20 V LI-ION CORDLESS
HEDGE TRIMMER FAH 20-I
User Manual
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual
Original instructions

Scope of delivery................................................................. 3
Components ............................................................................. 6
General information............................................................ 7
Reading and storing the user manual ..................................7
Proper use..................................................................................7
Residual risks............................................................................ 8
Explanation of symbols .......................................................... 8
Safety ...................................................................................9
Explanation of notes ............................................................... 9
General power tool safety instructions................................ 9
Supplementary safety instructions ..................................... 14
First use...............................................................................17
Checking the product and package contents ................... 17
Use.......................................................................................17
Attaching/swapping the battery......................................... 17
Cutting hedges .......................................................................19
Troubleshooting................................................................ 22
Maintenance and care....................................................... 22
Cleaning ...................................................................................23
Maintenance............................................................................23
Inspecting the product..........................................................23
Storage .....................................................................................24
Transport..................................................................................24
Technical data ................................................................... 24
General information...............................................................24
Important specifications for the rechargeable battery
and charger .............................................................................25
Noise/vibration information ............................................ 25
Disposal.............................................................................. 27
Disposing of the packaging ..................................................27
Disposing of the product .......................................................27
Declaration of Conformity.................................................28
Table of contents

3
Scope of delivery
Dok./Rev.-Nr. 198638_20201202
A
B
1 2 3
4
5
6
7
9 8
Scope of delivery

4
Scope of delivery
C
3 4
E
15°
15°
15°
15°
GF
D

5
Scope of delivery
H
I
6
1

6
Scope of delivery
Components
1Cutter bar (with double cutting blade)
2Hand guard
3Guide handle (with pressure switch)
4Handle (with pressure switch)
5Protective blade cover
6Impact protection
7Release button
8Rechargeable battery (not included)
9Battery holder

General information
7
General information
Reading and storing the user manual
This user manual accompanies this 20 V Li-ion cordless hedge trimmer
(referred to below only as the ‘product’). It contains important informa-
tion on safety, usage and care.
Before using the product, read the user manual carefully. Pay particular
attention to the safety notes and warnings. Failure to comply with the instructions in
this user manual may result in severe injury or damage to the product.
Comply with valid local or national provisions concerning the use of this product. Keep
this user manual in a safe place for future reference. Make sure to include this user
manual when passing the product on to third parties.
Proper use
The product is only intended for private use – such as hobby or do-it-yourself work –
when undertaking the following:
• cutting (trimming) hedges, shrubs and bushes
Any other applications are expressly prohibited and are deemed improper use.
This product does not come with a rechargeable battery or charger. These must be
bought separately. The product can be operated with the 20 V rechargeable battery
or with the 20/40 V rechargeable battery available from Activ Energy®. Only use the
rechargeable batteries specified in the chapter ‘Technical data’ for the product. Do not
operate the product with rechargeable batteries from other manufacturers.
Neither the manufacturer nor the retailer can accept any responsibility for injury, loss
or damage caused by misuse of this product of any kind. Examples of misuse are giv-
en in the following non-exhaustive list:
• using the product for other purposes other than those intended;
• failure to observe the safety notes and warnings as well as the assembly, operat-
ing, maintenance and cleaning instructions contained in this user manual;
• failure to comply with any regulations relating to accident prevention, occupational
health or safety, which specifically and/or generally apply to the use of the product;
• use of accessories and spare parts not intended for the product;
• changes to the product;
• product repairs performed by parties other than the manufacturer or a qualified
professional;
• use of the product for commercial, artisan or industrial purposes;
• operation or maintenance of the product by persons not familiar with how to
handle the product and/or who are not aware of the related risks.

General information
8
Residual risks
Despite proper use, inconspicuous residual risks cannot be completely ruled out.
The following risks may arise due to the design of the product:
• touching the moving or stationary cutting blades in uncovered areas;
• reaching into the running cutting blades (cutting injury);
• eye damage caused by flying plant parts if protective goggles are not worn;
• hearing loss if suitable ear protection is not worn;
• injury to health attributed to hand-arm vibration emissions if the device is used
over a prolonged period of time or is not guided and maintained properly.
Explanation of symbols
The following symbols are used in this user manual, on the product or on the
packaging.
This symbol provides you with useful supplementary information about
commissioning and usage.
Declaration of Conformity (see “Declaration of Conformity” chapter):
Products marked with this symbol meet all applicable Community regu-
lations for the European Economic Area.
Read the user manual.
Wear protective goggles.
Wear ear protection.
Wear suitable secure footwear.
Wear suitable protective gloves.
Do not expose the product to rain. Do not use it in wet or damp
conditions.

