Alcatel ZIP LTE User manual

English - CJB1HEA01AAA
Quick Start Guide
Thank you for choosing Alcatel. This booklet helps you get started with your new Alcatel Zip LTE.
For more information about how to use Alcatel Zip LTE, please go to www.alcatelonetouch.us for
complete user manual.
A576BL
Made and Printed in China

Table of contents
1 Your mobile ������������������������������������������������������������������������������������������������������������������������� 1
2 Text input��������������������������������������������������������������������������������������������������������������������������� 11
3 Call������������������������������������������������������������������������������������������������������������������������������������� 12
4 Contacts ���������������������������������������������������������������������������������������������������������������������������� 14
5 Messaging������������������������������������������������������������������������������������������������������������������������� 15
6 Email���������������������������������������������������������������������������������������������������������������������������������� 16
7 Getting connected������������������������������������������������������������������������������������������������������������� 17
8 Find my location using GPS satellites ����������������������������������������������������������������������������� 18
9 Data backup���������������������������������������������������������������������������������������������������������������������� 19
10 Factory data reset������������������������������������������������������������������������������������������������������������� 20
11 Applications & Internal storage��� ������������������������������������������������������������������������������������ 20
Safety and use����������������������������������������������������������������������������������������������������������������������������� 22
www.sar-tick.com
This product meets applicable national SAR limits of 1.6 W/kg.The specific
maximum SAR values can be found on page 31 of this user guide.
When carrying the product or using it while worn on your body, either
use an approved accessory such as a holster or otherwise maintain a
distance of 15 mm from the body to ensure compliance with RF exposure
requirements. Note that the product may be transmitting even if you are
not making a phone call.

1
1 Your mobile ����������������������������������������
1�1 Keys and connectors
Micro-USB/
Charger Connector
Headset connector
Touch screen
Back key
Home key
Menu Key
LED indicator
Front camera
Receiver

2
Camera
Volume down key
Volume up key
Power key
Back key
• Touch to go back to the previous screen, or to close a dialog box, options menu, the
notification panel, etc.
Home key
• From any application or screen, touch to return to the Home screen.
• Long press to open Google now.
Menu key
• Touch: Open a list of thumbnail images of apps you've worked with recently. Touch
a thumbnail to open an app. Swipe horizontally to remove a thumbnail from the list.
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the pop-up menu to select from Power off/Restart/Airplane
mode.
• Press and hold the Power key for more than 8 seconds to reboot.
• Press the Power key and Volume down key to capture a screenshot.

3
Volume Keys
• In call mode, adjusts the earpiece or headset volume.
• In Music/Video/Streaming mode, adjusts the media volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.
• In camera mode, press Volume up or down key to take a photo.
1�2 Getting started
1�2�1 Set up
Removing or installing the back cover
Installing or removing the microSD card
To install microSD card, place the microSD card with the chip facing downwards into the housing,
and then slide it into its slot.To remove microSD card, press and slide it out.

4
Charging the battery
It is advised that you fully charge your battery ( ). Connect the battery charger to your phone and
main socket respectively, charging status is indicated by the percentage on screen while the phone
is powered off. The percentage increases as the phone is charged.
To reduce power consumption and energy waste when the battery is fully charged,
disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-
running applications when not in use; reduce the backlight time, etc.
1�2�2 Power on your phone
Hold down the Power key until the phone powers on, unlock your phone (Swipe, PIN, Password,
Pattern) if necessary and confirm. The Home screen is displayed.
If you do not know your PIN code or if you have forgotten it, contact your service provider. Do not leave
your PIN code with your phone. Store this information in a safe place when not in use.
Set up your phone for the first time
The first time you power on the phone, you should set the following options: language, mobile data,
Google service, date & time, etc.
Even if you have no network signal, your phone will still power on and you will be able to connect to
a Wi-Fi network, sign into your Google account and use some of the phone's features.
1�2�3 Power off your phone
Hold down the Power key from any screen until the phone options appear, select Power off.
1�3 Home screen
You can bring all the items (applications, shortcuts, folders and widgets) you love or use most
frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen.

5
Status bar
• Status/Notification indicators
• Touch and drag down to open the notification panel.
Touch an icon to open an application, folder, etc.
Touch to enter application list.
Favorite tray applications
•Touch to enter the application.
•Touch and hold to move or change applications.
The Home screen is provided in an extended format to allow more space for adding applications,
shortcuts etc. Slide the Home screen horizontally to get a complete view.
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
To enter the available options for an item, touch and hold the item. For example, select a contact in
Contacts, touch and hold this contact, an options list will then appear on screen.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications, images, web pages… at your convenience.

6
Flick
Similar to swiping, but flicking makes it moves quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them apart or together to scale an
element on the screen.
Rotate
Automatically change the screen orientation from portrait to landscape by turning the device
sideways to have a better view.

