Alcatel One Touch X1 7053 Series User manual

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
1/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
ALCATEL
ONE TOUCH 7053
Note: this manual is non-contractual and TCT Mobile Limited can modify it without prior notice on
the characteristics of described equipments.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
2/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
V1.1
2016-04-05
Update software download
Yang Xiaolong
V1.0
2015-09-11
Draft creation
Liu hongqi
Rev.
Date
Modification description
Prepared By
Checked By
Approved By

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
3/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Content
1. General ..............................................................................................................................................4
2. Portable Label ...................................................................................................................................5
2.1. Zone information on the label ..........................................................................................................5
2.2. Commercial label samples: ..............................................................................................................6
2.3. L1 Spare Part List..............................................................................................................................7
2.4. Accessory..........................................................................................................................................7
2.4.1. Charger.......................................................................................................................................7
2.4.2. Stereo Headset...........................................................................................................................8
2.4.3. End user USB cable...................................................................................................................8
2.5. Maintenance policy...........................................................................................................................9
2.6. General ..............................................................................................................................................9
2.6.1. For handset: ...............................................................................................................................9
2.6.2. For standard accessories (charger, headset and USB cable).................................................9
2.6.3. If input the following codes on handset, you can:...................................................................9
2.6.4. User Data Format reset introduction: .......................................................................................9
2.7. Cell phone maintenance.................................................................................................................12
2.8. Invoice check ..................................................................................................................................12
2.9. IMEI Check.......................................................................................................................................13
2.10. Label Check..............................................................................................................................13
2.11. Visual Mechanical inspection..................................................................................................13
2.12. Accessories inspection ...........................................................................................................14
2.13. Cell phone maintenance procedure........................................................................................14
3. Replace the handset parts..............................................................................................................17
3.1. Preliminary ......................................................................................................................................17
3.2. Precaution .......................................................................................................................................18
3.3. Battery test......................................................................................................................................18
3.3.1. Charging Process ....................................................................................................................18
3.3.2. Charger test..............................................................................................................................20
4. Software download .........................................................................................................................21
4.1 Equipments requested when download：......................................................................................21
4.2 The upgrade process is as below: ..................................................................................................21

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
4/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
1. General
ALCATEL ONE TOUCH 7053 series are a smart phone with Qualcomm MSM8929 platform (4-core x 1.4
GHz + 4-core x 1.0 GHz), WIFI/GPS/Bluetooth and social network service functions etc. , It can work with
the GSM/ UMTS /FDD.
Detail features
Model
7053D(EMEA/APAC)
7053E(NA)
7053J(LATAM)
Design
Terminal Form Factor
Phone
Dimensions (mm)
145x 69.2x 6.99mm
Weight (g)
140g
OS
Open Operation Systerm
Android 5.1
Bearer
GSM bands
850/900/1800/1900
850/900/1800/1900
850/900/1800/1900
UMTS bands
850/900/1900/2100
850/1900/AWS/2100
850/900/1900/2100
FDD bands
B1/B3/B8/B20
CSFB
B2/B4/B5/B7/B12/B17
B1/B2/B3/B4/B7/B28
EDGE
Downlink only
HSDPA
HSDPA 42Mbps
HSUPA
HSUPA 5.76 Mbs
Input
Touch panel
Touch Window Capacitance
Main Display dimension
(Diagonal physical size)
5.0
Main display resolution
HD (1280 x 720)
Main display technology
AMOLED
WIFI
Wi-Fi / WLAN
802.11b/g/n
Wi-Fi Direct
Supported
Sensors
GPS
Supported
Accelerometer (G sensor)
Supported
Proximity Sensor
Supported
Light Sensor
Supported
E-Compass
Supported
Gyro
Supported
FM
FM Radio (RDS)
Supported
Camera
Still image capture
resolution
Main camera:13M AF
Still image capture
resolution
Front camera: 5M FF
USB
Micro USB connector
5 PIN
Memory
Storage capabilities
16GB ROM+ 2GB
RAM
32GB ROM+ 2GB RAM
16GB ROM+ 2GB
RAM
Ability to support a
memory card of up to at
least
64GB
Format
support
Audio
PCM, MP3, AAC, AAC+, eAAC+, MIDI, AC3, FLAC and WAV
Video
H.263/MPEG-4/H.264,25fpsQVGA streaming video，1080P video
Battery
Battery capacity (mAh)
2150mAh

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
5/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2. Portable Label
2.1. Zone information on the label

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
6/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.2. Commercial label samples:
Label information
1. Length = 42mm
2. Width = 22mm

