Akai CT-2110ASF User manual

Please read this manual carefully before operation.
COLOR TELEVISION
RECEIVER
OPERATION MANUAL
AKAI - JAPAN
CT-2110ASF

BEFORE OPERATION
Dear Customer:
Congratulations! You have purchased one of the finest Color TV's on the market!
This manual will help you use many exciting and useful features to make your TV viewing more enjoyable
than ever before.
Before operating your TV set, please read all these safety and operating instructions completely and then
retain for future reference.
Customer's Record
You will find the model number and chassis number on the back of your TV set.
Record these numbers in the spaces provided below.
Refer to them whenever you call upon your dealer regarding this product.
Model Number: Chassis Number:________________
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
The lightning symbol in the triangle tells
you that the voltage inside this product
may be strong enough to cause an electric
shock. DO NOT TRY TO SERVICE OR
CHANGE THIS PRODUCT YOURSELF.
The exclamation point in the triangle tells
you that important operating and mainte-
nance instructions follow this symbol.
CAUTIONS:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION
CORD RECEPTACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE FULLY INSERTED INTO
THE OUTLET TO PREVENT ANY EXPOSURE OF THE PRONGS ON THE POLARIZED PLUG.
Avoid displaying stationary images on your TV screen for extended periods of time. Stationary patterns
generated by computer displays, video games, stock market reports, etc .can become permanently en-
grained on the picture tube. This damage is not protected by your warranty as it is the result of misuse.
Should you wish to use your Television to display still images, it is always advisable to reduce brightness
and contrast settings. Never leave a video game or computer display unattended.
NOTE TO CABLE INSTALLER:
The cable ground shall be connected to the grounding system of the building, as close to the point of ca-
ble entry as practical.
Important Safety instructions
CAUTION
PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS AND HEED ALL WARNINGS.
FOLLOW ALL INSTRUCTIONS.
Electrical energy can perform many useful functions. This TV set has been engineered and manufactured
to assure your personal safety. However improper use can result in potential electrical shock or fire haz-
ards. In order not to defeat the safe guards incorporated in this TV set, observe the following basic rules
for antenna/TV installation, use and servicing. All operating and use instructions should be followed.
Do not remove the cabinet cover. This may expose you to dangerous voltages. Refer all servicing
to qualified service personnel.
I
RISK OF ELECTRIC SHOCK
DO NOT OPEN

BEFORE OPERATION (continued)
Precautions
Power Sources-The TV set should be operated only from the type of power source indicated on the TV
set or as indicated in the Operation Manual. If you are not sure of the type of power supply in your home,
consult your sales person or your local power company. For TV sets designed to operate from battery
power, or other sources, refer to the operating instructions.
Grounding or Polarization - Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Alternate Warnings-This plug will only fit into a grounding-type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet, contact your electrician to have a suitable outlet installed.
Do not defeat the safety purpose of the grounding plug.
Water and Moisture Warnings-Do not use the TV set near water-for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like. The TV set
shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be
placed on the TV set.
Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation
of the TV set and to protect it from overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the TV set on a bed, sofa, rug, or other similar surface. This
TV set should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have been adhered to.
Heat - Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Power-Cord Protection-Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Accessories-Do not place the TV set on an unstable cart, stand, tripod, bracket, or table. The TV set may
fall, causing serious injury to a child or adult, and serious damage to the TV set. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or accessory recommended by the
manufacturer, or sold with the TV set, and should use a mounting accessory recommended by the
manufacturer.
A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the TV set and cart combination to overturn.
Overloading- Do not overload wall outlets, extension cords or integral convenience receptacles as this
can result in fire or electric shock.
Lightning-For added protection for this TV set during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the product due to lightning and power-line surges.
Object and Liquid Entry-Never push objects of any kind into the TV set through openings as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the TV set.
II