7
1�3�2 Status bar
From the status bar, you can view both phone status and notification information.
Status icons
3G connected Vibrate mode
3G in use Alarm is set
4G connected Connected to a Wi-Fi network
4G in use Speakerphone is on
Signal strength No SIM card inserted
Roaming Battery is charging
No signal Battery is very low
Airplane mode Battery is low
Bluetooth is on Battery is partially drained
Headset connected Battery is full
GPS is on

8
Notification icons
New Gmail message Missed call
New Email message Radio is on
New text or multimedia message An open Wi-Fi network is available
Problem with SMS or MMS delivery Uploading data
Upcoming event Downloading data
Screenshot error System update available
Screenshot captured
Touch and drag down the Status bar to open the Quick settings panel or Notification panel. Touch
and drag up to close the panels. When there are notifications, you can touch them to access
notifications directly.
Notification panel
When there are notifications, touch and drag down the Status bar to open the Notification panel to
read the detailed information.

9
Touch to clear all event–based notifications (other
ongoing notifications will remain).
Touch to switch to the Quick settings panel.
Quick settings panel
Touch and drag down the Notification panel to open the Quick settings panel, where you can enable
or disable functions or change modes by touching the icons.
Touch to access Settings, where you can set more items.

10
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by creating a variety of patterns,
PIN or password etc.
1�3�4 Personalize your Home screen
Add
You can touch and hold a folder, an application or a widget to activate the Move mode, and drag the
item to any Home screen as you prefer.
Reposition
Touch and hold the item to be repositioned to activate the Move mode, drag the item to the desired
position and then release. You can move items both on the Home screen and the Favorite tray. Hold
the icon on the left or right edge of the screen to drag the item to another Home screen.
Remove
Touch and hold the item to be removed to activate the Move mode, drag the item up to the top of the
Remove icon, and release after the item turns red.
Create folders
To improve the organization of items (shortcuts or applications) on the Home screen and the Favorite
tray, you can add them to a folder by stacking one item on top of another. To rename a folder, open
the folder and touch the title bar to input the new name.
Wallpaper customization
Touch and hold the background on the Home screen then touch WALLPAPERS to customize
wallpaper.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your preference by pressing the Volume
up/down key, or touching Settings\Sound to set the volume.

11
2 Text input �������������������������������������������
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch the Application tab from the Home screen, select Settings\Language & input, touch the
keyboard name to access a series of settings
2�1�1 Google Keyboard
Touch to access number,
symbols, emoji input keyboard. Touch to select emoji.
Touch to enter text
or numbers.
Touch to enter voice input.
Touch to switch "abc/Abc"
mode; Touch and hold to
switch "ABC" mode.
2�2 Text editing
You can edit the text you have entered.
• Touch and hold or double tap the text you would like to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: CUT,COPY,SHARE,SELECT ALL, and ASSIST.
• Touch the other words that haven't been selected or an empty place in the entry bar to go back
without any action.

12
3 Call ������������������������������������������������
3�1 Placing a call
You can easily launch a call using Call. Touch the Application tab from the Home screen and select
Call, or touch the icon on the home screen to access Call application
Slide right to access
Favorites; slide left to
access Contacts.
Touch to hide
keyboard
Touch and hold to
access voicemail.
Touch to place a call

13
Enter the desired number from the keyboard directly or select a contact from Contacts or Call log
by sliding or touching tabs, then touch to place the call.
The number you entered can be saved to Contacts by touching the Create new contact.
If you make a mistake, you can delete the incorrect digits by touching .
To hang up a call, touch or the Power key (when the Settings\Accessibility\Power button to
ends call option is activated).
3�2 Answering or rejecting a call
When you receive a call, you can touch DISMISS to reject the call or touch ANSWER to connect the
call. For more, touch the incoming call then:
• Slide the icon up to answer;
• Slide the icon up to reject;
• Touch the icon to reject the call by sending a preset message.
• Touch the icon to reject the call with a reminder.
To mute the ringtone volume of an incoming call, press the Volume up/down key or turn the phone
over (when the Settings\Gesture\Turn over to mute option is set to On by default).
3�3 Consulting your call memory
You can access your call memory by touching the RECENT tab and then touch the View full call
history from the Call screen to view call history in categories of ALL and MISSED.

