ALCO EC3-33x User manual

EC3-33x
User Manual
Rev. 4 - 14.01.2003

EC3-33x Coldroom Controller with EX5
User Manual EC3-33x
A.6.5.063E - Rev 4
2
Emerson Electric GmbH & Co - ALCO CONTROLS - Heerstr. 111 - D-71332 Waiblingen - Germany - Tel.: ..[phone] - Fax: [phone]
The EC3-33x coldroom controller is a universal controller for
refrigeration applications with an electronic stepper motor
expansion valve like the EX5. The controller has six
temperature inputs for coil in, coil out, air in, air out and defrost
termination temperatures. The sixes temperature input is a
universal temperature input. For measurement of the saturation
pressure a PT3 pressure sensor with 4 – 20 mA interface can
be connected to the controller. The controller has four relay
outputs, one defined for compressor control, one defined for
defrost heater control, one defined for an alarm output and one
as a universal relay output. The TRIAC outputs is defined for
fan control. The TRIAC can drive 24V / 230V 4A. The controller
has four digital inputs for 24V AC/ DC or 230V AC. One input is
defined for compressor failure, one input is defined for a door
contact and two inputs are free for universal purpose. The
stepper motor interface can drive stepper motor with 24V DC
and 0.7 A. The optional display can show values with a decimal
point in the range between -19.9 and +19.9°C otherwise without
decimal point. An IR receiver for the optional IR remote control
unit is build in. For communication purposes, an Echelon
LONWorks interface is installed. Two transceiver types are
available RS485 or FTT10A. The supply voltage is 24 VAC.
Transformers for 230V or 110V mains supply are available as
options.
DISPLAY ECD-001:
The data to be shown on the display can be selected by the user.
In case of on alarm, the alarm code is displayed alternately with the
selected data. The alarm code can be inhibited by the user. To
scroll through all possible displayable data press the SEL button.
The display will show for one second the numerical identifier of the
data and then the selected data. After two minutes the display will
return to the by /1 selected data.
NEURON ID / SERVICE BUTTON:
•Display :
Press the button for app. 1 second to send the Neuron ID.
An LED in the left upper corner will indicate the transmission
of the Neuron ID.
Controller:
There is a small hole left of the network connector. Use a
small pen or screwdriver to press the switch behind the hole.
An LED close to the switch will light to indicate the
transmission of the Neuron ID.
LOAD DEFAULT PARAMETERS:
•Use a small pen or screwdriver to press the service pin switch
on the controller and switch on the power supply on. The
EC3-21x will be reset to default parameters.
PARAMETERS:
The configuration parameters are protected by a numerical
password. The default password is “12”. To select the
parameter configuration :
•Press the PRG button for more than 5 seconds
•A flashing 0 is displayed
•Press or until 12 is displayed; (password)
•Press SEL to confirm password
•The first modifiable parameter code is displayed (/1).
•To modify parameters see Parameters modification below.
PARAMETER MODIFICATION:
•Press or to show the code of the parameter that has to
be changed;
•Press SEL to display the selected parameter value;
•Press or to increase or decrease the value;
•Press SEL to temporally confirm the new value and display its
code;
Repeat the procedure from the beginning "press or to
show..."
To exit modifying the parameters with the new values:
•Press PRG to confirm the new values and exit the parameters
modification procedure.
To exit without modifying any parameter:
•Do not press any button for at least 60 seconds (TIME OUT).
•Press “ESC” on IR remote control.
DEFROST ACTIVATION:
A defrost cycle can be activated locally from the keypad :
•Press the button for more than 5 seconds
•A flashing 0 is displayed
•Press or until 12 is displayed; (password)
•Press SEL to confirm password
•The defrost cycle is activated
CLEAR ALARMS:
A defrost termination or fan activation alarm can be cleared
from the keypad :
•Press or for more than 5 seconds.
•“CL” will be shown in the display to indicate that the
alarms are cleared.
INDICATIONS ON THE DISPLAY :
COMPRESSOR Logical status of the compressor
relay
FAN Logical status of the fan relay
DEFROST Logical status of the defrost heater
relay
ALARM Alarm condition

