ALDI LIGHTWAY 872-B-S User manual

®
®
®
®
BATTERY-POWERED
SPOTLIGHT
User Manual

2

3
Scope of delivery ............................................................ 4
General information ....................................................... 8
Reading and storing the user manual........................... 8
Proper use........................................................................... 8
Explanation of symbols .................................................... 9
Safety..............................................................................10
Explanation of notes ........................................................10
General safety notes .........................................................11
First use ..........................................................................16
Checking the product and scope of delivery ..............16
Choosing an installation location..................................18
Assembly ........................................................................19
Mounting the spotlight....................................................19
Operation ...................................................................... 20
Configuring the sensor area.......................................... 20
Setting the lighting time ................................................. 21
Setting the sensitivity...................................................... 21
Adjusting the spotlight heads........................................22
Switching the product on and off.................................22
Troubleshooting ............................................................23
Cleaning..........................................................................25
Storage .......................................................................... 26
Technical data ............................................................... 26
Declaration of conformity ............................................ 28
Disposal ......................................................................... 28
Disposing of the packaging........................................... 28
Disposing of the product................................................ 29
Contents

Scope of delivery
4
A
17 18
5
1
2 3
4
67
8
9
10
11
12
Scope of delivery

Scope of delivery
5
C8
12
6
6
B
16
15
13
14

Scope of delivery
6
D
90°
E90°60°
F1
G
2 - 3 m 12 m

Scope of delivery
7
Components
1Tab 9Sensor housing
2LUX controller 10 Motion sensor
3SENS controller 11 Spotlight head, 2×
4TIME controller 12 Wall bracket
5Power switch 13 Battery compartment
cover
6Fixing screw 14 Fastening screw
7Spotlight 15 Battery compartment
8Rear panel 16 Batteries, 6×
Connecting elements supplied
17 Wall plug, 4× 18 Screw, 4×
Required tools (not included)
19 Electric drill
19
20 Cross-head
screwdriver
20
21 Garantie Card
The package contents include
six type AA 1.5 V batteries.

General information
8
General information
Reading and storing the user manual
This user manual accompanies this battery-
powered spotlight (referred to below only as the
‘product’).
It contains important information on start-up and
handling.
Before using the product, read the user manual carefully.
This particularly applies to the safety instructions.
Failure to follow this user manual may result in serious injury
or damage to the product.
The user manual is based on the standards and rules in force
in the European Union. When abroad, you must also observe
country-specific guidelines and laws.
Store the user manual for future use. Make sure to include this
user manual when passing the product on to third parties.
Proper use
The product is designed for permanent installation in a
location protected against rain and is intended only for
temporary lighting outdoors, e.g. to light building entrances,
garages or pathways and as a deterrent against burglary.
Do not use it for indoor lighting or for accent lighting. It is only
intended for private use and is not suitable for commercial
purposes.
Use the product only as described in this user manual. Any
other use is considered improper and may result in damage
to property.
The manufacturer or vendor accepts no liability for damage
caused by improper or incorrect use.

General information
9
Explanation of symbols
The following symbols are used in this user manual, on the
product or on the packaging.
This symbol provides you with useful
additional information about start-up or
operation.
Declaration of conformity (see chapter
“Declaration of conformity”): Products
marked with this symbol meet all applicable
Community regulations for the European
Economic Area.
The product’s type of protection is IP44. This
means it is protected against splashing water
and against ingress of solid foreign objects
with a diameter of more than 1mm.
This symbol identifies electric devices
corresponding to protection class III.
This means the product operates at low
voltage and is operated with a safety extra low
voltage (SELV).
Any cracked protective cover must be replaced.
Products marked with this symbol
meet all applicable regulations and
requirements in the economic area
of Great Britain.

Safety
10
Safety
Explanation of notes
The following symbols and signal words are used in this user
manual.
WARNING!
This signal symbol/word designates a hazard with moderate
degree of risk which may lead to death or severe injury if not
avoided.
CAUTION!
This signal symbol/word designates a hazard with low risk
that, if not avoided, may result in minor or moderate injury.
NOTICE!
This signal word warns against potential damages to
property.