BEFORE OPERATION (continued)
Precautions (continued)
Cleaning-Unplug the TV set from the wall outlet before cleaning or polishing it. Do not use liquid cleaners
or aerosol cleaners. Use a dry cloth for cleaning the exterior of the TV set.
Attachments-Do not use attachments not recommended by the product manufacturer as they may cause
hazards or electric shock.
If a snapping or popping sound from a TV set is heard continuously or frequently while the TV set is oper-
ated, unplug the TV set and consult your dealer or service technician. It is normal for some TV sets to
make occasional snapping or popping sounds, particularly when being turned on or off.
Damage Requiring Service-Unplug the TV set from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a.If the power cord or plug is damaged or frayed.
b.If liquid has been spilled or objects have fallen into the TV set.
c.If the TV set has been exposed to rain or water.
d.If the TV set has been subject to excessive shock by being dropped, or the cabinet has been damaged.
e.If the TV set does not operate normally by following the operating instructions. Adjust only those controls
that are covered by the operating instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the TV set to its nor
mal operation.
f. When the TV set exhibits a distinct change in performance-this indicates a need for service.
Warning: This unit should only be serviced by an authorized and properly trained technician. Opening the
cover or other attempts by the user to service this unit may result in serious injury or death from electrical
shock, and may increase the risk of fire.
Servicing-Do not attempt to service the TV set yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Replacement Parts-When replacement parts are required, be sure the service technician has used re-
placement parts specified by the manufacturer or have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
Safety Check-Upon completion of any service or repairs to the TV set, ask the service technician to per-
form routine safety checks to determine that the TV set is in proper operating condition.
When the TV set reaches the end of its useful life, improper disposal could result in a picture tube implo-
sion. Ask a qualified service technician to dispose of the TV set.
ANTENNA
Outdoor Antenna Grounding-if an outdoor antenna is installed, follow the precautions below. An outdoor
antenna system should not be located in the vicinity of overhead power lines or other electric light or power
circuits, or where it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM, EXTREME CARE SHOULD BE TAKEN TO
KEEP FROM CONTACTING SUCH POWER LINES OR CIRCUITS AS CONTACT WITH THEM IS
ALMOST INVARIABLY FATAL
Be sure the antenna system is grounded so as to provide some protection against voltage surges and
built-up static charges.
III

CONTENTS
INTRODUCTION
Remote Control Keys .............................................................................................1
INSTALLATION
To Connect the Antenna ........................................................................................2
Installing the Remote Control Batteries ....................................................................2
To Connect External Equipment .............................................................................3
GENERAL OPERATION
Power On/Off ......................................................................................................4
On-Screen Display ................................................................................................4
Intelligent Operation .............................................................................................4
Volume Control 4
Channel Selection .................................................................................................5
Recall ...............................................................................................................5
TV/AV Selection ....................................................................................................5
MENUS OPERATION
Menus .................................................................................................................5
Picture Menu ........................................................................................................6
Timer Menu .........................................................................................................6
Setup Menu .........................................................................................................7
Tune Menu ...........................................................................................................7
Swap Menu ..........................................................................................................8
Hotel Menu ........................................................................................................ 9
Biorhythm Menu ................................................................................................. 9
TROUBLESHOOTING GUIDE ...................................................................... 10
Note:
Designs are subject to change without notice.
......................................................................................................

1
INTRODUCTION
Remote Control Keys
Remote control
STANDBY
ON SCREEN DISPLAY
Direct Select
PICTURE MODE SELECT
RECALL
VOLUME DOWN
MENU SELECT
VOLUME UP
CHANNEL DOWN
VOLUME DOWN
BIORHYTHM MENU
DIGIT SELECT
TV/AV SELECT
AUTO (intelligent)
HELP
CHANNEL UP
VOLUME UP
CHANNEL UP
CHANNEL DOWN
TEXT ON/OFF
MUTE
•The color and INDEX buttons also function as fast menu selection in the TV mode.
Notes:
ķWhen in operation, please point your remote control directly to the infrared sensor.
ĸDo not expose the remote control to impacts, water or disassemble it.
DIGIT
DISP
P MODE.
AUTO
HELP
BIO TEXT
INDEX REVEAL SIZE
EAST WEST/
MIX CANCEL HOLD
SUBCODE