EC3-33x Coldroom Controller with EX5
User Manual EC3-33x
A.6.5.063E - Rev 4
3
Emerson Electric GmbH & Co - ALCO CONTROLS - Heerstr. 111 - D-71332 Waiblingen - Germany - Tel.: ..[phone] - Fax: [phone]
LIST OF PARAMETERS
Parameter Values
/ DISPLAY PARAMETERS Min Max Unit Def
/1 Value to be shown on display 0 11 - 0
/2 No alarms 0 1 flag 0
/5 Temperature unit 0 1 flag 0
/6 Decimal point 0 1 flag 0
/7 Display during defrost 0 2 flag 0
/C Temperature alignment for /1 = 0 -20.0+20.0 K 0.0
A ALARM PARAMETERS Min Max Unit Def
A0 Mean factor alarm temperature 0 100 % 100
A1 Low temperature alarm delay 0 180 min 5
A2 High temperature alarm delay 0 180 min 5
A3 High temperature alarm delay after 0 180 min 10
defrost
Ad Door alarm delay 0 180 min 2
AH High temperature alarm threshold AL 70 °C/K 40
AL Low temperature alarm threshold -50 AH °C/K -40
At Type of alarm threshold values 0 1 flag 0
0 = absolute temperatures °C
1 = relative temperatures K to setpoint
r THERMOSTAT PARAMETERS Min Max Unit Def
r0 Door contact function 0 15 flag 6
r1 Min set-point value -40 r2 °C -40
r2 Max set-point value r1 60 °C 40
r3 Day / night control 0 1 flag 1
0 = off
1 = on
r4 Thermostat mode 0 4 - 1
r6 Set-point night operation r1 r2 °C 4.0
r7 Difference night operation 0.1 20.0 K 2.0
r8 Mean factor day operation 0 100 % 100
r9 Mean factor night operation 0 100 % 50
rd Difference day operation 0.1 20.0 K 2.0
St Set-point day operation r1 r2 °C 2.0
d DEFROST PARAMETERS Min Max Unit Def
d0 Defrost mode 0 2 - 1
d1 Termination by time / temperature 0 3 - 0
d2 Defrost termination sensor 0 1 flag 1
d3 Pulsed defrost 0 1 flag 0
d4 Defrost at power up 0 1 flag 0
d5 Delay for power up defrost 0 180 min 0
d6 Pump down delay 0 180 sec 0
d7 Drain delay 0 180 min 2
d8 Injection delay 0 180 sec 0
d9 Demand defrost mode 0 2 - 0
dd Pulsed defrost difference 1 20 K 2
dH Pulsed defrost set-point -40 dt °C 5
dt Defrost termination temperature -40 90 °C 8
dP Maximal defrost duration 0 180 min 30
dI Defrost interval 0 192 h 8
dU Start up delay by synchronization 0 180 min 30
Parameter Values
F FAN PARAMETERS Min Max Unit Def
F1 Fan start-up sequence after defrost 0 4 - 0
F2 Fan status during no cooling 0 2 - 0
F3 Fan status during defrost 0 1 flag 0
F4 Fan stop delay time by no cooling 0 30 min 0
F5 Fan status during cleaning 0 1 flag 0
Fd Fan start delay time after defrost 0 30 min 0
Ft Fan on temperature after defrost -40 40 °C 0
c COMPRESSOR PARAMETERS Min Max Unit Def
c0 Delay first start of compressor 0 15 min 0
c1 Cycle time of compressor 0 15 min 0
c2 Min. stop time of compressor 0 15 min 0
c3 Min. run time of compressor 0 15 min 0
u SUPERHEAT PARAMETERS Min Max Unit Def
u0 Refrigerant 0 4 - 3
u1 Correction glide / pressure drop -20.0 20.0 K 0.0
u2 MOP control 0 1 flag 0
u3 MOP temperature -40 40 °C 0
u4 Control mode 0 2 - 1
u5 Superheat init set-point u6 u7 K 6
u6 Superheat set-point min 3 u7 K 3
u7 Superheat set-point max u6 20 K 15
u8 Saturation temperature 0 1 flag 1
uu Start opening 50 100 % 100
ut Valve type 0 3 - 0
H OTHER PARAMETERS Min Max Unit Def
H2 Keyboard and IR remote control 0 3 - 3
0 = all disabled (Caution, access to controller only via LON networ
possible)
1 = Keyboard enabled
2 = IR remote control enabled
3 = Keyboard and IR remote control enabled
H3 IR remote control access code 0 199 - 0
H5 Password 0 199 - 12
