USER MANUAL
Alb Filter® DUO
Kitchen faucet water filter
Blaufaktor GmbH & Co. KG
Riedweg 12
D-78607 Talheim
www.alb-filter.com
info@alb-filter.com

Thank you very much for purchasing our
Alb Filter®DUO
To ensure correct installation and ecient operation
of the water filter, please follow the installation
instructions below.
MEANING OF PICTOGRAMS
Increased attention required
Additional information
Note
Tool required
Purchase additionally
TABEL OF CONTENT
Preamble ......................................................................................... 4
Description ..................................................................................... 6
Scope of delivery ......................................................................... 7
Components – Alb Filter® DUO ............................................... 8
Please note before installation .............................................. 10
Determine connection thread ................................................ 10
Installation Alb Filter® DUO ....................................................... 12
Changing the filter cartridge ................................................... 16
Cartridge replacement interval .............................................. 20
Filter cartridges for the Alb Filter® DUO ............................. 21
Maintenance and care ................................................................ 21
Flow rates ....................................................................................... 22
Technical informations ............................................................... 23
General safety informations .................................................... 24
FAQ - Frequently asked questions ........................................ 26
Reminder to change the filter cartridge ............................ 28
Cartridge abonnement ............................................................... 29
2 3

PREAMBLE
Alb Filter® - a maer of heart.
We are pleased that you have chosen Alb filter.
Since 2001 we can look back on a great experience in the
field of water treatment.
At a time when even the smallest part seems to come from
the Far East, we at Alb Filter stand for quality from the
centre of the Swabian Alb. A production site in southern
Germany, which is characterized by the highest standards
and precision in many areas.
We feel commied to our region and manufacture our
products with our partners in the surrounding area.
A real piece of home - Made in Germany.
4 5

SCOPE OF DELIVERY
Note:
Please check that the delivery is complete before
commissioning - it consists of
• Alb Filter® DUO filter housing with aerator bypass
and changeover function
• Alb Filter® Cartridge
Further accessories as well as replacement filter cartrid-
ges, thread adapters and discount oers can be found at
www.alb-filter.com
DESCRIPTION
The Alb Filter® DUO - a high quality water filter for
installation directly on the tap.
Alb Filter® DUO is ideal for:
• Drinking water treatment
• Preparation of food (cooking water)
• Cleaning of food
The water filter is installed directly on the kitchen faucet. For
this purpose the bypass is screwed to the standardized out-
let (M22 AG/M24 IG) instead of the jet regulator.
By means of a practical switch lever, it is possible to choose
between filtered and unfiltered water.
6 7

Made in Germany
S/N 0000001
2
1. Upper sealing cap with internal sealing ring
2. Filter body with external thread at the top and boom
3. Threaded connection with union nut and head gasket
for water filter fiings with standard connection M22 x 1
female thread
4. Switch lever: unfiltered water / filtered water
5. Jet regulator thread (external thread: M22 x 1)
6. Jet regulator with head gasket (unfiltered water)
7. Supply line bridge for filter housing with 4 mm allen
hollow screw and sealing ring.
8. Lower sealing cap with internal sealing ring
9. Width across flats 24 mm for open-end wrench
10. Jet regulator thread (external thread: M22 x 1)
11. Jet regulator with head gasket (filtered water)
COMPONENTS – ALB FILTER®DUO
1
8
9
10
11
3
4
6
5
7
2
8 9

PLEASE NOTE BEFORE INSTALLATION
The Alb Filter® DUO has a standard M22 female thread, suitable
for most taps with M22 male thread. If your faucet does not
have a M22 external thread, you will need an adapter.
Adapter available at www.alb-filter.com
Shop Category: Accessories
DETERMINE CONNECTION THREAD
The two most common jet control variants are called M22 or
M24 in technical terms. Furthermore there are further sizes
e.g. M16, M18 and M21, which are however less common.
Online thread guide for more details at
www.alb-filter.com
Procedure for determining their connection thread:
1. Remove your aerator from the fiing. If necessary, use a
pipe wrench with jaw protection or a mounting key.
2. Measure the diameter of the thread on the tap.
Alternatively, measure the diameter at the unscrewed
aerator.
Ø (inner) mm Ø (outer) mm Type
16,9 17,8 M18 x 1
18,9 18,8 M19 x 1
20,9 21,8 M22 x 1
22,9 23,8 M24 x 1
10 11

