AJA HA5-PLUS-R0 Original operating instructions

Installation & Operation Guide
Version 1.2
Published: August 5, 2014
Mini-Converter
HA5-Plus

HA5-Plus Mini-Converter v1.2 www.aja.com
2
Table of Contents
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Contacting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
I/O Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
User Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MiniConfig Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 2: Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
USB Control and Setup—Using AJA MiniConfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing MiniConfig on a Mac. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing MiniConfig on a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Running MiniConfig. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PC Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mac Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Saving Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operating MiniConfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Tabbed Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Input Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Input Video Selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Output Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Audio Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Audio Selections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Update Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Software Update Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Info Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix B: Safety and Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Federal Communications Commission (FCC) Compliance Notices . . . . . . . . . . . . . . . . . . 17
Class B Interference Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
FCC Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Canadian ICES Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
European Union and European Free Trade Association (EFTA)
Regulatory Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Korea KCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Taiwan Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Japanese Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Recycling Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

HA5-Plus Mini-Converter v1.2 www.aja.com
3
Translated Warning and Caution Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Before Operation Please Read These Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

HA5-Plus Mini-Converter v1.2 www.aja.com
4
Notices
Trademarks
AJA®, lo®, Ki Pro®, KONA®, KUMO®,T-TAP®, Because it matters.® and ROI® are registered
trademarks of AJA Video Systems, Inc. in the United States. AJA and Ki Pro are trademarks
of AJA Video Systems, Inc. registered in other countries. AJA Control Room™, CION™,
Corvid Ultra™, FiDO™, Science of the Beautiful™, TruScale™, TruZoom™, V2Analog™ and
V2Digital™ are trademarks of AJA Video Systems, Inc.
AirPort, Apple, Apple logo, AppleShare, AppleTalk, FireWire, iPod, iPod touch, Mac and
Macintosh are registered trademarks of Apple Inc. Final Cut Pro, QuickTime and
QuickTime logo are trademarks of Apple Inc.
Avid, Avid DNxHD and Media Composer are registered trademarks of Avid Technology,
Inc.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
DVI is a registered trademark of DDWG.
TASCAM is a registered trademark of TEAC Corporation.
Dolby® and the double-D Dolby logo are registered trademarks of Dolby Laboratories
Licensing Corporation.
All other trademarks are the property of their respective holders.
Copyright
Copyright © 2014 AJA Video Systems, Inc. All rights reserved. All information in this
manual is subject to change without notice. No part of the document may be
reproduced or transmitted in any form, or by any means, electronic or mechanical,
including photocopying or recording, without the express written permission of AJA
Video Systems, Inc.
Contacting Support
When calling for support, have all information at hand prior to calling.
To contact AJA for sales or support, use any of the following methods:
Telephone: [phone]
FAX: [phone]
Web: http://www.aja.com
Support Email: [email protected]
Sales Email: [email protected]

HA5-Plus Mini-Converter v1.2 www.aja.com
5
Chapter 1: Introduction
Overview
The HA5-Plus converts HDMI to 3G, HD, or SD SDI. Up to eight channels of HDMI audio
are embedded into the SDI output allowing a convenient single cable audio/video
connection. Two external analog audio inputs can replace two of these embedded audio
channels, if desired. The HA5-Plus supports long HDMI cables on the input. The HA5-Plus
is useful for connecting HDMI cameras and other sources to SDI capture cards and
equipment.
Features • HDMI to 3G/HD/SD-SDI (see "Appendix A: Specifications on page 16" for a complete list of
supported inputs).
• Full 10-bit Conversion
• Full HDMI support including embedded audio
• Equalized HDMI input supports long HDMI cables up to 30m
• PLL clock filtering for low jitter SDI outputs
• Lock LED shows type of input source: SD (green), HD (red), or 3G (amber)
• Unbalanced analog audio input (2 RCA)
• Accepts 8 channels of HDMI embedded audio
• Outputs 8 channels of SDI embedded audio (Channels 1-8 or 9-16)
• HDMI cable supplied
• Uses universal input +5V power supply AJA model DWP-U-R1 (included)
NOTE: The HA5-Plus will not pass HDMI video with HDCP copy protection.

