SERVICE MANUAL
DATA
CSD-FD91
U
• BASIC TAPE MECHANISM:TN-51RV-240
• BASIC CD MECHANISM: CMS-B31TG6
S/M Code No. 09-001-426-8T1
SIMPLE
•Replace this Service Manual with “Revision Publishing” when it is issued.
COMPACT DISC STEREO RADIO
CASSETTE RECORDER
ELECTRICAL PARTS LIST - 1/5
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 607 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 604 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 601 87-010-313-080 CAP, CHIP 18P A...................
C 602 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 605 87-010-317-080 C-CAP,S 39P-50 CH A...................
C 603 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 614 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 611 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 615 87-010-493-040 CAP,E 0.47-50 GAS A...................
C 616 87-010-494-040 CAP,E 1-50 GAS A...................
C 613 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 610 87-010-555-040 CAP,E 100-10 GAS A...................
C 612 87-A10-189-040 CAP,E 220-10 A...................
C 625 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 620 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
D 601 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 602 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 611 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 612 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 623 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 627 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 601 8A-CH4-661-010 C-IC,LC867132V-**** A...................
L 601 87-003-171-010 COIL,15UH TROIDAL A...................
LCD 601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4 A...................
LED 607 88-CD6-630-010 LED,934ID RED A...................
LED 606 88-CD6-630-010 LED,934ID RED A...................
LED 604 88-CD6-630-010 LED,934ID RED A...................
LED 602 88-CD6-630-010 LED,934ID RED A...................
LED 603 88-CD6-630-010 LED,934ID RED A...................
LED 612 88-CD6-630-010 LED,934ID RED A...................
LED 610 88-CD6-630-010 LED,934ID RED A...................
LED 611 88-CD6-631-010 LED,934GD GRN A...................
Q 601 87-026-291-080 TR,DTC124XS A...................
Q 603 87-026-291-080 TR,DTC124XS A...................
Q 602 87-026-463-080 TR,2SA933S (0.3W) A...................
Q 607 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 608 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 609 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 606 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 605 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 604 87-026-464-080 TR,DTC114TS (0.3W) A...................
Q 610 87-026-464-080 TR,DTC114TS (0.3W) A...................
S 609 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 608 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 603 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 601 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 605 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 607 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 604 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 606 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 614 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 615 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 622 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 621 87-A91-704-080 SW,TACT EVQ 214 05R A...................
S 623 87-A91-704-080 SW,TACT EVQ 214 05R A...................
X 601 87-030-273-010 VIB,XTAL 32.768K5PPM A...................
X 602 87-030-376-080 VIB,CER CSA5.76MG200 A...................
C 276 87-016-280-080 CAP,E 3.3-50 M BP SME A...................
C 275 87-016-280-080 CAP,E 3.3-50 M BP SME A...................
CN 205 8A-CH4-686-010 CONN,2P V 2.5 A...................
CN 206 8A-CH4-686-010 CONN,2P V 2.5 A...................
CN 204 8A-CH4-687-010 CONN,4P V 2.5 A...................
CNA 203 8A-CD9-628-010 CONN ASSY,3P MA-HP A...................
CNA 204 8A-CH4-633-010 CONN ASSY,4P SP A...................
J 251 87-A60-569-010 JACK,HTJ-035-18 A...................
C 902 87-018-205-080 CAP, CERA-SOL 0.022 A...................
C 904 87-018-205-080 CAP, CERA-SOL 0.022 A...................
C 903 87-018-205-080 CAP, CERA-SOL 0.022 A...................
C 901 87-018-205-080 CAP, CERA-SOL 0.022 A...................
CNA 901 8A-CD9-627-010 CONN ASSY,3P PWR A...................
D 904 87-A40-465-010 DIODE,FR202 A...................
D 901 87-A40-465-010 DIODE,FR202 A...................
D 903 87-A40-465-010 DIODE,FR202 A...................
D 902 87-A40-465-010 DIODE,FR202 A...................
CN 601 87-099-033-010 16P 6216 H A...................
CN 602 87-099-201-010 CONN,8P 6216 H A...................
CN 605 87-A60-109-010 CONN,2P V S2M-2W A...................
CNA 603 8A-CD9-624-010 CONN ASSY,4P TU-FR A...................
