Aiwa HS-JS195 User manual

BASIC TAPE MECHANISM : TN-9XR-112
STEREO RADIO
CASSET RECORDER
HS-JS195
HS-JS185
S/M Code No. 09-986-288-30I
YZF YL YH YJ YZ
YL YH YZ
SERVICE MANUAL
HS-JS195 HS-JS185
All manuals and user guides at all-guides.com
all-guides.com

1
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES LIST
1 87-B30-068-010 HEADPHONE,HP-M007(T)<195>
1 87-B30-123-010 HEADPHONE,HP-M006(T)<185>
2 84-447-019-110 CLIP, BELT
3 87-HJ9-914-010 IB,EF-195<195YZF>
3 87-HJ9-911-010 IB,EGF-195<195YZ>
3 87-HJ9-910-010 IB,ESC-195<195YH,195YJ>
3 87-HJ9-909-010 IB,ESP-195<195YL>
3 87-HJ9-913-010 IB,PHNCZ-195<195YZ>
3 87-HJ9-912-010 IB,SID-195<195YZ>
3 87-HJA-910-010 IB,EGF<185YZ>
3 87-HJA-909-010 IB,ESC-185<185YH>
3 87-HJA-908-010 IB,ESP-185<185YL>
3 87-HJA-912-010 IB,PHNCZ<185YZ>
3 87-HJA-911-010 IB,SID<185YZ>
All manuals and user guides at all-guides.com

REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
W
Resistor Code
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
L
1.6
2
3.2
W
0.8
1.25
1.6
t
0.45
0.45
0.55
108
118
128
88
t
L
/ CHIP RESISTOR PART CODE
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance Symbol / Diamensions (mm)
/ Form Resistor Code : A
IC
87-001-379-010 IC,TA8122AF
87-A20-607-040 IC,CXA2500
87-001-371-080 IC,LA4533M
87-017-370-080 IC,MM1038AFF
87-002-232-080 IC,NJM2073M<195>
87-017-643-080 IC,MM1206XF<195>
TRANSISTOR
89-413-284-080 TR,2SD1328T
87-026-263-080 C-TR,RN1410
87-026-268-080 C-TR,RN2411
MAIN C.B
S7-J09-250-000 BATT,CONTACT(+)
S7-J09-260-000 BATT,CONTACT(-)
BPF1 87-030-312-010 FILTER BANDPASS,GFMB3-1
C102 87-010-044-080 CAP,E 47-4V
C103 87-016-350-040 CAP,E 470-4V
C113 87-010-401-010 CAP,E 1-50V
C201 87-010-115-010 CAP,E 100-4V
C202 87-010-115-010 CAP,E 100-4V
C203 87-010-067-080 CAP,E 0.1-50V
C204 87-010-067-080 CAP,E 0.1-50V
C209 87-010-482-010 CAP,E 220-4V
C210 87-010-482-010 CAP,E 220-4V
C215 87-010-401-010 CAP,E 1-50V
C216 87-010-401-010 CAP,E 1-50V
C217 87-010-401-010 CAP,E 1-50V
C218 87-010-401-010 CAP,E 1-50V
C219 87-010-401-010 CAP,E 1-50V
C220 87-010-401-010 CAP,E 1-50V
C221 87-010-115-010 CAP,E 100-4V
C222 87-010-115-010 CAP,E 100-4V
C223 87-010-044-080 CAP,E 47-4V
C227 87-010-067-080 CAP,E 0.1-50V
C228 87-010-067-080 CAP,E 0.1-50V
C232 87-010-044-080 CAP,E 47-4V
C235 87-016-350-040 CAP,E 470-4V
C307 87-010-482-010 CAP,E 220-4V
C308 87-010-482-010 CAP,E 220-4V
C309 87-010-482-010 CAP,E 220-4V
C310 87-010-115-010 CAP,E 100-4V
C311 87-010-401-010 CAP,E 1-50V
C312 87-010-401-010 CAP,E 1-50V
C404 87-010-482-010 CAP,E 220-4V
C501 87-010-067-080 CAP,E 0.1-50V<195>
C503 87-010-482-010 CAP,E 220-4V<195>
C505 87-010-075-040 CAP,E 10-16V<195>
CD3 87-A90-466-010 FLTR,CDF107E
CF1 87-A90-128-010 CERA,FIL CFAL-455
CF2 85-HRL-625-010 FLTR,SK107M2-AE20
J201 87-A60-361-010 JACK,HP 3.5MM
J301 87-A60-361-010 JACK,HP 3.5MM
J303 87-A60-360-010 JACK,DC DIA4.5
L1 87-HJ9-609-010 COIL,AM BAR ANT
L2 87-HJ9-605-010 COIL,FM RF(EX)
L3 87-HJ9-604-010 COIL,FM OSC(EX)
L4 87-A90-180-010 IFT,AM OSC 5P
L5 87-A90-177-010 IFT,AM IF 5P
L6 87-A50-096-010 COIL,ANT CH5KSY
L7 87-003-089-010 COIL,47UH FL5R200F
L251 87-007-189-010 COIL,OSC 50KHZ
S1 87-036-322-010 SW,SLIDE 2P3T
S2 87-A90-519-010 SW,SLIDE 2P2T
S3 87-A90-519-010 SW,SLIDE 2P2T
S4 87-A90-519-010 SW,SLIDE 2P2T
S5 87-A90-519-010 SW,SLIDE 2P2T
S6 87-036-123-010 SW,SLIDE 1P2T
S7 87-A90-520-010 SW,SL 2-4-2
SFR401 87-A90-518-010 SFR,1K V
VC1 87-A90-181-010 TUN-CAP,20-80-160 16X16
VR301 87-A90-521-010 VR,RTRY 10KH
X4 87-030-411-010 VIB,CER 19KHZ CMU2-456A01
LED C.B
LED301 87-017-827-080 C-LED SEC1201C<185>
LED601 87-017-828-080 C-LED,SEC1401C<195>
LED602 87-017-829-080 C-LED,SEC1901C<195>
LED603 87-017-827-080 C-LED SEC1201C<195>
All manuals and user guides at all-guides.com

