Getting Started
with the
Agilent Serial BERT
N4906B
If you need more detailed information on
the Serial BERT, check out the Online Help.
The Help also offers printable versions of the
User´s Guide and the Programming Guide.
You only need a few minutes to get started
with the Serial BERT.
This Getting Started Brochure helps you to
quickly understand the operating principles
and set up your first BER test.

Notice
2
Safety Summary
Technology Licenses
The material contained in this document is provided
“as is,” and is subject to being changed, without
notice, in future editions. Further, to the maximum
extent permitted by applicable law, Agilent disclaims
all warranties, either express or implied, with regard
to this manual and any information contained herein,
including but not limited to the implied warranties of
merchantability and fitness for a particular purpose.
Agilent shall not be liable for errors or for incidental
or consequential damages in connection with the
furnishing, use or performance of this document or
of any information contained herein. Should Agilent
and the user have a separate written agreement with
warranty terms covering the material in this document
that conflict with these terms, the warranty terms in
the separate agreement shall control.
Restricted Rights Legend
Services and Support
Any adjustment, maintenance, or repair of this
product must be performed by qualified personnel.
Contact your customer engineer through your local
Agilent Technologies Service Center. You can find
a list of local service representatives on the Web at:
http://www.agilent.com/find/techsupport
Operating personnel must not remove instrument
covers. Component replacement and internal
adjustments must be made only by qualified
personnel.
Instruments that appear damaged or defective
should be made inoperative and secured against
unintended operation until they can be repaired by
qualified service personnel.
The following general safety precautions must be
observed during all phases of operation of this
instrument. Failure to comply with these precautions
or with specific warnings elsewhere in this manual
violates safety standards of design, manufacture,
and intended use of the instrument.
Agilent Technologies Inc. assumes no liability for
the customer's failure to comply with these
requirements.
Before operation, review the instrument and manual
for safety markings and instructions. You must follow
these to ensure safe operation and to maintain the
instrument in safe condition.
This product is a Safety Class 1 instrument
(provided with a protective earth terminal).
The protective features of this product may be
impaired if it is used in a manner not specified in
the operation instructions.
All Light Emitting Diodes (LEDs) used in this
product are Class 1 LEDs as per IEC 60825-1.
Environmental Conditions
Verify that all safety precautions are taken.
The power cable inlet of the instrument
serves as a device to disconnect from the
mains in case of hazard.
The instrument must be positioned so that
the operator can easily access the power
cable inlet. When the instrument is rack-
mounted the rack must be provided with
an easily accessible mains switch.
Before Applying Power
To minimize shock hazard, the instrument chassis
and cover must be connected to an electrical
protective earth ground. The instrument must be
connected to the ac power mains through a
grounded power cable, with the ground wire firmly
connected to an electrical ground (safety ground)
at the power outlet. Any interruption of the
protective (grounding) conductor or disconnection
of the protective earth terminal will cause a
potential shock hazard that could result in
personal injury.
Do not operate the instrument in the presence of
flammable gases or fumes.
Do Not Operate in an Explosive Atmosphere
The hardware and/or software described in this
document are furnished under a license and may
be used or copied only in accordance with
terms of such license.
Warranty
If software is for use in the performance of a
U.S. Government prime contract or subcontract,
Software is delivered and licensed as “Commercial
computer software” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as defined
in FAR 2.101(a) or as “Restricted computer software”
as defined in FAR 52.227-19 (June 1987) or any
equivalent agency regulation or contract clause.
Use, duplication or disclosure of Software is subject
to Agilent Technologies’ standard commercial license
terms, and non-DOD Departments and Agencies of
the U.S. Government will receive no greater than
Restricted Rights as defined in FAR 52.227-19(c)(1-2)
(June 1987). U.S. Government will receive no greater
than Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2) (November
1995), as applicable in any technical data.
Revision 1.0, March 2005
Printed in Germany
Agilent Technologies, Deutschland GmbH
Herrenberger Str. 130
71034 Boeblingen, Germany
Revision
© Agilent Technologies, Inc. 2005
Copyright General Safety Precautions
General
Ground the Instrument
This instrument is intended for indoor use in an
installation category II, pollution degree
2 environment. It is designed to operate within
a temperature range of 5 – 40 °C (40 – 105 °F)
at a maximum relative humidity of 95% and
at altitudes of up to 2000 meters.
Refer to the specifications tables for the ac mains
voltage requirements and ambient operating
temperature range.
Do Not Remove the Instrument Cover