Safety
11
General safety notes
WARNING!
Risk of explosion and fire!
Improper handling of the product can
cause an explosion or a fire.
− Keep children away from the product.
− Keep the product away from water,
other liquids, open flames and hot
surfaces.
− Do not hang any objects over the
product and do not cover it. Maintain a
distance of 1m between the spotlight
and easily flammable materials.
− Do not use the product any more if it
shows signs of damage. Only replace
damaged parts with corresponding
original spare parts.
− Do not open the housing and do not
make any modifications to the product.
Have only qualified professionals
perform repairs.
− Do not position the product over bathtubs,

Safety
12
sinks or other objects filled with water.
− Never use non-rechargeable batteries
with this product.
− Protect the batteries against mechanical
damage.
− Do not throw batteries into fire. They
could explode or release toxic vapours.
− Do not expose batteries to unrestricted
sunshine or heat. Increased risk of
leaking!
− Do not take batteries apart and do not
short-circuit them. Danger of explosion!
− If necessary, clean the battery and
device contacts before inserting the
batteries.
− Make sure that the polarity is correct
when inserting the batteries.
− Only use batteries of the same type.
− Do not use used and new batteries
together. Always change all of the
batteries at the same time.
− Remove empty batteries from the
spotlight.

Safety
13
WARNING!
Risk of chemical burns!
Fluid leaked from the batteries could cause
chemical burns if it comes into contact with
skin or other body parts. Batteries that are
swallowed may result in severe internal
injuries or even death.
− If battery acid leaks out, avoid contact
with skin, eyes and mucous membranes.
In the event of contact, immediately
rinse the affected areas with plenty of
clean water and consult a physician.
− In the event of a leaky battery, be
absolutely sure to wear protective
gloves and remove the leaked battery
fluid with a dry, absorbent cloth.
− Store both new and used batteries so
that they are not accessible to children.
− If you are no longer able to securely
close the battery compartment, do not
use the spotlight. Remove the batteries
and store them in a location which is
inaccessible to children.

Safety
14
− If you suspect that a battery has been
swallowed or has otherwise entered the
body, promptly consult a physician.
CAUTION!
Risk of injury!
The light emitted by the LEDs is very bright
and can damage the eyes if looked at
directly.
− Never look directly into the light of the
product’s LEDs.
− Make sure you do not shine the light into
the eyes of people or animals when
inspecting or assembling the product.
WARNING!
Danger for children and persons with
impaired physical, sensory or mental
capacities (e.g. partially disabled
persons, older persons with reduced
physical and mental capacities) or lack
of experience and knowledge
(e.g. older children).

Safety
15
− This product may be used by persons
with impaired physical, sensory or
mental capacities or those lacking
experience and knowledge if they are
supervised or have been instructed in
how to safely use the product and have
understood the risks associated with
operating it. Children may not play with
the product.
− Cleaning and user maintenance must
not be performed by children.
− Keep children away from the product.
− Do not let children play with the
packaging wrapper. Children may get
caught in it when playing and suffocate.
NOTICE!
Risk of damage!
Improper handling of the product can
damage the product.
− Protect the product from drastic
temperature fluctuations, e.g. those
near ventilators, air conditioning units
and heaters.

First use
16
− The LEDs are permanently installed and
cannot be replaced. Once the light
source has reached the end of its service
life, the entire product has to be
replaced.
− Stop using the product if any plastic
parts of the product show cracks or
deformation. Replace damaged parts
only with corresponding original spare
parts.
− Do not make any modifications to the
product.
First use
Checking the product and scope of delivery
NOTICE!
Risk of damage!
If you do not take care when opening the
packaging with a sharp knife or other
pointed object, the product can quickly
become damaged.
− Be very careful when opening the
packaging.