INSTALLATION
•Please read the safety instructions in this manual completely before installation.
•Install your TV in an area where direct sunlight will not fall upon the screen.
•Soft, indirect light is best for television viewing.
•Allow enough space (at least 4 in.) between the TV and any walls or enclosures for proper ventilation.
•Optimum television viewing distance is 3-5 times the screen's size.
Auto-Degaussing
Color television can be easily affected by magnetism, which shows as color distortion on the screen. If
your TV is affected by nearby magnetic components or appliances, turn it off for a few minutes. The built-in
auto-degaussing circuit will eliminate the magnetic interference.
To Connect the Antenna
Notes:
1. It is recommended that a 75 ohm coaxial cable be used in order to eliminate interference and noise
which may occur due to nearby radio transmissions.
2. The antenna cable should not be tied together with other wiring.
3. Set up a lightning rod and check it regularly when an outdoor antenna is used.
Installing the Remote Control Batteries
1. Remove the battery compartment lid.
2. Insert two AAA batteries (included). Make sure the positive
correctly aligned.
3. Reattach the battery lid.
(+) and negative (-) polarities are
Notes:
1. Alkaline batteries are recommended for longer life.
2. Always replace both batteries at the same time.
3. Do not expose batteries to fire or break them open.
4. To avoid battery leakage, remove batteries from the remote control when it is not being used for a
long period of time.
VHF
UHF
or Cable
VHF
UHF
75-ohm coaxial cable (not supplied)
300-ohm twin-lead cable (not supplied)
A
ntenna adapter
(not supplied)
U/V mixer
(not supplied)
RF Input
(back of TV unit)
2

INSTALLATION (continued)
To Connect External Equipment
The following are diagrams showing basic instructions for attaching external equipment, like a VCR or
DVD player, to your TV set. Please refer to operation manuals of external audio/video equipment that will
be connected to your set for additional instructions. PLEASE TURN OFF ALL POWER BEFORE
CONNECTING DEVICES TOGETHER.
Notes:
ķPlease turn off the power supply of the TV set and the external equipment before connection.
ĸThe side terminals may be easier to use with a camcorder. The connections are identical.
3
VCR ANTENNA IN
ANTENNA IN
VCR
AV
VCR
AV
AUDIO VIDEO IN/
AUDIO VIDEO IN/
DVD player
AUDIO VIDEO IN/
AUDIO VIDEO IN/
Connect VCR's RF OUT terminal to the RF IN jack located on the rear
Coaxial Cable
RF IN
Camcorder
AV IN on the side panel
SCART Cable
Video Cable
Audio Cable
SCART terminal
SCART Cable
SCART terminal
VIDEO
AUDIO
R
AV IN()())(2)
L//MONO
L/MONO
AUDIO
R
AV IN()())(2)
VIDEO
or

GENERAL OPERATION
Power On/Off
1.Power on
Plug in the supply socket, and press the MAIN POWER SWITCH key on the TV. You may press any of
the POWER, Program Number (0-9) and PRO-/+ (or CH-/+) keys on the remote control to turn on the
TV.
2. Power off
To switch back to the Standby mode, press POWER key. You can also power off the TV directly by
pressing the MAIN POWER SWITCH key. Part of circuit on the TV remains active in the STANDBY
mode. To cut off the power off completely, please press the MAIN POWER SWITCH.
Auto off without signal received
When there is no signal received (for example, the program of a certain channel is over), the TV will
switch to the Standby mode if no key is pressed within 15 minutes. If you have set "Off Time" and the
remaining time is less than 15 minutes, Off Time will be carried out prior to AUTO OFF.
On-Screen Display
When switching channels, the current channel number will appear on the
upper-left corner of the screen, which will disappear in 3 sec.
Press the DISP button firstly when watching TV to display channel number,
color/sound system modes on the screen. To turn off the display, press the
button again.
Pressing the DISP button can turn off menu display.
Intelligent Operation
Press and hold down the AUTO button for 3 sec and the TV automatically completes some settings, such
as settings of language, volume, picture mode, color system and sound system. Then it starts Auto Pro-
gram. After Auto Program, the TV returns to Channel 1.At this time, you may watch the TV program 1.
Volume Control
Press the VOL-or VOL+ button to decrease or increase the volume.
Adjustable range: 0~100
During normal play, press the MUTE button and the sound is eliminated. The TV will display ared MUTE
on the screen.
To cancel MUTE, you may press the MUTE button again or the VOL+ buttons.
4
2
AUTO
D/K

