The Aleph Matrix 20mm pitch 64 pixel tile is designed for indoor applications. Its portability and
flexibility with link in-out data and power connections makes setting up quick and easy. Up to 100
tiles per data link for larger screen applications.
ENT
TEC
Aleph
LED 20mm Pitch Pixel Panel
MATRIX
?Control : using a dedicated USB interface and CAT5 link, the
driver software will accept any Art-Net input source from all
major pixel mappers. Perfect partner with
?Low maintenance: fanless, removes the need for regular
maintenance
?Greater flexibility of positioning: can be connected together in
any shape to create standard rectangular walls or any
configuration
?Versatile: great variety colour options
Ideal for wall mounted installations or free standing:
Shops
Offices
Restaurants
Nightclubs
Shopping centres
?
?
?
?
?
?Lightweight design
?Low power consumption (25W)
?High colour definition
?Easy to assemble
?Superior light output
?Simple to commission
?Different diffusers available
?Cost effective
?20mm led pitch
?64 RGB pixels per tile
?Daisy chain using AlephM data link
?Daisy chain IEC mains power
?3.5mm Mullion
?535g per tile
?Flexible mounting arrangements
?Multi platform pixel driver software
?Various diffusers available
Tile dimensions: L160xH160xW40mm (8'x8'x2')