First use
17
1. Take the product out of the packaging. Before start-up,
remove all protective films.
2. Check whether the delivery is complete (see Fig.A and B).
3. Check whether the product or the individual parts are
damaged. If this is the case, do not use the product.
Contact the manufacturer at the service address specified
on the warranty card.
Inserting batteries
WARNING!
Danger of explosion!
Improper handling of the rechargeable
batteries can cause an explosion or a fire.
− Never expose the batteries to direct
sunlight.
1. Remove the rear panel 8from the spotlight 7by
unscrewing the fixing screw 6(see Fig.B).
2. Remove the battery compartment cover 13 by
unscrewing the fastening screw 14 .
3. Insert the batteries in the battery compartment 15 ,
noting the correct polarity.
4. Reattach the battery compartment cover.
If you are setting up the spotlight for the first time there is
no need to reattach the rear panel to the spotlight; you can
continue with set-up immediately.

First use
18
Choosing an installation location
Motion sensors are electronic sensors that recognise
movement in their environment and work as electrical
switches, responding to this movement. Heat sources are
sensed using the lens. If a heat source in the product’s range
changes or moves, the spotlight will switch on for the
preconfigured time. In order to ensure that the spotlight
functions optimally, note the following requirements:
• Affix the product to a stable, vibration-free wall.
• Choose a location for installation that is protected against
wind and rain (e.g. under the eaves of a roof). The
installation surface must be free from shocks or
vibrations.
• To avoid unwanted triggering of the motion sensor, no
moving objects such as trees or bushes should be in the
range of the motion sensor. If the sensor’s range is on a
street, vehicles driving past may switch the spotlight on
unintentionally.
• To avoid disturbing the proper functioning of the
spotlight, the motion sensor should be protected against
direct sunlight and from light from halogen lamps or
light-reflective surfaces such as swimming pools or
ponds.
• Only intended for installation outside arm’s length:
The optimum height for installation is approx. 2–3m
or above. If the product is installed lower than this, the
sensor area may be reduced (see Fig.G).
• The spotlight works best if the sensor area of the motion
sensor is crossed horizontally. As far as possible, install
the motion sensor in such a way that the main direction of
approach is not straight in front of the sensor.

Assembly
19
Assembly
WARNING!
Risk of electric shock!
Improper installation may result in an
electric shock.
− Ensure that there are no cables or other
electrical lines behind the location
where the spotlight is attached.
To avoid triggering the product unintentionally,
the spotlight must be fitted firmly. If the product
moves, this has the same effect as moving heat
sources in the sensor area.
Mounting the spotlight
1. Choose a suitable surface for installation (see chapter
section “Choosing an installation location”).
2. Remove the rear panel 8from the spotlight 7by
unscrewing the fixing screw 6.
3. Hold the rear panel (for wall installation) or wall bracket
12
(for corner installation) to the installation surface and
mark the installation locations.
4. Drill two holes into the wall using a drill 19 and insert the
wall plugs 17 .

Operation
20
5. Screw the rear wall or the wall bracket to the fastening
points with screws 18 as based on the properties of the
installation surface (see Fig.C). Use a cross-head
screwdriver 20 for this purpose. Do not apply excessive
force in the process.
6. Attach the spotlight to the rear wall or wall bracket.
7. Use the fixing screw to fasten the spotlight and the rear
wall or wall bracket.
8. Tighten the fixing screw.
Operation
Configuring the sensor area
1. If necessary, turn the motion sensor housing 9to reach
the SENS controller 3.
2. Select the required sensor area:
− Turning the SENS controller clockwise increases the
sensor area range and the motion sensor will already
react from a distance of approx. 12 m.
− Turning the SENS controller anticlockwise decreases
the sensor area range. With the lowest setting, the
motion sensor only reacts starting at a distance of
approx. 1 m.
To further adjust the sensor area, turn the motion sensor
housing. The motion sensor housing can be turned by 90°
(see Fig.D). The sensor angle of approx. 110° (+/-10°) does not
change in the process.
− Select the required sensor area by turning the motion
sensor housing.