Made in Germany
S/N 0000001
D
B
A
Alb
f i lter
®
Made in Germany
Active
Al b
f i lter
®
Made in Germany
S/N 0000001
2
C
ATTENTION!
An adapter is
required!
INSTALLATION ALB FILTER®DUO
Procedure:
1. Make sure that your water tap is closed (A). Remove the
Alb Filter® DUO from its packaging.
If the cartridge is not pre-installed, please follow the
instructions for changing the cartridge on page 16.
2. Remove the aerator of your faucet using a suitable tool.
(B)
3. Check the condition of the thread of your fiing and, if
necessary, remove lime and other deposits.
4. If your armature does not have a standard M22 external
thread, screw the previously determined thread adapter
into your armature. (C)
If you have any questions about the thread adapters, you
can contact us using the contact details on our website.
5. Screw the Alb Filter® DUO to your
faucet or adapter by turning the
serrated union nut. (D)
Aention: Avoid placing the union nut
on the thread at an angle.
12 13

Made in Germany
S/N 0000001
H
E
F
G
1. Check that the Alb Filter® DUO is correctly and firmly
aached to your faucet. If necessary, use a pair of pliers
with jaw protection to tighten the union slightly.
2. Before opening the water inlet of your faucet, make sure
that the switch lever is in vertical (downward) position.
Mode: Unfiltered.
3. Set the switch lever to horizontal position (Mode:
Filtered) (E). Then slowly open the water inlet of your
faucet. (F)
4. Now let the water run through the water filter for 5
minutes to activate it. (G)
Production-related activated carbon dust may dissolve
during rinsing and slightly cloud the water during the
cartridge activation process.
5. Check the water filter housing and all connected
components for leaks. (H)
6. The Alb Filter® DUO is now ready for use.
We recommend to mount the Alb Filter® DUO on the
right side or aligned to the front to make the switchover
function (filtered/unfiltered) easier to operate.
14 15

Made in Germany
S/N 0000001
B
Made in Germany
S/N 0000001
A
Alb
f i lter
®
Made in Germany
Active
Alb
f i lter
®
Made in Germany
Active
Made in Germany
S/N 0000001
C
Alb
f i lter
®
Made in Germany
Active
Alb
f i lter
®
Made in Germany
Active
Made in Germany
S/N 0000001
D
Alb
f i lter
®
Made in Germany
Active
Alb
f i lter
®
Made in Germany
Active
Made in Germany
S/N 0000001
CHANGING THE FILTER CARTRIDGE
Procedure:
1. Close the inlet of your faucet.
2. Unscrew the lower cap of the Alb Filter® DUO from the
filter body. (A)
3. Pull the cap downwards. The filter cartridge becomes
visible. (B)
Please use a 24 mm open-end wrench if the cover is
tight. Use a cloth to avoid scratches.
The filter cartridge sits in the lower sealing lid with the
help of two O-rings (press fit).
4. Now pull the filter cartridge out of the lower cap with a
slight turning movement. (C)
5. Press the new filter cartridge into the receptacle of the
lower cap with slight turning movements. (D)
16 17

Made in Germany
S/N 0000001
F
H
E
G
If the filter cartridge is dicult to install, the sealing rings
of the filter cartridge should be weed with water or
vaseline/milking grease (food safe).
6. Screw the lower cap back onto the filter body and
tighten it hand-tight. A gap (1 mm) may be visible! (E)
7. Move the switch lever to the horizontal position (Mode:
Filtered) (F). Then slowly open the water inlet of your
faucet.
8. Now let the water run through the water filter for 5
minutes to activate it. (G)
Production-related activated carbon dust may dissolve
during rinsing and slightly cloud the water during the
cartridge activation process.
9. Check the water filter housing and all connected
components for leaks. (H)
10. The Alb Filter® DUO is now ready for use.
ATTENTION!
Avoid a slanted
positioning of
the threads.
18 19