SCHEMATIC DIAGRAM _1 (HS-JS195)
All manuals and user guides at all-guides.com

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
WIRING-1(HS-JS195)
All manuals and user guides at all-guides.com

SCHEMATIC DIAGRAM _2 (HS-JS185)
All manuals and user guides at all-guides.com
all-guides.com

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
WIRING-2(HS-JS185)
All manuals and user guides at all-guides.com

ADJUSTMENT
All manuals and user guides at all-guides.com

PRACTICAL SERVICE FIGURE
All manuals and user guides at all-guides.com

TRANSISTOR ILLUSTRATION
2SD1328
RN1410
RN2411
BE
C
All manuals and user guides at all-guides.com

IC BLOCK DIAGRAM
IC,CXA2500
IC.LA4553
IC,NJM2073M
All manuals and user guides at all-guides.com
all-guides.com

IC.MM1038AF
IC.TA8122AF
IC.MM1206XF
All manuals and user guides at all-guides.com

MECHANICAL EXPLODED VIEW 1/1 (HS-JS195)
All manuals and user guides at all-guides.com

REF. NO PART NO. KANRI DESCRIPTION
NO.
MECHANICAL PARTS LIST 1/1(HS-JS195)
1 87-HJ9-027-010 PANEL,CASS GRY
2 87-HJ9-004-010 PANEL,SPKR
3 87-HJA-206-010 SPR-T,CASS
4 87-HJ9-025-010 LID,CASS Y SIL
5 S1-440-004-210 SPKR
6 87-HJA-203-010 SPR-P,CASS
7 87-HJ9-003-010 WINDOW,CASS
8 87-HJA-007-110 WINDOW,TUN
9 87-040-196-010 COUNTER
10 87-HJ9-203-010 BELT,COUNTER
11 87-HJ9-026-010 FRAME,CENTER SIL
12 87-HJA-202-010 LEVER,REC
13 87-HJA-207-010 SPR-E,REC
14 87-HJ9-201-010 HLDR,COUNTER
15 87-HJA-040-010 BTN,REC A
16 87-HJA-010-110 BTN,PLAY
17 87-HJA-012-010 BTN,STOP
18 87-HJA-014-010 BTN,REW
19 87-HJA-013-010 BTN,FF
20 87-HJ9-609-010 COIL,AM BAR ANT
21 87-HJA-008-010 POINTER,TUN
22 87-HJA-021-010 KNOB,RTRY VOL
23 87-HJA-017-110 KNOB,RTRY TUN
24 87-HJA-201-010 CHASS,TUN
25 87-HJA-205-010 TERMINAL,BATT(-)
26 87-HJA-204-010 TERMINAL,BATT(+)
27 87-HJ9-022-210 CABI,REAR
28 87-HJA-004-010 LID,BATT
29 87-HJA-045-010 KNOB,SL BEAT GRY
30 87-HJA-044-010 KNOB,SL PAUSE GRY
31 87-HJA-043-010 KNOB,SL GRY
32 87-HJA-041-010 KNOB,SL BAND GRY
33 87-HJA-042-010 KNOB,SL POWER GRY
A 87-067-271-010 SCREW,1.7-4
B 87-352-508-310 SCREW,1.4-3.5(BLK)
C 87-264-529-310 SCREW,1.7-4(BLK)
D 87-067-769-010 SCREW,1.7-8
E 87-264-528-310 SCREW,1.7-3.5
F 87-354-529-310 SCREW,1.7-4
All manuals and user guides at all-guides.com

MECHANICAL EXPLODED VIEW 1/1 (HS-JS185)
All manuals and user guides at all-guides.com

