S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with ”Revision Publishing” when it is issued.

XR-H66MD

• BASIC CD MECHANISM: 4ZG-1 Z3MD

• BASIC MD MECHANISM: 7ZG-5 U • TYPE: EZ

S/M Code No. 09–985–262–1FE

MD/CD STEREO SYSTEM

ELECTRICAL MAIN PARTS LIST - 1/6

NOTE: The characters in the suffix column indicate the part usage.

EZ .....................XX..................................A...................

REF.NO PARTS NO. DESCRIPTION SUFFIX

87-NB5-211-010 GUIDE,OPE A...................

87-NB5-212-010 GUIDE,DISC MD A...................

87-NF5-203-010 GUIDE,FL A...................

C 3 87-012-145-080 CAP, CHIP S 270P CH A...................

C 5 87-012-145-080 CAP, CHIP S 270P CH A...................

C 1 87-012-145-080 CAP, CHIP S 270P CH A...................

C 9 87-012-145-080 CAP, CHIP S 270P CH A...................

C 8 87-012-145-080 CAP, CHIP S 270P CH A...................

C 2 87-012-145-080 CAP, CHIP S 270P CH A...................

C 4 87-012-145-080 CAP, CHIP S 270P CH A...................

C 6 87-012-145-080 CAP, CHIP S 270P CH A...................

C 7 87-012-158-080 C-CAP,S 390P-50 CH A...................

C 11 87-012-145-080 CAP, CHIP S 270P CH A...................

C 13 87-012-145-080 CAP, CHIP S 270P CH A...................

C 10 87-012-145-080 CAP, CHIP S 270P CH A...................

C 12 87-012-158-080 C-CAP,S 390P-50 CH A...................

C 103 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 104 87-010-198-080 CAP, CHIP 0.022 A...................

C 105 87-010-198-080 CAP, CHIP 0.022 A...................

C 108 87-010-391-040 CAP,E 10-35 SME A...................

C 107 87-012-157-080 C-CAP,S 330P-50 CH A...................

C 102 87-018-123-080 CAP, CER 220P-50V A...................

C 118 87-010-194-080 CAP, CHIP 0.047 A...................

C 114 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 112 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 119 87-010-408-040 CAP,E 47-50 SME A...................

C 116 87-010-494-040 CAP,E 1-50 GAS A...................

C 117 87-010-555-040 CAP,E 100-10 GAS A...................

C 113 87-A10-189-040 CAP,E 220-10 A...................

C 128 87-010-178-080 CHIP CAP 1000P A...................

C 124 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 125 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 127 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 123 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 126 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 120 87-010-404-040 CAP,E 4.7-50 SME A...................

C 121 87-010-404-040 CAP,E 4.7-50 SME A...................

C 122 87-018-208-080 CAP 0.047-50F A...................

C 132 87-010-178-080 CHIP CAP 1000P A...................

C 131 87-010-316-080 C-CAP,S 33P-50 CH A...................

C 130 87-010-320-080 CHIP CAP 68P A...................

C 225 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 226 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 263 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 265 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 262 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 264 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 266 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 261 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 357 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 355 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 354 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 353 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 356 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 352 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 351 87-012-158-080 C-CAP,S 390P-50 CH A...................

C 723 87-010-154-080 CAP CHIP 10P A...................

C 720 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 725 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 726 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 865 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 868 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 867 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 866 87-010-322-080 C-CAP,S 100P-50 CH A...................

CON 103 87-099-015-010 CONN,13P 6216V A...................

CON 104 87-099-197-010 CONN, 9P 6216 V A...................

CON 102 87-A60-587-010 CONN,25P V CFF5112 A...................

CON 202 87-A60-587-010 CONN,25P V CFF5112 A...................

CON 311 87-099-015-010 CONN,13P 6216V A...................

CON 310 87-099-015-010 CONN,13P 6216V A...................

CON 800 87-099-197-010 CONN, 9P 6216 V A...................

D 109 87-017-932-080 ZENER,MTJ6.2B A...................

D 106 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 104 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 108 87-A40-269-080 C-DIODE,MC2836 A...................

D 103 87-A40-270-080 C-DIODE,MC2838 A...................

D 107 87-A40-270-080 C-DIODE,MC2838 A...................

D 111 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 121 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 307 87-A40-269-080 C-DIODE,MC2836 A...................