HA5-Plus Mini-Converter v1.2 www.aja.com
6
Block Diagram
Figure 1. HA5-Plus Converter, Simplified Block Diagram
Audio
The HA5-Plus converter supports 8 audio channels (4 stereo pairs) at 24-bit/48 KHz which
it dis-embeds from HDMI and embeds into SDI. For proper embedding, audio must be
synchronous to video. If audio is not synchronous with video or the sample rate is not 48
KHz, then MiniConfig must be used to set the Sample Rate Converter to convert audio to
24-bit/48 KHz and then synchronize it with input video before embedding.
I/O Connections
Figure 2. HA5-Plus Converter
NOTE: The Lock LED indicates valid input video by color. Green is SD video, red is HD video,
amber is 3G video, off is no input.
A/D
Converter
8 Channel
Audio Sample Rate
Converter
Embed
Audio
HDMI
Processing
HDMI
Receiver
HDMI Cable
Equalizer
HDMI
In SDI ou t
Analog
Audio In 1
(RCA)
Analog
Audio In 2
(RCA)
USB Port
(connect to
PC or Mac)
Video
Audio
MiniCong Control
USB
Port
3G/HD/SD-SDI
Output BNC
Signal
Presence
Lock LED 2 Channel
Unbalanced
Analog Audio
In (RCA Jacks)
DC
Power
Input
Power
LED
HDMI
Input
Connector

HA5-Plus Mini-Converter v1.2 www.aja.com
7
User Controls
MiniConfig Control Auto controls configures the unit automatically to match the input and output video
parameters. Advanced MiniConfig control supports setting the RGB video range, and
adjusting audio input, conversion, and routing to embedded HDMI audio.
Configuration set via MiniConfig is stored in the HA5-Plus unit through subsequent
power cycles.
Installation
Typically, HA5-Plus installation consists of the following steps:
1. Ensure the HA5-Plus is disconnected from power.
2. Connect equipment to the converter HDMI input connector, the output BNC
connector, and the analog audio inputs (if used).
3. Connect audio equipment to RCA connectors (optional)
4. Apply power to the converter (AJA power supply included).
5. The converter will now run using the default factory settings. If you wish to alter the
factory settings, you’ll need to:
• Install the AJA MiniConfig software (supplied on CD) on your computer
• Attach the converter via USB
• Make your changes using MiniConfig setup screens.
6. This process is detailed in “USB Control and Setup—Using AJA MiniConfig” on page 8.

HA5-Plus Mini-Converter v1.2 www.aja.com
8
Chapter 2: Operation
USB Control and Setup—Using AJA MiniConfig
The HA5-Plus can usually be used right out of the box for most applications since it is
designed to recognize inputs and perform standard actions automatically by default.
However you can also manually configure the HA5-Plus using a supplied software
application for PCs and Macs called “MiniConfig.” This same application can be used to
update Mini-Converter firmware released by AJA.
Installing
MiniConfig on a Mac
To install the application on a Mac, insert the CD supplied with the
Mini-Converter into the computer, drag the “AJA MiniConfig”
application for your platform (Mac or PC) to your desktop or an
applications folder.
NOTE: Macintosh computers must be Intel-based (G5, G4 and earlier models will not work with
MiniConfig).
Installing
MiniConfig on a PC
To install the application on a Windows PC, insert the CD supplied with the Mini-
Converter into the computer, locate the “MiniInstaller” application, and then double-
click it.
Figure 3. MiniConfig Setup Wizard on PC
A Setup Wizard will guide you through the installation. Just click Next to begin.
Answer all questions in the subsequent dialogues; when done, you will be able to locate
the MiniConfig application in the AJA folder in the Programs listing.
Running MiniConfig Connect the Mini-Converter to the PC or Mac via the supplied USB cable. Connect the
external power supply (supplied) to the Mini-Converter.

HA5-Plus Mini-Converter v1.2 www.aja.com
9
PC Startup To run MiniConfig on a PC, find the AJA MiniConfig in the program list and locate the AJA
MiniConfig application.
Figure 4. PC MiniConfig Startup
Mac Startup To run MiniConfig on a Mac, double-click the Applications folder and locate the AJA
MiniConfig application. Double-click the application to launch it.
Figure 5. Mac MiniConfig Startup
NOTE: On a Mac, when the Mini-Converter is connected to the USB port, you may see an alert like
that shown below. If you do, press Cancel—this alert can be ignored.
Figure 6. Mac Network Message (ignore)
Saving Setups A File menu at the top of the MiniConfig application menu bar allows you to Save the
state of the Mini-Converter, with your current settings, to a file for later recall. This allows
you to set up the converter for different applications, storing each (with Save) to a unique
name for easy recall—using the Open menu item. A Revert to Factory Settings menu item
similarly allows you to change the settings back to AJA’s factory defaults. An Edit menu
allows you to cut and paste values to/from fields, just as in other applications.
Operating
MiniConfig
The MiniConfig application provides a graphic interface for viewing settings and
updating software. It consists of an information area at the top that shows the available
Mini-Converters attached to the computer via USB, with a graphical rendering of the
selected Mini-Converter showing all the connectors and their current state.
Colored text next to the connectors indicates the signal type and what the Mini-
Converter is doing:
•Blue text indicates the values automatically selected
•Black text indicates values that you have manually selected