CNA 604 8A-CH4-623-010 CONN ASSY,2P KEY A...................
C 211 87-010-805-080 CAP, S 1-16 A...................
C 212 87-010-805-080 CAP, S 1-16 A...................
C 215 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 216 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 239 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 231 87-010-213-080 C-CAP,S 0.015-50 B A...................
ELECTRICAL PARTS LIST - 2/5
C 232 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 237 87-010-408-080 CAP, ELECT 47-50V A...................
C 236 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 235 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 233 87-A10-201-080 C-CAP,S0.33-16 KB A...................
C 234 87-A10-201-080 C-CAP,S0.33-16 KB A...................
C 240 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 247 87-010-401-080 CAP, ELECT 1-50V A...................
C 248 87-010-401-080 CAP, ELECT 1-50V A...................
C 310 87-010-248-080 CAP, ELECT 220-10V A...................
C 483 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 484 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 819 87-010-426-080 C-CAP,S 0.012-25 B A...................
C 820 87-010-426-080 C-CAP,S 0.012-25 B A...................
D 310 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 203 87-A21-520-040 C-IC,M61509FP A...................
C 268 87-010-112-080 CAP, ELECT 100-16V A...................
C 267 87-010-112-080 CAP, ELECT 100-16V A...................
C 264 87-010-178-080 CHIP CAP 1000P A...................
C 263 87-010-178-080 CHIP CAP 1000P A...................
C 265 87-010-263-080 CAP, ELECT 100-10V A...................
C 266 87-010-263-080 CAP, ELECT 100-10V A...................
C 262 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 261 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 271 87-010-237-080 CAP, ELECT 1000-16V A...................
C 272 87-010-237-080 CAP, ELECT 1000-16V A...................
C 279 87-010-385-080 CAP, ELECT 220-25V A...................
C 278 87-010-405-080 CAP, ELECT 10-50V A...................
CN 202 8A-CH4-689-010 CONN,3P V 2.5 A...................
IC 202 87-A21-064-010 IC,LA4227 A...................
C 308 87-010-221-080 CAP, ELECT 470-10V A...................
C 307 87-010-401-080 CAP, ELECT 1-50V A...................
C 306 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 301 87-016-495-000 CAP,E 3300-25 M SMG A...................
C 311 87-010-374-080 CAP, ELECT 47-10V A...................
C 312 87-010-385-080 CAP, ELECT 220-25V A...................
C 325 87-010-405-080 CAP, ELECT 10-50V A...................
CN 301 8A-CH4-689-010 CONN,3P V 2.5 A...................
D 305 87-070-345-080 DIODE,IN4148 A...................
D 306 87-070-345-080 DIODE,IN4148 A...................
D 303 87-070-345-080 DIODE,IN4148 A...................
D 304 87-A40-648-080 ZENER,MTZJ8.2A A...................
D 311 87-027-702-080 DIODE,ZENER HZ6C2L (200MA) A...................
Q 303 87-026-291-080 TR,DTC124XS A...................
Q 305 87-026-462-080 TR,2SC1740 S(RS 0.3W) A...................
Q 302 87-026-463-080 TR,2SA933S (0.3W) A...................
Q 301 89-112-965-080 TR,2SA1296 (0.75W) A...................
Q 304 89-213-702-080 TR,2SB1370E A...................
Q 310 89-318-154-080 TR,2SC1815 (0.4W) A...................
C 30 87-010-260-080 CAP, ELECT 47-25V A...................
C 801 87-010-248-080 CAP, ELECT 220-10V A...................
C 807 87-010-405-080 CAP, ELECT 10-50V A...................
C 808 87-010-405-080 CAP, ELECT 10-50V A...................
C 809 87-010-405-080 CAP, ELECT 10-50V A...................
C 805 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 806 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 811 87-010-178-080 CHIP CAP 1000P A...................
C 812 87-010-178-080 CHIP CAP 1000P A...................
C 817 87-010-180-080 C-CER 1500P A...................
C 816 87-010-180-080 C-CER 1500P A...................
C 810 87-010-405-080 CAP, ELECT 10-50V A...................
C 824 87-010-175-080 CAP 560P A...................
C 823 87-010-175-080 CAP 560P A...................
