Alfa Network BRIIV User manual

User Manual
Compliance for CE
x

Setting Up For The First Time
Basic Operation
1 2
Alternate Power Sources
1. Find a suitable place for
your briiv near a power
outlet.
2. Connect the USB cable to
the base of the briiv unit.
3. Insert the plug into the
power outlet with the USB
cable connected.
4. briiv is now receiving power.
5. Remove the bag of moss
from the top of briiv.
6. Open the bag of moss.
7. Remove the moss and
gently place evenly within
the glass portion of briiv.
briiv operates with a touch-sensitive interface that also operates via touchless sensors.
Using the touchless features of briiv can help mitigate the spread of unwanted
pathogens, bacteria and other unwanted substances.
1. The front of the unit is indicated by a white
dot on the base of briiv. The control interface
is located above the white dot.
2. Wave your hand in front of briiv to wake it up.
3. Alternatively, you can touch briiv anywhere
on its interface to wake it up.
briiv’s low power consumption means it doesn’t necessarily need a mains
outlet in order to operate.
briiv can be powered by:
• Laptops • PCs • Portable battery packs/chargers
1.
5. 6. 7.
1
User Manual

Changing Moss & Coconut
1.
4. 5.
2. 3.
Carefully lift the glass of briiv upward (either with both hands or by carefully placing
your fingers within the air intake hole at the top of the glass and gently grip) and set
safely to one side.
Carefully lift
the glass of briiv
upward.
Once the coconut is in
place, you can insert your
new moss filter inside of
the glass.
The old moss and coconut
can be composted.
Replace the glass piece
on top of the briiv base
unit gently, making sure
to align with the base so
the glass piece is secure.
Push the moss &
coconut filters down
and out of the glass.
Place the new
coconut filter
on a flat surface
Place the glass on
top of the new
coconut filter so it
fits inside.
2
User Manual

Controlling The Speed
briiv has four speed settings to control the clean air delivery rate (CADR) you wish
to achieve.
Using the interface, select the speed you wish briiv to run at. The interface consists of a
illuminated + and – symbols. + increases the fan speed, - decreases the fan speed.
You can alter the speed by touching the interface or through touchless operation by
performing the same action without touching briiv.
The speed can also be controlled via the briiv app.
To activate the 1 Hour
Filter Cycle, either
touch or place your
hand near the ‘1’ part
of the interface.
1 Hour Filter Cycle
briiv’s 1 Hour Filter Cycle allows
you to set briiv running for one
hour before shutting off.
First, select the speed you wish
briiv to run at.
Once activated, a ‘1’ will illuminate. When the ‘1’ turns off, briiv will have completed the
one-hour cycle.
+
-
+
-
1
+
-
+
-
1
+
-
1
3
User Manual

Changing The Matix Filter
4. Insert your new matrix
filter dark-side facing up
into the square-shaped
recess.
1.
6.
2. 3.
Carefully lift the
glass of briiv upward
(either with both
hands or by carefully
placing your fingers
within the air intake
hole at the top of
the glass and gently
grip) and set safely
to one side.
Replace the glass top of
briiv with the coconut
and moss inside. Dispose
of the matrix in your
regular general waste.
Replace the glass piece
on top of the briiv base
unit gently, making sure
to align with the base so
the glass piece is secure.
Inside the
bioplastic base of
briiv is the matrix
filter housing.
Open the box
container to
access the filter.
Remove the
used matrix
filter.
5. Close the box container
4
User Manual

Placement
A central location within a space will give briiv the best opportunity to cycle all the air
as efficiently as possible.
If a central location is not viable, an elevated position elsewhere within a space is ideal
to keep briiv operating safely and effectively.
Avoid placing briiv in confined places (such as on a shelf with low clearance or close to
another surface directly above it).
Connecting to WiFi
Can I use briiv without WiFi?
To connect briiv to your WiFi signal, touch and hold the 1 Hour Filter Cycle button for 8
SECONDS and use the briiv app to connect to the internet.
Yes but you won’t be able to control briiv
via the app. briiv features touch buttons so
you don’t have to have it connected to the
internet in order for it to work.
5
User Manual
Get The App
Follow the QR code for further instructions