HA5-Plus Mini-Converter v1.2 www.aja.com
10
•Red text indicates the Mini-Converter is not detecting a signal or cannot negotiate with
the attached device
NOTE: Even if no output device is detected, it still shows the signal it is outputting.
NOTE: Configuration settings in red will change based on the attached output device as well as input
signals. For improved accuracy and reliability, you should configure the Mini-Converter only
when the target output device is attached and input signals are supplied at the inputs.
Screens are virtually the same on both PC and Mac, with subtle differences that reflect
the general look of the platform environment.
Running Multiple Mini-
Converters:
MiniConfig can manage multiple AJA Mini-Converters connected via USB—even when
they are of differing types. However it only connects to one at a time. You can choose
which Mini-Converter you wish to control using the pulldown menu in the upper right
hand corner. If you want to configure and update multiple Mini-Converters in parallel,
you can do it by running multiple instances of the MiniConfig application and have each
control a different Mini-Converter.
Figure 7. MiniConfig, Video Screen
Selecting a Mini-Converter with the dropdown menu causes this application to connect
to the selected converter. The graphic of Mini-Converter and text below it provides:
• Type of converter
• Firmware version
• Serial number of the unit
A status field at the bottom of the screen shows if your application is connected and
communicating with the Mini-Converter.
Tabbed
screens
Message
showing
status
Firmware
version
and serial
number
Each connector is labeled with
the signals currently detected: Select a USB
port and an
attached
Mini-Converter
(name in
parentheses)

HA5-Plus Mini-Converter v1.2 www.aja.com
11
When configuring the Mini-Converter, select it from the top pulldown, view the current
settings and change any values. Making a change communicates that new value to the
Mini-Converter’s non-volatile memory.
Tabbed Screens The Tabs delineate control screens with groups of controls for each type of task to be
performed. The controls for the actual configuration parameters are specific to each
Mini-Converter type. Click on any of the tab buttons and the screen below will change to
match. Each of these screens are described on the following pages.
Input Tab Screen With your Mini-Converter connected and selected, you’ll click on the Input tab to view
and make changes to the converter’s input settings.
Any changes you make are immediately implemented and are saved, overwriting
previous settings.
Figure 8. MiniConfig, Input Tab Screen
Input Video Selections
RGB Range: Selects the Input Video Color Range. Choose Auto, SMPTE or Full color range.

HA5-Plus Mini-Converter v1.2 www.aja.com
12
Output Tab Screen Click on the Output tab to view and make changes to the HA5-Plus output settings.
Figure 9. MiniConfig, Output Tab Screen
3G Mode: This control selects the type of 3G SDI output. Choose 3G-Level A or 3G-Level B.

HA5-Plus Mini-Converter v1.2 www.aja.com
13
Audio Tab Screen Click on the Audio tab to view and make changes to the HA5-Plus audio settings.
Figure 10. MiniConfig, Audio Tab Screen
Audio Selections
NOTE: When using the DVI video protocol no audio is output, since that protocol is video only.
Input Select: Choose what audio channels are routed to the SDI output.
• HDMI - Only the audio channels from the HDMI input are embedded.
• Analog - Only the two analog input channels are embedded. You can choose which of
the embedded SDI channels will receive the analog audio, using the Analog Out Map
and Channel Select settings. The other channels will be muted.
• Analog + HDMI - Both the analog inputs and HDMI audio are embedded. You can
choose which of the HDMI channels will be replaced by the two analog audio inputs,
using the Analog Out Map and Channel Select settings.
• None - No audio will be embedded. All channels are muted.
HDMI Conversion: Choose the audio conversion to be performed on the incoming HDMI audio.
• Convert Rate - The HDMI audio will be converted, if necessary, to 24-bit/48 KHz audio.
• Pass Through - The HDMI audio will be passed to the SDI embedded audio channels
without conversion.
Analog Out Map: Permits selecting the pair of SDI embedded audio channels that will receive the analog
audio from the RCA connectors. The audio pair replaced depends on the Channel Select
setting below, and your choice of Ch 1-2 through Ch 7-8 that correspond to that set of
embedded channels.
Channel Select: Choose which set of 8 channels (4 pairs) of embedded audio the SDI output will carry.
Select Channels 1-8 or Channels 9-16.

