-080 C-CAP,U 100P-50CH
C207 87-012-195-080 C-CAP,U 100P-50CH
C208 87-012-195-080 C-CAP,U 100P-50CH
C209 87-012-195-080 C-CAP,U 100P-50CH
C210 87-010-759-080 C-CAP,U, 0.1-25F
C211 87-010-263-040 CAP,E 100-10
C213 87-012-286-080 CAP, U 0.01-25
C214 87-010-759-080 C-CAP,U, 0.1-25F
C301 87-016-251-040 CAP,E 220-16 SMG
C302 87-A10-039-080 C-CAP,U 470P-50 J CH
C303 87-012-274-080 CHIP CAP,U 1000P-50B
C304 87-010-384-040 CAP,E 100-25 SME
C305 87-010-383-040 CAP,E 33-25 SME
C306 87-010-112-040 CAP,E 100-16
C307 87-010-759-080 C-CAP,U, 0.1-25F
C308 87-010-263-040 CAP,E 100-10
C309 87-010-759-080 C-CAP,U, 0.1-25F
C310 87-010-263-040 CAP,E 100-10
C311 87-010-759-080 C-CAP,U, 0.1-25F
C312 87-012-274-080 CHIP CAP,U 1000P-50B
C320 87-A10-025-080 C-CAP,U 0.22-16Z F
C321 87-A10-025-080 C-CAP,U 0.22-16Z F
C322 87-A10-025-080 C-CAP,U 0.22-16Z F
C401 87-010-759-080 C-CAP,U, 0.1-25F
C402 87-010-112-040 CAP,E 100-16
C403 87-010-759-080 C-CAP,U, 0.1-25F
C404 87-010-759-080 C-CAP,U, 0.1-25F
C433 87-010-759-080 C-CAP,U, 0.1-25F
C434 87-012-286-080 CAP, U 0.01-25
C435 87-010-263-040 CAP,E 100-10
C501 87-012-286-080 CAP, U 0.01-25
C502 87-012-286-080 CAP, U 0.01-25
C503 87-012-286-080 CAP, U 0.01-25
C504 87-012-172-080 CAPACITOR CHIP U 10P CH
C505 87-012-172-080 CAPACITOR CHIP U 10P CH
C506 87-012-286-080 CAP, U 0.01-25
C508 87-010-263-040 CAP,E 100-10
C509 87-010-759-080 C-CAP,U, 0.1-25F
C510 87-010-263-040 CAP,E 100-10
C511 87-010-759-080 C-CAP,U, 0.1-25F
C512 87-012-286-080 CAP, U 0.01-25
C513 87-012-286-080 CAP, U 0.01-25
C514 87-012-286-080 CAP, U 0.01-25
C517 87-012-168-080 C-CAP,U 6P-50 CH
C518 87-012-195-080 C-CAP,U 100P-50CH
C519 87-012-335-080 C-CAP,U 270P-50 SL
C520 87-012-336-080 CAP, CHIP SS 3300 SL
C521 87-012-197-080 C-CAP,U 150P-50 CH
C523 87-012-286-080 CAP, U 0.01-25
C524 87-012-286-080 CAP, U 0.01-25
C525 87-012-286-080 CAP, U 0.01-25
C526 87-012-286-080 CAP, U 0.01-25
C527 87-012-286-080 CAP, U 0.01-25
C528 87-012-286-080 CAP, U 0.01-25
C529 87-012-286-080 CAP, U 0.01-25
C530 87-012-286-080 CAP, U 0.01-25
C531 87-012-286-080 CAP, U 0.01-25
C532 87-010-374-040 CAP,E 47-10
C533 87-012-286-080 CAP, U 0.01-25
C534 87-010-263-040 CAP,E 100-10
C535 87-012-286-080 CAP, U 0.01-25
C536 87-010-374-040 CAP,E 47-10
C537 87-012-286-080 CAP, U 0.01-25
C538 87-010-759-080 C-CAP,U, 0.1-25F
C539 87-010-759-080 C-CAP,U, 0.1-25F
C540 87-010-374-040 CAP,E 47-10
C541 87-012-286-080 CAP, U 0.01-25
C542 87-012-195-080 C-CAP,U 100P-50CH
C543 87-012-274-080 CHIP CAP,U 1000P-50B
