Akai ASB70I User manual

CD Music Station with Universal
Dock for iPod
Gebruikershandleiding- Manuel d'utilisation-Manual de Instrucciones

IMPORTANT SAFETY INSTRUCTIONS............................................................ ... ..................... 2
PRECAUTIONS FOR UNIT......................................................................................................... 3
PRECAUTIONS FOR DISCS..........................................................
............................................. 3
TABLE OF CONTENTS............................................................................................................... 1
IMPORTANT NOTES................................................................................................................. 4
PREPARATION FOR USE.............................................................................. ............................ 5
LOCATION CONTROLS AND INDICATOR................................................................................ 6
REMOTE CONTROL.......................................................................................
........................... 7
CONNECTING EXTERNAL DEVICES............................. .......................... ................................ 8
OPERTING INSTRUCTIONS...................................................................................................... 9
RADIO OPERATION.....................................................................................
............................ 14
CD OPERATION....................................................................................................................... 17
PLAYING MP3 & WINDOWS MEDIA FORMATTED AUDIO.................................................... 24
USB OPERATION..................................................................................................................... 31
IPOD OPERATION.................................................................................................................... 32
SPECIAL FUNCTIONS...........................................................
.................................................. 35
CARE AND MAINTENANCE.................................................................................................... 40
TROUBLESHOOTING GUIDE....................................................................
............................. 41
TECHNICAL SPECIFICATION.................................................................... ............................. 42
TABLE OF CONTENTS
GB 1
Model No: ASB70i
Serial Number:
CLASS 1 LASER PRODUCT
This product contains a low power Laser Device.
BEFORE WE BEGIN
Thank you .......................
for purchasing this audio product. This is your assurance of quality, performance and value.
Our engineers have included many useful and convenient features in this product. Please be sure
to read this Owner's Manual completely to make sure you are getting the maximum benefit from each
feature.
This product was manufactured using the highest quality components and standards of
workmanship. It was tested by inspectors and found to be in perfect working order before it left our
factory. However, there is always the chance that some problem may occur because of rough
handling during shipment to the retail store or to the final consumer. If, after reading this Manual,
you experience any problems with the operation of this product, please refer to the instructions
for obtaining services at the end of this Manual. Once again, thanks for purchasing this audio
product. For future reference, record the serial number in the space provided.

1. READ INSTRUCTIONS - All safety and operating instructions should be read before the product is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS - All warnings on the product and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS - All operating and use instructions should be followed.
16. POWER LINES - An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.
15. LIGHTNING - For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will present damage
to the product due to lightning and power-line surges.
4. OUTDOOR ANTENNA GROUNDING - If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded so as to
provide some protection against voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode. See Figure 1.
13. NON-USE PERIODS - The power cord of the product should be unplugged from
the outlet when left unused for long periods of time.
12. POWER-CORD PROTECTION - Power-supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where exit from the product.
11. GROUNDING OR POLARIZATION -This product may be equipped with a polarized alternating-current line plug (a plug
having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature: If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
10. POWER SOURCES - This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company.
For products intended to operate from battery power, or other sources, refer to the operating instructions.
5. CLEANING - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
6. ATTACHMENTS - Do not use attachments not recommended by the product manufacturer as they may cause hazards.
9. VENTILATION - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the
product and to protect it from overheating, These openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in
installation, such as a bookcase or rack,unless proper ventilation is provided or the manufacturer instructions have been
adhered to.
7. WATER AND MOISTURE - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub; in a wet basement; or near a swimming pool.
8. ACCESSORIES - Do not place this product on an unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a child or adult, and serious damage to the product.
Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow the manufacturer instructions, and should use
a mounting accessory recommended by the manufacturer. A Product and Cart Combination Should Be
Moved with Care - Quick stops, excessive force and uneven surfaces may cause the product and cart combination to overturn.
17. OVERLOADING - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
18. OBJECT AND LIQUID ENTRY - Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the
product.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
GB 2

