AlcoSafe KX6000S-4 User manual

EN
Owner’s Manual
KX6000S-4
premium digital
alcohol breath detector
Please read this user manual before use.
Result of this unit for reference only.
Use ALKALINE batteries only.
DO NOT DRINK AND DRIVE!
TM

EN
The AlcoSafe KX6000S-4 is a premium grade digital alcohol
breath detector that quickly screens for the presence of alcohol
in breath. The 4-digit LCD display indicates the Blood Alcohol
Content (BAC) up to 3 decimal point of accuracy for the test
subject in seconds.
Please read this manual entirely before use.
Components Diagram
1
Mouthpiece Slot
Digital LCD Display
Left Button
(Select / Begin test)
Power Button
(OK / Conrm)
Right Button
(Recall last record /
Access user menu)
Battery Compartment
Mouthpiece Holder
(Hold 2 pcs)

EN
Installing the batteries
Press down the battery cover with small amount of pressure located on
the back of the unit. Push down and slide away from the unit to release
the cover. Install 2 AA ALKALINE batteries and close the battery cover.
How to use
IMPORTANT!
Wait 20 Minutes No Drinking No Smoking
Wait 20 minutes after the subject drinks, smokes or eats before testing. Failure to wait
20 minutes can give inaccurate BAC readings.
Insert mouthpiece: Insert the KX6000S-4 mouthpiece rmly
into the mouthpiece slot on the upper left hand side of the
unit.
Switch on: Press the Power button for 1
second to power on the unit. A single “beep”
is heard with current temperature displayed
on the Welcome screen.
Note: Unit will auto power-o after 30 seconds of inactivity.
Initialize sensor: Press the Left button to initi-
ate the sensor warm up and auto-cleansing
process. Timer will count down from 99.
Step 1
Step 2
Step 3
2

EN
Step 6
Read the results: The reading would be in range from 0.000 to
4.000 ‰BAC (i.e: 0.000 to 0.400%BAC or 0.000 to 2.000 mg/l)
depending on the user pre-set BAC display format.
Note: Refer to‘Set BAC display format’for more about how to change the display format
for the BAC result
Step 4 Ready: Wait until‘RDY’ (Ready) appears with a
single “beep” indicates the unit is ready to use.
3
Blowing: BLOW STEADILY into the mouthpiece
for 5 seconds. “BLOW 1-5...” appears on display
indicating sample being analyzed. Blow until
“beep”sound to signal completion of the test-
ing. A BAC reading will be displayed.
Note: KX6000S-4 allows user to view BAC result in 3-digit or
4-digit of display detail. Refer to‘Set number of display digit’
Step 5
Recall the last test record
Note: It is recommended toWAIT AT LEAST 1 MINUTE between tests for more accurate result
User could recall the last test record as below:
On Welcome screen, press Right button to show the cumulative
test count (the number of tests the unit performed).
Press Right button to show the last test record.
Note: KX6000S-4 stores a maximum of 64 test records. Refer to‘Display test result records’
for guidance for retrieving previous test records
Press Right button again to return to Welcome screen.

EN
LOW
‰BAC (g/l) 0.000 - 0.100
%BAC 0.000 - 0.010
mg/l 0.000 - 0.005
ATTN
‰BAC (g/l) Between 0.100 and alert level
%BAC Between 0.010 and alert level
mg/l Between 0.005 and alert level
HIGH
‰BAC (g/l) Reaches or exceeds alert level
%BAC Reaches or exceeds alert level
mg/l Reaches or exceeds alert level
KX6000S-4 detects BAC within the range 0.000 to 4.000 ‰BAC (i.e: 0.000
to 0.400%BAC or 0.000 to 2.000 mg/l).
Dierent system alert messages would be displayed on dierent measured
BAC level as below:
Note: Alert level is adjustable at (0.200 / 0.300 / 0.480 / 0.500 / 0.800 / 1.000 ‰BAC).
Refer to‘Set alert level’for guidance.
Illustration of BAC result
4

EN
On Screen Menu - Navigation path
5
SET temperature display format
SET BAC display format
SET alert level
(Refer to page 6)
(Refer to page 6)
(Refer to page 7)
OnWelcome screen, Press Right button for 2 seconds to enter the
menu structure of :
- SET (Temperature display format, BAC display format, Alert level,
Beep sound, Number of digit display)
- REC (Display test result record)
- TEST (Display cumulative test count)
- CAL (Calibration)
SET beep sound when blowing
(Refer to page 7)
Display test result records
(Refer to page 8)
Display cumulative test count
(Refer to page 8)
Calibration
(For dealer only,
not for end users)
SET number of display digit
(Refer to page 8)

Set temperature display format
EN
Set BAC display format
KX6000S-4 displays temperature in format of Celsius °C / Fahrenheit °F. The
display format could be set as below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed.
Press Left button to select your desired temperature display
format between Celsius °C / Fahrenheit °F. Press Power button to
conrm setting.
Press Power button 1 time to enter SET mode for setting temper-
ature display format. Current temperature display format blinks.
KX6000S-4 displays BAC result in format of ‰BAC, %BAC, g/l or mg/l. The
display format could be set as below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed.
Press Power button 2 times to enter SET mode for setting BAC
display format. Current BAC display format blinks.
Press Left button to select your desired BAC display format be-
tween ‰BAC, %BAC, g/l or mg/l. Press Power button to conrm
setting.
6