C544 87-012-286-080 CAP, U 0.01-25
C546 87-012-286-080 CAP, U 0.01-25
C547 87-012-199-080 CAP 220P
C548 87-012-195-080 C-CAP,U 100P-50CH
C549 87-012-199-080 CAP 220P
C550 87-010-759-080 C-CAP,U, 0.1-25F
C551 87-012-195-080 C-CAP,U 100P-50CH
C555 87-012-336-080 CAP, CHIP SS 3300 SL
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 6 –
C560 87-012-195-080 C-CAP,U 100P-50CH
C561 87-012-195-080 C-CAP,U 100P-50CH
C563 87-010-759-080 C-CAP,U, 0.1-25F
C564 87-012-197-080 C-CAP,U 150P-50 CH
C565 87-012-196-080 C-CAP,U 120P-50 CH
C567 87-012-196-080 C-CAP,U 120P-50 CH
C620 87-012-178-080 C-CAP,U 18P-50 CH
C621 87-012-178-080 C-CAP,U 18P-50 CH
C622 87-A10-025-080 C-CAP,U 0.22-16Z F
C624 87-012-191-080 CHIP CAP 68 PF
C625 87-012-274-080 CHIP CAP,U 1000P-50B
C626 87-A10-025-080 C-CAP,U 0.22-16Z F
C631 87-010-759-080 C-CAP,U, 0.1-25F
C637 87-010-759-080 C-CAP,U, 0.1-25F
C638 87-010-784-080 C-CAP,U 0.012-25 B
C639 87-012-197-080 C-CAP,U 150P-50 CH
C640 87-012-180-080 C-CAP,U 22P-50 CH
C641 87-010-759-080 C-CAP,U, 0.1-25F
C651 87-010-757-080 C.CAP,U 0.047-25F
C671 87-010-073-040 CAP,E 3.3-50 5L
C672 87-010-073-040 CAP,E 3.3-50 5L
C673 87-012-274-080 CHIP CAP,U 1000P-50B
C674 87-012-274-080 CHIP CAP,U 1000P-50B
C675 87-012-274-080 CHIP CAP,U 1000P-50B
C676 87-012-274-080 CHIP CAP,U 1000P-50B
C681 87-010-759-080 C-CAP,U, 0.1-25F
C682 87-A10-025-080 C-CAP,U 0.22-16Z F
C700 87-010-759-080 C-CAP,U, 0.1-25F
C702 87-010-759-080 C-CAP,U, 0.1-25F
C722 87-010-371-040 CAP,E 470-6.3
C749 87-010-401-040 CAP,E 1-50 SME
C751 87-012-196-080 C-CAP,U 120P-50 CH
C752 87-A10-463-080 C-CAP,U 0.47-10 Z F
C754 87-012-286-080 CAP, U 0.01-25
C756 87-012-286-080 CAP, U 0.01-25
C757 87-012-182-080 C-CAP,U 27P-50 CH
C758 87-012-182-080 C-CAP,U 27P-50 CH
CN101 87-A60-429-010 CONN,16P H TOC-A
CN102 87-A60-131-010 CONN,6P V FE
CN401 87-099-210-010 CONN,5P 6216 H
CN403 87-099-032-010 CONN,15P 6216 H
FB501 83-XM1-617-080 C-COIL,BK2125HM601
FB901 83-XM1-617-080 C-COIL,BK2125HM601
FB904 83-XM1-617-080 C-COIL,BK2125HM601
FB906 83-XM1-617-080 C-COIL,BK2125HM601
FB907 83-XM1-617-080 C-COIL,BK2125HM601
FB909 83-XM1-617-080 C-COIL,BK2125HM601
FFC101 88-CL4-704-010 FF-CABLE, 16P 1.0
FFC102 88-906-131-110 FF-CABLE,6P 1.25
FFC401 88-905-151-210 FF-CABLE,5P 1.25 150MM
J501 87-A61-472-010 JACK,PIN 1P YELLOW
L101 87-005-196-080 COIL,10UH
L301 87-A50-095-010 COIL,68UH RCR875D
L302 87-005-426-080 COIL,3.3UH K FLR50
L502 87-005-204-080 COIL,47UH
L503 87-005-189-080 COIL 2.7UH