HA5-Plus Mini-Converter v1.2 www.aja.com
14
Update Tab Screen Use this Update screen to view the software version currently installed on the converter
or install new software.
Figure 11. MiniConfig, Update Screen
NOTE: When discussing Mini-Converters, “Firmware” is software that will be stored in the Mini-
Converter’s non-volatile memory and used when it is powered up. This is something different
than the MiniConfig application software. The version numbers shown in the Update screen
refer only to the firmware.
The following fields and control are present in this screen:
Installed: This field shows the version of the firmware currently installed inside the Mini-Converter.
Desired: This field shows the version of firmware embedded in the MiniConfig application which
you can install into the Mini-Converter by clicking the Update button.
Update: This button initiates a software update operation loading the “Desired” version of
firmware into the Mini-Converter’s non-volatile memory.
Progress: This indicator bar shows the progress of software being installed.
Software Update
Procedure
1. Check the AJA website for new MiniConfig software for your Mini-Converter. If new
software is found, download it and uncompress the file archive (zip). Here is the URL
to use when checking:
http://www.aja.com/en/products/mini-converters/mini-config-software
2. Connect the Mini-Converter to a Mac or PC via a USB port on the computer and run
the new MiniConfig software just downloaded.
3. Click on the Update tab screen.
4. Check the Installed version level against the Desired version level. If the Desired is
newer, then click the Update button to download the new firmware to the Mini-
Converter.

HA5-Plus Mini-Converter v1.2 www.aja.com
15
Progress will be shown via the Progress thermometer bar, and when completed an
“Update Succeeded” message appears.
Info Tab Screen This screen provides basic information about the Mini-Converter. This information is
mostly useful when calling AJA Support for service or technical support.
Figure 12. MiniConfig, Info Screen
Name: This field allows you to give your Mini-Converter a name. This may be useful if you have
several Mini-Converters attached to a Mac/PC via USB so you can distinguish one of them
easily (especially if they’re the same model).
Type: This is the factory set model name of the Mini-Converter (HA5-Plus).
Assembly: This is the factory assembly number.
Serial Number: This is the factory set unique serial number of your Hi5-Plus. If you ever call AJA Support
for service, you may be asked for this number.

HA5-Plus Mini-Converter v1.2 www.aja.com
16
Appendix A: Specifications
Video
Video Input HDMI
Input Formats: •525i,525p
•625i,625p
• 720p 50/59.94/60
• 1080i 50/59.94/60
• 1080p23.98/24/25/29.97/30/50/59.94/60
• 2K 1080p23.98/24/25/29.97/30/50/59.94/60
Video Output SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 1 x BNC
Output Formats: • 525i 29.97
• 625i 25
• 720p 50, 59.94, 60
• 1080i 25, 29.97, 30
• 1080p 23.98, 24, 25, 29.97, 30
• 1080p 50, 59.94, 60 - SMPTE 425-1 Level A/Level B Mapping structure 1
(1920X1080 4:2:2 10-bit YCbCr)
• 2K 1080p23.98/24/25/29.97/30/50/59.94/60
(2048X1080 4:2:2 10-bit YCbCr)
HDCP Content not supported
Audio
HDMI Audio Input Eight channels (4 pairs) of embedded audio supported
Rates supported: • 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz
Analog Audio Input Unbalanced, -10 db, 2 x RCA
SDI Audio Output Eight channels (4 pairs) of embedded audio (24-bit/48 KHz)
Embed to either SDI audio Ch 1-8 or Ch 9-12
Physical
Size 4.6" x 2.4" x 1" (117 x 61 x 25 mm)
Power Uses AJA Power Supply model DWP-U-R1 (included)
100-240V, 50/60Hz Universal Input
+5-20V DC, 3 Watts

HA5-Plus Mini-Converter v1.2 www.aja.com
17
Appendix B: Safety and Compliance
Federal Communications Commission (FCC) Compliance Notices
Class B Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Canadian ICES Statement
Canadian Department of Communications Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio-noise emissions from a
digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications. This Class B digital apparatus complies with Canadian
ICES-003.
Règlement sur le brouillage radioélectrique du ministère des Communications
Cet appareil numérique respecte les limites de bruits radioélectriques visant les appareils
numériques de classe B prescrites dans le Règlement sur le brouillage radioélectrique du
ministère des Communications du Canada. Cet appareil numérique de la Classe B est
conforme à la norme NMB-003 du Canada.

