1 Scope
This manual is valid for Alfa Laval REMIND™
EPC 50 program, version 1.0 and for connection
of a PC to EPC 50 Control Systems.
The manual is intended for personnel with good
process knowledge and those who are operating
Separating Units with EPC 50 Control System.

1 Scope REMIND™ EPC 50 Network User´s Manual
6493107611 (3-1)

493107611 (3-1) 7
2 Introduction
REMIND™ EPC 50 Network, is an Alfa
Laval software specifically designed for
supervision and remote control of separation
units with EPC 50 Control System. With the
EPC 50 Control System in remote mode, you
can supervise and control the separator units
from a personal computer, PC, placed in a
control room.
2.1 Requirements
The program REMIND™ EPC 50 Network
will run on a PC which meets the following
requirements:
•Processor at least Pentium 200 MHz with
16 Mbyte RAM (32 Mbye is
recommended) and 30 Mbyte hard disk
space available.
•Operating system Windows 95 and later or
Windows NT 4.00 and later.
•One free RS232 COM-port or one free
ISA PC slot.
Warning! Before carrying out any operation that
may effect the EPC 50, take steps to ensure that
no injury to personnel or damage to equipment
can occur as a result of the changes.

2 Introduction REMIND™ EPC 50 Network User´s Manual
8493107611 (3-1)

REMIND™ EPC 50 Network User´s Manual 3 Software Installation
493107611 (3-1) 9
3 Software
Installation
This chapter describes how to install
REMIND™ EPC 50 software in your PC. The
installation program is contained on two
diskettes.
The program requires Windows 95 and later
or Windows NT 4.00 and later.
The installation can be aborted at any time by
clicking the button CANCEL.
The installation procedure
When installing the REMIND™ EPC 50
software, proceed as follows:
1. Insert "REMIND™ EPC 50 Network"
disk 1 into drive a:
Note1. Other PC applications should be
closed before installation.
Note 2. When requested, insert diskette no. 2.
2. Select Run... from the Start Menu.
3. Welcome" dialog box appears
Click the next button.
Fill in ”User information”
4. Click the button "Next". The dialog box
"Choose Destination Location" appears.
The recommended (default) volume and
directory path for the REMIND™ EPC 50
program is
C:\Program Files\Remind\EPC 50\Network
Click the button "Browse" if another path is
requested and enter volume an directory. Click
on "OK" to confirm the selected path.

493-1077-11 (0-3) 11
4 General about SattBus installation
A shielded twisted pair cable with a minimum
of 3 twists/m and 80–120 Ωcharacteristic
impedance should be used as the bus cable.
Minimum area is 0.35 mm 2.
Note! The same type of cable must be used for
the entire SattBus installation.
Cable length and number of nodes
The total length must not exceed 500 m.
Termination
The bus cable should be terminated with
100 Ωresistors, connected at the two most
remote ends, measured along the cable. See
figure above.
All units in EPC 50 system, i.e. OP, I/O and
MT 50, have internal termination resistors
which can be connected/disconnected by
jumpers.
For EPC 50 I/O-board termination resistor is
connected by placing jumper XJ3 in position
TERM.
I/O Board
Termination resistor connected
when XJ3 in this position
TERM XJ3 OPEN

4 General about SattBus installation EPC 50 Service Guide
12 493-1077-11 (0-3)
For MT 50 the termination resistor is con-
nected by placing a jumper wire between ter-
minal no. 5 and 6 in connector X3.
For EPC 50 Remote OP the termination resis-
tor is connected by placing a jumper wire
between terminal no. 5 and 6 in connector X1,
i.e the screw terminal in the panel box.
At the PC, a 100 Ωtermination resistor should
be connected in the SattBus connector. This is
valid for both SattBus PC board and SBSU
unit.
IMPORTANT! Only two termination resistor,
one at each end, of a SattBus network must be
connected!
1 2 3 4 5 6
1 2 3 4 5 6
X1
X3
MT50
Circuit Board
Termination resistor in MT50 is
connected when X3:5 - 6 is jumpered