L504 87-005-187-080 COIL,1.8UH
L505 87-005-204-080 COIL,47UH
L506 87-005-204-080 COIL,47UH
L507 87-005-204-080 COIL,47UH
PR301 87-A90-757-080 PROTECTOR,0.75A 60V 491
R130 87-022-237-080 C-RES,U 8.2K-1/16W F
R131 87-022-237-080 C-RES,U 8.2K-1/16W F
R132 87-022-237-080 C-RES,U 8.2K-1/16W F
R133 87-022-237-080 C-RES,U 8.2K-1/16W F
R134 87-022-237-080 C-RES,U 8.2K-1/16W F
R135 87-022-237-080 C-RES,U 8.2K-1/16W F
R184 87-022-237-080 C-RES,U 8.2K-1/16W F
R185 87-022-237-080 C-RES,U 8.2K-1/16W F
R186 87-022-237-080 C-RES,U 8.2K-1/16W F
R187 87-022-237-080 C-RES,U 8.2K-1/16W F
R190 87-022-221-080 C-RES,U 1.8K-1/16W F
R191 87-022-221-080 C-RES,U 1.8K-1/16W F
R193 87-022-221-080 C-RES,U 1.8K-1/16W F
R194 87-022-221-080 C-RES,U 1.8K-1/16W F
R507 87-022-222-080 C-RES,U 2.0K-1/16W F
S201 87-A90-300-010 SW,SL SSAA 1-3 B
X201 87-A70-124-080 VIB,CER 8.0MHZ
X501 87-A70-125-080 VIB,XTAL 27MHZ 50PPM
X601 87-030-270-080 VIB,XTAL 16.9344MHZ
RELAY C.B
CN301 88-CL4-701-010 CONN ASSY,7P RPEH
DECK C.B
CN1 87-009-352-010 CONN,9P PH H
CRD1 82-ZM1-625-010 RBN-CORD,4P-55
M1 87-045-347-010 MOT,SHU2L 70
SFR1 87-024-581-010 SFR,3.3K DIA6V K0A
SOL1 82-ZM3-627-010 SOL ASSY,27 SO
SW2 87-036-110-010 PUSH SWITCH
SW3 87-036-110-010 PUSH SWITCH
SW4 87-036-110-010 PUSH SWITCH
SW5 87-036-110-010 PUSH SWITCH
SW6 87-A90-248-010 SW,MICRO ESE11SH2CXQ
CD LOAD C.B
CN1 87-099-210-010 CONN,5P 6216 H
M1 87-045-305-010 MOTOR, RF-500TB DC-5V (2MA)
SW1 87-036-110-010 PUSH SWITCH
SW2 87-036-110-010 PUSH SWITCH
CD DRIVE C.B
M20 87-045-358-010 MOT,RF-310TA 43
M21 87-045-356-010 MOT,RF-310TA 30
PIN3 87-A60-086-010 CONN,6P H 6216
SW1 87-A90-042-010 SW,LEAF MSW-17310MVP0
!
TRANSISTOR ILLUSTRATION
DTA124XKA
DTC124XKA
DTC144TKA
DTC114TKA
DTC114EKA
– 7 –
B
C
E
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
WIRING – 1 (MAIN)
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
– 8 –
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
SCHEMATIC DIAGRAM 1 (MAIN / RELAY)
9
WIRING – 2 (FRONT)
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
– 10 –
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
SCHEMATIC DIAGRAM 2 (FRONT / DECK)
11
WIRING – 3 (VCD)
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
– 12 –
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
13
SCHEMATIC DIAGRAM 3 (VCD 1/2 / CD LOAD / CD DRIVER)
14
SCHEMATIC DIAGRAM 4 (VCD 2/2)
MECHANICAL EXPLODED VIEW 1 / 1
– 15 –
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
MECHANICAL PARTS LIST 1 / 1
– 16 –
!