Installing the Agilent Serial BERT
AgilentPulseGenarator
This Getting Started Brochure
Power Cable
3
USB Cable
Inspect Shipment
Check if the Serial BERT shipping container contains the following standard deliverables:
If the contents are incomplete, if there is mechanical
damage, or if the instrument does not work within its
specifications, notify the nearest Agilent office. The
Agilent office will arrange for repair or replacement
without awaiting settlement.
The Agilent Serial BERT
N4906B
Windows XP Professional and
Agilent IO Libraries Suite CDs
Power Requirements Connect the Instrument
Connect the keyboard and mouse.
This is optional, the instrument can be operated
without external input devices. Mouse and keyboard
are not included in the shipment. You can use
standard USB or PS/2 devices.
Connect the line cord.
Turn on the instrument.
Please refer to the Online Help for detailed
information about working with the instrument.
All data and clock input and output connectors of the
instrument that are not used in your test setup
must be terminated with 50 Ohm.
1
2
3
The instrument can operate from any single-phase
AC power source supplying 100 – 240 V in the
frequency range from 47 – 63 Hz. The maximum
power consumption is 350 VA with all options
installed. The power supply automatically adapts to
the applied AC power (Auto Selection) and monitors
the AC power range.
The mains plug can only be inserted in a socket
outlet that provides protective earth contact. Any
interruption of the protective earth contact inside or
outside the instrument makes any operation of the
instrument dangerous. Intentional interruption is
prohibited.
When the front panel switch is off, the instrument
is in standby mode. The instrument can only be
disconnected from the AC line power by
disconnecting the power cord. The instrument
must be positioned so that the operator can easily
access the power cable inlet.
Ventilation Requirements
Do not cover the ventilation holes.
Make sure that there is adequate clearance of 50 mm (2 in) at the top and right side of the
instrument to ensure adequate air flow. If the air flow is restricted, the internal
operating temperature will be higher, reducing the instrument's reliability.
For the complete content of your delivery
please refer to the Box Contents List.

USB
Local
Preset
Power
Supply
GPIB Port USB 2.0 VISA Port
Operating the Agilent Serial BERT
Now that the instrument is running, let’s take a look at its front
panel elements:
4
Instrument Setup Controls Accumulation Controls
Keypad and
Front Panel Knob
PG Connectors
ED ConnectorsED ControlsPG Controls
Power Switch and
Earth Terminal
PS/2 Keyboard
(purple)
PS/2 Mouse
(green)
Serial Port 1
Parallel Port
VGA Monitor
Ethernet Port 1/2 Audio Line
Output Jack
Audio Microphone
Input Jack
Diagnostic
LED Stack
USB 2.0
Channel 0-3
The Agilent Serial BERT is available in different versions. Depending on your
version, some of the hardware and functionality described in this brochure
may not be available.
The rear panel of the instrument provides the following connectors:
To avoid damage to the Serial BERT and your devices under test,
always use an ESD strap that is connected to the earth terminal.

Operating the Agilent Serial BERT
5
Changing Parameters
With the touchscreen, your finger is the
mouse. Tipping an item with your finger
is like clicking it with the mouse.
You can use the numeric keypad
to enter values by hand,
or the large knob to adjust values.
You can also use the knobs at the bottom
of the instrument to change certain
frequently used values in run-time.
Navigating the GUI
The menu buttons allow you to quickly
navigate through the instrument's four
software sections:
Pattern Setup
Pattern
Generator Setup
Error Detector Setup
Results

