Akai ADV-63-DR User manual

17
EXPLODED VIEW
PANEL

18
EXPLODED VIEW PARTS LIST
PANEL
Ref. No. Description RS Part No. Mfr’s Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
(Open) Spring ROHS
LCD Bracket Real (E) ROHS
LCD DVD3030 TN POS 23X84MM Pin Type ROHS
CD 1007 Back Light CHT/Red ROHS
Panel Top (Black/White) N/SD DVD3032 ROHS
Panel Bottom W/O SD ROHS
AKAI Logo Silver Hot Stamp ROHS
Open Knob ROHS
EJ Knob (S.N0000) ROHS
Power Knob (S.N0000) ROHS
S-M Knob (S.N0000) ROHS
BND Knob (S.N0000) ROHS
AMS Knob (S.N0000) ROHS
TITL Knob (S.N0000) ROHS
1PAU Knob (S.N0000) ROHS
2SCN Knob (S,N0000) ROHS
3RPT Knob (S.N0000) ROHS
4SHF Knob (S.N0000) ROHS
5 Knob (S.N0000) ROHS
6 Knob (S.N0000) ROHS
MOD Knob (S.N0000) ROHS
DSP/SCN Knob (S.N0000) ROHS
EQ Knob (S.N0000) ROHS
VOL Knob (S.N1204) ROHS
FF/FW Knob (S.N0000) ROHS
CD Light ROHS
Volume Decoration Ring ROHS
Lens: DVD3032 W/IR N/RDS (S.N0000/White) (AKAI-AD-63
DR) ROHS
Key Board
Volume Encoder EC11E15D4MA1 POSTEC ROHS
Screw Ø2X8 BA/ST Black ROHS
3600-040205-00
3900-0E2004-00
2710-303001-01Y
0200-001007-02
5100-303221-31W
5100-303223-000
5200-0G6240-01
5200-303224-000
5200-303225-310
5200-303226-310
5200-303227-320
5200-303228-310
5200-303228-312
5200-303228-313
5200-303228-340
5200-303228-350
5200-303228-360
5200-303228-370
5200-303228-380
5200-303228-390
5200-303228-314
5200-303229-320
5200-303230-320
5200-303232-800
5200-303234-300
5200-303235-000
5200-303238-000
5300-303236-37W
1121-303230-3313
1800-000115-00P
4000-012008-21

19
EXPLODED VIEW
CABINET

20
EXPLODED VIEW PARTS LIST
CABINET
Ref. No. Description RS Part No. Mfr’s Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Panel
Ring/ABS +SPY (S.N0000) ROHS
Base (W/O SD) ROHS
Rear-right Cabinet W/Spring For DVD-Wire ROHS
(DVD2685)+(HD65)+(M. Motor)With Convert PCB ROHS
Left Cabinet T-Heat Sink W/Spring ROHS
Top Cabinet ROHS
Bottom Cabinet ROHS
Main Fiber ROHS
Main Board
Mounting Box ROHS
Shade ROHS
CD Windows Sheet ROHS
Lock Panel Knob ROHS
Spring For EJ Panel CD200 ROHS
Hook Knob ROHS
Spring For Hook Knob CD200 ROHS
Deck Front BKT (Detachable) ROHS
Deck Rear BKT For DVD ROHS
Shield Cover (Mitsumi Tuner) ROHS
Mitsumi Tuner FAE376-P01(V-Type) ROHS
Power IC BKT ROHS
12VDC Fan 40X40X10MM Wire 80MM JS2.0 ROHS
Wire Clip 1.0MM ROHS
Screw Ø5X18 HH ROHS
Spring Washer M5 ROHS
Hexagon Nut M5 ROHS
Fan Cover ROHS
TV Tuner TALN-S200T(PAL+SECAM)(H-Type) LG ROHS
Screw Ø2.6 X 5 BH/TAPTITE ROHS
Screw Ø2.6 X 6 BH/MS ROHS
Screw Ø2.6 X 6 PH/MS Black ROHS
Screw Ø2.6 X 8 BH/MS ROHS
Screw Ø2.6 X 16MM BH/MS ROHS
Screw M2.6 X 20 PH/MS ROHS
Screw Ø2.6 X 4 BH/MS ROHS
5100-0E2022-30
5100-0H3927-00
6120-300003-002
9400-022685-01
6100-300004-003
6100-300001-000
6100-300002-000
3500-300001-000
1121-500031-0813
6100-300005-000
8100-069005-03
4300-0A3103-00
5200-0E2041-00
3600-0E2001-00
5200-0E2040-01
3600-0E2002-00
3900-300001-000
3900-300005-000
3900-0N2047-00
2900-000376-03
3900-300006-000
4900-004010-13
3900-0B1415-00
4000-005018-04
3500-050001-00
3500-040005-00
3900-0D2109-00
2900-S20000-00
4000-002605-03
4000-002606-01
4000-002606-20
4000-002608-01
4000-002616-01
4000-002620-00
4000-002604-01
