AL-KO LH KOMF User manual

1
3910834 Subject to changes in keeping with technical developments!
OPERATING AND INSTALLATION INSTRUCTIONS
AIR HEATER COMFORT
VENTILATION AND CENTRAL AIRCONDITONING DEVICES
GB

Translation from the original operating instruction2
AL-KO AIR HEATER COMFORT
Table of contents
1. Information concerning this handbook.................................................................. 4
1.1 Description of symbols...............................................................................................................................4
1.2 Regulations and standards .........................................................................................................................4
1.3 Legal information .......................................................................................................................................4
2. Safety information .........................................................................................5
2.1 Appropriate use ..........................................................................................................................................5
2.2 Possible inappropriate uses........................................................................................................................5
2.3 Residual risks.............................................................................................................................................6
2.4 Delivery ......................................................................................................................................................6
2.5 Storage, transport ......................................................................................................................................6
2.6 Duties of the operating company................................................................................................................7
2.7 Disposal of the packaging...........................................................................................................................7
3. Product description ........................................................................................ 7
3.1 Declaration of incorporation .......................................................................................................................8
3.2 Declaration of conformity ...........................................................................................................................9
3.3 Technical data........................................................................................................................................... 10
3.3.1 TYPE LH-KOMF… K.................................................................................................................................. 10
3.3.2 TYPE LH-KOMF… K/h ..............................................................................................................................11
3.3.3 TYPE LH-KOMF… K/o ..............................................................................................................................12
3.3.4 TYPE LH-KOMF… K/TA ............................................................................................................................13
3.3.5 TYPE LH-KOMF… KE/TA ..........................................................................................................................14
3.4 Performance diagrams ............................................................................................................................. 15
3.5 Accessory.................................................................................................................................................15
4. Transport .................................................................................................. 16
4.1 Fork lift / industrial truck transport...........................................................................................................16
5. Assembly .................................................................................................. 17
5.1 Ceiling installation of the devices..............................................................................................................17
5.2 Heat exchanger connection ......................................................................................................................19
5.3 Electrical connection.................................................................................................................................19
5.3.1 Fan............................................................................................................................................................20
5.3.2 Cable list...................................................................................................................................................21
6. Operation / general information ....................................................................... 22
7. Switch cabinet ............................................................................................ 22
8. Maintenance .............................................................................................. 22
8.1 Safety .......................................................................................................................................................22
8.2 Consumables and spare parts ..................................................................................................................22
8.3 Maintenance plan .....................................................................................................................................23
8.4 Checking the components ........................................................................................................................23
8.4.1 Checking the heat exchanger....................................................................................................................23
8.4.2 Checking outlet jalousies..........................................................................................................................23
8.4.3 Checking the fans .....................................................................................................................................24
8.5 Cleaning the components .........................................................................................................................24
8.5.1 Clean the heat exchangers........................................................................................................................24
8.5.2 Cleaning the outlet vents ..........................................................................................................................24
8.5.3 Clean the fans...........................................................................................................................................24

3
3910834 Subject to changes in keeping with technical developments!
"Table of contents"
8.6 Exchanging components ..........................................................................................................................25
8.6.1 Exchanging the heat exchanger ................................................................................................................25
8.6.2 Exchange the outlet vents.........................................................................................................................25
8.6.3 Exchanging the fan ...................................................................................................................................25
9. Help with faults........................................................................................... 25
9.1 Contact person .........................................................................................................................................26
9.2 General faults ...........................................................................................................................................26
10. Shut-down................................................................................................. 26
10.1 Decommissioning.....................................................................................................................................26
10.2 Dismantling ..............................................................................................................................................26
10.3 Disposal....................................................................................................................................................26