C 829 87-010-178-080 CHIP CAP 1000P A...................
C 821 87-010-401-080 CAP, ELECT 1-50V A...................
C 822 87-010-401-080 CAP, ELECT 1-50V A...................
C 830 87-010-178-080 CHIP CAP 1000P A...................
C 831 87-010-198-080 CAP, CHIP 0.022 A...................
C 834 87-010-248-080 CAP, ELECT 220-10V A...................
C 836 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 835 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 833 87-018-195-080 CAP, CER 1200P-16V A...................
C 845 87-010-178-080 CHIP CAP 1000P A...................
C 843 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 846 87-010-263-080 CAP, ELECT 100-10V A...................
C 844 87-018-124-080 CAP, CER 270P-50V A...................
C 852 87-010-178-080 CHIP CAP 1000P A...................
C 851 87-010-186-080 CAP,CHIP 4700P A...................
C 853 87-018-211-080 CAP, CER 0.01-50 A...................
CN 801 87-A60-110-010 CONN,4P V S2M-4W A...................
CN 802 8A-CH4-688-010 CONN,6P V 2.5 A...................
D 308 87-017-978-080 DIODE,1N4003 A...................
D 309 87-070-345-080 DIODE,IN4148 A...................
D 809 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 808 87-070-345-080 DIODE,IN4148 A...................
D 807 87-070-345-080 DIODE,IN4148 A...................
D 810 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 801 87-A21-431-010 IC,BA4560N A...................
L 801 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 801 89-318-154-080 TR,2SC1815 (0.4W) A...................
Q 810 87-026-464-080 TR,DTC114TS (0.3W) A...................
R 840 87-029-124-010 RES,FUSE 2.2-1/4 A...................
ELECTRICAL PARTS LIST - 3/5
SW 801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01 A...................
C 321 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 322 87-010-263-080 CAP, ELECT 100-10V A...................
CN 201 87-099-018-010 CONN,16P A...................
CN 302 8A-CD9-629-010 CONN ASSY,6P MA-TU A...................
D 32 87-027-399-080 ZENER,HZ7A3L (200MA) A...................
D 333 87-070-345-080 DIODE,IN4148 A...................
Q 321 89-318-154-080 TR,2SC1815 (0.4W) A...................
Q 841 87-026-291-080 TR,DTC124XS A...................
C 407 87-010-178-080 CHIP CAP 1000P A...................
C 405 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 402 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 408 87-010-198-080 CAP, CHIP 0.022 A...................
C 404 87-010-248-080 CAP, ELECT 220-10V A...................
C 409 87-010-248-080 CAP, ELECT 220-10V A...................
C 403 87-010-263-080 CAP, ELECT 100-10V A...................
C 406 87-010-374-080 CAP, ELECT 47-10V A...................
C 401 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 418 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 410 87-010-263-080 CAP, ELECT 100-10V A...................
C 412 87-010-401-080 CAP, ELECT 1-50V A...................
C 414 87-010-405-080 CAP, ELECT 10-50V A...................
C 416 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 417 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 413 87-016-369-080 C-CAP,S 0.033-25 B K A...................
C 411 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 419 87-A11-608-080 C-CAP,S 0.33-25 K B A...................
C 425 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 422 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 429 87-010-186-080 CAP,CHIP 4700P A...................
C 428 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 423 87-010-956-080 CHIP-CAP,S 0.068-25B A...................
C 424 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 420 87-016-369-080 C-CAP,S 0.033-25 B K A...................
C 421 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 426 87-A11-608-080 C-CAP,S 0.33-25 K B A...................
C 439 87-010-178-080 CHIP CAP 1000P A...................
C 434 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 435 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 436 87-010-374-080 CAP, ELECT 47-10V A...................
C 432 87-010-374-080 CAP, ELECT 47-10V A...................
C 433 87-010-401-080 CAP, ELECT 1-50V A...................
C 437 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 431 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 430 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 438 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 441 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 442 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 448 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 445 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 447 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 446 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 455 87-010-247-080 CAP, ELECT 100-50V A...................
C 459 87-010-263-080 CAP, ELECT 100-10V A...................
C 458 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 457 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 450 87-012-140-080 CAP 470P A...................