D 308 87-A40-269-080 C-DIODE,MC2836 A...................

D 304 87-A40-269-080 C-DIODE,MC2836 A...................

D 303 87-A40-269-080 C-DIODE,MC2836 A...................

D 305 87-A40-269-080 C-DIODE,MC2836 A...................

D 306 87-A40-269-080 C-DIODE,MC2836 A...................

D 352 87-A40-246-080 DIODE,IN4148 T-72 A...................

Q 108 87-A30-071-080 C-TR,RT1N 144C A...................

Q 103 87-A30-075-080 C-TR,2SA1235F A...................

Q 102 87-A30-076-080 C-TR,2SC3052F A...................

Q 110 87-A30-072-080 C-TR,RT1P 144C A...................

Q 272 87-A30-087-080 C-FET,2SK2158 A...................

Q 271 87-A30-087-080 C-FET,2SK2158 A...................

Q 273 87-A30-087-080 C-FET,2SK2158 A...................

Q 276 89-327-143-080 TR,2SC2714 (0.1W) A...................

Q 275 89-327-143-080 TR,2SC2714 (0.1W) A...................

Q 274 89-327-143-080 TR,2SC2714 (0.1W) A...................

Q 301 87-A30-076-080 C-TR,2SC3052F A...................

Q 305 87-A30-087-080 C-FET,2SK2158 A...................

Q 304 87-A30-087-080 C-FET,2SK2158 A...................

Q 308 87-A30-087-080 C-FET,2SK2158 A...................

Q 306 87-A30-087-080 C-FET,2SK2158 A...................

Q 307 87-A30-087-080 C-FET,2SK2158 A...................

Q 303 87-A30-087-080 C-FET,2SK2158 A...................

Q 722 87-A30-076-080 C-TR,2SC3052F A...................

Q 725 87-A30-087-080 C-FET,2SK2158 A...................

Q 801 87-A30-075-080 C-TR,2SA1235F A...................

Q 802 87-A30-075-080 C-TR,2SA1235F A...................

Q 803 89-109-521-080 TR,2SA952 (0.6W) A...................

S 305 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 303 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 304 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 301 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 302 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 329 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 325 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 326 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 322 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 327 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 324 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 323 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 328 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 321 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 345 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 343 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 347 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 344 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 342 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 341 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 348 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 346 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 369 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 368 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 367 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 363 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 364 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 366 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 362 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 361 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 365 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 371 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 370 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 809 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 808 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 807 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 806 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 810 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 812 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 811 87-A90-095-080 SW,TACT EVQ11G04M A...................

SW 102 87-A90-085-010 SW,RTRY EC16B 24204 A...................

SW 101 87-A90-535-010 SW,RTRY EC16B24304 A...................

X 202 87-A70-070-080 VIB,CER 5.76MHZ CRHF A...................

C 505 87-010-180-080 C-CER 1500P A...................

C 509 87-010-181-080 CAP,CHIP S 1800P A...................

C 504 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 508 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 506 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 507 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 502 87-010-319-080 C-CAP,S 56P-50 CH A...................

C 501 87-010-319-080 C-CAP,S 56P-50 CH A...................

C 503 87-012-393-080 C-CAP,S 0.22-16 R K A...................

C 516 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 515 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 510 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 518 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 519 87-010-263-040 CAP,E 100-10 A...................

C 514 87-010-494-040 CAP,E 1-50 GAS A...................

C 513 87-010-494-040 CAP,E 1-50 GAS A...................

C 512 87-010-553-040 CAP,E 47-16 GAS A...................

C 517 87-012-141-080 CHIP-CAPACITOR,0.22-16F A...................

C 511 87-018-209-080 CAP, CER 0.1-50V A...................

C 520 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 522 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 521 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 556 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 602 87-010-186-080 CAP,CHIP 4700P A...................

C 605 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 607 87-010-321-080 CHIP CAPACITOR,82P(J) A...................

ELECTRICAL MAIN PARTS LIST - 2/6

C 606 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 604 87-010-382-040 CAP,E 22-25 SME A...................

C 603 87-010-405-040 CAP,E 10-50 A...................

C 601 87-010-498-040 CAP,E 10-16 GAS A...................

C 609 87-010-545-040 CAP,E 0.22-50 SME A...................

