Alcatel-Lucent 9130 BSC Evolution Manual

Alcatel-Lucent GSM
9130 BSC Evolution Maintenance
Handbook
BSC & TC Document
Procedural Handbook
Release B10
3BK 21281 AAAA PCZZA Ed.13

Status RELEASED
Short title
All rights reserved. Passing on and copying of this document, use
and communication of its contents not permitted without written
authorization from Alcatel-Lucent.
BLANK PAGE BREAK
2/ 90 3BK 21281 AAAA PCZZA Ed.13

Contents
Contents
Preface . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . 7
1 Hardware Presentation . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . 11
1.1 Front and Rear Views of the 9130 BSC Evolution ... . . . . . ..... . . . . ...... . . . . ..... . . . . . 12
1.2 9130 BSC Evolution Interconnections .. . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 14
1.3 Board/Area/Slot/SBL Mapping .. . ........ . ........ . . ........ . ......... . ........ . .... 15
2 Safety Rules and Precautions . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . 17
2.1 Safety Rules for Equipment Under Power .... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 18
2.2 Electrostatic Precautions .......... . ........ . ......... . ........ . ......... . ........ . . 19
2.2.1 Environment ...... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 19
2.2.2 Tools .. ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 19
2.2.3 Transportation and Storage ... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 20
2.2.4 Components and PBAs .. . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 20
3 Maintain the ATCA Subrack . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . . 21
3.1 Before You Start ..... . ........ . . ........ . ........ . . ........ . ......... . ........ . .... 22
3.2 ATCA Subrack Presentation ... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 22
3.3 Fan Tray . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 24
3.3.1 Prerequisites ... . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 24
3.3.2 Replace Fan Tray ......... . ........ . ......... . ........ . . ........ . ....... 25
3.4 Air Filter ...... . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 26
3.4.1 Air Filter Cleaning .. . ........ . ........ . . ........ . ......... . ........ . .... 26
3.4.2 Air Filter Replacement ....... . ........ . . ........ . ......... . ........ . .... 26
3.5 Front RITs .... . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 28
3.5.1 Tips for Inserting ATCA Front RITs ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 28
3.5.2 Replace JBXTP ... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 33
3.5.3 Replace JBXOMCP . . ........ . ........ . . ........ . ......... . ........ . .... 37
3.5.4 Replace JBXCCP . . . ........ . ........ . . ........ . ......... . ........ . .... 41
3.5.5 Replace JBXSSW ........ . ........ . ......... . ........ . . ........ . ....... 42
3.5.6 Remove / Insert JBXFILL . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 46
3.6 Rear RITs ..... . ........ . ......... . ........ . ......... . ........ . ......... . ........ . . 47
3.6.1 Replace JAXPC ....... . ........ . ......... . ........ . ......... . ........ . . 47
3.6.2 Replace JAXSSW ........ . ........ . ......... . ........ . . ........ . ....... 51
3.6.3 Replace JAXSMM . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 53
3.6.4 Replace JBXPS ... . . ........ . ........ . . ........ . ......... . ........ . .... 57
3.6.5 Replace JAXFILL ...... . ........ . ......... . ........ . ......... . ........ . . 59
3.7 Replace Battery on JBXOMCP/JBXCCP .. . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 59
3.7.1 Board Takeover . ......... . ........ . ......... . ........ . . ........ . ....... 59
3.7.2 Remove Board ........ . ........ . ......... . ........ . ......... . ........ . . 60
3.7.3 Replace Battery ... . . ........ . ........ . . ........ . ......... . ........ . .... 60
3.7.4 Insert Board . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 60
4 Maintain the LIU Subrack . . . . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . 61
4.1 Before You Start ..... . ........ . . ........ . ........ . . ........ . ......... . ........ . .... 62
4.2 Replace LIU Board . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 63
4.2.1 Remove LIU Board .... . ........ . ......... . ........ . ......... . ........ . . 64
4.2.2 Insert LIU Board ... . . ........ . ........ . . ........ . ......... . ........ . .... 64
4.3 Replace JBXPEM .. ........ . ......... . ........ . ......... . ........ . . ........ . ....... 65
4.3.1 Remove JBXPEM ........ . ........ . ......... . ........ . . ........ . ....... 65
4.3.2 Insert JBXPEM ........ . ........ . ......... . ........ . ......... . ........ . . 66
4.4 Replace JBXMUX Board .......... . ........ . ......... . . . . ..... . . . . . ..... . . . . ..... . . 67
4.4.1 Remove JBXMUX ..... . ........ . ......... . ........ . ......... . ........ . . 67
4.4.2 Insert JBXMUX . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 68
4.5 Replace LIU Front Filler .... . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 69
4.5.1 Remove JBXDUM ..... . ........ . ......... . ........ . ......... . ........ . . 69
3BK 21281 AAAA PCZZA Ed.13 3/ 90