Translation from the original operating instruction4
AL-KO AIR HEATER COMFORT
1. Information concerning this handbook
Read this documentation before installation and commissioning. This is a requirement for safe working and fault-
free operation.
Adhere to the safety and warning notes in this documentation and on the product.
This documentation is a permanent part of the product described and should be handed to the buyer in the event
of a sale!
1.1 Description of symbols
Warning!
This symbol refers to safety procedures that are required to prevent injuries!
Caution!
This symbol refers to safety procedures that are required to prevent damage to goods!
Special information to improve comprehension and handling.
1.2 Regulations and standards
The following standards and regulations were applied during the design phase and also apply to installation, commis-
sioning, operation and maintenance:
DIN EN ISO 12100 Safety of machinery – General principles for design – Risk assessment and risk reduction
DIN EN 60204-1 Safety of machinery – Electrical Equipment of machines – Part 1: General requirements
DIN EN 349 Safety of machinery – Minimum gaps to avoid crushing of parts of the human body
DIN EN ISO 13857 Safety of machinery – Safety distances to prevent hazard zones being reached by upper and
lower limbs
VDMA 24167 Fans - Safety requirements
2006/42/EC Machinery Directive
97/23/EC Pressure Equipment Directive
2004/108/EC Electromagnetic Compatibility
1.3 Legal information
All data provided are only intended to describe the product. They do not guarantee a certain composition of the system
or its suitability for a specic application. This information does not release the user from his obligation to perform
evaluations and tests.

5
3910834 Subject to changes in keeping with technical developments!
2. Safety information
Please take note of these issues to prevent injuries, res and other hazards caused by inappropriate use and operation
of the air heater:
Warning!
Installation, electrical connection, media supply connection, maintenance, commissioning, repair, etc. may only
be performed by trained staff.
Before any work on the air heater is undertaken, it must be ensured that the power supply is switched off (all-pole separa-
tion) and secured against unauthorised re-operation!
Only operate the air heaters once they have been completely assembled and provided with appropriate reach-in protec-
tion.
All claims for damages or warranties become void when the installation does not comply with our stipulations or when
the fault/damage is causally related to inappropriate alterations, processing or other treatment. The user must prove that
the fault is not due to inappropriate installation.
The general maintenance instructions in the operating and installation instructions for the AL-KO air heaters must always
be adhered to.
The implementation and design of the air heater corresponds to the standards listed in the declaration of conformity and
declaration of incorporation to minimise the risk potential posed by the air heater. The potential risk can only be mini-
mised when these additional, applicable standards for the installation-ready system are adhered to by the system builder.
It must be ensured that all authorised persons have read and understood all of the operating and installation instructions
and adhere to them!
All plant, company and work instructions of the user apply in addition to these operating instructions to prevent hazards
within the company.
Personal protective equipment is required for work on the air heater!
2.1 Appropriate use
The application range for AL-KO air heaters is exclusively air heating of the air in rooms and buildings with normal cli-
mate and normal atmosphere.
The air heaters may only be operated in an environmental temperature range between -20 °C and +40 °C and a humidity
range between 50% and 85% relative humidity without condensation.
Installation of the air heaters at a location more than 800 m above sea level may lead to a drop in performance and has
to be investigated on a case-by-case basis.
Different areas of application should be discussed with the manufacturing plant.
2.2 Possible inappropriate uses
AL-KO air heaters may only be operated within the range specied in the technical data provided by AL-KO. Any other or
further use that deviates from the description in Point "2.1" Appropriate use" is deemed inappropriate use. The manufac-
turer is not liable for damage resulting from such use.
Possible inappropriate use includes, for example:
Transport of media with temperatures above or below the permitted range, aggressive media or media containing
a lot of dust.
Use in an explosive atmosphere.
Use in wet areas with a high humidity content (e.g. washing system)
"Safety information"