1 82-ZM1-264-010 LVR,EJECT R
2 88-CL4-215-010 CUSH,FOOT FR
3 8A-CG9-046-010 BOX,CASS MK111
4 8A-CL9-052-010 WINDOW,CASS
5 8A-CL9-080-010 KNOB,RTRY VOLUME
6 8A-CG9-051-010 WINDOW,DISP SK V
7 8A-CL9-077-010 RING,VOLUME
8 8A-CL9-088-110 LENS,REMOTE-C
9 8A-CG9-030-010 PANEL,TRAY SK A
10 8A-CL9-062-010 KEY,POWER
11 8A-CG9-001-010 CABI,FR SI-MS
12 8A-CL9-063-010 KEY,FUNC ASSY
13 8A-CL9-206-010 GUIDE,LED-FUNC
14 8A-CL9-085-010 REFLECTOR,LED-FUNC
15 8A-CL9-066-010 KEY,CONTROL
16 8A-CL9-065-010 KEY,OPEN
17 8A-CL9-067-010 KEY,Q-SOUND
18 8A-CL9-068-010 KEY,JOGMODE
19 8A-CL9-069-110 KEY,DEMO
20 82-NF5-229-010 PLATE,LOCK
21 86-NF9-224-010 SPR-C,LOCK
22 87-NF4-217-110 HLDR,LOCK 2
23 87-NF8-220-010 DMPR,150
24 88-CL4-220-010 SPR-T,CASS
25 82-NF7-210-110 GUIDE,FL(*)
26 8A-CL9-202-010 HLDR,CD
27 87-A80-083-010 AC CORD,HC BLK
28 8A-CL9-026-010 CABI,TOP
29 8A-CL9-211-110 HLDR,TRANS
30 8A-CG9-012-010 PANEL,REAR H
31 88-CL4-216-010 CUSH,FOOT REAR
32 8A-MA6-203-010 PLATE,FL
A 87-067-703-010 TAPPING SCREW, BVT2+3-10
B 87-B10-250-010 BVT2+3-12 W/O SLOT CR SILVER
C 87-581-170-410 UIT+4-8
D 87-B10-231-010 QT1+3-12 SILVER CR
E 87-B10-230-010 BVT2+3-10 W/O SLOT SILVER CR
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
LA Aqua Blue GL Light Green
TAPE MECHANISM EXPLODED VIEW 1 / 1
– 17 –
F
D
I
C
A
E
G
A
1
B
HLDR, IC
PWB
PWB
HLDR, MOTOR
PLATE, SHLD
M3
SH, 1.63-3.2
-0.5 SLT
MOTOR
2
3
4
37 5
6
7
8
9
10
11
12
13
14
15
5
17
18 19
20
21
22
24
25
23
27
16
26
28
29
30
31
33
35
36
34 31
38
39
40 41
42
43
44
45
32
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
TAPE MECHANISM PARTS LIST 1 / 1
– 18 –
1 82-ZM1-247-210 PULLEY,MOTOR
2 82-ZM1-354-010 BELT,SBU MAIN2 EPDM
3 82-ZM1-234-310 FLY-WHL ASSY,L
4 82-ZM1-226-010 GEAR,REW
5 82-ZM1-216-510 GEAR,REEL
6 82-ZM1-221-310 GEAR,CAM(*)
7 82-ZM1-237-610 FLY-WHL ASSY,R
8 82-ZM1-225-210 GEAR,FR
9 82-ZM1-224-410 LVR,FR
10 82-ZM3-333-310 SLIP DISK ASSY 2
11 82-ZM1-223-010 GEAR,PLAY
12 82-ZM1-220-210 GEAR,IDLER
13 82-ZM3-616-010 RING MAGNET 4
14 82-ZM1-227-310 LVR,TRIG
15 82-ZM1-305-210 SPR-E,TRIG 2
16 82-ZM1-255-310 SPR-E,LVR DIR