C 612 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 611 87-010-177-080 C-CAP,S 820P-50 SL A...................

C 614 87-010-248-040 CAP,E 220-10 SME A...................

C 610 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 670 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

D 501 87-017-931-080 ZENER,MTZJ5.6B A...................

D 601 87-A40-246-080 DIODE,IN4148 T-72 A...................

FB 601 87-008-372-080 FILTER, EMI BL OIRNI A...................

IC 501 87-A20-613-040 C-IC,BU9262AFS A...................

IC 601 87-017-888-080 IC,NJM4558MD A...................

J 601 87-A60-284-010 JACK,3.5MO (MSC) A...................

J 602 87-A60-284-010 JACK,3.5MO (MSC) A...................

L 501 87-005-448-080 COIL 220UH,K A...................

Q 601 87-A30-087-080 C-FET,2SK2158 A...................

C 407 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 408 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 409 87-010-198-080 CAP, CHIP 0.022 A...................

C 405 87-010-494-040 CAP,E 1-50 GAS A...................

C 406 87-010-494-040 CAP,E 1-50 GAS A...................

C 403 87-010-992-080 C-CAP,S 0.047-25 B A...................

C 404 87-010-992-080 C-CAP,S 0.047-25 B A...................

C 413 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 416 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 410 87-010-198-080 CAP, CHIP 0.022 A...................

C 414 87-010-374-040 CAP,E 47-10 A...................

C 415 87-010-549-040 CAP,E 47-6.3 GAS A...................

C 418 87-010-560-040 CAP,E 10-50 GAS A...................

C 417 87-016-081-080 C-CAP,S 0.1-16 RK A...................

C 411 87-A10-201-080 C-CAP,S0.33-16 KB A...................

C 412 87-A10-201-080 C-CAP,S0.33-16 KB A...................

D 401 87-A40-246-080 DIODE,IN4148 T-72 A...................

IC 401 87-A20-450-040 C-IC,BH 3864 F A...................

PR 6 87-026-682-080 PROTECTOR,10A 60V491 A...................

PR 5 87-026-682-080 PROTECTOR,10A 60V491 A...................

T 2 87-A60-317-010 TERMINAL, 1P MSC A...................

T 1 87-A60-317-010 TERMINAL, 1P MSC A...................

W 1 85-NF5-628-010 F-CABLE 7P-2.5 A...................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................

C 109 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 104 87-010-928-090 CAP,E 4700-25 SMG A...................

C 103 87-010-928-090 CAP,E 4700-25 SMG A...................

C 108 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 105 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 107 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 106 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 102 87-016-520-090 CAP,E 3300-65 A...................

C 101 87-016-520-090 CAP,E 3300-65 A...................

C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 112 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 119 87-010-260-080 CAP, ELECT 47-25V A...................

C 118 87-010-263-080 CAP, ELECT 100-10V A...................

C 113 87-010-408-080 CAP, ELECT 47-50V A...................

C 116 87-010-408-080 CAP, ELECT 47-50V A...................

C 117 87-016-285-080 CAP,E 47-100SME A...................

C 124 87-010-112-080 CAP, ELECT 100-16V A...................

C 126 87-010-194-080 CAP, CHIP 0.047 A...................

C 127 87-010-194-080 CAP, CHIP 0.047 A...................

C 125 87-010-235-080 CAP,E 470-16 SME A...................

C 123 87-010-384-080 CAP, ELECT 100-25V A...................

C 120 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 121 87-012-140-080 CAP 470P A...................

D 102 87-017-447-010 DIODE,GBU4DL A...................

D 101 87-017-447-010 DIODE,GBU4DL A...................

D 107 87-070-274-080 DIODE,1N4003 SEM A...................

D 106 87-070-274-080 DIODE,1N4003 SEM A...................

D 108 87-070-274-080 DIODE,1N4003 SEM A...................

D 104 87-A40-269-080 C-DIODE,MC2836 A...................

D 105 87-A40-270-080 C-DIODE,MC2838 A...................

D 103 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 112 87-070-334-080 ZENER,MTZJ10B A...................

D 110 87-A40-341-080 ZENER,MTZJ 36 A A...................

Q 103 87-026-610-080 TR,KTC3198GR A...................

Q 109 87-A30-075-080 C-TR,2SA1235F A...................

