Aktobis AG WDH-BGP03Pro User manual

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Fan heater WDH-BGP03Pro (3 kW)
Dear Customer,
You have chosen a high-quality product. To ensure that you get a lot of enjoyment from
this product, here are a few more tips:
Information relevant to energy consumption:
This product is only suitable for well-insulated rooms or for occasional use.
In case of any problems:
We hope that the unit meets your expectations! If, despite the greatest possible care, there
should ever be cause for complaint, please contact us briefly, as we are very concerned
about your satisfaction and would like to clear up any misunderstanding.

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
During the first operation:
As the heating elements are covered with a light film of oil at the factory for reasons of
protection, you will notice a slight smell of burning and possibly also some smoke during
the first operation. This is quite normal at first and is caused by the fact that the oil film is
now burnt by the heating elements during operation.
Important safety instructions:
- The heater is not suitable for use outdoors or in other wet or damp environments !
- Please note that the heater can become very hot during operation, so keep a sufficient
distance from flammable or easily combustible objects at all times !
- Do not place the heater directly next to a power socket !
- Do not use a timer or automatic on/off switch in conjunction with this heater !
- Never use the heater on moving surfaces, objects or vehicles ! There is a risk that the
heater may tip over.
- It is recommended to use a separate power source (socket) only for the supply of the
heater. (Please do not use multiple sockets to operate the heater.) Furthermore,
please ensure that the power cable is always laid with sufficient distance to the heat
source.
- Supervise the heater when children are near the appliance !
- Watch out for electricity, never walk into or insert objects into the appliance !
- Do not place any objects on the heater !
- Do not block the supply and/or exhaust air of the unit and please ensure sufficient
space/clearance around the unit !
- Ensure that there is sufficient air supply to the unit, otherwise it can lead to a reduction
in performance and, in the worst case, to overheating and/or fire !
- Only qualified personnel or electricians are allowed to open the unit!
- Make sure that no moisture gets into or onto the unit !
- Only use the recommended voltage for operating the unit !
- Make sure that the power cable is unfolded (untied) before connecting it to the socket !
- Make sure that the plug is cleanly and properly connected to the socket before using
the appliance !
- Never reach near the plug or socket with wet hands !
- Do not repair defective or damaged cables on the unit yourself, you could get a severe
electric shock !
- Make sure that highly flammable substances (e.g. gases/oils etc.) are never in the
vicinity of the unit !
- If the connecting cable of this appliance is damaged, it must be replaced by the
manufacturer or its after-sales service or a similarly qualified person in order to avoid
hazards.

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
- This appliance is not intended to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and/or knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- If you are not going to use the unit for a long time, switch it off and unplug it from the
mains !
Please switch off the unit immediately and disconnect it from the power supply if
something seems to be wrong! In this case, please contact a specialist and do not
try to repair the unit yourself!
Example: Fan does not run during operation or fuse has blown.
Description of the control panel:
1. Operating strength adjustment knob 2. Thermostat control dial

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Instructions for use:
1. Commissioning
1.1 Insert the mains plug properly into the socket.
1.2. Select the desired unit power with the operating power adjustment knob (left-hand
knob).
0 = Off
= Fan operation (cold blower)
= Level 1 (medium operating strength with 1,500 W heating power)
= Level 2 (highest operating strength with 3,000 W heating power)
1.3 Now set the desired temperature switch-off point (0 ~ 45°C) with the stepless
thermostat control dial (right-hand knob). It is best to do this as follows: Turn the
thermostat knob to the highest temperature (MAX.) and let the heater run until your
desired temperature value is reached. Now turn (adjust) the control downwards
towards the minimum until the heating function switches off automatically. Now let the
control dial
(thermostat) on this position and whenever it gets colder in the room, the unit
automatically starts heating and when the adjusted temperature is then reached again,
the unit automatically switches off again !!!
2. Switch off
To switch off the unit, turn the stepless thermostat control knob (right-hand knob) to
minimum (MIN) and let the unit run in fan mode for about 5 minutes to allow it to cool
down. Afterwards, also turn the operating strength adjustment knob to "0" to switch off the
unit completely.