17 82-ZM1-322-010 SPR-T,FR 60
18 82-ZM1-358-010 CHAS ASSY,FPC
19 82-ZM3-627-010 SOL ASSY,27 SO
20 82-ZM1-341-210 LVR ASSY,PINCH L2
21 82-ZM1-258-210 SPR-T,PINCH L
22 82-ZM1-333-210 PLATE,LINK2
23 82-ZM1-244-510 SPR-C,BT
24 82-ZM1-266-310 LVR,DIR
25 82-ZM1-214-010 SPR-T,DIR
26 82-ZM1-269-210 SPR-T,BRG
27 82-ZM1-217-410 REEL TABLE
28 82-ZM1-206-910 CHAS,HEAD
29 82-ZM1-219-110 SPR-T,LINK
30 82-ZM1-218-010 SPR-E,HB
31 82-ZM1-240-110 LVR,REC(*)
32 82-ZM1-259-210 SPR-T,PINCH R
33 82-ZM1-257-010 SPR-T,CAS
34 82-ZM1-285-410 SPR-C,BT L
35 82-ZM1-242-010 LVR,CAS
36 82-ZM1-243-010 LVR,STOP
37 82-ZM1-338-110 BELT,FR 4
38 82-ZM3-353-010 SPR-T,HEAD 2
39 82-ZM1-207-910 GUIDE,TAPE
40 82-ZM1-314-110 PLATE,HEAD
41 82-ZM1-208-310 HLDR,HEAD
42 87-A90-367-110 HEAD,RPH YK56R-BF414
43 82-ZM1-210-110 GEAR,H T
44 82-ZM1-222-310 LVR,PLAY(*)
45 82-ZM1-344-210 LVR ASSY,PINCH R2
A 87-251-070-410 U+2.6-3
B 87-741-073-410 UT2+2.6-6 GLD
C 87-B10-008-010 W-P,2.08-8-0.4-SLIP
D 80-ZM6-243-010 SH 1.75-3.6-0.5 SLT
E 82-ZM3-334-010 PW 2.16-6-0.4
F 86-ZM4-206-110 S-SCREW,AZIMUTH L
G 85-ZM3-202-010 S-SCREW,TG
H 82-ZM3-222-010 S-SCREW,SHILD PLATE
I 80-ZM6-207-010 V+1.6-7
CD MECHANISM EXPLODED VIEW 1 / 2
– 19 –
a
b
c
a
b
c
3
PWB
2
4
5
6
7
8
9
10
11
12
16
14
15
13
1
17
17
CUSH-G,
MAIN A
B
C
C
D
D
A
CUSH-G,
MAIN A
3ZG-2 E3
KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
CD MECHANISM PARTS LIST 1 / 2
– 20 –
1 83-ZG3-224-510 HLDR M2
2 83-ZG3-228-610 CHAS,L6
3 83-ZG3-208-010 PULLEY,MOTOR
4 83-ZG3-213-010 LVR,SW
5 83-ZG3-209-610 CAM,SLIDE
6 83-ZG3-207-010 GEAR,TRAY
7 83-ZG3-204-210 GEAR,C
8 83-ZG3-205-010 GEAR,D
9 83-ZG3-217-010 S-SCREW,GEAR D
10 83-ZG3-220-210 GEAR,PULLEY 2
11 83-ZG3-214-010 BELT,L
12 83-ZG3-229-410 TRAY,CD 2
13 83-ZG3-210-110 HLDR,CHUCK
14 83-ZG3-602-010 RING,MAG
15 83-ZG3-212-010 CAP,DISC
16 83-ZG3-211-010 PLATE,DISC
17 81-ZG1-254-010 S-SCREW,MECH HLDR
A 87-067-945-110 VFT2+3-12(F10)
B 87-251-071-410 U+2.6-4
C 87-512-074-210 SCREW, 2+2.6-8
D 87-352-075-210 VT2+2.6-10
Other manuals for XR-MK111
2
Table of contents
Other Aiwa CD Player manuals