19. SERVICING - Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
20. DAMAGES REQUIRING SERVICE - Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d)
If the product does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improving adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the product to its normal operation.
e) When the product exhibits a distinct change in performance - this indicates a need for service.
21. REPLACEMENT PARTS - When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorised substitutions may
result in fire, electric shock or other hazards.
22. SAFETY CHECK - Upon completion of any service or repair to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
23. HEAT - The product should be situated away from heat sources such as radiators, heat registers, stoves or other
products (including amplifiers) that produce heat.
HANDLING DISC
•To keep the disc clean, do not touch the play sides of the disc.
•Do not attach paper or ape to the disc.
•Keep the disc away from direct sunlight or heat sources.
•Store the disc in a disc case after playback.
CLEANING DISC
•Before playback, wipe the disc outwards from the center with clean cloth.
•Do not use any type of solvent such as thinner, benzine, commercially available cleaners or anti-static spray.
SECURITY
•Before operation, check if the voltage of the unit is in line with the local voltage.
•Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.
• When the plug of the unit is connected to the mains outlet, the unit will be still connected to AC even of the power is
turned off.
• Disconnect the plug as soon as liquid or objects enter the unit. The unit cannot be used until being checked by experts.
• Do not open the cabinet. Laser rays employed by the unit may damage eyes. Any servicing should be done by qualified
service personnel.
PLACEMENT
•Put the unit where ventilation is good enough to prevent overheating.
•Never put the unit in direct sunlight or near heat sources.
•Put the unit horizontally, never put any heavy object on the unit.
• To protect the pickup, do not put the unit where there is a lot of dust. If there is dust on the pickup, use a cleaning disc
to clean it.
•Refer to the operation instructions of the cleaning disc you bought.
CONDENSATION
Moisture will appear on the pickup lens in the following cases:
•The unit is suddenly moved from a cold place to a warm place.
• Use the unit in a humid place. In these cases, switch off and leave the unit in a good ventilation place for about one hour
to evaporate the water.
CLEANING
• Use soft cloth with a little neutral detergent to wipe the cabinet, panel and controls. Never use abrasive paper, polishing
powder or solvent like alcohol and gasoline.
CAUTION!
HAZARDOUS LASER RADIATION WHEN
OPEN AND INTERLOCK FAILED OR
DEFEATED. AVOID EXPOSURE TO BEAM.
CLASS 1 LASER PRODUCT
PRECAUTIONS FOR UNIT
PRECAUTIONS FOR DISCS
GB 3

GB 4
Avoid installing this unit in places exposed
to direct sunlight or close to heat radiating
appliances such as electric heaters, on top
of other stereo equipment that radiates heat,
places lacking ventilation or dusty areas,
places subject to constant vibration and/or
humid or moist areas.
Do not attempt to clean this unit with chemical
solvents as this might damage the finish.
Use a clean dry cloth.
Operate controls and switches as
described in the manual.
Before turning on the power, make
certain that the connecting cords and
power cord are properly installed.
Store your CDs in a cool area to avoid
damage from heat.
When moving the set, be sure to first
disconnect the power cord and remove
cords connected to other equipment.
Please do not dispose of your old electrical and electronic equipment with
your household
waste. For more detailed information about recycling of this product, please contact your
local council, your household waste disposal service or the shop where you purchased the
product.
Corrosion, oxidation, battery-leakage and any other gradually acidic defect of this nature
will invalidate the guarantee.
IMPORTANT NOTES

PREPARATION FOR USE
UNPACKING AND SET-UP
POWER SOURCE
AC OPERATION
Carefully remove the unit from the carton and remove all packing material from the unit.
If you do dispose of the carton and packing materials, please do so properly.
We care about our environment.
We suggest that you retain the original carton and packing materials in case it ever
becomes necessary to return your unit for service. This is the only sure way to protect
the unit from damage in transit.
Remove any labels or stickers which may be on the front or top of the set, but do not
remove any labels from the back or bottom.
GB 5
MW ANT
This system is designed to operate on 230~240V 50Hz AC house current. Connecting this
system to any other power supply could result in damage to the unit which is not covered by
your warranty.
2. Insert the plug into any convenient 230~240V 50Hz AC outlet.
1. Unwind the AC Power cord completely.
AC Plug
AC Outlet