Safety
9
20 V
AC battery voltage and DC symbol
Cut length
1Guaranteed sound power level
Safety
Explanation of notes
The following symbols and signal words are used in this user manual.
WARNING!
Indicates a hazardous situation that, if not avoid-
ed, could result in death or serious injury.
CAUTION!
Designates a dangerous situation that may result
in minor or moderate injury if not avoided.
NOTICE!
Warns against potential damages to property.
General power tool safety instructions
WARNING Read all the safety notes, instructions, illustrations and
technical details supplied with this power tool. Failure to follow the safety
notices and instructions may result in an electric shock, fire and/or severe
injury.
Save all warnings and instructions for future reference.
The term “power tool” used in the safety instructions refers to mains-operated
power tools (corded) and battery-powered power tools (cordless).
Work area safety
a) Keep your work area clean and well lit. Cluttered or dark areas
invite accidents.

Safety
10
b) Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool. If you are distracted, you could lose control of the power tool.
Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water enter-
ing a power tool will increase the risk of electric shock.
d) Do not use the cord for improper purposes such as for carrying the
power tool, for hanging it up or for pulling or unplugging it from
the socket. Keep cord away from heat, oil, sharp edges and moving
parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use only extension cords
that are suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.

Safety
11
c) Prevent unintentional starting. Ensure the switch is in the off-po-
sition before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your
finger on the switch or connecting the power tool to a power supply
while the switch is set to “on” may lead to accidents.
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the pow-
er tool may result in personal injury.
e) Take care to keep a normal body position. Maintain a stable
stance and balance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If there is an option for installing dust suction devices and dust
containers, these should be attached and used correctly. Use of
dust collection can reduce dust-related hazards.
h) Do not be lulled into a false sense of security and ignore the
safety rules for power tools, even if you are well acquainted with
power tools, having used them frequently. Using power tools
without due care and attention can cause serious injuries in a split
second.
Power tool use and care
a) Do not overload the power tool. Use the correct power tool for
your application. The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is dan-
gerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the
rechargeable battery from the power tool before making any
adjustments, changing insertion tools or storing the power tool.
Such preventive safety measures reduce the risk of starting the pow-
er tool accidentally.
d) Store idle power tools out of the reach of children. Do not let any
individual who is not familiar with the power tool or who has not

Safety
12
read these instructions operate this power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and insertion tools with care. Check for mis-
alignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If any
parts of the power tool are damaged, have them repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and fitted tools etc. in accordance
with these instructions, taking into account the working con-
ditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous
situation.
h) Keep handles and handle surfaces dry, clean and free from oil
and grease. Slippery handles and handle surfaces will prevent you
from operating and controlling the power tools safely in unforeseen
situations.
Cordless tool use and care
a) Only charge the rechargeable batteries with chargers recom-
mended by the manufacturer. Chargers designed for a particular
rechargeable battery type pose a risk of fire if used with other types
of rechargeable battery.
b) Only use the rechargeable batteries designated for use in power
tools. Using other rechargeable batteries may result in injury and a
risk of fire.
c) Keep the unused rechargeable battery away from paper clips,
coins, keys, nails, screws or other small metallic objects that
could bridge the contacts. A short circuit between the contacts of
the rechargeable battery could result in burns or fire.
d) If used improperly, liquid may leak out of the rechargeable bat-
tery. Avoid coming into contact with it. Rinse with water in the
event of accidental contact. If liquid comes into contact with your
eyes, also seek medical attention. Fluid leaked from the rechargea-
ble battery may cause skin irritations or burns.