GENERAL OPERATION (continued)
Channel Selection
Pressing the CH-/CH+ buttons can select another lower-numbered or upper-numbered channel.
Direct selection
To select a one-digit channel number
Press the DIGIT button to choose "-" firstly, then press one of 0-9 buttons.
To select a two-digit channel number
Press the DIGIT button to choose "--"firstly, then enter afirst-digit and second-digit.
To select a three-digit channel number
Press the DIGIT button to choose "---" firstly, then enter a first-digit, second-digit and third-digit.
Note:
Please finish entering within 6 sec.
Recall
Press the RECALL button and the TV will directly skip back to the former signal source reception mode.
TV/AV Selection
In the TV mode, press the TV/AV button to enter the AV mode. In the AV mode, the TV receives AV
signals from external equipment and automatically cuts off signals from the antenna terminal. To resume
broadcast viewing, press the TV/AV button repeatedly or CH-/CH+ buttons. To receive signals from
external equipment, please select the relevant AV mode.
MENUS OPERATION
Menus
Press the MENU button repeatedly when watching TV programes, and the TV will display seven kinds of
menus (including PICTURE, TIMER, SETUP, TUNE, SWAP, HOTEL and BIORHYTHM) cyclically. Press
the CH+ /CH- buttons to select an adjustment (the characters turn white to cyan), and press the VOL-
/VOL+ buttons to adjust.(Press the HELP button, and the operation hint will appear on the upper-right
corner of the menu.)
Menu selections are omitted in the following function with those buttons of the same name on the remote
control. If your remote control becomes invalid or lost, you can use many basic functions by pressing the
buttons on the TV.
Menu display disappears 6 sec after last selection.
Note: ln the AV mode, TUNE menu and SWAP menu are not available.
5

MENUS OPERATION (continued)
Picture Menu
1. Picture mode selection
Before shipment, the TV was given three preset picture modes: Soft, Nature and Rich. Press the P.
MODE button to select one of the three preset modes or the User mode. Refer to the following table
about each picture mode.
Mode Picture Quality
Soft The contrast is low, suitable for watching TV in mild surrounding light.
Nature Standard status, suitable for watching ordinary programs.
Rich The contrast is high, suitable for watching TV in bright environment.
User Picture quality user sets.
To perform the following operation, press the MENU button repeatedly or the red button directly (in the
TV/AV mode) to select the PICTURE menu. Press the CH-/CH+ buttons to choose an adjustment.
Press the VOL-/VOL+ buttons to adjust the digital level of the selected adjustment as desired.
Adjustment Effect
Item Press VOL- Press VOL+
Contrast Lower Higher
Brightness Darker Brighter
Color Weaker Stronger
Sharpness Lower Higher
The adjusted picture level is automatically stored in the User position.
Notes:
"Tint" appears only when the signal system is set to NTSC.
The adjustable "Tint" range is -50-+50, and other adjustments are 0-100.
Timer Menu
In the STANDBY or TURN ON mode, the TV can automatically complete some functions such as turn-on,
channel preset and turn-off as desired.
To perform the following operation, press the MENU button repeatedly or the yellow button directly (in the
TV/AV mode) to select the TIMER menu.
6
Contrast 50
Brightness 50
Color 50
Sharpness 50
........
2. To adjust picture quality

MENUS OPERATION (continued)
Timer Menu (continued)
1.On/Off timer
Press the CH-/CH+ buttons to select an adjustment.
Press the VOL-/VOL+ buttons to adjust the selection.
You may preset two kinds of On Time and On Channels.
After On Timer is performed, the set On Time is cleared and the On
Channel remains unchanged.
2. Sleep timer
After selecting "Sleep Time", press the VOL-/VOL+ buttons
repeatedly to set Sleep time to 10, 20, 30 or 180 min.
Display on the screen will remind you 5 times in the last 5 min. before
the preset SLEEP Time is up.
Notes:
If both the SLEEP TIME and OFF TIMER are set, the TV will perform the setting with less remaining
time prior to another.
The SLEEP function is cancelled at the same time that the OFF TIMER is performed.
If the SLEEP TIME setting is performed prior to OFF TIMER, the OFF TIMER still works.
Setup Menu
To perform the following operation, press the MENU button repeatedly or
the blue button directly (in the TV/AV mode) to select the SETUP menu.
1.OSD selection
NOTE: The OSD and illustration in this manual may be somewhat differ-
ent from the actual situation. Please take the TV as the normal.
2. Blue background
With this function on, the screen will display a mild blue background
and mute automatically in TV mode when no signal is received.
3. Picture enhancement
If the picture of a certain channel is abnormal, use this function to improve picture. It is recommended to
select "PIC Enhance Off" when the signal being received is good in case of influencing picture definition.
4. Color temperature adjustment
You may select one of color of background as preferred among Normal, Cool and Warm mode.
The adjusted Color Temp mode is automatically stored and remains unchanged until next adjustment.
5. AVL(Auto Volume Leveling)
When the AVL is activated, it automatically stabilizes the audio output signal to a certain level.
6. Child Lock
With Child Lock On, the keys on the TV do not function.
Notes:
The AVL function is selectable. The Child Lock function is selectable.
Tune Menu
This section gives descriptions about adjustment of items in the TUNE menu. Press the MENU button re-
peatedly or the INDEX button directly (in the TV mode) to select the TUNE menu.
1.Color/Sound system selection
In case the color/sound of a channel that you are watching is abnormal, please change the color/sound
system.
7
TIMER
Clock
On Time1
--:--
--:--
On Channel1 1
On Time2 --:--
On Channel2 1
--:--
Sleep Time 0
Off Timer
SETUP
English
Blue Back On
PIC Enhance On
Color Temp Cool
AVL Off
Child Lock Off