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
3. Cleaning & Storage
Always unplug the heater from the mains and allow it to cool down completely before
cleaning it !
3.1 Cleaning the housing:
- Use a soft and damp cloth to clean the outside of the housing.
- Only use mild cleaning agents to clean your heater.
- Also, make sure that no aggressive cleaning agents are used, as these can damage
your appliance !
- Please make sure that no water gets inside your heater at any time !
3.2 Storage:
- We recommend that you repack the unit in its original box for storage.
- Store the heater in a dry and sufficiently ventilated place/space.
4. Other operating instructions
4.1. Do not disconnect the mains plug by pulling on the power
cable !
4.2. Do not use insect repellent, oil spray, paint spray, etc. near
the heater. This may cause damage to the unit or even fire !
4.3. Do not place the appliance on sloping or uneven ground !
4.4. Please always keep a sufficient distance to the wall to
avoid possible overheating of the appliance.
4.5. For an effective and economical heating operation, please
close all doors and windows in the room of the heater !

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Technical data
Model designation: WDH-BGP03Pro (3 kW)
Voltage: 220 - 240V ~ 50Hz
Max. Power consumption: 3,000 W (13.6 A)
Power settings: 3 ( 1 = 40 W, 2 = 1,500 W, 3 = 3,000 W )
Thermostat: Stepless adjustment ( 0 ~ 45 °C )
Air flow rate: Approx. 284 m³/h
Rated heat output: 3.0 kW
Minimum heat output: 1.5 kW
Max. cont. Heat output: 3.0 kW
Auxiliary power consumption elmax:N/A
Auxiliary power consumption elmin:N/A
Auxiliary power consumption elSB:N/A
Type of temperature control: Mechanical thermostat
Protection class: IP24
Dimension (H/W/D): 330 x 235 x 350 mm
Weight: 6 kg
There may be deviations in the technical data!
Other
Warranty statement:
Notwithstanding the statutory warranty claims, the manufacturer grants a warranty in
accordance with the laws of your country, but at least 1 year (in Germany 2 years for
private individuals). The warranty begins on the date of sale of the appliance to the end
user.
The guarantee only covers defects that are due to material or manufacturing faults.
Warranty repairs may only be carried out by an authorised customer service. To make a
warranty claim, please enclose the original sales receipt (with date of sale).
Excluded from the guarantee are:
- Normal wear
- Improper applications, such as overloading the appliance or non-approved
accessories.
- Damage due to external influences, use of force or foreign bodies
- Damage caused by non-observance of the operating instructions, e.g. connection to
the wrong mains voltage or non-observance of the installation instructions.
- Completely or partially dismantled units

Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: [email protected]
Conformity:
The fan heater has been tested and itself and/or parts thereof have been manufactured
under the following (safety) standards:
Tested by TÜV Rheinland "GS" and of course with CE (LVD + EMC) conformity.
Tested safety according to: EN 60335-1:2012+A11+A13+A1+A14+A2+A15
EN 60335-2-30:2009+A11+A1+A12+A2+A13
EN 62233:2008
AfPS GS 2019:01 PAK
EK1 527-12 Rev. 2
CE (LVD) Conformity tested according to: EN 60335-1:2012+A11+A13+A1+A14+A2+A15
EN 60335-2-30:2009+A11+A1+A12+A2+A13
EN 62233:2008
CE (EMC) conformity tested according to: EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN IEC 61000-3-2:2019+A1
EN 61000-3-3:2013+A1+A2
Correct disposal of this product
Within the EU, this symbol indicates that this product should not be
disposed of with household waste. Waste equipment contains valuable
recyclable materials that should be recycled. Furthermore, the
environment or human health should not be polluted by uncontrolled
waste disposal. Therefore, please dispose of old appliances via suitable
collection systems or send the appliance for disposal to the place where
you purchased it. They will then recycle the appliance.
I wish you much pleasure with this appliance.
Your Aktobis AG
Keep these instructions for use in a safe place !
