AJAX Socket Type F User manual

Socket (type F) User Manual
Updated April 1, 2022
Socket (type F) is a wireless indoor smart plug with the power-consumption
meter for indoor use. Designed as a European plug adapter (type F), Socket
(type F) controls the power supply of electrical appliances with a load of up to
2.5 kW. Socket (type F) indicates the load level and is protected from overload.
Connecting to the Ajax security system via a secured radio protocol,
the device supports communication at a distance of up to 1,000 m in line of
sight.
Socket (type F) operates with only and does not support connecting via
or integration modules.
Use scenarios to program actions of (Relay, WallSwitch or
Socket (type F)) in response to an alarm, press or a schedule. A scenario
can be created remotely in the Ajax app.
Jeweller
Ajax hubs
ocBridge Plus uartBridge
automation devices
Button
How to create and congure a scenario in the Ajax security system

Two Socket models are available: with a (type G) and a (type F).
Functional Elements
Operating Principle
UK plug European plug
Buy smart plug Socket (type F)
1. Two-pin socket.
2. LED border.
3. QR Code.
4. Two-pin plug.

Socket (type F) switches on/off the 230 V~ power supply, opening one pole by
the user command in the or automatically according to ,
, .
Socket (type F) is protected against voltage overload (exceeding the range of
184–253 V~) or overcurrent (exceeding 11 A). In case of overload, the power
supply switches off, resuming automatically when voltage restored to normal
values. In case of overcurrent, the power supply switches off automatically, but
can only be restored manually by the user command in the Ajax app.
The maximum resistive load is 2.5 kW. When using inductive or capacitive loads, the
maximum switching current is reduced to 8 A at 230 V~.
Socket (type F) with rmware version 5.54.1.0 and higher can operate in pulse or
bistable mode. With this rmware version you can also select the relay contact
status:
Socket (type F) with rmware version below 5.54.1.0 only works in bistability
mode with a normally open contact.
In the app, users can check the power or amount of energy consumed by
electrical appliances connected via Socket (type F).
At low loads (up to 25 W), current and power consumption indications may be displayed
incorrectly due to hardware limitations.
Ajax app a scenario
Button press a schedule
Normally closed — Socket (type F) stops supplying power when activated,
and resumes when turned off.
Normally open — Socket (type F) supplies power when activated, and stops
feeding when turned off.
How to nd out the rmware version of the device?

Connecting
Before connecting the device
Only users with administrator rights can add a device to the app.
To pair Socket (type F) with the hub
1. Switch on the hub and check its Internet connection (the logo glows white
or green).
2. Install the . Create the account, add the hub to the app, and create
at least one room.
Ajax app
3. Make sure that the hub is not armed, and it does not update by checking its
status in the Ajax app.
1. Click Add device in the Ajax app.
2. Name the device, scan it, or enter the QR code manually (located on the
case and packaging), select the room.
3. Plug the Socket (type F) into a power outlet and wait 30 seconds — the LED
frame will ash green.
4. Click Add — the countdown will begin.
5. Socket (type F) will appear in the list of hub devices.

The device statuses update depends on the ping interval set in the hub settings.
The default value is 36 seconds.
If the device failed to pair, wait 30 seconds and then retry.
For detection and pairing to occur, the device should be located in the coverage
area of the hub’s wireless network (at the same object). A connection request is
transmitted only at the moment of switching on the device.
When pairing the hub with the smart plug that was previously paired with
another hub, make sure that it was unpaired with a former hub in the Ajax app.
For correct unpairing, the device should be in the coverage area of the hub’s
wireless network (at the same object): when unpaired correctly, the Socket (type
F) LED frame continuously blinks green.
If the device has not been correctly unpaired, do the following to connect it to
the new hub:
Socket (type F) can be connected to one hub only.
Icons
1. Make sure that Socket (type F) is outside the coverage area of the former
hub’s wireless network (the indicator of the communication level between
the device and the hub in the app is crossed out).
2. Select the hub with which you want to pair Socket (type F).
3. Click Add Device.
4. Name the device, scan or enter the QR code manually (located on the case
and packaging), select the room.
5. Click Add — the countdown will begin.
6. During the countdown, for a few seconds, give Socket (type F) at least 25 W
load (by connecting and disconnecting a working kettle or lamp).
7. Socket (type F) will appear in the list of hub devices.