MENUS OPERATION (continued)
Tune Menu (continued)
2. SKIP
After Auto Search, there may be some repeated program or inferior
signals received. Skipping the undesired program position can dra-
matically quicken channel selection.
After selecting "Skip" in the TUNE menu, press the VOL-/VOL+ but-
tons to set "Skip On". When the TUNE menu has disappeared, press
the CH-/CH+ buttons and you will find the channel number skipped. If
you select the channel number by the Direct Select buttons, the
channel number has changed from green to yellow.
To resume the channel number that has been skipped, repeat the operations mentioned above. Then
set "Skip Off".
3. Search
In case the desired channel cannot be preset with the Auto Program
function, or you would like to set the desired channels to specific
channel numbers, please use the Search function.
After selecting "Search" in the TUNE menu, press the VOL-/VOL+
buttons. The TV searches another lower/upper channel. To stop
search, press the MENU button.
If the selected channel is not the one you want, press the buttons a-
gain until the desired channel is selected. If the TV dose not stop searching when finding a channel,
please use the Fine Tune function.
4. Frequency fine-tuning
After selecting "Fine Tune" in the TUNE menu, press and hold down the VOL- or VOL+ button until you
get the best sound and picture effect.
Press the DISP button to check up the fine-tuned channel, and you will find that the position number
turns to red.
5. Auto Search
After selecting " Auto Search " in the TUNE menu, press the VOL+
button. The TV will search automatically in sequence. After auto
search, the TV will store receivable channels and returns to POS1.
Unused position number is automatically set to Skip On. During auto
Search, press the MENU button to stop searching.
Swap Menu
Use the SWAP function to resort program position. For example, you
want to change Channel 9 to Channel 1.
1. Press the MENU button repeatedly or the green button directly (in
the TV mode) to select the SWAP menu.
2. Press the CH-/CH+ buttons to highlight "Channel A". Press the
Numeric buttons to set it to 9. Then set channel B to 1in the way
mentioned above.
8
TUNE
Color
Sound
Skip
Channel
Search
Fine Tune
Auto Search
D/K
Off
2
Auto
Search
VHFL
VOL+: Up
MENU: Stop
Auto Search
VHFL
MENU: Stop
SWAP
Channel A 1
Channel B 3
Swap

MENUS OPERATION (continued)
Swap Menu (continued)
3. Select the SWAP menu, and press the VOL+ button. The current channel No. is changed to Channel 1
and the content of Channel 1 is exchanged with that of Channel 9. The current channel No. is Channel
1. Repeat the operations mentioned above to sort other searched channel position as desired
Hotel Menu
To perform the following operation, press the MENU button repeat-
edly (in the TV/AV mode) or the green button directly (in the AV
mode) to select the HOTEL menu.
Only after entering the correct password by pressing Numeric but-
tons, can you adjust the following items. (Each time you power on the
TV, you need enter the password)
Initial password: 0000 (preset before outgoing)
Universal password: 8888
Tuning lock: To allow/prohibit program (searching program). With
Channel Lock ON, the item is also set to ON.
AV Lock: To prohibit the AV button to shift VIDEO.
Maximum Vol : To adjust volume to maximum.
New Password: Enter new password twice and you may change original assword
Channel Lock: To lock up to 4 channels as user sets.
Generally the Hotel TV does not allowed guests to change setting.
With Tuning Lock ON, the TUNE and SWAP menus are not available.
Biorhythm Menu
Press the MENU button repeatedly or BIO button directly (in the
TV/ AV mode) to select the BIORHYTHM menu.
After entering your birthday, you may check the state about your
energy, intelligence or emotion in any day between the day after
your birthday and Dec.31, 2155.
9
HOTEL
Password * * * *
Tuning Lock Off
AV Lock On
New Password
Channel Lock Off
12 32 65 43
* * * *
Maximum Vol 26
BIORHYTHM
Today
OCT 18 2003
Birthday
JUN 25 1976
Energy
Intelligence
Emotion
Average

10
TROUBLESHOOTING GUIDE
Symptoms
Picture Sound Check the following items
No picture No sound
1. Make sure the power cord is plugged in. 2. Check if the MAIN
POWER SWITCH is pressed or not. 3. Check if the levels of
Contrast, Brightness and Volume are set to minimum.
Normal No sound Check if the TV is in the MUTE mode or the volume is minimum.
Try pressing the VOL+ button.
Normal Check if the chroma is set to minimum.
No color
With noise Check if the sound/color system is correct.
With stripes With noise The TV set is interfered by electric waves from automobiles, motors,
neon lights, etc.
With snow With noise 1. Check if the antenna cable is broken or disconnected.
2. Check if the antenna direction has changed.
Ghost picture Normal Check if the antenna direction has changed.
Unclear picture Normal or weak Preset channels again.
With spots Normal 1. The TV is moved with power on. 2. Check if
magnetic objects are put near the set.
The remote control doesn't work. The batteries are exhausted or improperly installed.

MANUAL DE UTILIZARE
Cititi cu atentie acest manual inainte de utilizarea aparatului!
TELEVIZOR COLOR
AKAI - JAPAN
CT-2110ASF

INAINTE DE UTILIZARE
Stimate Client,
Felicitari! Ati achizitionat unul din cele mai bune modele de televizoare color disponibile pe piata!
Acest manual va va ajuta sa folositi multe functii interesante si utile pentru ca Dvs sa profitati din plin
de o vizionare mai buna ca niciodata.
Inainte de a utiliza televizorul, va rugam sa cititi toate aceste instructiuni de siguranta si de utilizare si
sa pastrati manualul pentru consultari ulterioare.
Evidenta clientului
Veti gasi numarul modelului si numarul de serie pe spatele televizorului.
Notati aceste numere in spatiul de mai jos.
Veti avea nevoie de acestea de fiecare data cand veti consulta dealer-ul Dvs cu privire la acest produs.
Numar Model: ______________
Precautii de siguranta
Numar serie: ______________
ATENTIE : PENTRU A REDUCE RISCUL DE INCENDII SAU ELECTROCUTARE, NU EXPUNETI ACEST APARAT
Acest simbol indica faptul ca voltajul din interiorul
ATENTIE
RISC DE ELECTROCUTARE
NU DESCHIDETI
ATENTIE: PENTRU A REDUCE RISCUL DE
ELECTROCUTARE, NU SCOATETI CAPACUL (SAU
CARCASA). REPARATIILE TREBUIE EFECTUATE DOAR
DE CATRE PERSONAL CALIFICAT.
ATENTIE:
acestui aparat poate fi suficient de puternic
pentru a provoca electrocutare.
NU INCERCATI SA REPARATI SINGURI
APARATUL!
Acest simbol va atrage atentia asupra unor
instructiuni importante de utilizare si intretinere.
PENTRU A PREVENI RISCUL DE ELECTROCUTARE, NU FOLOSITI FISA POLARIZATA CU UN PRELUNGITOR
DECAT DACA LAMELELE DE CONTACT POT FI INTRODUSE COMPLET IN PRIZA, PENTRU A PREVENI
EXPUNEREA LAMELELOR LA FISA POLARIZATA.
Atentie - Acest televizor trebuie reparat doar de catre un tehnician autorizat si instruit adecvat.Deschiderea
carcasei sau orice alta incercare a utilizatorului de a repara acest televizor poate avea drept consecinte
accidente grave si chiar deces in urma electrocutarii, si poate amplifica riscul de incendii.
Evitati afisarea imaginilor stationare pe ecranul televizorului intervaluri mai lungi de timp. Paternurile
stationare generate de imagini computerizate, jocuri video, rapoarte de bursa etc se pot imprima
permanent in tubul de imagine. Aceasta defectiune nu este protejata de garantie, deoarece se considera
a fi provocata de utilizarea necorespunzatoare a aparatului. Daca alegeti sa folositi televizorul pentru
afisarea de imagini statice, este intotdeauna recomandat sa reduceti nivelurile de luminozitate si contrast.
Nu lasati niciodata imaginea unui joc video sau o imagine computerizata fara supraveghere.
OBSERVATIE PENTRU INSTALATORUL CABLULUI:
Firul de impamantare trebuie conectat la sistemul de impamantare al cladirii, cat mai aproape de locul
de intrare al cablului.
Instructiuni importante de siguranta
ATENTIE
VA RUGAM CITITI ACESTE INSTRUCTIUNI, PASTRATI-LE SI RESPECTATI TOATE INSTRUCTIUNILE SI ATENTIONARILE.
Energia electrica poate indeplini multe functii utile. Acest televizor a fost creat si produs pentru a va asigura
starea de siguranta personala. Totusi, utilizarea neadecvata a aparatului poate produce risc de electrocutare
sau incendiu. Pentru a nu deteriora sistemele de siguranta incorporate in acest teelvizor, respectati urmatoarele
reguli de baza pentru instalarea antenei si a televizorului, utilizarea si reparatiile aparatului. Toate instructiunile
de operare si utilizare trebuie respectate.
Nu scoateti carcasa televizorului: va expuneti la un voltaj ridicat. Pentru orice tip de reparatie apelati la personal
calificat.
LA PLOAIE SAU UMEZEALA.