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
7/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.3. L1 Spare Part List
This table lists ONE TOUCH 7053D L1 spare parts for example. Regarding more spare part list, you could
also refer to: https://css.tclmobile.cn/
Item
PN
Name
Repair
level
Description
Quantity
1
BMH0000003C0
SIM Card Tray
Pin
L1
SIM 卡托盘顶针,SIM Card Tray
Pin,ACE,不锈
钢,Grinding+PVD,metal,glossy,
32x8x0.7mm,For Diablo
Alpha,HERO,ECT
1
2
CPG1DL002AC0
battery cover
sticker
L1
电池盖贴纸,battery cover sticker,X1,A
Version,PET,N/A,N/A,With
Glue,N/A,N/A,TCT
1
3
CPG1DL004AC0
LCD sticker
L1
LCD 贴纸,LCD sticker,X1,A
Version,N/A,66.00×130.00
mm,N/A,With Glue,N/A,For
Russian,TCT
1
4
CBA0058AK0C2
Normal Charger
L1
普通充电器,Normal
Charger,Black(High Glossy),RUSSIAN
STANDARD,N/A,W/O
Wire,N/A,MOU,5.0 V,1000
mA,ALCATEL onetouch,6
LEVEL,N/A,Reach,UC11,N/A,TENPAO
1
5
CDA0000025C2
Data Cable
L1
数据线,Data Cable,black,micro USB,1
m,Reach,for UC12,N/A,JUWEI
1
6
CCB0023A11C2
Stereo Earphone
L1
立体声耳机,Stereo Earphone,3.5
connection port,N/A,N/A,In
Ear,black+black,ALCATEL
onetouch,1.0 mW,Reach,wh35,TS909A-
44MS07BR1-M,LIANYUN
1
7
F-A1DL0AA101
swap handset
L1
(X)客服周转机头,,X1,EU-2S,Black,,CU
编码:7053D-2AALRU1,,,
1
2.4. Accessory
2.4.1. Charger
1) The power supply is a current generator. It includes an electrical part: AC to DC convertor based on
a regulator which must connect to an indoor plug.
Table 1.1 L1 Spare Part List

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
8/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.4.2. Stereo Headset
2.4.3. End user USB cable

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
9/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.5. Maintenance policy
This chapter describes the maintenance of the ONE TOUCH 7053 series phones authorized at L1 repair
center. The maintenance operations can only be performed in approved repair centers.
2.6. General
Main L1 maintenance operations are as following:
2.6.1. For handset:
1) Warranty check
2) Function test
3) SW downloading
4) Replacement of the defective handset.
2.6.2. For standard accessories (charger, headset and USB cable)
1) Warranty check
2) Functional check
3) Replacement of defective accessories
2.6.3. If input the following codes on handset, you can:
Code
Description
*#06#
Display IMEI number
*#2886#
Enter Auto Test mode
End user format
Long press volume up key +power key
2.6.4. User Data Format reset introduction:
How to use:Press Power Key + Volume up key until device turn on logo interface, then loosen Power
Key ,in power off mode to enter recovery mode.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
10/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
When to use: If you cannot start your handset or when you start your handset, there will be something
wrong with it, like cannot charge or cannot charge normally.
What does it do when you use End user format function: it will format end user area, and your handset
will come back to factory model, everything you save or set in the handset (except SIM card) will lose.
Detail steps：
1. Long press “power”key + “volume up”key until device turn on logo interface, then loosen “power”key ,
enter the Data Format interface
Press volume up /volume down key to select “wipe data / factory reset”, press power key to confirm.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
11/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2. Press volume down key to select “Yes—delete all user data”and the press “power”key to double
confirm the factory reset;
3. Factory reset complete, press volume key to select “reboot system now”and press power key to confirm.
Then the phone will be rebooted.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
12/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.7. Cell phone maintenance
1) Equipments for handset test.
One SIM card.
2) It is recommended the following tools:
One PC with Windows 2000/NT/XP/Windows 7.
One USB cable.
One charger.
2.8. Invoice check
Check warranty status of Handset by POP (Proof of Purchase)
If the end user lost his POP, then consider the data code as the purchasing day. Date code: (HER)
Note:
Coding
Day
Day
Coding
Month
Month
Coding
Year
Year
1
1st
E
January
O
2005
2
2nd
F
February
P
2006
…
…
G
March
Q
2007
9
9th
…
…
…
…
A
10th
O
November
Y
2015
B
11th
P
December
Z
2016
…
…
U
30th
V
31st
Coding day
Coding Month
Coding Year