Translation from the original operating instruction6
AL-KO AIR HEATER COMFORT
2.3 Residual risks
The air heater may pose risks when it is used by untrained persons or in an incorrect or inappropriate way.
Residual risks are potential risks that are not obvious, e.g.:
Injuries due to not adhering to the safety instructions, standards, guidelines or regulations
Injuries due to uncoordinated work.
Risk due to working on the electrical system, the cables and the connections
2.4 Delivery
AL-KO air heaters are delivered in cardboard boxes or on pallets incl. lm packaging!
2.5 Storage, transport
Warning! Caution!
Store the air heaters in their original packaging in a dry place and protected against the weather.
Cover open pallets with tarpaulins and protect the air heaters against dirt (e.g. chips, stones, wire, etc.)
Additional, protective packaging must be used for transport under harsh conditions, (e.g. on open vehicles, exposed
to unusual vibration, transport by sea or in subtropical countries).
Prevent repeated and, in particular, sudden temperature changes. They are particularly harmful when the humidity
can condense.
Check the ease of movement of the fan bearings (turn them by hand) after storage periods longer than 1 year.
The device can be transported with a fork lift or and industrial truck as described in Point 4.1 "Fork lift / industrial
truck transport".
Clear vision must be ensured during the transport
(use support staff as required)
No persons may remain in the transport area.
The relevant worker safety and environmental protection regulations must be adhered to during transport.
The air heater may only be transported by educated, trained and instructed personnel and with appropriate consid-
eration of safety issues.
It must be ensured that drivers have appropriate driving licences when transporting devices requiring a driving li-
cence.
Avoid twisting of the housing or other forms of damage.
Damage caused by in appropriate packaging, storage or transport are to be borne by the party that caused them.
When the system stands still for more than one month, the fan must be turned once a month to prevent damage to
the bearings.

7
3910834 Subject to changes in keeping with technical developments!
2.6 Duties of the operating company
The operator of the AL-KO products must regularly train his staff with regard to the following:
Adherence to and use of the operating and installation instructions as well as the legal regulations.
Appropriate operation of the air heater.
Adhere to the instructions of the company security and the operating instructions of the operating company as re-
quired.
Conduct in emergencies
2.7 Disposal of the packaging
Disposal of the packaging must be performed according to the currently valid, local environmental and
recycling regulations of your country and your municipality.
3. Product description
AL-KO air heaters of the COMFORT series consist of a stable, self-supporting steel sheet housing which is sendzimir-
galvanised and has additional powder coating. Individually adjustable ns are arranged on all four sides. A maintenance-
free axial fan ensures low-noise operation. The drives of the AL-KO air heaters are external rotor motors. They have a
permanently lubricated deep-groove ball bearing and the fan forms a single unit with the rotor. A heat exchanger for air
heating will be installed in the housing next to the fan. This is implemented as a nned heat exchanger (made of Cu / Al).
The air heaters can be extended with various electrical accessories.
Type key COMFORT:
LH KOMF 140 3 K
Device type
LH KOMF Air heater COMFORT
Device size
140
250
400
650
Heat exchanger type
1 1 row of pipes, distance of ns 2.1 mm
2 2 row of pipes, distance of ns 2.5 mm
3 3 row of pipes, distance of ns 2.5 mm
Device versions
K for low room heights (intake at the bottom)
K/o for low room heights (intake at the top)
K/h for medium room heights (intake at the side)
K/TA for gate air curtain systems (intake at the side)
KE/TA for gate air curtain systems (intake at the side)
Supplementary text for additional options
a Console (adjustable)
c Console (bracket)
"Safety information / Product description“

Translation from the original operating instruction8
AL-KO AIR HEATER COMFORT
3.1 Declaration of incorporation

9
3910834 Subject to changes in keeping with technical developments!
3.2 Declaration of conformity
"Product description"