C 451 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 463 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 461 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 462 87-010-248-080 CAP, ELECT 220-10V A...................
C 467 87-010-263-080 CAP, ELECT 100-10V A...................
C 465 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 469 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 466 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 460 87-015-819-080 CAPACITOR,0.01 A...................
C 475 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 479 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 477 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 476 87-010-236-080 CAP,E 1000-10 SME A...................
C 478 87-010-263-080 CAP, ELECT 100-10V A...................
C 470 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
C 474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
C 473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
C 471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
C 480 87-010-221-080 CAP, ELECT 470-10V A...................
C 481 87-010-405-080 CAP, ELECT 10-50V A...................
C 482 87-010-405-080 CAP, ELECT 10-50V A...................
C 489 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 494 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 490 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 495 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 503 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 505 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 504 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 501 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 510 87-016-669-080 C-CAP,S 0.1-25 K B A...................
CN 205 87-A60-109-010 CONN,2P V S2M-2W A...................
CN 403 87-099-201-010 CONN,8P 6216 H A...................
ELECTRICAL PARTS LIST - 4/5
CN 401 87-A60-424-010 CONN,16P V TOC-B A...................
CNA 402 8A-CD9-625-010 CONN ASSY,6P CD-ME A...................
D 403 87-070-345-080 DIODE,IN4148 A...................
D 402 87-070-345-080 DIODE,IN4148 A...................
D 401 87-070-345-080 DIODE,IN4148 A...................
IC 401 87-A20-446-010 C-IC,LA9241ML A...................
IC 402 87-A20-459-010 C-IC,LC78622ED A...................
IC 404 87-A21-093-010 IC,LA6541D A...................
L 401 87-003-102-080 COIL, 10UH A...................
L 404 87-003-152-080 COIL, 100UH A...................
Q 404 87-026-295-080 TR,DTC144TK A...................
Q 405 87-026-295-080 TR,DTC144TK A...................
Q 403 87-026-295-080 TR,DTC144TK A...................
Q 401 89-109-332-380 TR,2SA933RS A...................
Q 402 89-113-187-080 TR,2SA1318TU A...................
X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 A...................
C 491 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 492 87-010-221-080 CAP, ELECT 470-10V A...................
D 491 87-070-345-080 DIODE,IN4148 A...................
D 494 87-070-345-080 DIODE,IN4148 A...................
Q 492 87-026-291-080 TR,DTC124XS A...................
Q 491 89-112-965-080 TR,2SA1296 (0.75W) A...................
C 6 87-010-313-080 CAP, CHIP 18P A...................
C 1 87-010-314-080 C-CAP,S 22P-50V A...................
C 3 87-010-314-080 C-CAP,S 22P-50V A...................
C 2 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 8 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 7 87-014-049-080 CAP,PP 470P-100 J A...................
C 5 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 13 87-010-150-080 C-CAP,S 6P-50 CH A...................
C 15 87-010-178-080 CHIP CAP 1000P A...................
C 11 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 10 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 12 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 17 87-010-198-080 CAP, CHIP 0.022 A...................
C 19 87-010-263-080 CAP, ELECT 100-10V A...................
C 14 87-010-303-080 C-CAP,S 330P-50CH A...................
C 16 87-010-374-080 CAP, ELECT 47-10V A...................
C 18 87-015-835-080 C-CAP,0.047 D A...................
C 22 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 23 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 21 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 24 87-010-303-080 C-CAP,S 330P-50CH A...................
C 20 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 25 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 29 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 28 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 27 87-A11-067-080 C-CAP,S 1-10 K B A...................
C 37 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 31 87-010-198-080 CAP, CHIP 0.022 A...................
C 30 87-010-198-080 CAP, CHIP 0.022 A...................
C 36 87-010-263-080 CAP, ELECT 100-10V A...................
C 38 87-010-374-080 CAP, ELECT 47-10V A...................
C 39 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 33 87-012-358-080 C-CAP,S 0.47-10 F Z A...................
C 34 87-012-358-080 C-CAP,S 0.47-10 F Z A...................
C 35 87-015-819-080 CAPACITOR,0.01 A...................
C 43 87-010-178-080 CHIP CAP 1000P A...................
C 41 87-010-178-080 CHIP CAP 1000P A...................