6
User Manual
Important Safety Instructions
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
1.Read all instructions before using the appliance.
2. To avoid fire or shock hazard, always use an appropriate 5v plug or USB outlet.
3. Keep the cord out of heavy traffic areas. To avoid fire hazard, NEVER put the
cord under rugs, near heat registers, radiator, stoves, or heaters.
4. To protect against electrical hazards, DO NOT immerse in water or other liquids.
Do not use near water.
5. Close supervision is necessary when any appliance is used by or near children.
6. Always unplug briiv before moving it, removing the glass, changing filters,
cleaning, or whenever the air purifier is not in use. Be sure to pull by the plug and
not the cord.
7. NEVER drop or insert any object into any openings.
8. DO NOT operate any appliance with a damaged cord or plug, if motor fan fails to
rotate, after the appliance malfunctions, or if it has been dropped or damaged in
any manner.
9.Use appliance only for intended use as described in this manual. Any
other use not recommended by the manufacturer may cause fire, electric shock, or
injury to persons.
10. DO NOT use outdoors.
11. NEVER block the air openings, outlets or place on a soft surface such as
a bed or sofa, as this could cause the unit to tip over, blocking the air intake opening or
causing damage to the glass of briiv. 12. Keep unit away from heated surfaces and open
flames.
13.DO NOT attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void your warranty. The inside of the unit contains no user serviceable
parts. All servicing should be performed by qualified personnel only.
14. WARNING: To reduce the risk of fire or electric shock, DO NOT use this airpurifier
with any solid-state speed control device.
15.DO NOT place anything on top of unit.
People with a history respiratory problems or lung disease should consult a physician
before using this product.
Caution: Keep electrical appliances out of reach from children.
Do not let them use the appliances without supervision.

7
User Manual
FAQs
Where can I order filters?
You can order filters from www.alfadb.net
How long do filters last?
The moss and coconut filters
last up to one year of usage
and the silk filters last up to
three months of usage.
1.Moss Filter (lasts one year)
2. Coconut Filter (lasts one year)
3. Matrix Filter (lasts three months)
What is your warranty policy like?
We offer a one year guarantee against
defects and faults with briiv. We also
offer a 30 day money back guarantee if
you change your mind (minus shipping
and handling), provided briiv is in
the same condition as when it was
taken out of the box and in its original
packaging.
What is your sustainability policy?
briiv uses as much recycled and
sustainable material as is possible
with the current scales of industry
available to us. Over time, we hope
to see more factories and suppliers
using sustainable materials so that
we can eventually get briiv to its 100%
sustainable goal.
How much power does briiv use?
briiv is low-powered via USB, using
just 5Vto operate.
How loud is it?
briiv is rated at around 45dB, the
equivalent of a quiet office.
Does briiv use an ionizer or generate
ozone?
briiv doesn’t use an ionizer and
doesn’t generate ozone.
1
2
3
General Safe Usage
Do not eat or place in the mouth any element of the filter media (this includes the moss,
coconut and matrix filter).
We recommend not using briiv in places of high moisture such as bathrooms. Humid
environments will increase the usage of the filters and poses a risk to the electronic
components within.
If the glass surround becomes broken, dispose of it in its entirety immediately in a safe
and responsible manner. Replacement surrounds can be ordered from www.alfadb.net
We recommend keeping briiv out of reach of children and away from pets in order to
mitigate the chances of damage occurring to any element of the briiv unit or the unit as
a whole.
Do not insert any part of your or anyone or anything’s body into briiv when it is
operating, receiving power or doing nothing at all.
Do not squash, tear or compress the moss as this will cause irreparable damage to it
and inhibit its ability to filter the air.
Do not water the moss or add water to any part of the product.