MAINTENANCE AND CARE
The Alb Filter® DUO is generally low maintenance.
However, the maximum service life of the filter cartridges
must be observed.
Clean and lime-free fittings are the prerequisite for hygie-
nically perfect drinking water.
To remove limescale, we recommend the use of a vinegar
cleaner
Depending on the water quality, it may be necessary to
remove any deposits that have formed inside the housing
with a cloth (e.g. kitchen towel) every two months.
In case of calcareous water (>15°dH) and very frequent
operation, the changeover valve in the changeover lever
(6) may be damaged under certain circumstances. In this
case the bypass can be replaced. (Available under the
store category: Accessories)
FILTER CARTRIDGES FOR THE
ALB FILTER® DUO
You can use dierent filter cartridges in the Alb Filter® DUO,
including the filter types:
ACTIVE, ACTIVE PLUS+ and NANO
Further information on the respective filter cartridges can be
found on our website at www.alb-filter.com as well as on the
documents belonging to the filter cartridge.
CARTRIDGE REPLACEMENT INTERVAL
We recommend changing the filter cartridges every four
to six months (according to DIN 1988). They should also
be replaced after longer periods of standing (> 6 weeks).
Warranty claims are void if these instructions are not
observed.
Please dispose of used filter cartridges in residual waste.
20 21

FLOW RATES
The diagrams show approximate values. The flow rate may vary
slightly depending on the batch and installation situation. Values
measured with new cartridges.
TECHNICAL INFORMATIONS
• Design: Filter housing for installation on (kitchen) faucets.
• Material: Stainless steel
• Cartridge and capacity: Depending on the selected version
• Connection inlet faucet: Standard connection for faucets with
M22x1 outlet thread (female thread)
• Outlet (filtered / unfiltered):
Jet regulator with head gasket on M22 x 1 external thread
• Flow rate: approx. 5-11 liters per minute - depending on cartridge
type (at approx. 2-3 bar water pressure)
• Dimensions WxHxD: 109 x 122 x 69 mm
• Weight without cartridge: approx. 450 g
69 mm
50
mm
109 mm
122
mm
Made in Germany
S/N 0000001
2
Active Filterkartusche
Active Plus+ Filterkartusche
Nano Filterkartusche
0
2
4
6
8
10
12
14
16
18
0 0.5 1 1.5 2 2.5 3 3.5
l/min
bar
Active S Filterkartusche
Durchflussbereich Max (l/min) Min (l/min)
Nano Filterkartusche
Flow range
Active filter cartridge
Flow range
Active Plus+ filter cartridge
Flow range
Nano filter cartridge
22 23

GENERAL SAFETY INFORMATIONS
• No liability will be accepted for any damage caused by improper
installation.
• Maximum operating temperature: 45 degrees.
• Protect from frost.
• Do not use on a faucet with a pull-out shower.
• The cartridge should be changed aer 4-6 months. However,
note the replacement interval of the cartridges used individually.
• Earlier replacement may be necessary if the water flow is visibly
reduced, or if the water quality deteriorates.
• An early change is not a defect of the cartridge used, but an
indication of increased occurrence of fine particles or pollutants
in the unfiltered water.
• In exceptional cases, when the water in the supply line is very
cold (for physical reasons) condensation water may form on the
filter housing.
• To ensure complete safety with regard to the quality of your
filtered water, a water test in a competent laboratory is
mandatory.
• In connection with pressureless boilers, please note that due
to the high fineness of the cartridge, a pressure is built up in
front of it (approximately equal to the mains pressure), which is
reduced only slowly. Under certain circumstances, this can lead
to damage to the non-pressure-resistant boiler. Please contact
your responsible installer for this.
• No liability can be accepted for the consequences of using filter
cartridges from other manufacturers. We strongly recommend
the use of original Alb filter cartridges.
• Caution: In accordance with applicable regulations, never opera-
te the water filter on the drinking water network without a sys-
tem separator. Make sure that the connection of your domestic
waterworks, on which the water filter is operated, is equipped
with a system separator according to EN 12729 type BA. Water
that has flowed through a system separator is no longer consi-
dered drinking water.
• Please observe the applicable drinking water regulations of your
respective country before installation and commissioning.
• Use only with drinking water.
24 25