Safety
13
e) Do not use a damaged or modified rechargeable battery. Dam-
aged or modified rechargeable batteries can be unpredictable and
may result in fire, an explosion or a risk of injury.
f) Do not expose a rechargeable battery to fire or excessively high
temperatures. Fire or temperatures above 130 °C may cause an
explosion.
g) Follow all instructions for charging and never charge the battery
or cordless tool outside of the temperature range indicated in the
user manual. Improper charging or charging outside of the permit-
ted temperature range may damage the battery and increase the risk
of fire.
Service
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
b) Never perform maintenance on damaged rechargeable batteries.
Only the manufacturer or authorised service companies may perform
maintenance on rechargeable batteries.
Safety instructions for hedge trimmers
a) Keep all body parts away from the cutter. When the cutter is mov-
ing, do not try to remove clippings or hold the material to be cut.
Only remove trapped clippings when the device is switched off. A
single moment of inattentiveness when using the hedge trimmer can
result in serious injury.
b) When the cutter is at a standstill, carry the hedge trimmer by the
handle. Always fit the protective blade cover when transporting
or storing the hedge trimmer. Handle the hedge trimmer with care
to minimise the risk of injury caused by the cutter.
c) Only hold the power tool by the insulated handle surfaces as
the cutter may come into contact with hidden power lines. If the
cutter comes into contact with a voltage-carrying line, the device’s
metallic parts may be energised, resulting in an electric shock.
d) Keep any wires away from the cutting area. When you are work-
ing, wires hidden in the bushes may be accidentally severed.

Safety
14
Supplementary safety instructions
Despite proper use, inconspicuous residual risks cannot be completely ruled
out.
WARNING!
Danger of suffocation!
Parts of the product are packed in plastic film or plastic bags when delivered.
Children may get caught in these when playing and suffocate.
− Do not allow children to play with the plastic film or plastic bags.
WARNING!
Risk of electric shock or fire!
Improper modifications or repairs may affect the operational safety of the product.
This may result in electric shock or a short circuit, which could in turn lead to fire.
− Do not make any modifications to the product.
− Do not carry out any independent repair work on the product.
− Repairs should only be carried out by trained personnel.
− Only parts that comply with the original device data may be used for
repairs. This product contains electrical and mechanical parts that are
essential for protection against hazards.
WARNING!
Risk of injury!
Serious injury can occur if the product is used improperly or negligently.
− Children must not use the product.
− Do not use the product if other people (especially children) or animals are
nearby.
− Before starting work, check that all screws are tight and check that the
cutting blades are sufficiently sharp. Before each use, make sure that all
protective devices are in place and working properly.
− Inspect the product regularly. Do not use the product if the blades are
damaged or excessively worn.

Safety
15
− Familiarise yourself with your environment before starting work. Be
aware of your environment during work. Be aware of potential hazards
that you may not be able to hear because of the noise of the product.
− Stand firmly when using the product. This is particularly important if you
are stood on uneven ground or a ladder or similar whilst working.
− Always guide the product with both hands when working.
− Walk slowly when holding the product in your hand. Do not run.
− Be careful when walking backwards. There is a risk of tripping.
− The pressure switches must not be fixed.
− Keep all body parts away from running cutting blades. Do not reach into
the running cutting blades.
− Never touch the cutter bar of the product.
− Do not wear any loose clothing which could get caught in the cutting
blades.
− Wear sturdy shoes and protective gloves.
− Wear protective goggles when working to prevent flying plant parts get-
ting into your eyes and damaging them.
− Switch the product off, wait until the cutting blades stop and remove the
battery before cleaning the product, checking for damage, servicing or
removing any objects trapped between the cutting blades. Accidentally
starting the cutting blades can cause severe cuts or lacerations.
− Stop using the product immediately and remove the battery if the cutting
blades are jammed by cuttings or other foreign objects.
− Wear protective gloves when removing cuttings or other foreign objects
stuck between the cutting blades.
WARNING!
Health hazard!
Under certain circumstances, the electromagnetic field that occurs during op-
eration may affect active or passive medical implants.
− Consult your doctor or the manufacturer of the medical implant before
using the product.

Safety
16
CAUTION!
Hearing damage!
You may damage your hearing if you use the product over a longer period of
time.
− Wear ear protection.
CAUTION!
Danger to health!
You may damage your health if you use the product over a longer period of time
due to the hand-arm vibration.
− Wear vibration-reducing gloves.
NOTICE!
Risk of damage!
Improper handling of the product can damage the product.
− Take batteries out of the battery holder when they are empty or when not
using the product for a prolonged period of time. This avoids damage that
could be caused by leakage of the battery which is being used.
− Do not expose the batteries to extreme conditions by, for example, placing
them on radiators or exposing them to direct sunlight.
− If necessary, clean the contacts of the battery and device before inserting
them, e.g. with a piece of emery cloth.
− Do not clean the product with aggressive solvents.