Q 107 87-A30-075-080 C-TR,2SA1235F A...................

Q 104 87-A30-076-080 C-TR,2SC3052F A...................

Q 106 87-A30-076-080 C-TR,2SC3052F A...................

Q 108 87-A30-076-080 C-TR,2SC3052F A...................

Q 105 87-A30-196-080 TR,2SC4115SRS A...................

Q 102 89-213-750-010 TR,2SB1375 (25W) A...................

Q 101 89-213-750-010 TR,2SB1375 (25W) A...................

Q 112 87-026-609-080 TR,KTA1266GR A...................

Q 111 87-026-609-080 TR,KTA1266GR A...................

Q 114 87-A30-075-080 C-TR,2SA1235F A...................

Q 110 87-A30-076-080 C-TR,2SC3052F A...................

RY 101 87-045-389-010 RELAY,OSA-SS-212DM5 A...................

C 206 87-010-180-080 C-CER 1500P A...................

ELECTRICAL MAIN PARTS LIST - 3/6

C 205 87-010-180-080 C-CER 1500P A...................

C 201 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 202 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 208 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 207 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 209 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 212 87-010-186-080 CAP,CHIP 4700P A...................

C 211 87-010-186-080 CAP,CHIP 4700P A...................

C 215 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 219 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 213 87-010-260-080 CAP, ELECT 47-25V A...................

C 214 87-010-260-080 CAP, ELECT 47-25V A...................

C 210 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 223 87-010-194-080 CAP, CHIP 0.047 A...................

C 220 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 222 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 221 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 227 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 229 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 226 87-A10-516-080 C-CAP,S 100P-200 J CH A...................

C 225 87-A10-516-080 C-CAP,S 100P-200 J CH A...................

C 236 87-010-191-080 C-CAP,S 0.015-50 F A...................

C 235 87-010-191-080 C-CAP,S 0.015-50 F A...................

C 237 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 238 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 233 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 234 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 230 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 243 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 242 87-010-406-080 CAP, ELECT 22-50 A...................

C 244 87-010-406-080 CAP, ELECT 22-50 A...................

D 209 87-070-136-080 ZENER,MTZJ5.1B A...................

D 201 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 202 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 203 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 206 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 205 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 204 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 210 87-070-136-080 ZENER,MTZJ5.1B A...................

D 217 87-A40-184-090 DIODE,RK34(F) A...................

D 218 87-A40-184-090 DIODE,RK34(F) A...................

D 211 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 213 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 216 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 212 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 214 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 227 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 222 87-A40-291-080 DIODE,1N4148 (CPT) A...................

D 221 87-A40-291-080 DIODE,1N4148 (CPT) A...................

J 252 87-A60-024-010 JACK 6.3BLK W/S WKM A...................

J 254 87-A60-238-010 TERMINAL,SP 4P (MSC) A...................

J 253 87-A60-568-010 JACK,PIN 3P B/W/R HSP-243V19 A...................

L 202 87-003-383-010 COIL,1UH-S A...................

L 201 87-003-383-010 COIL,1UH-S A...................

PR 202 87-026-682-080 PROTECTOR,10A 60V491 A...................

PR 201 87-026-682-080 PROTECTOR,10A 60V491 A...................

Q 202 87-A30-086-070 C-TR,CSD1306E A...................

Q 201 87-A30-086-070 C-TR,CSD1306E A...................

Q 206 87-A30-106-070 C-TR,CMBT5551 A...................

Q 204 87-A30-106-070 C-TR,CMBT5551 A...................

Q 205 87-A30-106-070 C-TR,CMBT5551 A...................

Q 203 87-A30-106-070 C-TR,CMBT5551 A...................

Q 208 87-A30-111-080 TR,C2N5401 A...................

Q 207 87-A30-111-080 TR,C2N5401 A...................

Q 209 87-A30-137-010 TR,2SD2494 A...................

Q 213 87-A30-106-070 C-TR,CMBT5551 A...................

Q 214 87-A30-106-070 C-TR,CMBT5551 A...................

Q 210 87-A30-137-010 TR,2SD2494 A...................

Q 211 87-A30-138-010 TR,2SB1625 A...................

Q 212 87-A30-138-010 TR,2SB1625 A...................

Q 219 87-A30-162-010 FET,2SK2937 A...................

Q 223 87-A30-072-080 C-TR,RT1P 144C A...................