C 42 87-010-178-080 CHIP CAP 1000P A...................
C 40 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 48 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 47 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 46 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 44 87-010-311-080 CAP 12P A...................
C 45 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 49 87-012-140-080 CAP 470P A...................
C 50 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 71 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 75 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 73 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 72 87-010-263-080 CAP, ELECT 100-10V A...................
C 93 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 92 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 91 87-012-140-080 CAP 470P A...................
CF 3 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 2 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 1 87-A91-094-010 FLTR,CDA10.7 MG80A A...................
CN 2 87-099-854-010 CONN,6P S2M-6W A...................
CN 3 87-A60-110-010 CONN,4P V S2M-4W A...................
D 6 87-017-072-080 ZENER,HZS3B1 A...................
D 1 87-070-345-080 DIODE,IN4148 A...................
D 2 87-070-345-080 DIODE,IN4148 A...................
D 4 87-A40-128-080 C-VARI-CAP,HVU202A A...................
D 5 87-A40-128-080 C-VARI-CAP,HVU202A A...................
D 3 87-A40-616-070 VARI-CAP,SVC384(S/T) A...................
HD 1 88-CD6-661-010 HLDR,BAR ANT. A...................
HD 2 88-CD6-661-010 HLDR,BAR ANT. A...................
IC 2 87-A21-185-040 C-IC,LC72121M A...................
IC 1 87-A21-550-010 IC,TA2149N A...................
L 8 87-005-849-080 COIL,10UH(CECS) A...................
L 4 87-A50-420-010 COIL,MW OSC(SYN) A...................
ELECTRICAL PARTS LIST - 5/5
L 2 87-A50-560-010 COIL,FM BPF(ACD) A...................
L 5 87-A50-566-010 COIL,FM RF EX(ACH) A...................
L 6 87-A50-567-010 COIL,FM OSC(ACH) A...................
L 7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK) A...................
L 3 8A-CH4-670-010 BAR-ANT,MW 2B-ACH(COI) A...................
Q 4 87-026-213-080 CHIP-TR,DTC114YK A...................
Q 2 87-026-447-080 TR,2SC1740S R A...................
Q 3 89-111-624-080 TR,2SA1162Y A...................
Q 1 89-327-143-080 TR,2SC2714 (0.1W) A...................
Q 71 89-327-125-080 CHIP TR,2SC2712GR A...................
TC 1 87-011-254-080 TRIMER,20P LAR A...................
X 1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-B00-010-010 BADGE,AIWA 30.5-5.2 S 2.5L A...................
88-CH6-019-010 PANEL,CD A...................
8A-CH4-001-010 CABI,FR A...................
8A-CH4-002-010 CABI,REAR A...................
8A-CH4-007-010 BOX,CASS A...................
8A-CH4-011-010 LID,BATT A...................
8A-CH4-012-010 PANEL,TW L A...................
8A-CH4-013-010 PANEL,TW R A...................
8A-CH4-014-010 GRILLE,FR L A...................
8A-CH4-015-010 GRILLE,FR R A...................
8A-CH4-016-010 GRILLE,TW L A...................
8A-CH4-017-010 GRILLE,TW R A...................
8A-CHE-004-010 CHAS,CD 8K E A...................
8A-CHE-009-010 PANEL,LCD E A...................
8A-CHE-018-010 HANDL,GRIP E A...................
8A-CHE-019-010 COVER, HANDL E A...................
8A-CHE-126-010 WINDOW,CASS RV E A...................
8A-CHR-010-010 WINDOW,LCD R A...................
8A-CHR-121-010 BOX,CD U R A...................
8A-CH4-022-010 BTN,PLAY A...................
8A-CH4-023-010 BTN,SKIP A...................
8A-CH4-024-010 BTN,EQ A...................
8A-CH4-025-010 BTN,FUNC A...................
8A-CH4-027-010 BTN,BASS A...................
8A-CH4-028-010 BTN,SOUND A...................
8A-CH4-029-010 CAP, PLAY A...................
8A-CH4-030-010 CAP, STOP A...................
8A-CH4-031-010 CAP, FF A...................
8A-CH4-032-010 CAP, REW A...................
8A-CH4-033-010 CAP, REPEAT A...................
8A-CH4-034-010 LENS,FUNC A...................