Contents
4.5.2 Replace JBXDUM ........ . ........ . ......... . ........ . . ........ . ....... 69
5 9130 BSC Evolution Cables .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . 71
5.1 Intervention Levels ...... . ......... . ........ . ......... . ........ . ......... . ........ . . 72
5.2 ATCA Subrack Cables . ........ . . ........ . ........ . . ........ . ......... . ........ . .... 74
5.3 LIU Subrack Cables .. . ........ . . ........ . ........ . . ........ . ......... . ........ . .... 75
6 Software Procedures . . . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . . . . . . . .. . . . . . . . .. . . 77
6.1 Modify Community String Name .... . ........ . ......... . ........ . ......... . ........ . . 78
6.2 Software and Hardware Diagnosis ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 79
6.3 Modify 9130 BSC Evolution IP Configuration .... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 80
6.3.1 General Information ...... . ........ . ......... . ........ . . ........ . ....... 80
6.3.2 Modify BSC IP Subnetwork Address . ...... . . . . ..... . . . . . ..... . . . . ..... . . 84
6.3.3 Modify BSC IP Configuration from 1 LAN to 2 LANs .. . . . . . ..... . . . . ..... . . 85
6.3.4 Modify BSC IP Configuration from 2 LANs to 1 LAN ..... . . ........ . ....... 86
6.4 Tool collecting On-Demand Traces/Logs .. . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 87
6.4.1 Backup/Restore/Stop Trace Selection .. . . . . . ..... . . . . ...... . . . . ..... . . . . . 87
6.4.2 Get Start/End Time of Trace Collection Period ..... . . . . ...... . . . . ..... . . . . . 88
6.4.3 Get Problem Type: (OAM, CS, PS, ATRUNK) ........ . ......... . ........ . . 88
6.4.4 Get telecom trace collect period/id (For CS, PS, ATRUNK only) .. . ........ . . 89
6.4.5 Send telecom trace config to TRF Master (For CS, PS, ATRUNK only) . . . .... 89
6.4.6 Wait enough time for telecom trace collection (For CS, PS, ATRUNK only) ... 89
6.4.7 Trigger all VCE to dump the remaining trace ...... . ......... . ........ . .... 89
6.4.8 Wait enough time for trace dumped to disk ..... . . . . ..... . . . . . ..... . . . . .... 90
6.4.9 Get trace files from CCP boards ....... . . ........ . ......... . ........ . .... 90
6.4.10 Clean secure disk space & move required trace data into it on both OMCP . . 90
6.4.11 File Transfer to 9153 OMC-R . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 90
4/ 90 3BK 21281 AAAA PCZZA Ed.13