1. EQ Button
2. PRESET - Button
3. PRESET + Button
4. TUNING SKIP/SEARCH Button
5. TUNING SKIP/SEARCH Button
6. CD Door
7. FUNCTION Button
8. PLAY/PAUSE Button
9. STOP/BAND Button
10. VOLUME Button
11. VOLUME Button
12. POWER Button
13. Remote Sensor
14. CD Door OPEN/CLOSE Button
15. STANDBY/ON indicator
16. PHONES Jack
17. AUX IN Jack
18. iPod/USB Tray
19. AC IN Jack
20. Component Pr Jack
21. Component Y Jack
22. Component Pb Jack
23. VIDEO OUT Jack
24. S-VIDEO OUT Jack
25. FM ANT Jack
26. MW ANT Jack
16 17 18 19 20 21 22 23 24 25 26
GB 6
LOCATION OF CONTROLS AND INDICATOR
MW ANT
front back
top

1. STANDBY / ON Button
2. ST / ESP / ID3 / FIND Button
3. EQ Button
4. DBBS Button
5. REPEAT / VIDEO OUT Button
6. RANDOM / RDS Button
7. PRESET / ALBUM / MENU - Button
8. MENU / INTRO Button
10. SELECT Button
11. STOP Button
12. PLAY / PAUSE Button
13. MUTE Button
15. AUX Button
16. TIMER Button
17. SLEEP Button
18. PROG / CLK Button
21. BAND Button
23. FUNCTION Button
22. VOLUME Button
19. PRESET / ALBUM / MENU + Button
20. SKIP TUNING Button
14. VOLUME Button
9. SKIP TUNING Button
TIMERSTANDBY/ON
EQ DBBS SLEEP
PROG /
CLK
MUTE VOLUME
PRESET / ALBUM / MENU
MENU / INTRO
SELECT
PLAY / PAUSE BAND
STOP
AUX
FUNCTION
ST / ESP
ID3 / FIND
REPEAT /
VIDEO OUT
RANDOM /
RDS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
REMOTE CONTROL
GB 7

GB 8
CONNECTING EXTERNAL DEVICES
Complete the connections as shown below.
Pr / Y / Pb connection requires an component cable, not included.
S-VIDEO connection requires an S-VIDEO cable, not included.
VIDEO connection requires an VIDEO cable, not included.
tnempiuqelanretxE
ton(elbaC
)dedulcni
ton(elbaC
)dedulcni
VTfotupniOEDIV-SoT
VT
V
t
T
on(elbaC
)dedulcni
To Component input of TV
MW ANT
Connect the audio output jack(s) or headphone jack of the external audio equipment to the
AUX IN jacks on the front panel of this system.
CONNECTION CABLES ARE NOT INCLUDED.
You may leave your external device permanently connected to this system if you wish.
It is not necessary to disconnect the external device in order to listen to the Tuner or CD
player in this system.

Make sure that you have fully extended the FM antenna wire.
Make sure that you have installed batteries in the remote control handset.
Make sure that the system is connected to an AC outlet that is always “live”.
General Controls
Most of the main functions of this system can be operated by the controls on the top panel of
the unit, or by the buttons on the remote control handset. If a specific function can only be
operated by the remote handset, or by the top panel controls, this will be clearly indicated in the
instructions.
When operating this system with the remote control handset make sure that the
IR (Infrared)
transmitter on the front of the remote handset is pointed at the remote sensor on the top panel
of the main unit.
The effective operating range of the remote control is approximately 4.5 meters.
Please note that bright sunlight or room lighting may interfere with the remote control operation.
If the remote is not operating properly try reducing the brightness of the room or moving closer
to the main unit. If this does not solve the problem, it may be time to change the remote control
battery.
OPERATING INSTRUCTIONS
GB 9

