SERVICE MANUAL
Models:
ACR46MPS
CD/MP3–RECIVER
www.akai.ru
ACR46MP

AKAI ACR-46MP
ITEM PARTS NO. DESCRIPTION-2 LOCATION PRICE REMARK
1 83-CM110-SB01-A CM110B-CD Deck
2 83-CM203-MB08-B CM203 2×2V RDS
3 84-CM203-KB06-A CM203A-SCE-RDS
4 84-CM203-SA00-A CM203
5 84-RMT203-0022-0 RDS NEW FORYOU REM
6 11-0901-0075-A IC TDA7384 IC801
7 11-1500-0002-A XT 4.500MHZ (-20°C~+70°C) HC XT401
8 11-1500-0004-A XT 16.9344MHZ (-20°C~+70°C) X1
9 11-1500-0010-A CRYSTAL 4.332MHZ DIP W/18PF XT490
10 11-2701-0001-A FM/AM TUNER(CET-7000AFL) TUN101
11 11-3501-0008-B CD DECK CL-C01 SHINWA VER.B
12 13-0706-0001-0 RIM FOR 203A (BIG)
13 15-0700-0001-A PANEL BOX FOR CMV100
14 11-3101-0020-0 20PIN PWR/SPK EST-KNT-20-04 SK801
15 11-3101-0014-0 20PIN PWR/SPK EST-KNT-20-05
16 11-0321-0005-0 CHOKE INDUCTOR 470μHCM203) L801
17 11-0311-4R70-0 COIL 4.7μH 3X5MM L201
18 11-0402-4148-A DIODE IN4148 1/2W D1A,D103,D107~109,D401,D404~405,D408,D414,D420,D429~
430,D425,D501~502,D802,D805~
19 11-0406-0005-0 LED 2.2V 10MA GREEN SMT 0603 LED102~103,LED106~117,LED119~120
20 11-0406-0007-0 LED 3.5V 20MA BLUE SMT 0603 LED101,LED104~105
21 11-0406-0011-0 PHOTOTRANSISTOR IR928-6C D105.D106
22 11-0421-0001-0 REMOTE-CRM HEADER(IRM2038F4) REM1
23 11-0501-0001-A TR DTC343TK(SMT SOT-23) Q501~504
24 11-0501-0001-A TR DTC343TK(SMT SOT-23) Q102~104
25 11-0501-0002-A TR 3904(SMT SOT-23)NPN Q101~4,Q109,Q201,Q203,Q410,Q505,Q802,Q804~5,Q813
26 11-0501-0003-A TR 3906(SMT SOT-23)PNP Q202,Q806,Q801,Q110,Q1A
27 11-0501-0003-A TR 3906(SMT SOT-23)PNP Q201
28 11-0501-0009-0 TR S8050 SMT SOT-23 RQ1
29 11-0512-0011-A T.R.BD435S SAMSUNG Q808

30 11-0522-0001-A TR B1243 POWER SWITCH Q803,Q814
31 11-0901-0002-A IC DRAM 4MX4 TSOP 3.3V IC3
32 11-0901-0003-A IC.S1L9226 IC201
33 11-0901-0004-A IC.KA9259D IC5
34 11-0901-0005-A IC S5L9276 IC1
35 11-0901-0006-A IC.S5L9290 IC301
36 11-0901-0011-A IC.PT2313L SO-28 IC501
37 11-0901-0016-A IC.KIA7035AF TO-92 IC402
38 11-0901-0024-0 IC 78L05 REGULATOR ST IC803
39 11-0901-0026-A IC 78L18 REGULATOR ST IC802
40 11-0901-0032-B IC.DSC-790R IC401
41 11-0901-0036-0 IC.AMS1085CT-3V3 TO-220 IC806
42 11-0901-0038-A IC BU1924 RDS DEMOUDULATOR IC490
43 11-0901-0055-A IC L7809 REGULATOR ST IC804
44 11-0901-0059-A IC LC75823E LCD DRIVE IC101
45 11-0901-0063-A IC MC 4558 SOP-8 IC601~602
46 11-0901-0092-0 IC SC6121 SOP20 IC1
47 11-1500-0012-0 CER RESONATOR 455KHZ RCT1
48 11-1841-0061-0 PCB CM203 FB FLEX FPC
49 11-2001-0010-1 CD310 DECTOR (GAODY) 2PIN EJSW
50 11-2011-0002-0 KEY SWITCH 4.3MM SW101~118
51 11-2011-0005-A CD DETECTOR CDX100 CLSW1
52 11-2101-0001-0 15A DIN FUSE
53 11-2501-0002-0 ANT SOCKET W/GND L=230MM ANT
54 11-2511-0001-0 INFRARED LED 3MM RD1
55 11-2602-0002-0 CM203 LCD TCM3620 MASK TN NEGTATIVE LCD101
56 11-3101-0012-0 P=2.0MM 3PIN WAFER CON803A
57 11-3101-0013-A 18PIN SOCKET MALE DTC-P1803 CN101
58 11-3102-0010-0 3PIN FLAT CABLE COLOR P=2.0 SOLDER IN SENSOR PCB
59 11-3102-0020-A 18PIN SOCKET FMALE DTC-R1803
60 11-3111-0003-A 18PIN FPC SOCKET 1.0 CON403
61 11-3111-0004-A 15PIN FPC SOCKET PITCH=1.0MM CN212
62 11-3111-0007-0 25PIN FPC SOCKET 1.25 CON402
63 11-3300-0602-0 LCD BACKLIGHT FOR CM203 LED118