14
4 Contacts ����������������������������������������
From Contacts app, you can view and create contacts on your phone and synchronize these with
your Gmail contacts or other applications on the web or on your phone.
4�1 Adding a contact
Touch Application tab on the Home screen, select Contacts, then, you can touch to create a
new contact.
4�2 Importing, exporting and sharing contacts
This phone enables you to import or export contacts between SIM card and phone storage.
From the Contacts screen, touch the Menu icon to open the options menu, touch Import/Export,
then select the location to copy contacts from, touch NEXT, then select the location to copy contacts
to, touch NEXT.
To import/export a single contact, select the contact you want to import/export, and touch the
icon to confirm.
To import/export all contacts from/to your SIM card, touch the icon and then the icon to
confirm.
You can share a single contact or contacts with others by sending the contact's vCard to them via
Bluetooth, Gmail, etc.
Touch a contact you want to share, long press the Menu icon and Share from the contact details
screen, choose a phone number or touch if there is more than one number, then touch and
select the application to perform this action.

15
5 Messaging������������������������������������
You can create, edit and receive SMS and MMS with this phone.
To access this feature, touch the Application tab from the Home screen, then select Messaging.
5�1 Write message
On the message list screen, touch the new message icon to write text/multimedia messages.
Touch to create a new message.
• Touch to view the whole message thread.
• Touch and hold to activate delete mode.
Sending a text message
Enter the mobile phone number of the recipient in the To bar or touch to add recipients and
touch the Type message bar to enter the text of the message. When finished, touch to send
the text message.
An SMS of more than 160 characters will be charged as several SMS. A counter will be
on the right of the text box to remind you how many characters are allowed to be entered
in one message. Specific letters (accent) will also increase the size of the SMS, this may
cause multiple SMS to be sent to your recipient.

16
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations and sounds to other compatible
phones and e-mail addresses.
An SMS will be converted to MMS automatically when media files (image, video, audio, etc.) are
attached or Subject or email addresses are added.
6 Email���������������������������������������������
Besides your Gmail account, you can also set up external POP3, IMAP or Exchange email accounts
in your phone.
To access this feature, touch the Application tab from the Home screen, then select Email.
An email wizard will guide you through the steps to set up an email account.
• Enter the email address and password of the account you want to set up.
• Touch NEXT. If the account you entered is not provided by your service provider in the phone,
you will be prompted to go to the email account settings screen to enter settings manually.
Alternatively, you can touch MANUAL SETUP to directly enter the incoming and outgoing settings
for the email account you are setting up.
• Enter the account name and display name in the outgoing emails.
• To add another email account, you can touch and Settings. Touch Add account to
create an account.
To create and send emails
• Touch the icon from the Inbox screen.
• Enter recipient(s) email address(es) in the To field.
• If necessary, touch the icon beside the To field to add Cc/Bcc to add a copy or a blind carbon
copy to the message.
• Enter the subject and the content of the message.
• Touch to add an attachment.
• Finally, touch to send.
• If you do not want to send the mail right away, you can touch and Save draft key or touch the
Back key to save a copy.

17
7 Getting connected������������������������������
To connect to the Internet with this phone, you can use 4G networks or Wi-Fi, whichever is most
convenient.
7�1 Connecting to the Internet
7�1�1 4G
The first time you turn on your phone, it will automatically configure your network service: 4G.
To check the network connection you are using, touch the Application tab from the Home screen, then
touch Settings\More���\Cellular networks, and touch Network carriers.
7�1�2 Wi-Fi
Using Wi-Fi, you can connect to the Internet when your phone is within range of a wireless network.
Wi-Fi can be used on your phone even without a network signal.
To turn Wi-Fi on and connect to a wireless network
• Touch the Application tab from the Home screen, then touch Settings\Wi-Fi.
• Touch the switch beside Wi-Fi to turn on/off Wi-Fi.
• Touch a Wi-Fi network to connect. If the network you selected is secured, you are required to
enter a password or other credentials (you can contact the service provider for details). When
finished, touch CONNECT.
7�2 Browser������������������������������������������������������������������������
Using Browser, you can enjoy surfing the Web.
To access this function, touch the Application tab from the Home screen, then touch Browser.
To go to a web page
On the Browser screen, touch the URL box at the top and enter the address of the web page, then
touch to confirm.

18
7�3 Connecting to a computer
With a USB cable, you can transfer media files and other files between your microSD card/internal
storage and the computer.
To connect/disconnect your phone to the computer:
To connect:
• Use a USB cable to connect the phone to a USB port on your computer. You will receive a
notification USB for file transfers.
• Open the Notification panel and touch USB for file transfers, then choose a way in the dialog that
opens to confirm that you want to transfer files.
Before using MTP, make sure that the driver (Windows Media Player 11 or higher version)
has been installed.
To locate data you have transferred or downloaded in your phone/microSD card:
• Touch the Application tab to open the applications list.
• Touch File Manager.
• All data you have downloaded is stored in the File Manager, where you can view media files
(videos, photos, music and others), rename files, install applications into your phone, etc.
8 Find my location using GPS satellites
To activate your phone’s global positioning system (GPS) satellite receiver:
• Touch the Application tab from the Home screen.
• Touch Settings\Location.
• Touch the switch beside Location to turn on.
You can then open Maps to find your location:
