Akw 23123 User manual
Ergonomic Toilet Seat
INSTALLATION AND USER MANUAL
Please read all instructions before installation and leave this document
with the end user for future reference as it contains important warranty information
General: 01905 823 298 | www.akw-ltd.co.uk2
2
COMPONENTS & INSTALLATION
Components & Installation
1Steel Hinge Block
2Hinge Pad
3Hinge Spacer
4Hinge Washer
5Hinge Block Nut
6Pivot Sleeve
7Pivot Cap
8Adjustable Buffer
9Toilet Seat
10 Toilet Lid
1
2
3
4
5
7
6
9
10
8
Step 1 - Remove the washer, spacer and nut. Step 2 - Fit the hinge blocks to the seat.
Note that the hinges are handed and
must be tted to the correct sides.
Fit the Pivot caps (7) into place.
Installation Without Lid
Technical Support: 01905 560 219 3Order: 01905 823 299 |orders.akw-ltd.co.uk
3
INSTALLATION
Installation
Step 4 - Align the hinge blocks with the toilet
holes and replace the spacer, washer and nut.
Repeat for both sides and tighten into position.
Ensure the hinge pad (2) is correctly tted.
Step 3 - Align and secure the adjustable
buffers (8) into position. Ensure these
are correctly tted to position the seat
centrally on the toilet.
Step 1 - Remove the washer, spacer and nut.
Installation With Lid
Step 2 - Fit the hinge blocks to the seat.
Note that the hinges are handed and must be
tted to the correct sides.
Step 4 - Align the hinge blocks with the toilet
holes and replace the spacer, washer and nut.
Repeat for both sides and tighten into position.
Ensure the hinge pad is correctly tted.
Step 3 - Align and secure the adjustable
buffers (8) into position. Ensure these
are correctly tted to position the seat
centrally on the toilet.
Orders & Quotes
01905 823 299
General Enquiries
01905 823 298
Technical Enquiries
01905 560 219
Kitchen Enquiries
01905 823 262
Fax
01905 823 297
AKW
Pointon Way, Hampton Lovett
Droitwich Spa, WR9 0LR
www.akw-ltd.co.uk
orders.akw-ltd.co.uk
Follow us on Social:
© AKW Medi-Care Limited 2021 06-021-040-02
Contact
Guarantee
The life time guarantee applies only
to manufacturing or material defects,
conditional on the one-time correct
installation of the product.
It does not apply to:
• Inappropriate use or accidental damage.
• Damage or defects that result from
incorrect installation.
• Lack of maintenance including the build
up of grime or damage resulting from
inappropriate cleaning.
• Damage or defects that result from
repairs or modications undertaken
by unauthorised persons.
• This guarantee excludes general wear
and tear through usage and does not
apply to surface nishes.
What to do if something goes wrong?
If you have a problem with this product,
please contact your local installer. If this
does not resolve the issue, contact the
AKW Technical Enquiries who can provide
further advice and, if necessary, arrange for
a maintenance engineer to visit and report
any issues. See the T&Cs on our website or
catalogue for further information. None of
the foregoing affects your statutory rights.