Q 229 87-A30-073-080 C-TR,RT1N 141C A...................

Q 222 87-A30-075-080 C-TR,2SA1235F A...................

Q 225 87-A30-075-080 C-TR,2SA1235F A...................

Q 226 87-A30-075-080 C-TR,2SA1235F A...................

Q 227 87-A30-076-080 C-TR,2SC3052F A...................

Q 221 87-A30-076-080 C-TR,2SC3052F A...................

Q 220 87-A30-162-010 FET,2SK2937 A...................

Q 235 87-A30-075-080 C-TR,2SA1235F A...................

Q 233 87-A30-075-080 C-TR,2SA1235F A...................

Q 236 87-A30-075-080 C-TR,2SA1235F A...................

Q 234 87-A30-075-080 C-TR,2SA1235F A...................

Q 231 87-A30-106-070 C-TR,CMBT5551 A...................

R 229 87-A00-257-080 RES,M/F 0.15-1W J A...................

R 230 87-A00-257-080 RES,M/F 0.15-1W J A...................

RY 201 87-045-382-010 RELAY,OUAZ-SH-112L A...................

TH 201 87-A90-221-080 C-THMS,100K A...................

TH 202 87-A90-221-080 C-THMS,100K A...................

C 406 87-010-101-080 CAP, ELECT 220-16 A...................

C 401 87-010-187-080 CAP CHIP S5600P A...................

C 402 87-010-187-080 CAP CHIP S5600P A...................

ELECTRICAL MAIN PARTS LIST - 4/6

C 407 87-010-188-080 CAP,CHIP 6800P A...................

C 408 87-010-188-080 CAP,CHIP 6800P A...................

C 405 87-010-260-080 CAP, ELECT 47-25V A...................

C 404 87-010-405-080 CAP, ELECT 10-50V A...................

C 403 87-010-405-080 CAP, ELECT 10-50V A...................

C 409 87-012-140-080 CAP 470P A...................

C 413 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 414 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 412 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 411 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 418 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 415 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 417 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 416 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 410 87-012-140-080 CAP 470P A...................

C 422 87-010-402-080 CAP, ELECT 2.2-50V A...................

C 421 87-010-402-080 CAP, ELECT 2.2-50V A...................

D 441 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 442 87-A40-269-080 C-DIODE,MC2836 A...................

IC 401 87-A20-056-010 IC,BA3880S A...................

C 516 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 615 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 619 87-010-263-080 CAP, ELECT 100-10V A...................

C 613 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 614 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 611 87-016-081-080 C-CAP,S 0.1-16 RK A...................

C 623 87-010-194-080 CAP, CHIP 0.047 A...................

C 622 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 629 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 620 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 621 87-010-263-080 CAP, ELECT 100-10V A...................

C 639 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 641 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 646 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 640 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 642 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 647 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 696 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................

C 697 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................

CON 602 87-099-194-010 CONN,6P 6216V A...................

D 603 87-070-136-080 ZENER,MTZJ5.1B A...................

D 602 87-A40-003-080 ZENER,MTZJ4.3A A...................

D 601 87-A40-246-080 DIODE,IN4148 T-72 A...................

IC 601 87-A20-456-040 C-IC,BH3810 FS A...................

J 601 87-A60-664-010 JACK,PIN 6P W/R HSP-246V6E A...................

L 601 87-003-231-080 C-COIL 1UH A...................

L 616 87-A50-267-010 COIL,33UHRCR-875D A...................

Q 603 87-A30-074-080 C-TR,RT1P 141C A...................

Q 601 87-A30-076-080 C-TR,2SC3052F A...................

Q 602 87-A30-076-080 C-TR,2SC3052F A...................

C 704 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 703 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 701 87-010-381-080 CAP, ELECT 330-16V A...................

C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 713 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 714 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 711 87-010-263-080 CAP, ELECT 100-10V A...................

C 715 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 725 87-010-178-080 CHIP CAP 1000P A...................

C 723 87-010-178-080 CHIP CAP 1000P A...................

C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 728 87-010-248-080 CAP, ELECT 220-10V A...................

C 722 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 721 87-010-312-080 C-CAP,S 15P-50 CH A...................

D 721 87-A40-234-080 ZENER,MTZJ5.6A A...................

