Uponor Smatrix Move PRO SPI Sensor Snow S-158 User manual

04 | 2017
Uponor Smatrix Move PRO
SPI Sensor Snow S-158
QUICK GUIDE
1
≥ 0,2 m ≥ 0,1 m
≤ 200m
A
B
≤
23 mm
https://www.uponor.com/smatrix/downloads.aspx

2
G
C D
E
H
F
BA
≤
23 mm
2

4
#
25 26
14
X-159
S-158
S-158
3
3
#
24 25 26
813
X-159
S-158
S-158
43 3/4
3 4
3
#
12
7
X-159
S-158 34
#
13
X-159
S-158 3
3

1088078 04_2017 INT Production: Uponor AB, MRY, Virsbo; Sweden
Uponor GmbH
Industriestraße 56, D-97437 Hassfurt, Germany
www.uponor.com
Uponor reserves the right to make changes, without prior notification, to the specification of
incorporated components in line with its policy of continuous improvement and development.
5
78 mm
63.5 mm
32 mm
60 mm 2500 mm
NEMA 6P / IP 68
-50...70 °C
6 x 0.15 mm2(≤25 m)
NTC 10
-50 °C...+100 °C, ±0.1 °C
220 Ω +/- 10%
0,1 A @24V
ROFF = ∞ Ω
RON < 2MΩ