FAQ - FREQUENTLY ASKED QUESTIONS
F What does the NANO cartridge filter?
A The NANO cartridge filters only germs and bacteria down
to a size of 0.1 μm. This corresponds to 99.9999% (log6) of
microorganisms harmful to humans.
F Can activated carbon germinate?
A Yes. Please pay aention to the specified service life of the
cartridges.
F Does the activated carbon filter lime?
A No, the Alb Filter® is not explicitly a lime filter - it filters
bound lime flakes, but not dissolved calcium carbonate.
F Is the water safe to drink in Germany?
A The tap water provided by water suppliers in Germany is
treated in a complex process. Aer treatment, it complies
with the German Drinking Water Ordinance (TrinkwV).
However, the variety of substances that can be dissolved in
water is enormous. It is estimated that more than 50,000
dierent chemical compounds are present in water. Only a
few of these are filtered by water suppliers as standard.
F When does the filter need to be changed?
A The ACTIVE and ACTIVE PLUS+ cartridges should be changed
aer 4 months at the latest, the NANO cartridge aer 6 months
- at a consumption of approx. 150 l/week. If the flow rate of the
cartridge decreases prematurely, this may be due to poor input
water quality.
F What are signs that a filter change is necessary?
NANO: The water flow is greatly reduced or no water is coming
through at all.
ACTIVE, ACTIVE Plus+: The flow rate decreases only in rare cases.
Therefore, it is important to change the cartridges at regular
intervals, at the latest aer 4 months or 3,000 l of water flow.
F How high must the eective water pressure be to operate the
filters?
A For a good flow, the pressure should be between 2.3 and 2.6
bar for all cartridges. With the NANO cartridge, 1 bar is already
sucient for a good flow. The average water pressure in German
households is between 3 and 4 bar.
26 27

Alternatively, make a note of the time of startup in this table.
Observe the information on the cartridge change interval on
page 21.
Replacement cartridges available at
www.alb-filter.com – Shop category: Filter Cartridges
Start End Note
REMINDER TO CHANGE THE
FILTER CARTRIDGE
We would like to remind you to change your filter car-
tridge. Please use our practical Email reminder service:
www.alb-filter.com/reminder
Protects the environment and your
wallet! With our cartridge abonne-
ment, the replacement cartridge is
guaranteed to be delivered to you
on time.
To set up the cartridge abonnement,
go to www.alb-filter.com under
Shop - Replacement cartridges.
Select the filter cartridge, go to „Pur-
chase options“ and click on „Save
subscription“.
Place the cartridge abonnement in
the shopping cart and complete the
order.
CARTRIDGE
ABONNEMENT
28 29

All rights reserved. No part of this manual may be reproduced in any
form or copied or processed by any electronic, mechanical or chemical
means without the written permission of the publisher.
It is possible that this manual still contains typographical defects or
printing errors. However, the information in this manual will be checked
regularly and corrections will be made in the next edition. We accept no
liability for errors of a technical or printing nature and their consequen-
ces.
All trademarks and industrial property rights are acknowledged.
Changes in the sense of technical progress can be made without prior
notice. Illustrations and diagrams are not binding. All brand and product
names used are only to illustrate the compatibility of our products with
certain products of various other manufacturers and are the property of
the respective owner.
DUO V1.0 STAINLESS STEEL (04/2022)
© 2022
Blaufaktor GmbH & Co. KG
Riedweg 12
78607 Talheim
Germany
www.alb-filter.com
info@alb-filter.com
USER MANUAL ONLINE
https://alb-filter.com/pages/installation-wasserhahnfilter?lang=en
Alb Filter® is a trademark of Blaufaktor GmbH & Co. KG registered in the European Union.
30 31