The icons show some of the Socket (type F) states. You can view them in the
Ajax app on the Devices tab.
Icon Meaning
Jeweller signal strength — displays the signal strength between the hub and
the smart plug.
The device is connected via a .
Current protection is activated.
Voltage protection is activated.
Temperature protection is activated.
States
The states include information about the device and its operating parameters.
Socket (type G) states are available in the Ajax app. To access them:
Parameter Value
Jeweller Signal Strength
Jeweller is a protocol for the transmission of
events and alarms.
The eld displays the Jeweller signal strength
between a hub or a range extender and Socket
(type F).
Recommended values: 2–3 bars.
Connection via Jeweller
Connection status between a hub or a range
extender and a smart plug:
ReX Displays the connection status of the plug to
radio signal range extender
1. Go to the Devices tab.
2. Select Socket (type F) in the list.
More about Jeweller
Online — the smart plug is connected.
Oine — no connection with the smart plug.

the :
The eld is displayed if the plug is operated via
the radio signal range extender.
Active
The smart plug state:
The eld is displayed if Socket (type F) operates
in the bistable mode.
Voltage
The value of voltage commuted by Socket (type
F).
The frequency of value updates depends on the
Jeweller settings. The default value is 36
seconds.
Values of voltage are displayed in increments of
1 V AC.
Current
The value of current commuted by Socket (type
F).
The frequency of value updates depends on the
Jeweller settings. The default value is 36
seconds.
Values of current are displayed in increments of
10 mA.
Current Protection Indicates whether the overcurrent protection is
enabled.
Voltage Protection Voltage protection state:
radio signal range extender
Online — the smart plug is connected.
Oine — no connection with the smart plug.
Yes — plug contacts are closed. The
electrical appliance connected to the plug is
energized.
No — plug contacts are open. No current is
being supplied to the appliance connected
to the plug.
On — voltage protection is enabled. The plug
switches off automatically when the power
supply voltage exceeds 184–253 V~.

The smart plug will automatically continue to
operate when the voltage returns to normal.
Power
The power consumption of an appliance
connected to the smart plug.
The frequency of value updates depends on the
Jeweller settings. The default value is 36
seconds.
The power consumption values are displayed in
increments of 1 W.
Electric Energy Consumed
The electric power consumed by the device
connected to the Socket (type F).
The frequency of value updates depends on the
Jeweller settings. The default value is 36
seconds.
The counter is reset when the Socket (type F)
lose the power
Temporary Deactivation
Shows the state of the device temporary
deactivation function:
Firmware Smart plug rmware version.
Device ID Device ID/serial number. It can be found on the
plug box and its body.
Device No. The number of the smart socket loop (zone).
Settings
Off — voltage protection is disabled.
No — the device operates normally,
responds to commands, executes
scenarios, and transmits all events.
Entirely — the device is excluded from the
system operation. The smart plug doesn’t
respond to commands, doesn’t run
scenarios, and doesn’t transmit events.
Learn more

To change the smart plug settings in the Ajax app:
Setting Value
First eld
Socket (type F) name. It is displayed in SMS and
notications in the event feed.
Click on the pencil icon to change the device
name.
The name can contain 12 Cyrillic characters or
up to 24 Latin characters.
Room
Selection of Socket (type F) virtual room.
The room name is displayed in SMS and
notications in the event feed.
Mode
Selecting Socket (type F) operation mode:
Settings are available with rmware version
5.54.1.0 and higher.
Contact status Selection of the normal state of the plug
contacts:
1. Go to the Devices tab.
2. Select Socket (type F) in the list.
3. Go to Settings by clicking on the gear icon .
4. Set the required parameters.
5. Click Back to save the new settings.
Pulse — when activated, Socket (type F)
generates a pulse of a given duration
Bistable — Socket (type F), when activated,
changes the state of contacts to the opposite
(e.g., closed to open) when activated.
Normally closed (NC) — the plug contacts are
closed in the normal state. The electric
appliance connected to the plug is supplied
with current.

Pulse duration
Selection of the pulse duration: 0.5 to 255
seconds.
The setting is available when Socket (type F)
operates in the pulse mode.
Current Protection
If enabled, power supply switches off if the
current load exceeds 11A, if disabled the
threshold is 16A (or 13A for 5 seconds).
Voltage protection
When this option is active, the power of the
appliance connected to the plug will be cut off if
voltage exceeds 184–253 V~.
Indication The option of disabling the LED frame of the
device.
LED Brightness The option of adjusting the brightness of the LED
frame of the device (max or low).
Scenarios
Opens the menu for creating and conguring
automation scenarios.
Scenarios offer a brand-new level of property
protection. With them, the security system not
only noties about a threat but also actively
resists it.
Use scenarios to automate security. For example,
switch on lighting in the facility when an opening
detector raises an alarm.
Jeweller Signal Strength Test
Starts Jeweller signal strength test for Socket
(type F).
The test allows checking the Jeweller signal
strength and the stability of the connection
between a hub or a range extender and a smart
plug to choose the best place for installing the
device.
Normally open (NO) — the plug contacts are
open in the normal state. The electric
appliance connected to the plug is not
supplied with current.
Learn more
Learn more