3 Software Installation REMIND™ EPC 50 Network User´s Manual
10 493107611 (3-1)
Note1. The program must be locally placed.
Do not use a network path.
Note 2. If a new directory is selected which
does not exist, a dialog box appears requesting
to create one.
Click the next button ”Setup type”
Select typical installation.
5. Click "Next" to open the next dialog box
"Select Folder Selection". This folder
name will, when installed, appear in the
"Start Up" menu for Windows 95 or NT
4.0.
Accept proposed name or enter a new one.
Note. If there is an already existing
version of REMIND™ EPC 50, a dialog
box appears asking if the old version
should be overwritten or not. Click "Yes"
to overwrite the old version or click "No"
to select another destination.
Click next button ”Start copying files”.
Confirm that the setting are OK.
6. Click "Next" to start the installation. It
takes a few seconds. The dialog box
"Setup Complete" appears. Mark the
checkbox if you want launch the
REMIND™ EPC 50 program.
Click on "Finish" to complete the installation.

493107611 (3-1) 13
5 Hardware Installation
This chapter describes how to connect the PC
with REMIND EPC50 Network installed, to
EPC 50 Control Cabinets via SattBus
network. Up to nine EPC 50 Control Cabinets
can be connected.
Warning! When handling electronics, avoid
electrostatic discharge e.g. by wearing an ESD
bracelet.
5.1 Overview
SattBus interconnects the EPC 50 units,
MT50, OP and I/O module, in the EPC 50
control system. See figure below.
An optional remote OP may also be connected
to SattBus.
A PC with REMIND™ EPC 50, Network can
be connected to SattBus in two alternative
ways:
•to SattBus via a SattBus PC board which
is mounted inside the PC. (REMIND™
EPC 50, Network Kit, PC-card art.no.
31830-6410-1)
•to SattBus via a SattBus Serial Unit,
SBSU. One of the serial ports of the PC is
then used. (REMIND™ EPC 50, Network
Kit, SBSU art.no. 31830-6411-1).

5 Hardware Installation REMIND™ EPC 50 Network User´s Manual
14 493107611 (3-1)
A maximum of 9 EPC 50 Control Cabinets
can be controlled and monitored by the PC
with the REMIND™ program.
The two alternatives for REMIND™ EPC 50,
Network.
5.2 Connect a PC to
EPC50 Control
Cabinet using a
SattBus PC Board
This is an alternative which connects the
SattBus network directly to the PC using a
SattBus PC board. Below is a step-by-step
description that shows how to connect the PC
to a single or the first one of several EPC 50
Control Cabinets.
EPC 50
No. 1 EPC 50
No. 9
EPC 50
No. 2
SBSU
PC
PC
Alternative 1: PC with SattBus PC board
Alternative 2: PC and SBSU
SattBus
SattBus RS232
EPC 50
No. 1 EPC 50
No. 9
EPC 50
No. 2
Remote
OP
(optional)

REMIND™ EPC 50 Network User´s Manual 5 Hardware Installation
493107611 15
1. Unpack the SattBus PC board and check
that switches S1 - S5 are set in appropriate
positions as described below. Detailed
information for the SattBus PC board is
found in chapter ‘‘SattBus PC-board
Description’’ on page 35.
S1 DIP switch for selection of segment start
address location of the dual port RAM in the
host processor RAM area.
S2 Not used
S3 Reset switch
S4 DIP switch which must have following
setting
S5 Set switch S5 in position "OFF".
2. Mount the SattBus PC board in an empty
ISA slot.
3. Connect the SattBus cable to connector
X1 on the SattBus PC board and to
connector X3 on I/O board in EPC 50
Control Cabinet.
Memory area
in PC
(HEX)
Switch S1 Note
-1 -2 -3 -4 -5 -6 -7 -8
D0 ON ON ON ON OFF ON OFF OFF
D1 OFF ON ON ON OFF ON OFF OFF Default setting
C8 ON ON ON OFF ON ON OFF OFF
BC ON OFF OFF ON ON ON OFF OFF
BE OFF OFF OFF ON ON ON OFF OFF
Switch S4
-1 -2 -3 -4 -5 -6
OFF OFF OFF ON OFF OFF