EN
Set alert level
Set beep sound when blowing
KX6000S-4 gives alert message (blinking reading, beeping sound) when the BAC
result exceeded the alert level. Alert level could be set at dierent levels (0.200 /
0.300 / 0.480 / 0.500 / 0.800 / 1.000 ‰BAC) as below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed.
Press Power button 3 times to enter SET mode for setting alert
level. Current alert level blinks.
Press Left button to select your desired alert level between (0.200
/ 0.300 / 0.480 / 0.500 / 0.800 / 1.000 ‰BAC. Press Power button
to conrm setting.
KX6000S-4 could be congured to give beep sound / no sound when blowing as
below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed.
Press Power button 4 times to enter SET mode for setting beep
sound when blowing.
Press Left button to select your desire setting (beep sound
enabled: b-1; beep sound disabled: b-0) Press Power button to
conrm setting.
7

EN
8
Set number of display digit
Display test result records
KX6000S-4 stores BAC test results up to 64 records. The stored records could be
recalled as below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed. Again press Right button to enter the REC (Record)
mode.
Press Power button to display the latest record (indicated by the
serial number ‘1’on the screen, followed by the corresponding
result) Press Power button again and so on to display the next
records sequentially. Press Right button to see the records in
reverse time direction.
Press Right button to exit REC (Record) mode. Press Right button
3 more times to return to the Welcome screen.
KX6000S-4 could be congured to display 3-digit / 4-digit of BAC information as
below:
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed.
Press Power button 5 times to enter SET mode for setting num-
ber of display digit.
Press Left button to select your desire setting (3-digit display: d-3;
4-digit display: d-4) Press Power button to conrm setting.

EN
9
Display cumulative test count
Precautions
1. Allow at least 20 minutes after drinking, smoking before testing.
2. For more accurate results, it is recommended to have the unit recali-
brated for every 6 months or 300 tests.
3. Only use the unit in a temperature range of 10 - 40°C or 50 - 104°F.
Operation above or below this range may aect the results.
4. Do not blow smoke, food or liquid into the unit.
5. Conditions that increase the amount of ketones on the breath, such as
diabetes and low caloric intake, may cause a false positive test.
6. Do not let yourself or anyone else drink and drive. Always use a desig-
nated driver when you or anyone else drinks alcohol.
7. Do not use the unit as a tool to determine you should operate a motor
vehicle or equipment. The BAC results are for reference only. The
manufacturer and distributor / importer disclaims any legal responsibil-
ity for the measured test value.
Error messages
KX6000S-4 stores the number of tests it has performed as a cumulative test count.
On Welcome screen, press Right button for 2 seconds. SET mode
is displayed. Again press Right button 2 more times to enter the
TEST mode. Press Power button to show the cumulative test
count.
Press Right button to exit TEST mode. Press Right button 2 more
times to return to the Welcome screen.

EN
Calibration
The KX6000S-4 is calibrated during manufacture using advanced alcohol simula-
tion equipment. Known alcohol concentrations are passed through the sensor
to set baseline values for testing. During testing, the unit compares users’ breath
samples to these baseline values.
The accuracy of breath alcohol testers can uctuate after six to twelve months of
normal use, depending on the number of tests performed and operating condi-
tions.
If this product is providing inconsistent test results, is not providing any test
results, or provides unusually high or low test results, the product should be recali-
brated by a trained professional.
Please contact your local dealer for recalibration and technical support.
10
Error messages
Error message Cause and Course of Action
REP This message means insucient or uneven blowing is
detected. Repeat ‘HOW TO USE’ steps 2 – 6.
REP + Snr
This message means Sensor Not Ready (Snr) and the unit
needs another warm-up / autocleansing. It occurs when
the unit has not been used for long time / occurs when
there is alcohol residue on the sensor. Another autocleans-
ing process is needed. Repeat ‘HOW TO USE’steps 2 – 6.
HThis message displays when the unit detected a very high
alcohol concentration (above 4.00‰BAC).
Err This message displays when the sensor has sustained dam-
age; please contact your local dealer for further support.
This message displays when Low Battery. Install two (2)
new AA alkaline batteries.

Specications
BAC Detection Range 0.000 to 4.000 ‰BAC (i.e: 0.000 to 0.400%BAC or 0.000 to
2.000 mg/l)
Accuracy +/- 0.07 ‰BAC or +/- 0.007 %BAC at cal. point
Warmup Between 20-60 seconds
Response time 5 seconds
Sensor Premium Sensitive Semiconductor
Operating temperature 10 - 40°C (50 - 104°F)
Display panel Digital LCD DOT matrix display with backlight
Digital display User option to display 3-digit / 4-digit information
Power Two 1.5V AA Alkaline Batteries (Not Included)
Battery life Approx. 200 - 300 tests with new batteries
Dimensions 114 x 51 x 18 mm
Recalibration Recommended every 6-12 months or 300 tests
KX6000S-4
Don’t Risk It, Know Your Limit. Do Not Drink And Drive!
TM
Warranty
The manufacturer warrants this product against defects in materials and
workmanship under normal use for a period of ONE (1) YEAR from the date of
purchase. The manufacturer’s obligation under this warranty is limited to replac-
ing, adjusting or repairing the unit if returned along with proof of purchase. This
warranty is void if the unit has been tampered with or maliciously damaged.