Figures
Figures
Figure 1: Front View of a Standalone 9130 BSC Evolution ... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 12
Figure 2: Rear View of a Standalone 9130 BSC Evolution ... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 13
Figure 3: 9130 BSC Evolution Interconnections ... . ........ . ......... . ........ . ......... . ........ . . 14
Figure 4: The ATCA Subrack, Front View ..... . . ........ . ........ . . ........ . ......... . ........ . .... 22
Figure 5: ATCA Subrack, Rear View . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 23
Figure 6: Front Fan Unit .. . . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 24
Figure 7: Fan Unit Cover ........ . ........ . ......... . ........ . ......... . ........ . . ........ . ....... 25
Figure 8: ATCA Front Board Handles - First Step to Remove a Board ... . . . . ..... . . . . . ..... . . . . ..... . . 28
Figure 9: ATCA Front Board Handles - Second Step to Remove a Board ......... . ......... . ........ . . 29
Figure 10: Board Handle - Remove or Insert Board ... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 29
Figure 11: Guides for Board Insertion ..... . ......... . ........ . ......... . ........ . . ........ . ....... 30
Figure 12: Align Holes with Needles ....... . ......... . ........ . ......... . ........ . . ........ . ....... 31
Figure 13: Protect EMI Stripes when Inserting / Removing the Boards ..... . . . . ..... . . . . . ..... . . . . .... 32
Figure 14: JBXSSW Board . . . . ..... . . . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 42
Figure 15: Extraction of Front Fillers ....... . ......... . ........ . ......... . ........ . . ........ . ....... 46
Figure 16: JAXPC Board Front View .. ........ . . ........ . ........ . . ........ . ......... . ........ . .... 47
Figure 17: JAXPC: Shelf Geographic Address Rotary Switches .... . . . . . ..... . . . . ...... . . . . ..... . . . . . 48
Figure 18: JAXSSW Rear Transition Module ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 51
Figure 19: Shelf Manager Board . . ........ . ......... . ........ . ......... . ........ . . ........ . ....... 54
Figure 20: JAXSMM - Handle Switch Positions .... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 55
Figure 21: Power Entry Module .. . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 57
Figure 22: Front View of the LIU Subrack ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 62
Figure 23: LIU Board . . ......... . ........ . ......... . ........ . ......... . ........ . . ........ . ....... 63
Figure 24: JBXPEM Board ... . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 65
Figure 25: JBXMUX Board ... . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 67
Figure 26: JBXDUM Filler .... . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 69
Figure 27: 9130 BSC Evolution Rack Intervention Levels . . ..... . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 72
Figure 28: ATCA Front View (with Cable Positions) . ........ . ......... . ........ . ......... . ........ . . 73
Figure 29: ATCA Rear View (with Cable Positions) . . ........ . ......... . ........ . ......... . ........ . . 73
3BK 21281 AAAA PCZZA Ed.13 5/ 90

Tables
Tables
Table 1: ATCA Shelf Front View Board-Area-Slot-SBL Mapping . . ......... . ........ . . ........ . ....... 15
Table 2: ATCA Shelf Rear View Board-Area-Slot-SBL Mapping . . . . . . ..... . . . . ..... . . . . . ..... . . . . .... 16
Table 3: LIU Shelf Board-Slot-SBL Mapping ... . . . . . ..... . . . . ..... . . . . . ..... . . . . ...... . . . . ..... . . . . . 16
Table 4: JAXSSW Ethernet Connections ...... . . ........ . ........ . . ........ . ......... . ........ . .... 51
Table 5: ATCA Configuration .. . . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 74
Table 6: Power Cords for ATCA . . . ..... . . . . ...... . . . . ..... . . . . ...... . . . . ..... . . . . . ..... . . . . ..... . . 75
Table 7: Cable List for GE Links between LIU and ATCA ....... . ......... . ........ . . ........ . ....... 75
Table 8: IP Assignment in 9130 BSC Evolution External Subnet A ...... . . . . ..... . . . . . ..... . . . . ..... . . 80
Table 9: IP Assignment in 9130 BSC Evolution External Subnet B ...... . . . . ..... . . . . . ..... . . . . ..... . . 81
Table 10: IP Assignment in 9130 BSC Evolution External Subnet C . . . . . ..... . . . . ...... . . . . ..... . . . . . 81
Table 11: IP Assignment in 9130 BSC Evolution External Subnet A . . . . . ..... . . . . ...... . . . . ..... . . . . . 82
6/ 90 3BK 21281 AAAA PCZZA Ed.13

Preface
Preface
Purpose This Maintenance Handbook describes how to replace units and cables in
the subracks and how to install, configure and change 9130 BSC Evolution
software.
What’s New In Edition 13
Description improvement in following sections:
Insert JBXSSW (Section 3.5.5.2)
IP Assignment Rules in 9130 BSC Evolution with the 1 LAN Solution
(Section 6.3.1.2).
In Edition 12
Description improvement in following sections:
Insert JBXSSW (Section 3.5.5.2)
Insert JAXSMM (Section 3.6.3.2)
Insert JBXPEM (Section 4.3.2).
In Edition 11
Description improvement in the following sections:
Modify BSC IP Configuration from 1 LAN to 2 LANs (Section 6.3.3)
Modify BSC IP Configuration from 2 LANs to 1 LAN (Section 6.3.4).
Tool collecting On-Demand Traces/Logs (Section 6.4)
3BKA20FBR226586 Restriction removed from Replace JBXTP (Section 3.5.2)
In Edition 10
Update for new equipment naming.
Description improvement in:
Replace JBXPS (Section 3.6.4)
Modify 9130 BSC Evolution IP Configuration (Section 6.3).
3BK 21281 AAAA PCZZA Ed.13 7/ 90