5 Hardware Installation REMIND™ EPC 50 Network User´s Manual
16 493107611 (3-1)
The electric diagram below shows the
connections.
4. As switch S5 is set to "OFF" a resistor,
100 Ω, should be connected for SattBus
termination. See figure below.
Termination of the SattBus cable.
X3
X1
1
2
3
4
EPC 50
I/O board
X3
PC card
or SBSU
X1
1
2
3
4
11
2
2
100
1
2
3
4
X1
SattBus
cable

REMIND™ EPC 50 Network User´s Manual 5 Hardware Installation
493107611 17
5.3 Connect a PC to
EPC50 Control
Cabinet using a
SattBus Serial Unit,
SBSU
This alternative connects SattBus to the PC
via a SattBus Serial Unit, SBSU. Below is a
step-by-step description that shows how to
connect the PC to a single EPC 50 unit or to
the first of several EPC 50 units.
1. Remove the cover from the SBSU unit and
set the switches as described below. The
SBSU layout, function etc. is described in
‘‘SattBus Serial Unit, SBSU Description’’
on page 39.
Node identity
Set the node address to 19 for control and
monitoring. If node address is set to 18 only
monitoring is possible. The address is set by
the two hexadecimal switches “Node
identity”. See chapter ‘‘SattBus Serial Unit,
SBSU Description’’ on page 39.
Set switch marked “H” to "1" and switch
marked "L" to "3" for control and monitoring
or to "2" for only monitoring.
Other settnings are described in chapter
‘‘SattBus Serial Unit, SBSU Description’’ on
page 39.
Filter address
All four switches SW1–SW2 must be set to
zero.

5 Hardware Installation REMIND™ EPC 50 Network User´s Manual
18 493107611 (3-1)
Mode switch
The mode switch SW must be set to zero, see
chapter ‘‘SattBus Serial Unit, SBSU
Description’’ on page 39).
Serial channel parameters
The DIP switch below the node identity
switches (see chapter ‘‘SattBus Serial Unit,
SBSU Description’’ on page 39) is used to set
the serial channel parameters. Normally 9600
baud, no parity (SW1 - 5), and "Host interface
mode" (SW6 - 8) should be chosen.
Other settings are described in ‘‘SattBus Serial
Unit, SBSU Description’’ on page 39.
2. Mount the SBSU unit close to the PC by
means of 4 screws or a DIN rail. The unit
needs a power supply, see the step below.
The unit is described in ‘‘SattBus Serial
Unit, SBSU Description’’ on page 39.
3. Connect 24 V DC from the power supply (
art.no.: 490083613) to the SBSU 3-pole
jackable screw terminal block (marked
“POWER”). A suitable cable is 3 × 1.5
mm 2 . The voltage at the terminal screws
must be 19–32 V DC. Connect protective
ground to the relevant terminal screw, and
connect 0 V to ground only at one end of
the cable.
Parameter
switch SW 12345678
ON ON ON OF
FON ON ON OF F

REMIND™ EPC 50 Network User´s Manual 5 Hardware Installation
493107611 19
4. Use the serial communication cable (RS-
232, art.no.: 490173740) for connection
between the serial port of the PC and the
SBSU unit (channel 1). Maximum cable
length is 15 m. Use a screened cable and
connect the screen to the metal case of the
connector. Use a 25-pole metallic male D-
type connector on the SBSU side. The
electric diagram below shows the required
connections.
5. Connect the SattBus cable to the 4-pole
plug-in screw connector, ‘‘SattBus Serial
Unit, SBSU Description’’ on page 39. The
connector is delivered with the SBSU.
Connect the other end to connector X3: 1
and 2 on EPC 50 I/O board in EPC 50
Control Cabinet.
2 RD
3 TD
5 GND
PC
9-pole
D-sub
SBSU
25-pole D-sub
Channel 1
2 RD
3 TD
7 GND
112 2
3 3
X3

5 Hardware Installation REMIND™ EPC 50 Network User´s Manual
20 493107611 (3-1)
The electric diagram below shows the
connections.
How to connect SattBus to the next EPC 50 is
described in the next section.
1
2
3
4
EPC 50
I/O board
X3
SBSU
SattBus
connector
1
2
3
4
11
2
2
