Akitio Taurus Mini Super-S3 LCM Assembly instructions

Manual
Handbuch
Manual
使用說明書
© 2012 by AKiTiO - All Rights Reserved
AKiTiO assumes no responsibility for any errors or dierences between the product you
have and the one mentioned in this document and reserves the right to make changes in
the specications and/or design of this product without prior notice. The diagrams
contained in this document are for reference and may not fully represent the real product.
www.akitio.com
EN
DE
ES
CH
Hard Drive Enclosure
Festplattengehäuse
Caja Para Disco Duro
硬碟外接盒
Taurus Mini Super-S3 LCM
E15-570Q1AA031
4/24/2012 - v1.0
For more detailed instructions,
please download the PDF manual at
http://www.akitio.com/support/user-manuals

Front View - Frontansicht
Vista frontal - 正面
Green = Data access (read/write)
Red = Error or empty drive bay
Grün = Datenzugri (lesen/schreiben)
Rot = Error oder leerer Laufwerksschacht
Verde = Acceso a datos (lectura/escritura)
Rojo = Error o bahía de unidad vacía
綠色 = 資料存取中
紅色 = 硬碟未放入或者硬碟錯誤
Orange = Rebuilding data
Orange = Am Wiederherstellen der Daten
Naranja = Reconstruyendo datos
橘色 = 重建資料中
Select
Select menu or mode
Wähle Menü oder Betriebsart aus
Seleccionar menú o modo
選擇設定選單或模式
OK
Conrm or enter
Bestätigen oder önen
Conrmar o entrar
確定或者進入
A B
A B
A B
A B

Rear View - Rückansicht
Vista posterior - 背面
USB 3.0
USB 3.0 SuperSpeed port
USB 3.0 SuperSpeed Anschluss
Puerto de USB 3.0 SuperSpeed
USB 3.0 極速傳連接埠
FW800
FireWire 800 ports
FireWire 800 Anschlüsse
Puertos FireWire 800
FireWire 800 連接埠
eSATA
eSATA port
eSATA Anschluss
Puerto de eSATA
eSATA 連接埠
DC IN +12V
Power receptacle
Netzanschluss
Toma de alimentación
電源插座
HDD A/B
Hard drive A/B
Festplatte A/B
Disco duro A/B
硬碟 A/B

1

2

3

4
Note:
When bus-power is insucient, plug in the external power supply.
Hinweis:
Wenn die Stromversorgung über das Datenkabel nicht ausreicht,
schließen Sie das externe Netzteil an.
Nota:
Cuando la alimentación del bus sea insuciente enchufe la fuente de
alimentación externa.
注意事項:
當傳輸線供電不足，請使用外接電源。
RAID Mode Setup
RAID 1 Enter>
1
2Select Select Select OK Select

5
Windows
1. Start / Run... diskmgmt.msc
2. Create NTFS partition
Mac
1. Applications / Utilities Disk Utility
2. Create Mac OS Extended (HFS+) partition
For more detailed instructions, please visit our website at
http://www.akitio.com/information-center/formatting-external-hard-drives