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
13/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.9. IMEI Check
1) Power on the handset, enter *#06#
2) The IMEI number must be the same with the one on the IMEI label. If not, it‟s out of guarantee.
2.10.Label Check
If one of the 2 labels not good, the cell phone will be considered as out of guarantee.
1) IMEI Label removed, scratched, unreadable, not approved or provided by Alcatel.
2.11.Visual Mechanical inspection
Mechanical warranties check items:
1) Corrosion
Corrosion on the USB connectors, SIM connectors, and other metal surfaces
2) Hole
Holes (Diameter > 1mm) on any surface, including front casing, decorate frame, battery cover,
LCD Lens, keypad.
3) Bump
Bumps (Diameter>1mm) on any surface, including the front casing, decorate frame, battery cover,
LCD Lens, keypad
4) Scratch (length > 3mm)
Scratches on any surface, including the front casing, furnished frame, battery cover, LCD Lens,
keypad
5) Distortion
Bend, twisted or crushed on the h/s, cover/casing or connectors
6) Broken
LCD broken, casing broken, cover broken
7) Dropped.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
14/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Keypad tear off, LCD lens, connectors fallen off
8) Gap:
External physical damage relating to abnormal use, like front case and frame opened
9) Others:
Damage caused by disassembly like wrong part assembly, lost of components
Use in abnormal environment like too high temperature with plastic melts
2.12.Accessories inspection
Accessories warranties check items:
1) Any use in abnormal temperature, other than the one specified in the user manual. Any evidence of
plastic/casing melted.
2) Any mark of food or liquid around the accessory or in the USB socket.
3) Any evidence of mechanical shocked which damage the enclosure of the USB cable, charger or
headset.
4) Any mark of tentative of disassembly the accessory
5) Any abnormal use which induce wire damage, wire broken or USB socket deformed.
2.13.Cell phone maintenance procedure
1) Check that the SIM card and SD card is set correctly.
2) Power on the cell phone.
3) If the cell phone can not power on, insert the charger check whether the battery died.
4) If the cell phone asks to input NCK code, which means it is SIM locked, and can only be worked with
dedicated SIM card. Use the correct SIM card.
5) Enter the phone code if necessary.
6) If power on, test step by step with the auto test code:
Press *#2886# in dial screen and select “Auto” to start the auto test, then you will see the interface
displaying the version. Press “Pass”to continue.
If one of the test failed, it will ask you “Restart?”, press “YES”to restart the auto test from the first one
and “NO”to exit the auto test, while “NEXT”to continue the auto test.
TRACABILITY Test
I. You can get some information such as IMEI, CU, BT, WIFI, etc…
II. Press “Pass” to continue.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
15/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
TP
I. Show “TP Raw Test Passed! “, Press “PASS” to continue.
II. Please draw the yellow data according to display and it will show “TP Tested Success!” ,
Press “PASS” to continue.
LCD MIRE/BLACK/GREYCHART/WHITE
I. You will see the LCD color changes if it functions well.
II. Press “Pass” to continue.
KEYPAD.
I. Press the key displayed on the screen. The key on the screen will disappear when
you press it if it functions well.
II. Press “Pass” to continue.
KEYPAD&LCD BACKLIGHT
I. The screen backlight will be flashing if it functions well.
II. Press “Pass” to continue.
Flash LED Light Test.
I. The light near the camera will flashing.
II. Press “Pass” to continue.
BACK CAMERA
Press “Pass” to continue if the camera functions well.
FRONT CAMERA
Press “Pass” to continue if front camera functions well.
HALLTEST
Press “Pass” to continue if HALL functions well.
CAMERA LED
I. Back and Front Camera LED will be turned on if functions well.
II. Press “Pass” to continue.
CHARGER LED
I. CHARGER LED will be turned on if functions well.
II. Press “Pass” to continue.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
16/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
RECEIVE/SPEAKER/MIC/MIC2
I. You will hear the melody if it functions well.
II. Press “Pass” to continue.
VIBRATOR
I. You can feel the phone‟s vibrating if it functions well.
II. Press “Pass” to continue.
ACCESSORY
Insert earphone to test, if it functions well press “Pass” to continue.
CHARGE
Insert USB to charge, show „charge ok‟ press “Pass” to continue.
USB
I. Insert USB cable and the phone will detect “Charger: OK” “USB: OK” if it functions well.
II. Remove USB cable according to the instruction and then press "Pass" to continue.
USB OTG
I. Insert USB OTG device and the phone will detect “OTG: OK” if it functions well.
II. Remove USB OTG device according to the instruction and then press "Pass" to continue.
COMPASS
Show compass data press “Pass” to continue.
G-SENSOR
I. Screen will display “put the handset up and towards up”, follow this prompt screen will
display left arrow, right arrow, up arrow, down arrow and face down arrow. Put the phone to
the positions according to the arrows‟ direction. It will say “all positions checked” if
functions well.
II. Press “Pass” to continue.
LIGHT SENSOR/PROXIMITY
I. It will say “Proximity Sensor detected”, put the phone near your skin and then move away
from your skin. values such as “near->far:2” will be shown if functions well;
II. Press “Pass” to continue.
GYROSCOPE