INAINTE DE UTILIZARE (continuare)
Precautii
Surse de alimentare
Acest televizor trebuie conectat la o sursa de alimentare care sa respecte indicatiile din acest Manual.
Daca nu sunteti sigur cu ce tip de alimentare este dotata locuinta Dvs, consultati personalul de vanzari
sau compania electrica locala. Pentru televizoarele create sa functioneze cu alimentare de la baterii,
consultati instructiunile de operare.
Impamantare si polarizare
Nu defectati fisa polarizata sau impamantata. O fisa polarizata are doua lamele, dintre care una este
mai lata decat cealalta. O fisa cu impamantare are doua lamele si o a treia de impamantare. Lamela
lata sau cea de-a treia este creata pentru siguranta Dvs. Daca fisa prevazuta nu se potriveste cu priza
Dvs, consultati un electrician pentru inlocuirea respectivei prize.
Atentionari
Aceasta fisa este compatibila numai cu prizele de tip impamantare. Aceasta este o functie de siguranta.
Daca nu reusiti sa introduceti fisa in priza, contactati un electrician pentru a va instala o priza adecvata.
Nu ignorati scopul de siguranta al fisei cu impamantare.
Apa si umiditate
Nu folositi televizorul langa surse de apa - de ex: langa o cada, chiuveta sau spalatorie, intr-un beci
umed sau langa o piscina. Televizorul nu trebuie expus pericolului de a fi stropit; nu asezati pe televizor
obiecte care contin apa, cum ar fi o vaza cu flori.
Ventilatie
Spatiile si orificiile televizorului sunt prevazute pentru ventilatie si pentru a asigura operarea corecta a
televizorului si pentru a-l proteja de supraincalzire; aceste spatii nu trebuie obstructionate sau acoperite.
Nu asezati niciodata televizorul pe un pat, canapea sau o suprafata similara. Trebuie instalat intr-un
spatiu in care sa fie incorporat, cum ar fi o biblioteca, dar acest spatiu trebuie sa ofere televizorului
ventilatia corespunzatoare.
Caldura
Nu instalati televizorul langa surse de caldura (calorifer, hota, aeroterma) sau alte aparate (inclusiv
amplificatori) care genereaza caldura.
Protectie cablu de alimentare
Protejati cablul de alimentare, nu calcati pe el si nu il intepati, in special in zona de contact cu aparatul.
Accesorii
Nu asezati televizorul pe suprafete instabile, deoarece poate cadea, provocand accidente serioase
persoanelor implicate, plus defectarea sa tehnica. Asezati televizorul doar pe suprafetele indicate de
producator sau comercializate impreuna cu produsul si folositi accesorii de montare recomandate de
producator.
Suprasarcina
Nu supraincarcati prizele de perete, prelungitoarele, deoarece exista risc de incendiu.
Fulger/Trasnet
Pentru protectia suplimentara a acestui televizor in timpul unei furtuni, sau cand este lasat nesupravegheat
sau nefolosit pentru perioade mai lungi de timp, deconectati de la priza si deconectati antena sau
sistemul de cablu. Acest lucru va preveni deteriorarea produsului datorata unei eventuale caderi de
retea.
Patrunderea obiectelor straine si a lichidelor
Nu introduceti obiecte prin orificiile si spatiile cu care este prevazut televizorul, deoarece puteti atinge
puncte cu voltaj ridicat si exista risc de electrocutare. Nu varsati niciodata lichide in aparat.

