CREE LIGHTING 304 Series User manual

304 Series™
Recessed Canopy Petro Box Retrofit
Includes: CAN-227-RM
1 of 3 CI343X02R3_A
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D’INSTALLATION
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. DANGER – RISK OF SHOCK – DISCONNECT POWER BEFORE INSTALLATION
DANGER – RISQUE DE CHOC – COUPER L’ALIMENTATION AVANT L’INSTALLATION
2. WARNING – Risk of re or electric shock. LED Retrot Kit installation requires knowledge of luminaires electrical systems. If not
qualied, do not attempt installation. Product must be installed in accordance with NEC or your local electrical code. If you are not
familiar with these codes and requirements, contact a qualied electrician.
ATTENTION- Risque d’incendie ou de choc électrique. L’installation du kit retrot LED exige la connaissance des systèmes électriques pour
luminaires. Si non qualié, ne tentez pas d’installation. Ce produit doit être installé conformément à NEC ou votre code électrique local. Si vous
n’êtes pas familier avec ces codes et ces exigences, veuillez contacter un électricien qualié.
3. WARNING – Risk of re or electric shock. Luminaire wiring and electrical parts may be damaged when drilling for installation of the LED
retrot kit. Check for enclosed wiring and components.
ATTENTION - Risque d’incendie ou de choc électrique. Câblage électriques peuvent être endommagés lors du perçage pour l’installation du kit
retrot LED. Vérier les ls et composants.
4. WARNING – Risk of re or electric shock. Install this kit only in the luminaires that have the construction features and dimensions
shown in the photographs and/or drawings.
ATTENTION - Risque d’incendie ou de choc électrique. Installez ce kit seulement dans les luminaires qui ont les caractéristiques de construction
et les dimensions dans les photographies ou les dessins de la page suivante.
5. Only the holes indicated in the photographs or drawings may be made or altered as a result of the kit installation. Do not leave any
other holes open in a wiring enclosure or electrical component.
Seulement les trous indiqués dans les photographies ou les dessins peuvent être faits ou altérés pour l’installation du kit retrot LED. Ne laissez
aucun trou ouvert dans le compartiment électrique.
6. WARNING – To prevent wiring damage or abrasion, do not expose wires to the edge of sheet metal or any other sharp objects.
ATTENTION - Pour éviter les dégâts de câblage par l’abrasion, ne pas mettre en contact les ls électriques avec des bords de tôle ou d’autres
objets pointus.
7. Ensure that the existing luminaire is installed according to original manufacturer’s specication.
S’assurer que les luminaires sont installés selon les spécications du fabricant.
8. The retrot kit contains a universal LED driver and can be operated at voltages of 120-277V.
Le kit de rénovation contient une alimentation universelle et peut fonctionner à des tensions de 120-277V.
9. Once the Retrot kit is installed, the luminaire can no longer accept HID lamps and shall not be converted back to an HID luminaire.
Une fois le kit retrot LED installé, l’appareil peut ne plus accepter les lampes HID et ne pourra pas être retransformé en luminaire HID.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
HOUSING SIZES:
NOTE: Ensure the sizes of the existing luminaire housings are
approximately as follows:
Elsco Merritt: 19-3/4” square X 8-1/2” high
Whiteway Riviera: T21-1/8” square X 10” high
LSI Masters/Dakota: 23” square X 10” high
Rig-a-Lite: 21-18” square X 8-1/8” high
Jet-Philips: 22” square X 8-3/8”high
Elsco Franciscan*: 23-3/4” square X 7” high
*This fixture must be surface mounted
UPGRADE KIT LIST OF COMPONENTS:
1. Retrofit assembly XCP(304) or XCR(227)series.
2. (2) - Corner mount brackets
3. (2) - Corner mount brackets with suspension cables
4. (4) - Mounting screws
5. (8) - Self-drilling screws

2 of 3 CI343X02R3_A
TO INSTALL:
RETROFIT FIXTURE INSTALLATION
STEP 1:
Open and remove lens frame assembly. Remove door
mounting hardware, lamp, reflector, ballast cover
and socket assembly. Disconnect incoming power
leads.
Note: Existing ballast and capacitor may be left in
fixture if they do not interfere with the LED retrofit
module and if the existing luminaire is not supported
solely by the j-box. If removed, components should be
recycled according to all local, state, and/or federal
ordinances.
STEP 2:
Check the caulk between the Canopy and the existing
luminaire housing. Add caulk as needed to ensure
water tight installation.
STEP 3:
Slide corner brace brackets onto corners of housing
flanges. Use a non-metallic mallet only when
installing. Kit contains two brackets with cable
attachments and two brackets without. Secure
brackets in place with self-drilling screws (included)
at holes in brackets as show in Figure 1 and Figure
2. Insert (4) Oval head mounting screws (included)
into bracket panel nuts so that screw head is slightly
below luminaire level.
STEP 4:
For (B)XCP (304 Series) Retrofit Assemblies,
the retrofit pan must first be secured to the retrofit
housing. Set the retrofit housing on top of the retrofit
pan and secure the trim frame to the bottom of the
luminaire as shown in Figure 3.
STEP 5:
Attach (2) hooks on ends of cables to hook mounts
on fixture panel, Figure 4. This will allow for hands
free wiring and support during mounting and fixture
closure, Figure 5.
F1
3
2
1
(B)XCR (227 Series) (B)XCP (304 Series)
4
5

3 of 3 CI343X02R3_A
www.creelighting.com
© 2019 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content
is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree®and the Cree logo are
registered trademarks of Cree, Inc. 304 Series™ is a trademark of Cree Lighting, A company of IDEAL
INDUSTRIES.
ELECTRICAL CONNECTIONS
STEP 1:
Using 90°C minimum rated wire connectors, make the following
electrical connections:
a. Connect the black fixture lead to the voltage supply position of
the terminal block or Hot 1 (for 208/240V wiring).
b. Connect the white fixture lead to the neutral supply position of
the terminal block or Hot 2 (for 208/240V wiring).
c. Connect the green or green/yellow ground lead to the green wire
position of the terminal block.
d. If Dimming is an option; connect the violet dimming positive lead
to the supply dimming positive lead.
e. If Dimming is an option; connect the grey dimming negative lead
to the supply dimming negative lead
LINE
OR HOT 1
GREEN
LINE-BLACK
GROUND-GREEN
NEUTRAL-WHITE
DIM (-) GREY
DIM (+) VIOLET
NEUTRAL
OR HOT 2
VIOLET
GREY
SUPPLY WIRING
(DIMMING OPTIONAL)
LUMINAIRE
STEP 6:
For (B)XCR (227 Series): Make wiring connections using min. 90C
wire connectors (supplied by others). Ground connection should include
previous luminaire ground as well as ground from retrofit panel.
STEP 7:
For (B)XCP (304 Series): Connect the cord to the supply wiring. Verify
that the supply voltage is within the fixture’s voltage rating. Locate the
electrical supply wiring in the ceiling junction box. Connect the supply
wiring to the fixture’s supply cord as follows:
• Ground (green) to green conductor
• Line (black) to black conductor
• Neutral (white) to white conductor
STEP 8:
Rotate panel to horizontal position and push upward into the existing
luminaire housing, Figure 6. Slide panel over mounting screw heads
using key slots in panel, Figure 7. This will allow for panel support while
securing it into place.
STEP 9:
Secure fixture panel in place by tightening mounting screws. For best
results tighten screws half way in clockwise fashion. Then repeat order,
tightening completely.
STEP 10:
Reconnect power to the fixture.