Preface
In Edition 09
3BKA20FBR226586 Restriction introduction in Replace JBXTP (Section 3.5.2)
3BKA20FBR229377 Restriction introduction in Replace JBXOMCP (Section
3.5.3)
In Edition 08
Description improvement in Replace JBXOMCP (Section 3.5.3).
In Edition 07
The following sections were added:
Modify BSC IP Configuration from 1 LAN to 2 LANs (Section 6.3.3)
Modify BSC IP Configuration from 2 LANs to 1 LAN (Section 6.3.4).
Description improvement in:
Insert JBXTP (Section 3.5.2.2)
Update the NE1OE Firmware for the New JBXTP or JBXMUX Boards
(Section 3.5.2.3)
Insert JBXMUX (Section 4.4.2).
Section “Check Firmware Version for the New JBXTP or JBXMUX Board”
was removed.
In Edition 06
Description update in ATCA Subrack Presentation (Section 3.2).
In Edition 05
Description improvement in Replace Battery on JBXOMCP/JBXCCP (Section
3.7).
In Edition 04
Section Replace Battery on JBXOMCP/JBXCCP (Section 3.7) was added.
In Edition 03
Restriction introduction 3BKA20FBR209413.
In Edition 02
Description improvement in:
Remove JBXSSW (Section 3.5.5.1)
Remove JBXOMCP (Section 3.5.3.1)
Board/Area/Slot/SBL Mapping (Section 1.3).
In Edition 01
First release of the document.
8/ 90 3BK 21281 AAAA PCZZA Ed.13

Preface
Audience This Maintenance Handbook is intended for:
Maintenance engineers
System support engineers
Network technicians
Network operators.
Assumed Knowledge You must have a basic understanding of the following:
Alcatel-Lucent operations and maintenance concepts for the BSC
BSC hardware configurations
Telecommunications engineering
Anti-static procedures
Windows environment
Linux enviroment.
3BK 21281 AAAA PCZZA Ed.13 9/ 90

Preface
10 / 90 3BK 21281 AAAA PCZZA Ed.13

1 Hardware Presentation
1 Hardware Presentation
This section provides a short equipment and interconnections presentation.
3BK 21281 AAAA PCZZA Ed.13 11 / 90

1 Hardware Presentation
1.1 Front and Rear Views of the 9130 BSC Evolution
The following figure shows the front view for a standalone 9130 BSC Evolution
Evolution.
12345678901234567890
12345678901234567890
12345678901234567890
12345678901234567890
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
CLOSED / OPEN
H/S OOS
−48 / 60
VDC
4A
−48 / 60
VDC
4A
XPEM XLIU XMUX XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XLIU XPEM XMUX
JSXLIU
Shelf 1
(BSC1)
JSXATCA
Shelf 3
(BSC1)
JSXATCA
Shelf 4
(BSC2)
JSXPDU
Air inlet
JSXLIU
Shelf 2
(BSC2)
JBXSSW
JBXTP
JBXCCP
JBXOMCP
JBXTP
Not Used Not Used
JBXCCP JBXCCP JBXCCP
JBXOMCP
JBXSSW
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
JBXCCP JBXCCP
Figure 1: Front View of a Standalone 9130 BSC Evolution
12 / 90 3BK 21281 AAAA PCZZA Ed.13

1 Hardware Presentation
The following figure shows the rear view for a standalone 9130 BSC Evolution
Evolution.
−(POWER)
+(RETURN)
−(POWER)
+(RETURN)
−(POWER)
+(RETURN)
−(POWER)
+(RETURN)
OOS
OK
ACT
H/S
OOS
OK
ACT
H/S
OOS
OK
ACT
H/S
OOS
OK
ACT
H/S
12345678901234567890
12345678901234567890
12345678901234567890
12345678901234567890
Air outlet
GND
JAXPC
JAXSMM
JBXPS JBXPSJBXPSJBXPS
JAXSMM
JAXPC
JAXSSW
JAXSSW
JAXPC JAXPC
JAXSMM JAXSMM
JSXATCA
Shelf 3
(BSC1)
JSXLIU
Shelf 2
(BSC2)
JSXLIU
Shelf 1
(BSC1)
JSXATCA
Shelf 4
(BSC2)
JSXPDU
Figure 2: Rear View of a Standalone 9130 BSC Evolution
3BK 21281 AAAA PCZZA Ed.13 13 / 90