Translation from the original operating instruction10
AL-KO AIR HEATER COMFORT
3.3 Technical data
3.3.1 TYPE LH-KOMF… K
Type Dimensions in mm Heat exchanger connection
Noise pressure level
3 m distance
L
mm
b
mm
c
mm
d
mm
1
RR
2
RR
3
RR
Max.
rotation
speed
Min.
rotation
speed
dB(A) dB(A)
LH-KOMF 140 K 600 572 40 420 1“ 1“ 1“ 51 45
LH-KOMF 250 K 700 672 46 520 1“ 1“ 1“ 54 47
LH-KOMF 400 K 800 772 52 620 1“ 1“ 1“ 57 50
LH-KOMF 650 K 900 872 76.9 720 1“ 1“ 1“ 60 53
Type Weight in kg Water content in l
1
RR
2
RR
3
RR
1
RR
2
RR
3
RR
LH-KOMF 140 K 23 24 26 1.2 1.9 2.6
LH-KOMF 250 K 30 31 34 1.3 2.3 3.1
LH-KOMF 400 K 36 38 40 1.5 2.6 3.6
LH-KOMF 650 K 48 50 53 1.6 2.9 4.1
L
d
b
L
d
180
210c
Internal thread
G 1"
b
50
123
Fig.: Type LH-KOMF…-K device series

11
3910834 Subject to changes in keeping with technical developments!
3.3.2 TYPE LH-KOMF… K/h
Type Dimensions in mm Heat exchanger connection
Noise pressure level
3 m distance
L
mm
b
mm
c
mm
d
mm
1
RR
2
RR
3
RR
Max.
rotation
speed
Min.
rotation
speed
dB(A) dB(A)
LH-KOMF 140 K/h 600 572 108.2 420 1“ 1“ 1“ 51 46
LH-KOMF 250 K/h 700 672 108.2 520 1“ 1“ 1“ 56 49
LH-KOMF 400 K/h 800 772 108.2 620 1“ 1“ 1“ 58 51
LH-KOMF 650 K/h 900 872 108.2 720 1“ 1“ 1“ 61 54
Type Weight in kg Water content in l
1
RR
2
RR
3
RR
1
RR
2
RR
3
RR
LH-KOMF 140 K/h 28 30 32 1.2 1.9 2.6
LH-KOMF 250 K/h 37 38 41 1.3 2.3 3.1
LH-KOMF 400 K/h 45 47 49 1.5 2.6 3.6
LH-KOMF 650 K/h 59 61 64 1.6 2.9 4.1
L
d
b
L
d
123
193,5
223c
Internal thread
G 1"
b
50
Fig.: Type LH-KOMF…-K/h device series
"Product description"

Translation from the original operating instruction12
AL-KO AIR HEATER COMFORT
3.3.3 TYPE LH-KOMF… K/o
Type Dimensions in mm Heat exchanger connection
Noise pressure level
3 m distance
L
mm
b
mm
c
mm
d
mm
1
RR
2
RR
3
RR
Max.
rotation
speed
Min.
rotation
speed
dB(A) dB(A)
LH-KOMF 140 K/o 600 572 26.9 420 1“ 1“ 1“ 51 45
LH-KOMF 250 K/o 700 672 32.9 520 1“ 1“ 1“ 54 47
LH-KOMF 400 K/o 800 772 38.9 620 1“ 1“ 1“ 57 50
LH-KOMF 650 K/o 900 872 63.8 720 1“ 1“ 1“ 60 53
Type Weight in kg Water content in l
1
RR
2
RR
3
RR
1
RR
2
RR
3
RR
LH-KOMF 140 K/o 22 24 26 1.2 1.9 2.6
LH-KOMF 250 K/o 29 31 33 1.3 2.3 3.1
LH-KOMF 400 K/o 36 38 40 1.5 2.6 3.6
LH-KOMF 650 K/o 44 46 49 1.6 2.9 4.1
L
d
L
d
b
123
180
210 c
Internal thread
G 1"
b
50
Fig.: Type LH-KOMF…-K/o device series