REF. NO PART NO. KANRI DESCRIPTION
NO.
MECHANICAL PARTS LIST 1/1(HS-JS185)
1 87-HJA-046-010 PANEL,CASS GRY
2 87-HJA-208-010 HLDR,MIC
3 87-HJA-206-010 SPR-T,CASS
4 87-HJA-035-010 LID,CASS Y SIL
5 82-TP3-609-010 MIC
6 87-HJA-203-010 SPR-P,CASS
7 87-HJA-005-010 WINDOW,CASS
8 87-HJA-007-110 WINDOW,TUN
9 87-HJA-036-010 FRAME,CENTER SIL
10 87-HJA-202-010 LEVER,REC
11 87-HJA-207-010 SPR-E,REC
12 87-HJA-040-010 BTN,REC A
13 87-HJA-010-110 BTN,PLAY
14 87-HJA-012-010 BTN,STOP
15 87-HJA-014-010 BTN,REW
16 87-HJA-013-010 BTN,FF
17 87-HJA-609-010 COIL,AM BAR ANT
18 87-HJA-008-010 POINTER,TUN
19 87-HJA-021-010 KNOB,RTRY VOL
20 87-HJA-017-110 KNOB,RTRY TUN
21 87-HJA-201-010 CHAS,TUN
22 87-HJA-205-010 TERMINAL,BATT(-)
23 87-HJA-204-010 TERMINAL,BATT(+)
24 87-HJA-003-210 CABI,REAR
25 87-HJA-004-010 LID,BATT
26 87-HJA-045-010 KNOB,SL BEAT GRY
27 87-HJA-044-010 KNOB,SL PAUSE
28 87-HJA-043-010 KNOB,SL GRY
29 87-HJA-041-010 KNOB,SL BAND GRY
30 87-HJA-042-010 KNOB,SL POWER GRY
A 87-067-271-010 SCREW,1.7-4
B 87-352-508-310 SCREW,1.4-3.5(BLK)
C 87-264-529-310 SCREW,1.7-4(BLK)
D 87-067-769-010 SCREW,1.7-8
E 87-264-528-310 SCREW,1.7-3.5
F 87-354-529-310 SCREW,1.7-4
G 87-067-732-010 SCREW,1.4-3
All manuals and user guides at all-guides.com
all-guides.com

TAPE MECHANISM EXPLODED VIEW 1/1
All manuals and user guides at all-guides.com

REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
TAPE MECHANISM PARTS LIST 1/1
1 S1-909-013-040 CHASSIS ASSY
2 S1-909-020-190 FR PLATE
3 S1-909-020-090 LOCK PLATE
4 S1-909-020-140 STOP SPRING
5 S1-909-120-030 REC LEVER SPRING
6 S1-909-120-070 REC LEVER
7 S1-909-120-020 MG GUIDE
8 S6-207-100-020 HEAD E TC-230AN(SL)
9 S1-852-140-020 M LUBBER
10 S1-909-030-050 HEAD PANEL
11 S1-909-040-020 P/R SPRING
12 S1-909-030-080 R/C SPRING
13 S1-909-030-070 R/C PLATE
14 S1-909-030-060 TAPE GUIDE
15 S1-852-140-030 M COLLOR
16 S1-944-030-020 HEAD SPRING PLATE
17 S6-202-030-410 RP HEAD MS15R-BA2N1
18 S1-909-020-100 STOP LEVER
19 S1-909-110-040 AUTO LEVER
20 S1-909-110-020 A PUSH ARM
21 S1-909-110-050 M CONTROL SPRING
22 S1-909-060-150 SENSOR SPRING C
23 S1-909-063-030 T REEL ASSY
24 S1-909-060-130 TAKE UP GEAR
25 S1-909-030-090 HP SPRING
26 S1-909-083-050 MOTOR ASSY
27 S1-909-050-130 BRAKE BELT
28 S1-909-043-020 PINCH ROLLER ASSY
29 S1-909-020-200 FR PLATE SPRING
30 S1-909-020-120 FF LEVER
31 S1-909-053-040 FLYWHEEL ASSY
32 S1-909-080-100 MAIN BELT
33 S1-909-050-100 FL BRACKET
34 S1-909-020-150 R/C LEVER(R)
35 S1-909-020-160 R/C LEVER(F)
36 S1-909-060-120 CAM GEAR
37 S1-909-020-170 R/C BRACKET
38 S1-909-020-110 RWD LEVER
39 S1-909-020-180 FF STOPPER
40 S6-401-011-630 LEAF SW MSW-1541TA
41 S1-909-077-010 RWD GEAR
42 S1-909-020-130 FR SPRING
43 S1-909-120-090 REC SPRING PLATE
44 S1-909-120-100 REC SW LEVER
A S9-C01-174-030 CAMERA 1.7-4
B S9-C01-173-530 CAMERA 1.7-3.5
C S9-P14-203-310 +/- SCREW M2-3.3
D S9-C18-300-100 CAMERA 1.7-3
E S9-P08-173-410 PST 1.7-3.4
F S9-P14-206-320 +/- SCREW M2-3.6
G S9-W02-300-100 P WASHER CUT 1.2-3.8-0.3
H S9-W08-350-200 LUMILER WASHER CUT 0.98-3-0.3
I S9-W05-200-600 HL WASHER 1.16-3-0.2
J S9-W05-200-100 HL WASHER 1.55-3-0.13
K S9-C16-171-410 CAMERA 1.7-1.4
All manuals and user guides at all-guides.com

931261 Printed in Singapore
2–11, IKENOHATA1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