IC 720 86-NFZ-655-010 IC,LC72131D(Z) A...................

Q 711 87-A30-196-080 TR,2SC4115SRS A...................

X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................

C 758 87-010-149-080 C-CAP,S 5P-50 CH A...................

C 756 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 755 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 757 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 763 87-010-194-080 CAP, CHIP 0.047 A...................

C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 765 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 762 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 766 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 768 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 767 87-010-405-080 CAP, ELECT 10-50V A...................

C 769 87-010-408-080 CAP, ELECT 47-50V A...................

C 772 87-010-194-080 CAP, CHIP 0.047 A...................

C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 776 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 774 87-010-263-080 CAP, ELECT 100-10V A...................

C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 778 87-010-401-080 CAP, ELECT 1-50V A...................

C 779 87-010-401-080 CAP, ELECT 1-50V A...................

C 775 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 771 87-010-407-080 CAP, ELECT 33-50V A...................

C 770 87-015-821-080 C-CAP 0.047 A...................

C 789 87-010-179-080 CAP,CHIP S B1200P A...................

ELECTRICAL MAIN PARTS LIST - 5/6

C 787 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 788 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 784 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 786 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 785 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 782 87-010-405-080 CAP, ELECT 10-50V A...................

C 781 87-010-405-080 CAP, ELECT 10-50V A...................

C 783 87-015-819-080 CAPACITOR,0.01 A...................

C 793 87-010-177-080 C-CAP,S 820P-50 SL A...................

C 790 87-010-179-080 CAP,CHIP S B1200P A...................

C 797 87-010-180-080 C-CER 1500P A...................

C 798 87-010-180-080 C-CER 1500P A...................

C 799 87-010-194-080 CAP, CHIP 0.047 A...................

C 796 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 791 87-010-405-080 CAP, ELECT 10-50V A...................

C 794 87-010-406-080 CAP, ELECT 22-50 A...................

C 795 87-010-596-080 CAP, S 0.047-16 A...................

D 770 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 771 87-A40-246-080 DIODE,IN4148 T-72 A...................

IC 770 87-A20-438-010 IC,LA1837 A...................

L 770 87-005-849-080 COIL,10UH(CECS) A...................

L 771 87-A50-165-010 COIL,FM DET-N(TOK) A...................

L 772 87-A90-245-010 FLTR,CFAZH-450 (TOK) A...................

C 859 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 865 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 867 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 869 87-010-314-080 C-CAP,S 22P-50V A...................

C 868 87-010-316-080 C-CAP,S 33P-50 CH A...................

C 866 87-010-405-080 CAP, ELECT 10-50V A...................

C 864 87-010-405-080 CAP, ELECT 10-50V A...................

C 863 87-012-140-080 CAP 470P A...................

C 862 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 861 87-012-156-080 C-CAP,S 220P-50 CH A...................

IC 850 87-A20-440-040 C-IC,BU1920FS A...................

L 850 87-005-847-080 COIL,2.2UH(CECS) A...................

Q 851 87-A30-076-080 C-TR,2SC3052F A...................

Q 850 87-A30-076-080 C-TR,2SC3052F A...................

X 850 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 A...................

C 815 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 814 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 812 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 813 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 819 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 816 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 823 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 821 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 822 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 820 87-010-408-080 CAP, ELECT 47-50V A...................

C 942 87-010-151-080 C-CAP,S 7P-50 CH A...................

C 947 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 940 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 949 87-014-049-080 CAP,PP 470P-100 J A...................

C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 952 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 958 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 957 87-010-311-080 CAP 12P A...................

C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 962 87-010-401-080 CAP, ELECT 1-50V A...................

CF 802 82-785-747-010 CF MS2 GHY R A...................

CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 A...................

D 944 87-A40-246-080 DIODE,IN4148 T-72 A...................

D 942 87-A40-270-080 C-DIODE,MC2838 A...................

FFE 801 A8-6ZA-19C-070 6ZA-1 YFEENC A...................

J 801 87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 A...................

L 832 87-005-847-080 COIL,2.2UH(CECS) A...................

L 942 87-A50-019-010 COIL,OSC LW(COI) A...................

L 941 87-A50-020-010 COIL,ANT LW(COI) A...................

L 981 87-NF4-651-010 COIL,AM PACK2N(TOM) A...................