Preparing the Test
6
What Are We Testing?
The quickest way to familiarize yourself with the instrument is to set up a
short test. You can test the BER on a cable. All you need for this test is an
APC/RPC cable for the data port connection and an APC/RPC-SMA adapter
cable to connect the PG clock output to the ED clock input.
Setting up the Pattern Generator
First we need to set up the pattern generator.
To keep things simple, let's set up LVDS logic
levels for both the data and clock output.
Reset the instrument. This sets all voltages
and parameters to
default values.
Now select the logic
family LVDS for the data
and clock port. Check the values to
make sure you can’t
damage your device.
You can change the output
signal parameters according
to the needs of your device.
Let's increase the
signal's data offset
by 100 mV. Just tip
the offset field,
and turn the fine-tuning
knob until you have the
desired value.
1
The pattern generator's
output ports are always active.
Therefore, you must be sure that
your device can handle these
ranges before you connect it.
4
5
6
USB
Local
Preset
Switch to the
PG Setup.
3
Connect the DUT
In our case you just have to
connect the following ports:
PG Clock Out PG Data Out
ED Data In
ED Clock In
2
All pattern generator
output ports that are not
connected must be
terminated with 50 Ohm.

Setting Up the Instrument
7
Set the Bit Rate
Now we want to set the pattern generator's bit rate. For now, we will use the
instrument's internal clock:
Switch to the
Bit Rate Setup.
Select the Internal
Clock Source.
Enter the required
clock rate or select
one of the presets
from the list.
You can also define
your own entries.
1
3
2
Now select the data pattern
to be used for the test:
Select the Pattern
Press the Pattern Setup
button to switch to the
pattern editor.
Open the Pattern
Select dialog box.
Select the pattern
type 2^n-1 PRBS.
Select the pattern
size 2^31-1.
The cable does not convert any data.
Therefore, we use the same pattern
for the pattern generator and the
error detector.
Besides generated patterns like PRBS, you can also use memory-based
patterns. A large variety of useful test patterns is already provided, but
you can also set up your own custom patterns. See the Help for details.
1
2
3
4
5
34
5

8
Setting up the Instrument
Setting up the Error Detector
The next step is to set up the error detector’s inputs.
Defining the Clock
Press the ED Setup button
to switch to the error
detector setup.
Set the Active Input. In our
case, we choose Normal
because we are testing a
cable that is connected to
the data input port.
Set the Input Range so that
it covers both the high and low
voltage levels of the data signal.
Enter the termination voltage
that matches the output
termination of the DUT, in our
case equal to the pattern
generator’s data output.
1
2
3
4
Switch to the
Clock Setup. Select External Clock
Source as the source
for the clock signal.
1
2
We have to make sure that the error detector
uses the clock from the pattern generator:
2

Setting Up the Instrument
9
Synchronizing the Pattern
Now make sure that the error detector
automatically syncs to the data pattern:
With this setting, the error detector starts
synchronizing when the BER exceeds a
certain threshold value. You can see when
it has synchronized when the Sync Loss
indicator goes off.
Setting the Sampling Point
Now set the optimum sampling point:
Open the Pattern Sync
Setup dialog box.
Make sure that
Normal Sync Mode
and Automatic Sync
are selected.
1
2
Switch to the
Sampling Point Setup.
Press the Auto Align button
to measure the eye diagram
and to position the sampling
point at the center of the eye.
This usually takes
about 10 seconds.
The BER indicator in the top left
corner displays the current BER
at this sampling point which
should be 0 for this test.
1
2
If sync fails, the sampling point is
probably outside of the eye. You should proceed with
setting the sampling point anyway. As soon as the instrument
finds the eye, with the settings we just made, it will
automatically synchronize the patterns.

10
Modifying the Test Setup
Adjusting the Sampling Point
You can adjust the sampling point manually, for example, to test the
performance of your DUT closer to the edge of the eye:
Use the Decision Threshold
knob to move the sampling
point vertically.
Use the Data In Delay
knob to move the
sampling point
horizontally.
You can see how the BER
increases when measuring
at the edge of the eye.
1
2
Viewing Eye Results
Now let’s check the resulting eye:
Press the Results button
to switch to the Results tab.
Switch to the
Eye Results.
Here you can see the measured
eye diagram along with all the
important eye parameters. If
you have done a measurement
previously, these results are
listed here too, for comparison.
1
2