1 Hardware Presentation
1.2 9130 BSC Evolution Interconnections
BTS
BTS
BSC
MSC
GMLC
HLR
SGSN
CBC
SMLC
MFS
Router A−GPS
Server
MS
Lg
Lg
Lh
LSN1 LSN2
Lb
Interface
Gs
Interface
A Interface
Gb Interface
LCS Client
SAGI
Figure 3: 9130 BSC Evolution Interconnections
The BSC is connected with the following network elements for telecom
functions:
MFS, TC: Atermux interface
MSC: A interface
BTS: Abis interface.
14 / 90 3BK 21281 AAAA PCZZA Ed.13

1 Hardware Presentation
1.3 Board/Area/Slot/SBL Mapping
The following tables give the Board/Area/Slot/SBL mapping for the modules
used in 9130 BSC Evolution.
JBXFAN area
Board JBXFAN1 JBXFAN2
Slot
number 81 82
SBL FAN1 FAN2
Board JBXFAN3 JBXFAN4
Slot
number 83 84
SBL FAN3 FAN4
Slot area
Board J
B
X
T
P
1
J
B
X
T
P
2
J
B
X
C
C
P
4
J
B
X
C
C
P
1
J
B
X
O
M
C
P
1
J
B
X
S
S
W
1
J
B
X
S
S
W
2
J
B
X
O
M
C
P
2
J
B
X
C
C
P
2
J
B
X
C
C
P
3
Physical
slot
number
1 2 3 4 5678 9 10 11 12 13 14
Logical
slot
number
13 11 9 7 5 3 1 2 4 6 8 10 12 14
SBL T
P
-
H
W
1
T
P
-
H
W
2
C
P
-
H
W
6
C
P
-
H
W
3
C
P
-
H
W
1
S
S
W
-
H
W
1
S
S
W
-
H
W
2
C
P
-
H
W
2
C
P
-
H
W
4
C
P
-
H
W
5
Table 1: ATCA Shelf Front View Board-Area-Slot-SBL Mapping
3BK 21281 AAAA PCZZA Ed.13 15 / 90

1 Hardware Presentation
Rear area
Board ... JAXSSW2 JAXSSW1 ...
Physical
slot number 14 ... 87 ... 1
Logical slot
number 30 ... 24 23 ... 17
SBL SSW-HW2 SSW-HW1
JBXPS area JAXSMM area JAXPC area
Board JBXPS1 JBXPS2 JBXPS3 JBXPS4 JAXSMM2 JAXSMM1 JAXPC2 JAXPC1
Physical
slot number 1 2 3 4 1 2 1 2
Logical slot
number 33 34 35 36 66 65 50 49
SBL PEM1 PEM2 PEM3 PEM4 SMM2 SMM1 BSCENV3 BSCENV2
Table 2: ATCA Shelf Rear View Board-Area-Slot-SBL Mapping
Board J
B
X
P
E
M
1
J
B
X
L
I
U
1
J
B
X
L
I
U
2
J
B
X
L
I
U
3
J
B
X
L
I
U
4
J
B
X
L
I
U
5
J
B
X
L
I
U
6
J
B
X
L
I
U
7
J
B
X
L
I
U
8
J
B
X
M
U
X
1
J
B
X
M
U
X
2
J
B
X
L
I
U
9
J
B
X
L
I
U
10
J
B
X
L
I
U
11
J
B
X
L
I
U
12
J
B
X
L
I
U
13
J
B
X
L
I
U
14
J
B
X
L
I
U
15
J
B
X
L
I
U
16
J
B
X
P
E
M
2
Slot
Nb. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
SBL P
E
M
5
E
T
U
1
E
T
U
2
E
T
U
3
E
T
U
4
E
T
U
5
E
T
U
6
E
T
U
7
E
T
U
8
E
C
U
1
E
C
U
2
E
T
U
9
E
T
U
10
E
T
U
11
E
T
U
12
E
T
U
13
E
T
U
14
E
T
U
15
E
T
U
16
P
E
M
6
Table 3: LIU Shelf Board-Slot-SBL Mapping
16 / 90 3BK 21281 AAAA PCZZA Ed.13

2 Safety Rules and Precautions
2 Safety Rules and Precautions
This section contains the following information:
Safety rules for equipment under power
Electrostatic precautions.
3BK 21281 AAAA PCZZA Ed.13 17 / 90