Q 806 87-A30-072-080 C-TR,RT1P 144C A...................

Q 805 89-327-143-080 TR,2SC2714 (0.1W) A...................

Q 948 87-A30-086-070 C-TR,CSD1306E A...................

Q 947 89-505-434-540 C-FET,2SK543(4/5) A...................

Q 951 87-A30-074-080 C-TR,RT1P 141C A...................

Q 952 87-A30-086-070 C-TR,CSD1306E A...................

TC 942 87-011-221-080 CAP, TRIMMER 30P A...................

ELECTRICAL MAIN PARTS LIST - 6/6

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

EZ .....................XX..................................A...................

REF.NO PARTS NO. DESCRIPTION SUFFIX

87-NB5-002-010 PANEL,FR A...................

87-NB5-003-010 PANEL,TRAY CD D A...................

87-NB5-004-010 PANEL,TRAY MD D A...................

87-NB5-005-110 WINDOW,MD A...................

87-NB5-007-010 WINDOW,CD A...................

87-NB5-085-010 PANEL,REAR EZS A...................

87-NB5-087-010 CABI,FR EZ A...................

87-NB5-088-010 WINDOW,DISP EZ A...................

87-NB5-089-010 CABI,STEEL EZ A...................

87-NB5-016-010 KNOB,RTRY VOL A...................

87-NB5-017-010 KNOB,RTRY JOG A...................

87-NB5-020-010 KEY,ASSY FUN CD A...................

87-NB5-021-010 KEY,ASSY FUN TUN A...................

87-NB5-027-010 KEY,POWER A...................

87-NB5-028-010 KEY,RDS A...................

87-NB5-029-010 KEY,ASSY OPE A...................

87-NB5-031-010 KEY,REC A...................

87-NB5-032-010 KEY,MIC A...................

87-NB5-033-010 KEY,EDIT A...................

87-NB5-035-010 KEY,VF A...................

87-NB5-036-010 KEY,DISC CD A...................

87-NB5-037-010 KEY,DISC MD A...................

87-NB5-038-010 KEY,OPEN CD A...................

87-NB5-039-010 KEY,OPEN MD A...................

87-NB5-040-010 KEY,SURROUND A...................

87-NB5-015-010 RING,VOL A...................

87-NB5-018-010 PANEL,JOG A...................

84-ZG1-245-210 CAP,OPTICAL A...................

87-084-077-010 NYLON RIVET, 3.5-4.5 A...................

87-NB5-213-010 GUIDE,DISC CD A...................

87-NB5-214-010 GUIDE,LED MD A...................

87-NB5-227-010 FOOT,DIA25 -6 A...................

87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................

87-067-689-010 TAPPING SCREW, BVTT+3-8 A...................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................

87-067-758-010 BVT2+3-12 W/O SLOT A...................

87-078-019-010 S-SCREW,IT+4-6 A...................

87-591-094-410 TAPPING SCREW, QIT+3-6 A...................

87-721-097-410 QT2+3-12 GLD A...................

87-743-095-410 TAPPING SCREW, UT2+3-8 (B) A...................

87-B10-150-010 UIT+3-4 W/O SLOT BLK A...................

87-NF4-224-010 S-SCREW,IT3B+3-8 CU A...................

87-050-079-010 AC-CORD ASSY,E A...................

87-085-185-010 BUSHING, AC CORD (E) A...................

87-NB5-608-010 PT,7NB-5 EZ A...................

C 651 87-018-119-080 CAP, CER 100P-50V A...................

C 652 87-018-119-080 CAP, CER 100P-50V A...................

C 663 87-018-131-080 CAP, CER 1000P-50V A...................

F 101 87-035-364-010 FUSE, 1.6A 250V A...................

FB 1 87-003-317-010 F-BEAD,F0H2515-LG7 A...................

FB 3 87-A90-762-010 F-BEAD, 3407MFT A...................

FB 2 87-A90-762-010 F-BEAD, 3407MFT A...................

FC 202 87-NB5-634-010 FF-CABLE, 25P 1.00 170MM A...................

FC 205 87-ZG5-634-010 CABLE,FFC 4P-1.00 A...................

FC 301 88-913-151-110 FF-CABLE, 13P 1.25 A...................

FC 311 88-913-321-110 FF-CABLE, 13P 1.25 320MM A...................