13
3910834 Subject to changes in keeping with technical developments!
3.3.4 TYPE LH-KOMF… K/TA
Type Dimensions in mm Heat exchanger connection
Noise pressure level
3 m distance
L
mm
b
mm
c
mm
d
mm
1
RR
2
RR
3
RR
Max.
rotation
speed
Min.
rotation
speed
dB(A) dB(A)
LH-KOMF 140 K/TA 600 572 193 420 1“ 1“ 1“ 51 45
LH-KOMF 250 K/TA 700 672 210 520 1“ 1“ 1“ 54 47
LH-KOMF 400 K/TA 800 772 233 620 1“ 1“ 1“ 57 50
LH-KOMF 650 K/TA 900 872 257 720 1“ 1“ 1“ 60 53
Type Weight in kg Water content in l
1
RR
2
RR
3
RR
1
RR
2
RR
3
RR
LH-KOMF 140 K/TA 30 31 33 1.2 1.9 2.6
LH-KOMF 250 K/TA 39 40 43 1.3 2.3 3.1
LH-KOMF 400 K/TA 49 51 53 1.5 2.6 3.6
LH-KOMF 650 K/TA 62 64 67 1.6 2.9 4.1
L
d
b
L
d
123
193,5
223c
b
Internal thread
G 1"
50
Fig.: Type LH-KOMF…-K/TA device series
"Product description"

Translation from the original operating instruction14
AL-KO AIR HEATER COMFORT
3.3.5 TYPE LH-KOMF… KE/TA
Type Dimensions in mm Heat exchanger connection
Noise pressure level
3 m distance
L
mm
b
mm
c
mm
d
mm
1
RR
2
RR
3
RR
Max.
rotation
speed
Min.
rotation
speed
dB(A) dB(A)
LH-KOMF 140 KE/TA 600 572 193 420 1“ 1“ 1“ 52 46
LH-KOMF 250 KE/TA 700 672 210 520 1“ 1“ 1“ 55 50
LH-KOMF 400 KE/TA 800 772 233 620 1“ 1“ 1“ 57 50
LH-KOMF 650 KE/TA 900 872 257 720 1“ 1“ 1“ 60 54
Type Weight in kg Water content in l
1
RR
2
RR
3
RR
1
RR
2
RR
3
RR
LH-KOMF 140 KE/TA 29 31 33 1.2 1.9 2.6
LH-KOMF 250 KE/TA 38 40 42 1.3 2.3 3.1
LH-KOMF 400 KE/TA 49 51 54 1.5 2.6 3.6
LH-KOMF 650 KE/TA 61 63 66 1.6 2.9 4.1
L
d
b
L
d
123
193,5
223c
b
50
Internal thread
G 1"
Fig.: Type LH-KOMF…-KE/TA device series

15
3910834 Subject to changes in keeping with technical developments!
3.4 Performance diagrams
Air heaters LH-KOMFORT
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
140
250
400
650
Heating power (kW) at PWW 60/40 °C, tL1 = 15 °C
Device size
Fig.: Heat performance diagram
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
140
250
400
650
Air volume (m³/h)
Device size
Fig.: Air volume diagram
3.5 Accessory
Console a
The Console Set a is suited for ceiling installation of the air heaters on suspended or inclined ceilings. The distance of the
air heater to the ceiling is freely adjustable from 150 – 250 mm. It consists of four consoles and the fastening screws.
L
Type L
mm
Weight kg*
a 160 - 260 1.4
* Weight of the console set
"Product description"

Translation from the original operating instruction16
AL-KO AIR HEATER COMFORT
Console c
The Console Set c is suited for ceiling installation of the air heaters. The distance of the air heater to the ceiling is about
40 mm. The set consists of four consoles and the fastening screws.
Type Weight kg*
c 0.35
* Weight of the console set
4. Transport
Caution!
The individual components of the system may only be moved with the transport devices intended for this purpose.
Do not step or work under suspended loads.
Only permitted lifting tools with sufcient carrying capacity may be used.
The lifting tools must be fault-free.
The load-handling equipment must be checked for carrying capacity and damage before use.
Protective gloves should be worn during transport and installation of the devices (risk of cutting).
Only remove the packaging immediately before installation.
4.1 Fork lift / industrial truck transport
AL-KO air heaters can be transported in their original packaging with a fork lift or an industrial truck!
Caution!
Always place the lifting forks of the fork lift against the timbers.
Pay attention to any objects that may protrude (e.g. media connections)
Use suitable fork lengths to prevent damage to the device.
Use suitable intermediate timber layers.