HA5-Plus Mini-Converter v1.2 www.aja.com
18
European Union and European Free Trade Association (EFTA)
Regulatory Compliance
This equipment may be operated in the countries that comprise the member countries
of the European Union and the European Free Trade Association. These countries, listed
in the following paragraph, are referred to as The European Community throughout this
document:
AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA,
FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA,
LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA,
SLOVENIA, SPAIN, SWEDEN, UNITED KINGDOM, ICELAND, LICHTENSTEIN, NORWAY,
SWITZERLAND
Declaration of
Conformity
Marking by this symbol indicates compliance with the Essential Requirements of the EMC
Directive of the European Union 2004/108/EC.
This equipment meets the following conformance standards:
Safety:: CB- IEC 60065:2001 + A1:2005
NRTL - UL 60065:2003 R11.06, CSA C22.2 NO. 60065:2003 + A1:06
GS - EN 60065:2002 + A1
Additional licenses issued for specific countries available on request.
Emissions:: EN 55103-1: 1996
EN61000-3-2:2006, EN61000-3-3:1995 +A1:2001 +A2:2005
Immunity:: EN 55103-2: 1996
EN61000-4-2:1995 + A1:1999 + A2:2001, EN61000-4-3:2006, EN61000-4-4:2004,
EN 61000-4-5: 2005, EN 610004-6:2007, EN61000-4-11:2004
The product is also licensed for additional country specific standards as required for the
International Marketplace.
Warning!
This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case, the user may be required to take appropriate measures.
Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse B. In Wohnbereichen
können bei Betrieb dieses Gerätes Rundfunkstörungen auftreten, in welchen Fällen
der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist.
Attention! Ceci est un produit de Classe B. Dans un environnement domestique, ce
produit risque de créer des interférences radioélectriques, il appartiendra alors à
l?utilisateur de prendre les mesures spécifiques appropriées.

HA5-Plus Mini-Converter v1.2 www.aja.com
19
Korea KCC Compliance Statement
Taiwan Compliance Statement
This is a Class B product based on the standard of the Bureau of Standards, Metrology
and Inspection (BSMI) CNS 13438, Class B.
Japanese Compliance Statement
This is a Class B product based on the standard of the VCCI Council. If this is used near a
radio or television receiver in a domestic environment, it may cause radio interference.
Install and use the equipment according to the instruction manual.
Recycling Notice
This symbol on the product or its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to
dispose of your waste equipment by handing it over to a designated collection point
for the recycling of waste electrical and electronic equipment. The separate collection
and recycling of your waste equipment at the time of disposal will help conserve
natural resources and ensure that it is recycled in a manner that protects human
health and the environment. For more information about where you can drop off your
waste for recycling, please contact your local authority, or where you purchased your
product.

HA5-Plus Mini-Converter v1.2 www.aja.com
20
Translated Warning and Caution Messages
The following caution statements, warning conventions, and warning messages apply to
this product and manual.
Before Operation Please Read These Instructions
Warning!
Read and follow all warning notices and instructions marked on the product or
included in the documentation.
Avertissement ! Lisez et conformez-vous à tous les avis et instructions
d'avertissement indiqués sur le produit ou dans la documentation.
Warnung! Lesen und befolgen Sie die Warnhinweise und Anweisungen, die auf dem
Produkt angebracht oder in der Dokumentation enthalten sind.
¡Advertencia! Lea y siga todas las instrucciones y advertencias marcadas en el
producto o incluidas en la documentación.
Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na
documentação.
Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi
nella documentazione.
Warning!
Do not use this device near water and clean only with a dry cloth.
Avertissement! N'utilisez pas cet appareil près de l'eau et nettoyez-le seulement avec
un tissu sec..
Warnung! Das Gerät nicht in der Nähe von Wasser verwenden und nur mit einem
trockenen Tuch säubern.
¡Advertencia! No utilice este dispositivo cerca del agua y límpielo solamente con un
paño seco.
Aviso! Não utilize este dispositivo perto da água e limpe-o somente com um pano
seco.
Avviso! Non utilizzare questo dispositivo vicino all'acqua e pulirlo soltanto con un
panno asciutto.