8A-CHE-021-010 KEY,CASS 8K E A...................
8A-CHE-026-010 BTN,VOL E A...................
87-CD6-041-010 PLATE,AC A...................
8A-CHR-053-010 PLATE,SPEC U R A...................
84-CD5-215-010 GEAR A...................
84-CD5-216-010 BRACKET A...................
84-CD5-217-010 PLATE,MAGNET A...................
85-CD7-217-010 HLDR,CHUCK A A...................
86-CT4-218-010 CUSHION,FOOT/PORON A...................
87-036-368-010 MAGNET A...................
87-CD6-213-010 SPR-C,BATT (-) A...................
8A-CH4-201-010 HLDR,LCD A...................
8A-CH4-203-010 HLDR,TU A...................
8A-CH4-204-010 SPR-T,CD A...................
8A-CH4-205-010 SPR-T,CASS A...................
8A-CH4-206-010 HLDR,OIL-DMPR A...................
8A-CH4-208-010 SPR-P,REC 8K A...................
8A-CH4-209-010 HLDR,PT A...................
8A-CH4-210-010 HLDR,ANT A...................
8A-CH4-211-010 COVER, HLDR PT A...................
8Z-CH4-204-010 HLDR,SPEAKER A...................
8Z-CH4-211-010 BASE,CHUCK A...................
8Z-CH4-212-010 RING,CHUCK A...................
87-067-566-010 TAPPING SCREW, VFTT+3-6 A...................
87-254-097-410 U+3-12 CR A...................
87-342-074-010 UT2+2.6-8 A...................
87-571-032-410 VIT+2-3 A...................
87-661-100-410 VFT1+3-16 A...................
87-741-095-410 UT2+3-8 GLD A...................
87-741-096-410 UT2+3-10 A...................
87-741-100-410 UT2+3-16(W/O) SLOT A...................
87-744-095-410 UT2+3-8CR A...................
87-751-075-410 VT2+2.6-10 A...................
87-B10-239-010 QT2+3-8 W/O CR A...................
87-A90-086-010 COVER,AC-SOCKET A...................
8Z-CH4-645-010 SPKR,MAYLOR 8OHM SILVER A...................
* 87-036-389-010 SW,PUSH LOCK A...................
* 87-A60-177-010 JACK,AC U W/SW A...................
* 8A-CD9-620-010 FF-CABLE, 16P FR-MAIN A...................
* 8A-CD9-621-010 FF-CABLE, 16P CD-RF A...................
* 8A-CD9-622-010 FF-CABLE, 8P CD-FR A...................
* 8A-CD9-626-010 CONN ASSY,2P DOOR A...................
* 8A-CD9-630-010 CONN ASSY,4P RPH A...................
* 8A-CD9-631-010 CONN ASSY,4P TP-ME A...................
* 8A-CH4-634-010 CONN ASSY,2P S-SP.L A...................
* 8A-CH4-635-010 CONN ASSY,2P S-SP.R A...................
* 8A-CH4-682-010 SPKR,10- 7OHM A...................
* 8Z-CH4-640-010 ANT,ROD A...................
PT 901 8A-CD9-606-010 PT,U 2.5W A...................
ACCESSORIES / PACKAGE LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8A-CH4-903-010 IB,U(ESF)B A...................
87-A80-109-010 AC CORD,HK7281 BLK U A...................
8Z-CK4-962-010 RC UNIT,RC-ZAT04 (VS) A...................
SCHEMATIC DIAGRAM _1 (MAIN 1/2)
SCHEMATIC DIAGRAM _2 (MAIN 2/2)
SCHEMATIC DIAGRAM _3 (FRONT 1/2)
SCHEMATIC DIAGRAM _4 (FRONT 2/2)
SCHEMATIC DIAGRAM _5 (TUNER)
SCHEMATIC DIAGRAM _6 (PT)
2–11,IKENOHATA1–CHOME,TAITO-KU,TOKYO110,JAPAN TEL:03(3827)3111
L
Printed in Singapore
A4
2-11,IKENOHATA1-CHOME,TAITO-KU,TOKYO110,JAPANTEL:03(3827)3111
9920594
Other manuals for CSD-FD91
2
Table of contents
Other Aiwa CD Player manuals