2 Safety Rules and Precautions
2.1 Safety Rules for Equipment Under Power
Injury from Equipment
Possible death or serious physical harm to personnel and damage to equipment
may result from mishandling.
While performing any maintenance tasks or procedures, you must follow any
local safety requirements, and those mentioned in this chapter.
For maintenance purposes, field operators may have to work on equipment
under power (-48 VDC or -60 VDC). This means that it is possible to touch
some parts under power that are only protected by heavy fuses. Maintenance
activities must be carried out carefully to avoid short circuits and to prevent
serious personal injury.
Conductive Objects: Remove all conductive objects from hands and arms
such as rings, bracelets, metallic wrist watches or similar. Use appropriate
insulated tools for maintenance activities.
Mobile Telephone: Do not use a mobile telephone when the BSC doors are
open. It can interfere with the operation of the BSC.
Uncommon Replacements: Alcatel-Lucent will perform a case-by-case
study and, if necessary, prepare a special replacement procedure. Any such
procedure is handled solely by Alcatel-Lucent.
18 / 90 3BK 21281 AAAA PCZZA Ed.13

2 Safety Rules and Precautions
2.2 Electrostatic Precautions
2.2.1 Environment
You must observe the following electrostatic precautions:
Ensure that work benches, tools, and floor mats have a conducting surface
connected to ground. Before handling static-sensitive components and
assemblies, ground yourself to the conducting surface by using an anti-static
wrist strap.
When handling static-sensitive components and assemblies, do not wear
or use clothes made of wool, nylon or any other synthetic material. Such
fabrics are major sources of static build-up.
When handling static-sensitive components and assemblies, do not use
gloves and finger covers, unless they are made of cotton.
2.2.2 Tools
You need the following tools to perform the procedures described in this
handbook:
An anti-static wrist strap
A serviceable replacement unit
A Torx screwdriver
A Flathead screwdriver
A Philips crosshead screwdriver.
You must respect the following rules:
Ensure that all the tools which come into contact with static-sensitive
components are at the same voltage level as the conducting work surfaces
and floor mats.
These tools include soldering irons, oscilloscopes, power supplies, and
metal parts of tools and fixturesthat are used to hold, assembleor test PBAs.
Do not use rough cleaners or erasers to clean the gold-plated contacts
on PBAs
Do not mark a PBA with a lead pencil or any other writing instrument
Do not use synthetic brushes to clean equipment, and do not use dry
cleaning methods.
3BK 21281 AAAA PCZZA Ed.13 19 / 90

2 Safety Rules and Precautions
2.2.3 Transportation and Storage
You must respect the following rules:
Pack all containers used to transport and store static-sensitive components,
and use aluminum container tubes if possible. If not, insert the component
terminations into electrically conductive foam
Before shipping a PBA, wrap it in a conducting synthetic bag or in aluminum
foil. Also pack the PBA in a polyethylene transport box
Before shipping a PBA which has metal oxide semiconductor components,
ensure that an appropriate warning symbol is displayed on the package
Store spare PBAs in their appropriate polyethylene boxes. Keep the boxes
closed except when access to their contents is required
Do not store PBAs in an area where the air is polluted with smoke, dust,
dangerous gases or other airborne particles that may cause damage
Do not stack PBAs side-by-side or on top of each other with the board
surfaces or components in contact with one another
Before cleaning a PBA, remove or disconnect the damage protection, such
as protective foam, to allow the PBA to be cleaned thoroughly. Replace the
damage protection upon completion of the task.
2.2.4 Components and PBAs
You must respect the following rules:
Components and PBAs not in protective containers must only be handled by
trained personnel in static-controlled work areas
Before removing a PBA from an equipment rack, discharge any static by
touching the metal frame of the rack with your hand
Always handle a PBA by the edges
Do not handle or carry a PBA by any of the mounted components
Do not handle a PBA by the gold-plated contact terminals and do not apply
direct pressure to the components
Do not touch PBA connection pins or conductor paths
Do not touch PBAs with wet hands
Place PBAs that have been removed during maintenance with the soldered
side downwards on a conductive surface
Do not scratch or rub the soldered side of a PBA with a sharp or rough object
Do not repair PBAs in the switch room
Do not handle components and assemblies by their leads
Do not use excessive force when inserting connection boards.
20 / 90 3BK 21281 AAAA PCZZA Ed.13