To increase or decrease the system volume press the VOLUME or VOLUME buttons on the
remote control or VOLUME Control on the front panel.
The Volume Level Indicator will appear on the display
when you change the volume level.
The preset equazer allows you to adjust the sound characteristic for the most popular types
of music.
Press the EQ button on the remote control to cycle through
the following equalizer settings:
The level indicator ranges from “00” (Minimum) to
The system remembers the volume level when the power is switched ‘Off’ and automatically
returns to the same level when the power is switched ‘On’ again.
“30” (Maximum).
The appropriate EQ indicator briefly appears in the display to confirm your selection.
Press the DBBS button on the remote control to increase the bass response.
Press again to cancel the Bass Boost function.
The system remembers the EQ setting when the power is switched ‘Off’ and returns to the
same setting when the power is switched ‘On’ again.
GB 10

GB 11
Press the MUTE button on the remote control to shut off the speakers temporarily, for example,
to answer the telephone.
MUTE Button (On Remote Control Only)
Press the MUTE button again to cancel the mute function and restore the sound.
The “MUTE” indicator disappears.
The sound stops and the “MUTE” indicator flashes in
the display.
The mute function will also be cancelled automatically by pressing the VOLUME or
VOLUME
buttons.

GB 12
Setting The Clock
When the unit is connected to the AC outlet for
the first time the “- -:- -” flashes on the display.
Press the SKIP/TUNING or buttons to
select between “24 HOUR” or “12 HOUR” modes
if necessary.
1.) Press and hold the PROGRAM/CLOCK button on the
remote control. “24 HOUR” flashes on display.
3.) Press the SKIP/TUNING or buttons to set the display to the correct hour.
5.) Press the SKIP/TUNING or buttons to set the
display to the correct minutes.
2.) Press the PROGRAM/CLOCK button again.
Just the Hour digits will continue flashing.
4.) Press the PROGRAM/CLOCK button again.
The Minute digits will begin flashing.
6.) Press the PROGRAM/CLOCK button once more.
Only the “ :” flashing and the clock begins to run.
Note: Do not turn the main unit power ‘On’. The clock can only
be set while the main unit power is ‘Off’.
The clock can only be set with the Remote Control.

GB 13
RDS (RADIO DATA SYSTEM)
RDS is a system transmitting additional information via FM stati ons. Broadcasting stations
with RDS transmit their program name or program type for instance . This is indicated in
the multifunction display.
Reviewing for Stations with RDS:
While station with RDS received, press RDS mode button to review their program type,
radio name, program type, radio test if avaliable from the received stations.
1. Press "RDS MODE" repeatedly
PS PTY RT
Frequency
2. RT (Radio Text mode)
Display Radio text information
If the station does not provide Radio Text
or reception is poor,(NORT) appears in the display
Searching for stations according to type of program
PTY (Program Type)
1. Press PTY button. "PTY SEL" appear.
2. Press Skip
Up or Down button repeatedly, choose among 29 types of progams the
type that the tuner should search for.
3. In order to start the search mode, press PTY button.
If a sender is fround with the desired program type,
the search mode stops and the
program name appears in the display unit.
REPEAT/PTY
RANDOM
RDS
TUNING TO A PRESET STATION
Select the desired station preset number by pressing the PER-UP/PER-DOWN button.
ANTENNA
For FM reception there is a built-in antenna wire at the rear of the unit. Unravel the wire
and move it around to obtain the best reception

RADIO OPERATION
1.) Press the STANDBY/ON button to turn the system ‘On’.
3.) Tune to the desired station as follows:
5.) Adjust the VOLUME,DBBS and EQ controls to the desired settings.
6.) When you are finished listening press the STANDBY/ON button to return the system to
the Standby (Off) mode.
4.) If you tuned to an FM Stereo station the ST indicator will
appear in the display. If the FM Stereo reception is
noisy or weak, press the ST/ESP/ID3/FIND button
on the remote control to select the FM Mono mode.
2.) Press the FUNCTION button to select the Tuner function.
An MW or FM frequency will apperar on the display.
Press the TUNER/BAND button to switch
between the MW and FM bands if necessary.
The display lighting comes on and the display briefly
shows “HELLO”.
The display lighting goes off and the display changes from radio frequency to correct time.
Press and hold the SKIP/TUNING or buttons the display begins to move, then
release the buttons.
The Tuner will search up or down the band for the next strong signal
and stop on that station. Reqeat this procedure until the tuner stops on your desired station.
Repeatedly press the SKIP/TUNING or buttons until the display shows the exact
frequency of the desired station. Use the Manual Tuning method to tune to stations that
are not strong enough to be recognized by the Automatic Tuning system.
Manual Tuning
Automatic Tuning
GB 14

