Alango Technologies BeHear PROXY User manual

[email protected]
www.alango-behear.com
Quick Start
Guide
TV LISTENING SYSTEM
BeHear PROXY + HearLink PLUS
[email protected]
www.alango-behear.com

1. Connect HearLink PLUS to a power outlet (a) or the TV set’s
USB port (b) using the supplied USB power cable. HearLink
PLUS will turn ON automatically.
TV
a
b
Remove for
Bypass use
TX
TX Verify that the mode switch
is set to TX position
2. Connect the HearLink PLUS TX port to the TV (or other
media device) via the supplied optical or 3.5mm audio
cable. The active connection type is indicated by the
illuminated text ( or ).
OPT AUX
Remove for
Bypass use
AUX OPT
Make sure to remove the plastic
protectors from the optical cable
terminals prior to insertion.
Getting Started
A
2

3. Turn on the BeHear PROXY
neck speaker by sliding up
the Power button and holding
it until the unit vibrates and
the LED turns light blue.
A voice prompt will be played.
Verify that the mode
switch is set to
Loudspeaker position.
4. Successful connection of the BeHear PROXY is indicated
by the illuminated A on the HearLink PLUS panel.
The LL is illuminated to indicate that the Low Latency
APTX-LL Bluetooth CODEC is being used.
LL
A
If the automatic connection is delayed, briefly shift
up the BeHear PROXY Power button to reconnect it
to the HearLink PLUS transmitter.
3

Press to increase the volume. A tone is played
when maximum volume is reached.
Press to decrease the volume. A tone is played
when minimum volume is reached.
Short press to toggle audio Play/Pause.
1. HearLink PLUS Manual Control
Press to decrease the volume. A tone is played
when minimum volume is reached.
Press to increase the volume. A tone is played
when maximum volume is reached.
Short press to toggle Play/Pause audio.
2. BeHear PROXY Remote Control
Manage audio play using controls on the neck speaker.
4
Audio Playback
B

Helpful Information
C
5
2. If you do not hear audio:
Ensure that the ‘audio out’ port of your TV connected to
the HearLink PLUS is active. For some devices you need
to enable the audio output. Refer to your device’s user
manual.
Toggle the Play/Pause button on the BeHear neck
speaker or button on the HearLink PLUS.
3. If the automatic connection is delayed, briefly shift up
the BeHear PROXY Power button to reconnect it
to a previously paired HearLink PLUS transmitter.
1. Charge the neck speaker directly from a wall outlet or
computer USB port.
The LED indicator is red during charging and turns green
when the neck speaker is fully charged.
Full charging takes up to 3 hours.

6
TX
AB
When pairing is complete (after 5-30 seconds) will
be illuminated on the HearLink PLUS panel.
Successful connection of the BeHear PROXY neck
speaker is indicated by the illuminated or on the
HearLink PLUS panel.
TX
4. To restore connection between BeHear PROXY and
Hearlink Plus transmitter:
Place HearLink PLUS into pairing mode with a short
press on its button.
When in pairing mode the indicator light will flash TX
quickly.
Turn OFF BeHear PROXY.
Shift its power switch up and hold it until the voice
prompt says: “Pairing mode active” and the LED blinks
in alternating red and blue.
Place the BeHear PROXY neck speaker close to the
HearLink PLUS device.

5. Use the HearLink PLUS Bypass mode to maintain the
existing interfaces between your TV and peripheral
audio equipment.
Remove protection sticker from the rear panel and
connect the Hearlink PLUS TX port to the TV via the optical
or 3.5mm audio cable, and the RX port to a speaker or
other peripheral audio equipment using the same type of
cable as the TX port connection.
To passthrough HearLink PLUS
set its Mode switch to Bypass
position, indicated by .
Bypass
AUX OPT
AUX
OPT
Remove the sticker to expose the RX ports.
Non-Wireless Speaker
7
6. More details about Hearlink Plus and BeHear PROXY can
be found in their user manuals.
[email protected]
www.alango-behear.com
To restore connection with the
BeHear PROXY neck speaker set
the Mode switch to TX.
TX