User Guide Opens Socket (type F) user manual in the Ajax
app.
Temporary Deactivation
Allows temporarily disable the device without
removing it from the system.
Two options are available:
After deactivation, Socket (type F) will keep the
previous state: active or inactive.
Unpair Device Disconnects the device from the hub and deletes
its settings.
Indication
Socket (type F) informs the user of the power level consumed by connected
appliances using the LED.
If the load is more than 3 kW (purple), the current protection activates.
No — the device operates normally, responds
to commands, executes scenarios, and
transmits all events.
Entirely — the device is excluded from the
system operation. The smart plug doesn’t
respond to commands, doesn’t run scenarios,
and doesn’t transmit events.
Learn more

Load level Indication
No power on the Socket (type F) Don’t have any indication
Socket (type F) turned off Blue
Socket (type F) turned on, no load Green
~550 W Yellow
~1250 W Orange
~2000 W Red
~2500 W Dark red
~3000 W Purple
One or more types of protection triggered Smoothly lights up and goes out red
Hardware failure Quick red ashes
The exact power can be seen in the .
Functionality Testing
Socket (type F) functionality tests do not begin immediately, but not later than
over a single hub – smart plug polling period (36 seconds with the Jeweller
standard settings). You can change the ping period of devices in the Jeweller
menu of the hub settings.
To run a test, in the Ajax app:
Selection of the installation site
When choosing where to install Socket (type F), take into account the Jeweller
signal strength and the distance between the device and the hub or the
Ajax application
1. Select a hub if you have several or use a PRO app.
2. Go to the Devices tab.
3. Select Socket (type F) in the list.
4. Go to Settings .
5. Select and run the Jeweller Signal Strength Test.

presence of objects that obstruct the radio signal: walls, inter-oor slabs or large
structures located at the premises.
Socket (type F) must be installed with a stable Jeweller signal level of 2 to 3
bars.
To roughly calculate the signal strength at the place of installation, use our
. Use a if the signal
strength is less than 2 bars at the intended installation location.
Do not place Socket (type F):
Installation
radio
communication range calculator radio signal range extender
1. Outdoors. Doing so may cause the device to malfunction or not work
correctly.
2. Near metal objects or mirrors (e.g., in a metal cabinet). They can shield and
attenuate the radio signal.
3. Inside any premises with the temperature and humidity beyond permissible
limits. Doing so may cause the device to malfunction or not work correctly.
4. Close to radio interference sources: less than 1 meter away from the router
and power cables. This can cause a loss of connection between a hub or a
range extender and the smart plug.
5. In places with low or unstable signal strength. This can cause a loss of
connection between a hub or a range extender and the smart plug.

Before installing the smart plug, make sure that you have selected the optimal
location and that it complies with the requirements of this manual.
When installing and operating the device, follow the general electrical safety
rules for using electrical appliances and the requirements of electrical safety
regulations.
To install Socket (type F):
Socket (type F) will turn on within 3 seconds after connection. The device
indication will inform you that it is on.
Maintenance
The device does not require maintenance.
Tech specs
Actuating element Electromagnetic relay
Service life At least 200,000 switches
Voltage and type of external power supply 110–230 V~, 50/60 Hz
Voltage protection for 230 V mains Yes, 184–253 V~
Maximum load current 11 A (continuous), 13A (up to 5 s)
Operating modes
Pulse and bistable (rmware version is 5.54.1.0
or higher. Manufacture date from March 4,
2020)
Only bistable (rmware version under 5.54.1.0)
Pulse duration 0.5 to 255 seconds (rmware version is
5.54.1.0 or higher)
Maximum current protection Yes, 11 A if the protection is turned on, up to 13
A if the protection is turned off
Maximum temperature protection Yes, +85°С. The socket turns off automatically if
1. Select the plug into which you want to install the Socket (type F).
2. Plug the Socket (type F) in.

the temperature is exceeded
Electric shock protection class Class I (with grounding terminal)
Energy consumption parameter check Yes (current, voltage, power consumption)
Load indicator Yes
Output power (resistive load at 230 V) Up to 2.5 kW
Average energy consumption of the device on
standby Less than 1 W⋅h
Radio communication protocol
Jeweller
Radio frequency band
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sale.
Compatibility Operates with all Ajax , and
Maximum radio signal power 8,97 mW (limit 25 mW)
Radio signal modulation GFSK
Radio signal range Up to 1000 m (when there are no obstacles)
Installation method In power outlet
Operating temperature range From 0°С to +40°С
Operating humidity up to 75%
Protection class IP20
Overall dimensions 65.5 × 45 × 45 mm (with plug)
Weight 58 g
Service life 10 years
In case of using inductive or capacitance load, the maximum switched current is
reduced to 8 A at 230 V~!
Learn more
hubs radio
signal range extenders

Complete Set
Warranty
Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY
COMPANY products is valid for 2 years after the purchase.
If the device does not work correctly, you should rst contact the support
service—in half of the cases, technical issues can be solved remotely!
Customer support:
Compliance with standards
1. Socket (type F).
2. Quick Start Guide.
The full text of the warranty
User Agreement
suppor[email protected]

Subscribe to the newsletter about safe life. No spam
Subscribe
Email