Hints For Better Reception
FM: The FM lead wire antenna on the back panel should be extended to its full length. You
may also have to vary the direction of this antenna until you find the position that provides
the best reception.
FM ANT
MW ANT
MW : Insert the wire of loop aerial into the MW AERIAL connector on the unit.
Adjust the position of the loop aerial until you find the position that provides the best
reception
the best reception for your favorite MW stations.
FM ANT
GB 15
MW ANT
MW ANT

GB 16
Presetting Stations In The Tuner Memory
You can store up to 40 of your favourite stations (30 FM / 10 MW) in the tuner memory for
easy recall at any time.
Example “03”.
Example “03”.
1.) Press the PROGRAM/CLOCK button on the remote
control. The display shows “PRG” and the channel
number “01” indicator flashes.
Press the PROGRAM/CLOCK button again,
the “03” stops flashing confirming that your
station has been entered in preset channel
number “03”.
Press the ALBUM/EME CH. + or - buttons
select your next preset memory number.
Press the PROGRAM/CLOCK button again to enter your station in preset channel
number.
2.) Press the ALBUM/EME CH. + or - buttons to
select your preset memory number.
3.) Tune to the next station you wish to memorise
Example: FM 106.70 MHz
4.) Repeat Step 3 until you have stored up to 30 stations on the FM band, then press the
BAND button to switch to the MW band and follow the same procedure to enter up to
10 MW stations in the tuner memory.
Using either the manual or automatic tuning method described on page 13, tune to the first
station you wish to memorize (Example: FM 103.50 MHz) and then:

3.) Press the CD Door on the top panel
2.) Press the FUNCTION button to select CD function.
4.) Load your own CD into the player with the printed ‘label’ facing up.
1.) Press the STANDBY/ON button to turn the system ‘On’.
to open the CD door.
GB 17
CD OPERATION
Normal Playback
IMPORTANT: This CD player can play normal CDs plus CD Recordable (CD-R) and CD
Rewriteable (CD-RW) discs. However the playability of CD-R/RW discs may be affected by
the type of software that was
used in ‘ripping’ the tracks from the original discs and ‘burning’
the tracks onto the blank media. Playability may also be affected by the quality and condition
of the blank media you use for recording. 100% compatibility cannot be guaranteed.
This is not an indication of any problems with your player.

GB 18
5.) Close the CD door.
8.) Playback will continue until all tracks on the disc have been played, then the player stops
and the display shows the total tracks number and playing time on the disc.
7.) Adjust the VOLUME,DBBS and EQ controls as desired.
9.) If you are finished listening, press and open the CD door, remove your disc from the
player, re-close the CD door and press the STANDBY/ON button to return the system to
the Standby (Off) mode.
6.) Press the PLAY/PAUSE button to begin playback.
The display will show flashing “READ” as the player
reads the disc.
After reading the disc the display will show the total
tracks and playing time.
To stop playback at any time, press the STOP button.
You may turn the “ESP” function “Off” or “On” by pressing
the ST/ESP/ID3/FIND button on the remote control.
“ESP” meaning is Electronic Stability Program.
Note:
The reading time may be even longer if you are using CD-RW (rewritable) discs.
This is normal and not an indication of any problem with your unit.

GB 19
Pause Control
Skip Track and High Speed Music Search
To pause temporarily during CD playback press the PLAY/PAUSE button again.
During playback, repeatedly press the SKIP/TUNING or buttons to skip to higher
or lower numbered tracks. Playback will begin on the selected track.
During playback, press and hold the SKIP/TUNING or buttons to search within a
track at high speed to locate a specific musical passage.
Release the SKIP/TUNING or buttons when you hear the desired passage.
Normal speed playback will resume at that point.
Press the PLAY/PAUSE button once more to cancel.
Pause mode and resume playback at the same point,
the elapsed time stops flashing.
The sound stops and the elapsed time flashes in the display,
but the disc continues spinning.