64 11-3400-0003-0 ZEBRA STRIP FOR CM203
65 13-0106-0701-0 PANEL-FRONT FOR 203 SILVER
66 13-0206-0001-1 PANEL BACK FOR 203
67 13-0206-0003-1 COVER ROTATE BRACKET
68 13-0206-0004-1 TRAY COVER FOR 203
69 13-0206-0005-0 BOTTOM COVER ABS FOR RMT203
70 13-0406-0813-0 LENS CM203 SCE/RDS NEW FORYOU
71 13-0506-0001-0 KNOB-SELECT FOR 203 NATVRAL
72 13-0506-0002-1 KNOB-S-OPEN FOR 203 NATVRAL
73 13-0506-0003-0 KNOB-OPEN FOR 203 NATVRAL
74 13-0506-0801-0 KNOB-EJECT FOR 203 BLACK
75 13-0506-0802-0 KNOB-PWR-SRC FOR 203 BLACK
76 13-0506-0803-0 KNOB-NUMBER FOR 203 BLACK
77 13-0506-0804-0 KNOB-SEEK FOR 203 IN BLACK
78 13-0706-0501-0 TRIM-RIM FOR 203
79 13-0706-0502-0 RING-WING FOR 203
80 13-0806-0002-0 HOOK SIDE FOR 203 HOOK SIDE FOR 203
81 13-0806-0003-1 HOOK FRONT FOR 203
82 13-0806-0006-1 E SENSOR SWITCH BRACKET 203
83 13-0809-0001-0 LOCKER FOR CM310
84 13-0809-0002-1 PUSH FOR CM310
85 13-0906-0001-0 REFECTOR FOR 203
86 13-1106-0001-A GEAR FOR 203
87 13-1106-0002-A DAMPER FOR 203
88 13-2300-0001-0 ISOLATOR STEP WASHER
89 13-2300-0002-0 E-WASHER FOR 203
90 14-0106-0001-0 SHUTOUT-SHEET FOR 203
91 14-0106-0003-0 HOLD-SEEK FOR 203
92 14-0107-0001-0 WASHER-22-025MM FOR 206
93 14-0206-0001-0 SPRING FOR SLIDE DOWN FOR 203
94 14-0206-0002-0 SPRING FPC SHAFT FOR 203
95 14-0206-0003-0 SPRING SENSOR SWITCH BRACKET
96 14-0206-0004-0 SPRING SIDE LOCK FOR 203
97 14-0206-0005-0 SPRING-S-OPEN FOR 203

98 14-0206-0006-0 SPRING-OPEN FOR 203
99 14-0209-0001-0 LOCKER SPRING FOR CM310
100 14-0306-0002-A LCD-COVER FOR 203
101 14-0306-0003-A SHAFT-ARM FOR 203
102 14-0306-0004-A SIDE-GUIDE-BRACKET FOR 203 R
103 14-0306-0005-A SIDE-GUIDE-BRACKET(L) FOR 203
104 14-0306-0006-A ROTATE-MOUNT-BRACKET FOR 203
105 14-0306-0008-A LOCK BRACKET FOR 203
106 14-0306-0009-A DECK SUPPORT BRACKE KOMEC 203
107 14-0306-0010-A BRACKET FOR AMP IC FOR 203
108 14-0306-0012-C TRAY FOR FRONT PANEL
109 14-0306-0013-B PANEL LOCKET FOR 203
110 14-0306-0014-C BRACKET SOCKET FOR 203
111 14-0309-0001-0 REAR BRACKET FOR KOMEC CM310
112 14-0406-0001-B FRAME FOR 203
113 14-0506-0001-C TOP COVER
114 14-0606-0001-0 SHORT SHEET FOR CM203
115 14-0706-0001-0 FPC SHAFT FOR 203
116 14-0706-0002-1 ROTATE SHAFE R FOR 203
117 14-0706-0003-1 ROTATE SHAFE L FOR 203
118 14-0906-0002-1 HEATSINK
119 14-0907-0002-A HEATSINK IC 7809&BD435 FOR 206
120 14-2106-0001-0 GEAR SECTION FOR CD203
121 14-2906-0003-0 SIDE LOCK PIN
122 14-2909-0001-0 PANEL LOCATED PIN FOR CM310
123 16-0100-0013-0 25PIN FFC 1.25MM L=100MM CN1