FC 602 88-906-481-110 FF-CABLE, 6P 1.25 480MM A...................

FC 800 88-909-261-110 FF-CABLE,9P 1.25 A...................

87-NB5-211-010 GUIDE,OPE A...................

87-NB5-212-010 GUIDE,DISC MD A...................

87-NF5-203-010 GUIDE,FL A...................

W 1 85-NF5-628-010 F-CABLE 7P-2.5 A...................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................

NOTE: The characters in the suffix column indicate the part usage.

EZ .....................XX..................................A...................

REF.NO PARTS NO. DESCRIPTION SUFFIX

87-NB5-906-010 IB,E(9L)I A...................

87-006-225-010 AM LOOP ANT NC2 A...................

87-043-095-010 WIRE ANTENNA A...................

87-NB5-650-110 RC UNIT,RC-7AS15 A...................

ACCESSORIES / PACKAGE LIST - 1

DESCRIPTIONREF.NO. KANRI

NO.

PARTNO.KANRI

NO.

REF.NO. DESCRIPTIONPARTNO.

MD MECHANISM PARTS LIST 1 / 2

1 87-ZG5-204-010 COVER, T-T

2 87-ZG5-210-010 SLIDER,OPEN

3 87-ZG5-236-010 SPR-P,SHUTTER

4 87-ZG5-237-010 SPR-C,T-T

5 87-ZG5-202-010 TURN TABLE,MD

6 87-ZG5-208-010 SLIDER,LOCK T-T

7 87-ZG5-211-010 LEVER,REC

8 87-ZG5-201-010 TRAY,MECHA

9 87-ZG5-221-010 GEAR,CAM

10 87-ZG5-209-010 SLIDER,REC

11 87-ZG5-214-010 CLR,T-T

12 87-ZG5-205-010 SLIDER,MAIN

13 87-ZG5-213-010 LEVER,SW2

14 87-ZG5-223-010 GEAR,WORM-WHL-1

15 87-ZG5-227-010 GEAR,2

16 87-ZG5-226-010 GEAR,1

17 87-ZG5-207-010 LEVER,MODE-CHG

18 87-ZG5-212-010 LEVER,SW1

19 87-ZG5-225-010 GEAR,WORM-WHL-2

20 87-ZG5-229-010 GEAR,4

21 87-ZG5-228-010 GEAR,3

22 87-ZG5-224-010 GEAR,WORM-2

23 87-ZG5-222-010 GEAR,WORM-1

24 87-ZG5-220-010 GEAR,LOCK-TRAY

25 87-ZG5-234-010 PLATE,G-TRAY

26 87-ZG5-203-010 GUIDE,TRAY

27 85-HM1-222-010 DMPR,PLATE

28 87-ZG5-206-010 HLDR,MECHA

29 87-045-305-010 MOTOR, RF-500TB DC-5V (2MA)

30 87-ZG5-633-010 CABLE,FFC 8P-0.50-135

31 87-NB5-635-110 FF-CABLE,23P 1.00 750MM

32 87-NB5-636-110 FF-CABLE,12P 1.00 900MM

A 87-357-503-310 VT2+1.4-2

B 87-763-095-410 VFT2+3-8 W/O BLK

C 87-723-036-410 SCREW QT2+2-8 BLK

D 87-ZG5-238-010 S-SCREW,CUSH MD

E 87-067-746-010 SCREW,M 1.4-2(H0.5)

F 87-262-507-310 SCREW V+1.4-3

Other manuals for XR-H66MD

Table of contents

Popular Stereo System manuals by other brands

LG CM3330B owner's manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Denon

Denon UCD-250 Service manual

Sanyo

Sanyo DC-MX41i instruction manual

Sharp

Sharp CD-ES600V Service manual

Exibel

Exibel BDX600-UK user manual

Sanyo

Sanyo DC-F320 Service manual

Philips

Philips FWM583X Specifications

Sharp

Sharp CD-C462 Service manual

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio instruction manual

Cyrus

Cyrus Lyric user guide

Philips

Philips MCM159/98 quick start guide

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C owner's manual

RCA

RCA RS3965SB user manual

Sharp

Sharp XL-UH240 Operation manual

Philips

Philips FW 690 Instructions for use

LG FB165DAB Service manual

Aiwa XR-H66MD User manual

Popular Stereo System manuals by other brands