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
17/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Please rotate cube, press “Pass” to continue if functions well .
SIM
I. Insert the SIM card and the phone will detect it if it functions well.
II. Press “Pass” to continue
MEMORY CARD
I. Insert the SD card and the phone will detect it if it functions well.
II. Press “Pass” to continue
BATTERY TEMP
I. Battery temperature will be displayed on the screen.
II. Press “Pass” to continue.
BT
I. The phone will running the BT and show the BT address on screen.
II. Press "Pass" to continue.
WIFI
I. The phone will running the WIFI and search available network.
II. Press "Pass" to continue.
GPS
I. The phone will running the GPS and search satellite.
II. Press "Pass" to continue.
MMI TEST STATUS
I. Show all test status, if functions is fail, press „Yes‟ to retest fail, or press „No‟ to complete
test.
3. Replace the handset parts
3.1. Preliminary
Before any disassembly (except the antenna), the back cover, SIM card must be removed firstly.

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
18/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
3.2. Precaution
The heart of the handset contains all digital circuit (microprocessor, ASIC, memories, display, keypad, etc)
and the high-frequency transceiver circuit which is protected by the upper and lower cover.
However, some ESD sensitive area is completely or partially visible (keypad keys, micro-SIM drive, etc).
In order to prevent any risk of ESD damage during disassembly or assembly of the handset, the operator's
wrist should be grounded.
This picture illustrates the connection. The operator wears an electrostatic conduct bracelet which
connected to an anti-static pad. And the pad place on the work surface which connected to the metal
structure workbench, the whole being earthed.
3.3. Battery test
3.3.1. Charging Process
1) Table 2.1 describes the various events related to a standard charger connected to a cell phone.
ALCATEL ONETOUCH 7053
Cell phone status before
charger connected
ON
OFF

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
19/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
During charging
Display lights up and following battery icon displayed:
After charging
(charger connected)
Following fixed battery icon display :
Table 2.1 Battery charge status on handset
2) If the display does not light on or battery icon does not flash when the charger or the cell phone‟s
charge function is defective with mechanical or electronics.
In this case:
a) Replace the charger to charge.
Confirm it works correctly or not.
If it can not work correctly after change charger
b) Check the Charge connector on the cell phone.
If it is damaged, replace the cell phone.
3) For a normally discharged battery (with not a long time of storage), charging time listed on below table

L1 Service Manual TCTMobile Limited
Rev.
ALCATEL ONE TOUCH 7053 Level 1 Service Manual
Page
1.1
20/28
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Battery
Typical Charge Time
Lithium
2 h +50min
4) Battery specification
Type
Li-polymer
Nominal Voltage
3.8V
Capacity
Minimum 2150mAh (0.2ItAdischarge 3.0V cut-off)
Charge Method
CC / CV (Constant Current / Constant Voltage)
Standard Charge Current
0.2ItA
Max Charge Current
0.5ItA
Max Recommend charge Voltage
4.35V
Max Discharge Current
1.0ItA(Constant current)
Discharge Cut-off Voltage
3.0V
Operating temperature
Charge
0 ~ +60℃,90%RH max
Discharge
-20 ~ +60℃,90%RH max
Storage Temperature
1 month
-20 ~ +60℃(*)
3 months
-20 ~ +45℃(*)
1 year
-20 ~ +25℃(*)
Storage Relative Humidity
65±15%
3.3.2. Charger test
When the standard charger is connected to the cell phone, check correct running of the charge indicator on
the display.
Use the ampere meter to test the current of the charger.
1) Connect the power supply to ampere meter with adapter.
Power on adapter
2) Connect the cables from “OUT” on other side to handset.
Power on charger
3) Connect charger to the meter “ IN “ on the side
4) You can read the current on ampere-meter
5) The reading of the charger output should be 940 mA~970 mA