17
3910834 Subject to changes in keeping with technical developments!
5. Assembly
Warning!
Installation, electrical connection, media supply connection, maintenance, commissioning, repair, etc. may only
be performed by trained staff.
The place of installation as well as the installation structure must provide permanent and vibration-free support of
the devices.
The place of installation and the installation structure has to be checked by a structural engineer, if required.
AL-KO air heaters are delivered in pre-assembled form.
The manufacturer documentation must be considered before installation or removal.
The air heaters must be levelled during the installation!
5.1 Ceiling installation of the devices
Device Version K
The Device Version K is intended for low rooms. The recirculated air is sucked in at the bottom centre of the device. The
heated air is distributed in four directions. The outlet louvres should be directed slightly downwards. The air heater can
either be mounted directly under the ceiling or fastened at a distance to the ceiling with Console Set a or c (optional).
Max. permitted distance from the oor to the bottom edge of the device:
Type 140-K = 2400 mm
Type 250-K = 2500 mm
Type 400-K = 2700 mm
Type 650-K = 3400 mm
Device Version K/h
The K/h device version is intended for medium-high rooms. The recirculated air is taken in at the ceiling on all four sides,
heated and blown downwards into the room in a cone-shaped stream. The air heater can either be mounted directly
under the ceiling or fastened at a distance to the ceiling with Console Set a or c (optional).
Max. permitted distance from the oor to the bottom edge of the device:
Type 140-K/h = 3500 mm
Type 250-K/h = 4000 mm
Type 400-K/h = 4500 mm
Type 650-K/h = 5000 mm
Device Version K/o
The K/o device version is intended for low rooms. The recirculated air is sucked in at the centre top of the device. The
heated air is distributed in four directions. The outlet louvres should be directed slightly downwards. The air heater must
be mounted to leave at least a distance of 150 mm from the fan to the ceiling. Console set a (optional) can be used for
this purpose.
Max. permitted distance from the oor to the bottom edge of the device:
Type 140-K/o = 2400 mm
Type 250-K/o = 2500 mm
Type 400-K/o = 2700 mm
Type 650-K/o = 3400 mm
"Assembly"

Translation from the original operating instruction18
AL-KO AIR HEATER COMFORT
Device Version K/TA and KE/TA
The K/TA and KE/TA device version is well suited for gate air curtain systems, due to its conical outlet hood. This device
version should be mounted as close as possible to the gate openings. The recirculated air is taken in at the ceiling on all
four sides, heated and blown downwards into the room against the intake direction. The air heater can either be mounted
directly under the ceiling or fastened at a distance to the ceiling with Console Set a or c (optional).
Max. permitted distance from the oor to the bottom edge of the device:
Type 140-K/TA = 2500 mm Type 140-KE/TA = 4000 mm
Type 250-K/TA = 3000 mm Type 250-KE/TA = 4500 mm
Type 400-K/TA = 3500 mm Type 400-KE/TA = 5000 mm
Type 650-K/TA = 4000 mm Type 650-KE/TA = 5500 mm
Mount the bracket set on the air heater (if it was not pre-installed at the factory)
Drill fastening holes into the ceiling.
Attach the air heater to the ceiling.
Establish the media connections.
Example for ceiling mounting:
Max. permitted floor
distance must be considered
Max. permitted floor
distance must be considered
Fig.: Installation example for Device Version K Fig.: Installation example for Device Version K/h
Fig.: with Console Set c
Max. permitted floor
distance must be considered
min. 150 mm
Max. permitted floor
distance must be considered
h
h/4
approx. 100
max.
30°
Fig.: Installation example for Device Version K/o Fig.: Installation example for Device Version K/TA; KE/TA
Fig.: with Console Set a Fig.:
Fig.:

19
3910834 Subject to changes in keeping with technical developments!
5.2 Heat exchanger connection
Take care not to mix up the feed and reux pipe during the pipe installation.
The feed line must be connected at the bottom and the reux line at the top of the devices to ensure optimal
warm water distribution within the nned heat exchanger.
Caution!
Hold the connectors in place with a suitable tool (e.g. pipe wrench) when connecting the heat exchanger to
prevent damage.
Attach pipes and connectors to ensure free access to the heat exchangers for maintenance purposes.
When temperatures below the freezing point occur, the heat exchanger must either be emptied and blown out
with compressed air or a standard anti-freeze with corrosion protection must be lled in to prevent damage due
to frost or corrosion!
CU/AL heat exchanger:
Maximum operating pressure: 16 bar.
Maximum ow temperature: 120 °C.
Feed and reux pipes must be connected according to the professional regulations.
May only be operated with water that has no corrosive properties (e.g. no high-purity water) and that contains nei-
ther oxygen or carbon dioxide!
Valves and actuators must be professionally mounted (provided by customer).
Carefully bleed the heat exchanger.
The bleeding and draining facilities for the heat exchanger must be provided by the customer.
The complete piping must be checked for leaks!
5.3 Electrical connection
Warning!
The electrical connection may only be performed by a registered electrician and with consideration of the DIN
and VDE regulations and the directives of the local energy supply company.
The electrical connection of the AL-KO air heater must be performed according to the connection plans. Only use
the device-specic circuit diagram to connect the device.
The air heaters must be grounded.
It must be possible to switch off all poles of the supply line with a maintenance switch.
Fluctuations or deviations from the mains voltage may not exceed the tolerances specied in the technical data, as
malfunction can otherwise not be excluded.
All electrical motors of the fans have a thermal contact as standard equipment. It must be integrated into the con-
troller.
"Assembly"

Translation from the original operating instruction20
AL-KO AIR HEATER COMFORT
5.3.1 Fan
Check the rotation direction of the fan.
The rotation direction must correspond with the rotation direction arrow on the fan blade or the fan housing.
Technical data for 400-V fan:
Type 140-K… 250-K… 400-K… 650-K…
Operating voltage in V 3~400 V/50 Hz 3~400 V/50 Hz 3~400 V/50 Hz 3~400 V/50 Hz
ΔYΔYΔYΔY
Power consumption
in kW
0.05 0.03 0.11 0.07 0.16 0.10 0.35 0.21
Nominal current in A 0.13 0.07 0.28 0.15 0.38 0.19 0.78 0.39
Operating speed
rpm
910 720 890 710 670 500 660 500
Insulation class THCL 155 (F) THCL 155 (F) THCL 155 (F) THCL 155 (F)
Protection type IP 54 IP 54 IP 54 IP 54
Motor contactor Thermal contact Thermal contact Thermal contact Thermal contact
Type 140-KE… 250-KE… 400-KE… 650-KE…
Operating voltage in V 3~400 V/50 Hz 3~400 V/50 Hz 3~400 V/50 Hz 3~400 V/50 Hz
ΔYΔYΔYΔY
Power consumption
in kW
0.18 0.13 0.29 0.21 0.35 0.25 0.75 0.47
Nominal current in A 0.33 0.20 0.50 0.32 0.80 0.46 1.50 0.83
Operating speed
rpm
1350 1000 1330 1020 890 660 880 680
Insulation class THCL 155 (F) THCL 155 (F) THCL 155 (F) THCL 155 (F)
Protection type IP 54 IP 54 IP 54 IP 54
Motor contactor Thermal contact Thermal contact Thermal contact Thermal contact
Terminal strip 400 V without AL-KO rotation speed control
Fan 3x400 V 50 Hz Fan 3x400 V 50 Hz
Fig.: Connection scheme for 1-level operation Fig.: Connection scheme for 1-level operation
Fig.: Low rotation speed (star connection) Fig.: High rotation speed (delta connection)