First use
17
First use
Checking the product and package contents
1. Lift the product out of the packaging with both hands.
2. Place the product on a level, stable base, such as a workbench.
3. Check to make sure that all the contents have been received (see Fig. A).
4. Check whether the product or the individual parts are damaged. If this is the case,
do not use the product. Contact the manufacturer at the service address specified
on the warranty card.
The product is ready for use on delivery. No assembly is required. You
only need to attach an appropriate battery.
Use
This chapter describes how to use the product. The following instructions are intend-
ed for your safety and successful, careful use of the product.
Attaching/swapping the battery
The battery for the product is a system battery that needs to be purchased separately.
Read the user manual for the battery before inserting it.
WARNING!
Risk of explosion and fire!
If batteries are handled incorrectly they may cause an explosion or a fire due to
reversed polarity or a short circuit.
− Only use suitable batteries approved by the manufacturer (see chapter
“Technical data”).
− Insert the battery correctly in the product.
− Do not use damaged batteries.

Use
18
NOTICE!
Risk of damage!
Using the wrong batteries or handling them incorrectly, including inserting a
battery incorrectly, may damage the product.
− Read and follow the instructions in the user manual for the battery and
charger used.
− To charge the battery, follow the instructions in the user manuals for the
battery and charger which are being used.
− The battery may not be inserted before making any adjustments to the
product, changing fitted parts, or storing the power tool.
Attaching the battery
1. To attach a rechargeable battery 8, put the rechargeable battery on the battery
holder 9. You will hear a click as soon as the rechargeable battery snaps into the
lock (see Fig.B).
2. Check that the rechargeable battery is positioned securely.
The product has undervoltage detection. If the rechargeable battery is
empty, the product switches itself off.
Removing the battery
1. Press and hold the release button 7on the attached rechargeable battery 8.
2. Remove the rechargeable battery from the battery holder 9.
If the rechargeable battery cannot be removed easily, this means that
the release button has not been pressed with enough force. Press the
release button on the rechargeable battery more firmly.

Use
19
Cutting hedges
WARNING!
Risk of injury!
The product has a cutter bar with cutting blades that move in opposite direc-
tions. Contact with running cutting blades can result in severe cuts or lacera-
tions.
− Keep all body parts away from running cutting blades. Never reach into
the running cutting blades.
− Do not try to remove material stuck between the cutting blades when the
cutting blades are running. Switch off the product, wait until the cutting
blades stop running and remove the battery before removing trapped
cuttings.
− Do not hold on to the material to be cut.
− Every time you interrupt work, place the protective blade cover on the
cutter bar to avoid injury.
WARNING!
Risk of electric shock and injury!
If the cutting blades come into contact with a live wire, this can send current up
exposed metal parts of the power tool and give the operator an electric shock.
− Only hold the product by the insulated handles during work.
− Keep any wires away from the cutting area.
− Check the hedge to be pruned for any concealed wires before you start work.
− If, despite taking all precautions, you hit a wire and a short circuit, and
a bang or spark occurs, do not be alarmed. Do not continue to press the
pressure switches, but do not let go of the product. Wait until the cutting
blades stop running and put the product down.
− Do not repair the damaged wire. Arrange for the damaged wire to be
replaced by qualified personnel.

Use
20
WARNING!
Risk of injury!
Improper or negligent handling of the product can result in serious injury.
− Handle the product with extra care when cutting hedges, shrubs and
bushes. Hold the product with both hands when working.
− Wear protective goggles when working to prevent flying cuttings from
hitting your eyes and injuring them.
− Stand firmly when using the product. This is particularly important if you
are stood on uneven ground or a ladder or similar whilst working.
− Walk slowly when holding the product in your hand. Do not run.
− Be careful when walking backwards. There is a risk of tripping.
NOTICE!
Risk of damage!
If the moving cutting blades of the cutter bar come into contact with hard ob-
jects, this can damage the blades
− Before starting work, check the hedge for concealed objects such as wire
fences or fence posts.
NOTICE!
Risk of damage!
The product cuts through thicknesses of up to 14 mm. Attempting to cut branch-
es with a diameter of more than 14 mm can damage the cutting blades of the
cutter bar.
− Do not cut branches with a diameter of more than 14 mm.
1. Check whether the hedge to be cut is wet. Wet hedges must not be cut. Also check the
hedge for concealed wires and objects such as wire fences, fence posts or similar.
2. Cut off thick branches with pruning shears or a chainsaw before you start.
3. Pull the protective blade cover 5off the cutter bar 1of the product and put it
down (see Fig. A).
4. Check that all screws are tight and check that the cutting blades are sufficiently
sharp.