INAINTE DE UTILIZARE (continuare)
Precautii (continuare)
Curatare
Deconectati televizorul de la priza inainte de a-l curata sau sterge. Nu folositi agenti de curatare lichizi
sau de tip aerosoli. Folositi un material uscat pentru a sterge exteriorul televizorului.
Dispozitive atasate
Nu folositi dispozitive atasate decat cele recomandate de producator; pericol de accidente si electocutare.
Daca auziti pocnituri sau sunete anormale din interiorul televizorului, in mod continuu, atunci cand
televizorul este in functiune, deconectati aparatul de la priza si apelati la un service sau un tehnician
calificat. La unele televizoare este normal sa se auda unele zgomote cand il porniti sau il opriti.
Defectiuni care necesita service
Deconectati teelvizorul de la priza si apelati la personal calificat de service in oricare dintre urmatoarele
situatii:
a. Daca cablul de alimentare sau stecherul este defect sau deteriorat.
b. Daca s-au varsat lichide sau au patruns obiecte straine in interiorul televizorului.
c. Daca televizorul a fost expus la ploaie sau apa.
d. Daca televizorul a fost supus unui soc excesiv daca a cazut pe jos sau cabinetul televizorului s-a
defectat.
e. Daca televizorul nu functioneaza normal desi ati respectat instructiunile de operare. Reglati doar
acele functii cuprinse in manualul de instructiuni, deoarece reglarea incorecta a altor functii poate
provoca defectiuni si va necesita deseori operatii elaborate de reparatii din partea unui tehnician calificat
pentru a restabili functionarea normala a televizorului.
f. Daca televizorul isi modifica vizibil conditiile de functionare - acest lucru indica necesitatea reparatiilor.
Atentie: Aparatul trebuie sa fie reparat doar de catre un tehnician autorizat si bine pregatit. Deschiderea
carcasei aparatului sau orice alta incercare de a repara pe cont propriu aparatul poate avea consecinte
grave, chiar deces din cauza riscului de electrocutare; de asemenea, exista pericol de incendii.
Service
Nu incercati sa reparati singuri televizorul, deoarece deschiderea carcasei va poate expune la voltaj
periculos si alte accidente. Adresati-va unui centru de service sau unui tehnician calificat pentru orice
reparatii.
Inlocuirea pieselor
Cand este nevoie sa se inlocuiasca piese, asigurati-va ca tehnicianul pe care l-ati solicitat pentru reparatii
foloseste piese de rezerva specificate de catre producator sau are aceleasi caracteristici ca piesele
originale. Folosirea pieselor neautorizate poate provoca incendiu, electrocutare si alte pericole.
Verificare de siguranta
La terminarea oricarei lucrari de reparatii a televizorului, cereti tehnicianului sa efectueze verificari de
siguranta pentru a se asigura ca televizorul functioneaza normal.
Cand durata de functionare a televizorului se incheie, aruncarea incorecta a aparatului poate avea drept
rezultat implozia tubului de imagine. Cereti unui tehnician calificat sa arunce aparatul in mod corespunzator.
ANTENA
Impamantarea antenei exterioare - daca este instalata o antena externa, respectati instructiunile
urmatoare: Sistemul unei antene externe nu trebuie amplasat in apropierea liniilor electrice sau alt
lumina electrica sau circuite electrice, sau in locuri unde poate intra in contact cu astfel de linii sau
circuite electrice. CAND INSTALATI UN SISTEM DE ANTENA EXTERNA, AVETI MARE GRIJA CA
ACESTA SA NU INTRE IN CONTACT CU ASTFEL DE LINII SAU CIRCUITE ELECTRICE. UN ASTFEL
DE CONTACT ESTE APROAPE INTOTDEAUNA FATAL. Asigurati-va ca sistemul antenei este racordat
la impamantare pentru a oferi protectie impotriva undelor de voltaj si a sarcinilor statice incorporate.
